10 Viewing Waybox Diagnostics 89
D: Web Manager manual 90
1 Procedure for accessing the Web Manager tool 91
2 Procedure for seing the Waybox in “standalone” mode in case of lack of connectivity
and for commissioning 92
3 Seing the Waybox access mode, power, and Supply System 93
4 Association of the Waybox with Waymeter 96
5 Wi-Fi 99
E: Procedure for installing the external protection release solution for
Waybox with control board 100
1 Introduction 101
2 Procedure for installing the external protection release solution 101
3 Composition of Siemens Protection Kits 103
F: What-if Manual - Special installation cases 105
1 Purpose of the Manual and Method 106
2 List of Special Installation Cases 107
2.1 Data network signal with SIM is insucient 108
2.2 Single-phase IT power grid 109
2.3 Customer smaphone connectivity not adequate 110
2.4 Lockable garage with shuer (or other type) that weakens signal 111
2.5 Single-phase TT/TN power grid 112
2.6 Three-phase TT/TN power grid 113
2.7 Single-phase TT electrical grid without neutral 114
2.8 Waybox with control board in Italy and in Holland 114
2.9 EV ready Installation 115
2.10 Waybox with Load Optimization Pro (without photovoltaics) 115
2.11 Waybox with Load Optimization Pro (with photovoltaics) 116
2.12 Customer's vehicle not available during installation 116
2.13 Renault Zoe, Sma 22 kW, Twingo Electric 117
2.14 Load Optimization Pro with transformer 117
