EnGenius EOC2611P Manuel utilisateur

EOC2611P Long Range Wireless Access Point / Client Bridge

• 2.4GHz

• 108Mbps

• 802.11 b/g/Super G

• MSSID, WDS

PRODUCT DESCRIPTION

EOC2611P is a long range outdoor wireless Access Point / Client Bridge that operates

seamlessly in the 2.4GHz frequency spectrum and provides high bandwidth up to 108Mbps with

Super G. With dual polarization antenna, it features high transmitted output power and high

receivable sensitivity. High output power and high sensitivity can extend range and coverage to

reduce the roaming between Access Points to get a more stable wireless connection. It also

reduces the expense of equipment in the same environment. With IPx4 protection, it can provide

effective in keeping out water.

It supports distance control by 1km to 30km and RSSI indicator which enables the best transmit

and receive signals for traffic communication. This product comes with PoE injector for building

in outdoor environment easily.

To protect your wireless connectivity, it can encrypt all wireless transmissions through 64/128-bit

WEP data encryption and also supports WPA/WPA2. The MAC address filter lets you select

exactly which stations should have access to your network. In addition, the User Isolation function

can protect the private network between client users.

The attractive design, high performance, and array of features make EOC2611P a suitable

wireless solution for your residence or office.

Package Content

¾1* 802.11b/g Long range AP/CB (EOC2611P)

¾1* PoE Injector (EPE-1212)

¾1* Power Adaptor

¾1* CD with User’s Manual

¾1* QIG

¾1* Metal strap

¾1* Special screw set

Learn more about EnGenius Solutions at www.engeniustech.com.sg

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 b, g chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

FEATURES

Wireless

- 2.4GHz It works in 2.4GHz frequency spectrum

- High output power Transmit high output power programmable for different country selections

- High Data Rate High speed transmitting rate up to 108Mbps with Super G, support large payload such as MPEG video streaming

- Multifunction application Access Point/Client Bridge/Client Router/WDS Function

- Long range transmitting Transmit power control and distance control (ACK timeout)

- Narrow Bandwidth Provide 5MHz/10MHz/20MHz bandwidth selection

- Signal Strength Display RF signal strength status shown LEDs of 3 colors, making network build-up easier. LED indicators have

the best transmit and receive signal for traffic communication

- Multiple SSID 4 SSID supported. Each SSID can set itself wireless or WAN access setting.

QoS(WMM) Enhance performance and density

Networking

- PPPoE Point-to-Point Protocol over Ethernet at Client Router mode. This function will keep trying when failed or disconnected

- PPTP Point-to-Point Tunneling Protocol (PPTP) is a method for implementing virtual private networks

- VPN Pass Through

Security

- 802.11i WEP, WPA, WPA2 (Encryption support TKIP/AES)

- MAC address functions MAC address filter (AP mode)

- 802.1x IEEE802.1x Authenticator

- Station isolation L2 Isolation

Management

- Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade

- Reset & Backup Reset to factory default. User can export all setting into a file via WEB

- Ping & Trace Route Built-in PING function & Trace Route function in Web GUI

- MIB MIB I, MIB II(RFC1213) and Private MIB

- SNMP V1, V2c

Learn more about EnGenius Solutions at www.engeniustech.com.sg

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

Datasheet

EOC2611P

TECHNICAL SPECIFICATION

> Hardware Specification

MCU/RF Atheros AR2316 Single Chip

Memory 32MB SDRAM

Flash 8MB

Physical Interface One 10/100 Fast Ethernet RJ-45

One Reset Button

One SMA Connector

One switch (external and internal antenna switching)

LED indicators Power/ Status

LAN (10/100Mbps)

WLAN (Wireless is up)

3 x Link Quality (Client Bridge mode)

yGreen: Good Quality

yYellow: Marginally Acceptable Quality

yRed: Bad Quality

Power Requirements Active Ethernet (Power over Ethernet) Proprietary PoE design

Power Adapter 24V / 0.6A DC

Regulation Certifications FCC Part 15C/15B, EN 300 328, EN 301 489-1/-17, EN60950

> RF Specification

Frequency Band 802.11b/g

2.412~2.472GHz

Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Operating Channels 802.11b/g

11 for North America, 14 for Japan, 13 for Europe

Receive Sensitivity (Typical) 802.11g

-92 dBm @ 6Mbps

-74 dBm @ 54Mbp

802.11b

-97 dBm @ 1Mbps

-89 dBm @ 11Mbps

Available transmit power (Average power) FCC ETSI

Frequency Power Frequency Power

2.412~2.462

GHz

IEEE802.11g

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

23dBm@54Mbps

2.412~2.472

GHz

IEEE802.11g

28dBm@6~24Mbps

26dBm@36Mbps

24dBm@48Mbps

23dBm@54Mbps

2.412~2.462

GHz

IEEE802.11b 28dBm@1~11Mbps 2.412~2.472

GHz

IEEE802.11b 28dBm@1~11Mbps

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOC2611P

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

Antenna Specification

Gain 10dBi

Radiation Directional

Frequency Band Range 2.4-2.5GHz

Horizontal -3dB Bandwidth 70o

Internal Antenna

Vertical -3dB Bandwidth 35o

Internal Antenna Pattern

External Antenna 1* SMA connector



SOFTWARE FEATURES

> General

Topology Infrastructure

Protocol / Standard IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.11b/g (2.4GHz WLAN)

Operation Mode 802.11 b/g

Access Point

Client Bridge

Client Router

WDS AP/CB

LAN DHCP Server

DHCP Client

VPN VPN – pass through

Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOC2611P

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

Wireless Channel Selection (Setting varies by countries)

Transmission Rate

11 b/g：54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps

Super G : 108 Mbps

Long distance transmission : 1km to 30km

Transmit power table

Signal Strength indication using LEDs

PPPoE(CR mode) and PPTP

Narrow Bandwidth 5MHz/10MHz/20MHz Support

PING function and Trace Route function

MSSID Support

VLAN Support

Security WEP Encryption-64/128/152 bit

WPA/WPA2 Personal (WPA-PSK using TKIP or AES)

WPA/WPA2 Enterprise (WPA-EAP using TKIP)

802.1x Authenticator

Hide SSID in beacons

MAC address filtering, up to 50 field

Wireless STA (Client) connected list

QoS WMM

> Management

Configuration Web-based configuration (HTTP)

Firmware Upgrade - Upgrade firmware via web-browser

- Keep latest setting when f/w update

Administrator Setting Administrator password change

Reset Setting - Reboot (Press 1 second)

- Reset to Factory Default (Press 5 seconds)

System monitoring Status, Event Log

SNMP V1, V2c

MIB MIB I, MIB II (RFC1213) and Private MIB

Backup & Restore Settings through Web

Time setting NTP (Auto-setting of time)

Time setting manually



Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOC2611P

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change

without notice

ENVIRONMENTAL AND MECHANICAL

Temperature Range Operating -20°C~70°C

Storage -30°C to 80°C

Humidity (non-condensing) 0%～90% typical

Dimensions 260mm (L) x 84mm (W) x 55mm (H)

Weight 380g

APPLICATION

Access Point + Client Bridge scenario



Long Range transmitting



Learn more about EnGenius Solutions at www.engeniustech.com.sg

Datasheet

EOC2611P

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice



Front Rear



\



V1.0

Learn more about EnGenius Solutions at www.engeniustech.com.sg

BUSINESS CLASS

EOC2611P

EOC2611P Datasheet Version 26112009

*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g, n chipset used. Actual throughput may vary.Network conditions and

environmental

factors lower actual throughput rate.

** All specifications are subject to change without notice

Pole mount

Standard Mounting Kits IPx4 Standard

Datasheet
