ENERGY SISTEM BT 3 Manuel utilisateur

User manual

ENGLISH

INTRODUCTION

Energy Sistem® thanks you for buying your new Energy™ Wireless BT 3 we wish

you enjoy using it.

Stereo Bluetooth® V3.0 headsets with circumaural design for high noise isolation

offering a great music experience. Built-in noise cancelling microphone. Totally

adjustable, foldables and with rechargeable li-ion battery.

We recommend you to read this user manual in order to enjoy the product in a safe

way and with the best results.

CARE AND MAINTENANCE

Do not expose your Energy™ Wireless BT 3 to shock, dust, humidity or high

temperatures.

Do not use cleaners or scouring agents.

Keep the unit clean and dust with a soft, dry cloth.

Do not disassemble the device. Any repairs must be done by qualified service

personnel authorised only by Energy Sistem Soyntec SA

Switch off your Energy™ Wireless BT 3 when not in use.

TECHNICAL DETAILS

≥Fully enclosed dynamic headsets.

≥Hi sensibility and noise cancelling microphone.

≥Clear sound with 96 dB sensibility.

≥Total compatibility with Tablets, Smartphones, laptops, MAC and PCs.

≥Function control PLAY, STOP, <<, >>, and VOLUMEN on the ear cup.

≥Ergonomic and light weight design for a maximum comfort in long sessions.

≥Effective use distance up to 10m.

≥Rechargeable li-ion battery.

≥Autonomy up to 15 hours.

PACKAGE CONTENT

≥Energy™ Wireless BT 3.

≥USB cable.

ENGLISH

GENERAL OVERVIEW

1. ON / OFF BUTTON - CONTROL TALK - PAIRING – PLAY / PAUSE.

2. VOLUME CONTROL - FORWARD / BACK.

3. MIC.

4. USB CONNECTION.

5. STATUS LED

6. CHARGING LED.

MAIN FEATURES

≥Bluetooth® V3.0 Class 2 headset.

≥Compatibility with ANDROID™ and iOS devices.

≥Easy pair without complex codes.

≥Built-in microphone.

≥Automatically call reception.

TURN ON / OFF YOUR DEVICE

To turn on your device you have to press the button (1) 3 seconds, you will see the

STATUS LED flashing red and turns to blue. When your device is working you can see

the STATUS LED flashing blue all the time.

To turn off your device you only have to keep pressed the button (1) for 3 seconds, the

STATUS LED turns to red and after the device will be off.

CHARGING

When the headset lacks sound or start to hear some interference in short distance, is

time to recharge. Plug the mini USB cable end to your Energy™ Wireless BT 3 and the

other end to any other device with USB port that provides energy (such as PC, a USB

wall charger, etc). The CHARGING LED (6) turns red when it is charging and when the

charge is completes the CHARGING LED light stops.

ENGLISH

NOTE: To keep the battery in good conditions, we recommend you to charge when

the battery has completely run out. At the same time, do not interrupt the charging

process until the battery is full.

BLUETOOTH PARING

Having your Energy™ Wireless BT 3 turned off, press the PARING button (1) in the

almost position for about 6 seconds, wait until the STATUS LED (5) starts flashing

and changing color (red/blue) at that time your Energy™ Wireless BT 3 is waiting for

the paring with your other Bluetooth® device. When you reach the Energy™ Wireless

BT 3 in your device you only have to select and pair.

FUNCTION CONTROL

Once you have pair your Energy™ Wireless BT 3 to your audio device, you can control

the main functions from the ear pad; hold the upwards control (2) and you can

increase the volume, press one time an you can pass to the next song. If you hold the

downwards control (2) and you can decrease the volume, press one time and you can

pass to the last song.

CONTROL TALK

Having your Energy™ Wireless BT 3 paired with your mobile or smartphone, you can

receive phone calls and use the MIC (6) to answer calls.

To answer an incoming call, press the button (1) and when you finish, press the button

(1) again to end the call. If you are listening to the music when you receive the call, the

music will be paused and when you finish the call the music continue.

WARRANTY

≥Energy Sistem Soyntec SA is liable for any lack of conformity which exists at

the time the goods were purchased during a period of 36 months. Batteries are

excluded from the 36-month warranty, having a warranty period of 12 months.

This warranty covers any defects in workmanship or materials. This warranty

doesn’t cover any failure of the product due to accidents, misuse or alteration

made by an unauthorized person.

The special 36-months warranty is valid for the European Union. For other

countries, please refer to your specific legislation or your local distributor.

ENGLISH

WARRANTY PROCEDURE

1. Visit the Support section at http://support.energysistem.com and select your

product to view the FAQ (Frequently Asked Questions). The solution to your

problem is very likely to have been already published there. You will also be able to

download user manuals, user guides, drivers and updates.

You can check the availability of the user manual in your language at

http://www.energysistem.com/es-es/support/manuals

2. If you cannot find an appropriate solution in the Support section, you may send us

your enquiry or warranty service request by email: support@energysistem.com

3. Alternatively, you may prefer to contact the distributor from which you purchased

the product, presenting the purchase receipt or invoice.

Important: This warranty doesn’t cover any damage or loss to any data stored in

the product memory, therefore Energy Sistem’s Technical Service will not assume

any loss of the above mentioned information so it is recommended to make a

backup of your data and to remove any data or personal info from its internal

memory before you send the product, or to send it only with the original factory

default values.

Specifications are subject to change without notice.

Trademarks. All company, brand and product names are trademarks or registered

trademarks of their respective companies.

DECLARATION OF CONFORMITY

Manufacturer Name: Energy Sistem Soyntec S.A.

Address: Pol. Ind. Finestrat, C/. Calpe, 1 - 03509, Finestrat Alicante (Spain)

Tel: 902 388 388

Fax: 902 119 034

NIF: A53107488

We declare under our own exclusive responsibility that the product:

Energy Sistem®Energy™ Wireless BT 3.

Manufacturing country: China

Is in compliance with the essential norms and standards of the Directive 2004/108/EC

of the European Parliament and of the Council of December 15th 2004.

This symbol on the product or the instructions means that your electrical and electronic

equipment should be disposed at the end of life separately from your household waste. For more

information, please contact the local authority or dealer where you purchased the product.

17/09/2012
