Enel X JUICEBOX PRO Guide de l'utilisateur

JUICEBOX PRO &

JUICEBOX PLUS

Installer Manual

In this document

Purpose of this document 6

Installation Process 6

Document Structure 6

A. JuiceBox Pro & JuiceBox Plus - Installation Manual 8

1 JuiceBox 9

1.1 Features 10

1.2 Dimensions 11

2 Impoant safety information 12

2.1 Electric and electronic equipment end of life user’s information 12

3 Package Contents 13

4 Tools Needed 14

5 Installation Prerequisites 15

5.1 Protections 16

5.2 Power and signal cables 18

5.3 JB4Installers App 18

5.4 JuicePass App 18

6 Standard Installation 19

7 Special Installation Cases 36

7.1 Three phase JuiceBox installed on a Single-phase or Bi-phase supply system 36

7.2 Other special cases 36

8 Firmware Update 36

9 Load Optimization Pro 37

10 JuiceBox Commissioning through the JuicePass App 38

10.1 Commissioning via Cellular Connectivity 38

10.2 Commissioning via Wi-Fi Connectivity 44

10.3 Procedure for Unpairing the JuiceBox from the JuicePass Account 51

11 Charging Test 53

11.1 Charging in Unlock to Charge mode 54

11.2 Charging in Connect&Charge Mode 56

11.3 Recording the Charging Session in the Charging history 57

11.4 Checking Charging Power 58

11.5 Testing Load Optimization Pro 58

12 LED indicator 59

B. JuiceMeter- Installation Manual 60

1 JuiceMeter 61

1.1 Electric and electronic equipment end of life user’s information 61

2 Single-phase JuiceMeter 62

2.1 Features 62

2.2 Installation 64

2.3 JuiceBox connection diagrams 68

3 Three-phase JuiceMeter 70

3.1 Features 70

3.2 Installation 72

3.3 JuiceBox connection diagrams 77

C. JuiceBox Pro & JuiceBox Plus - JB4Installers App Manual 80

1 Purpose of the Manual 81

2 Pre-requisites 81

3 Login 81

4 New rmware download 83

5 Loading the JuiceBox serial on the app 84

6 Connecting the JuiceBox to the App 86

7 Firmware Update 89

8 JuiceBox Connectivity Check for Cellular Versions 92

9 JuiceBox Conguration 94

9.1 Conguration of the “Supply System” Parameter 94

9.2 Wi-Fi Conguration 95

9.3 JuiceMeter Conguration (for JuiceBox Pro) 96

9.4 Conguration of the JuiceBox in Standalone Mode 97

9. 5 Conguration of the JuiceBox in Absence of Cellular Connectivity 98

9.6 Conguration of the JuiceBox in case of installation on the IT network or in absence

of neutral 102

9.7 GPD disabling procedure 102

10 Viewing JuiceBox Diagnostics 103

D. JuiceBox Pro & JuiceBox Plus - JuiceBox Web Manager manual 104

1 Procedure for accessing the Web Manager tool 105

2 Procedure for seing the JuiceBox in “standalone” mode in case of lack of

connectivity and for commissioning 106

3 Seing the JuiceBox access mode, power, and Supply System 107

4 Association of the JuiceBox with JuiceMeter 110

5 Wi-Fi 113

E. JuiceBox Pro & JuiceBox Plus - Procedure for installing the external

protection release solution for JuiceBox with control board 114

1 Introduction 115

2 Procedure for installing the external protection release solution 115

3 Composition of Siemens Protection Kits 117

F. JuiceBox Pro & JuiceBox Plus - HW GPD Deactivation Procedure 119

1 GPD Deactivation Procedure 120

G. JuiceBox Pro & JuiceBox Plus - What-if Manual - Special installation

cases 123

1 Purpose of the Manual and Method 124

2 List of Special Installation Cases 125

2.1 Data network signal with SIM is insucient 126

2.2 Single-phase IT power grid 127

2.3 Customer smaphone connectivity not adequate 128

2.4 Lockable garage with shuer (or other type) that weakens signal 129

2.5 Single-phase TT/TN power grid 130

2.6 Three-phase TT/TN power grid 131

2.7 Single-phase TT electrical grid without neutral 132

2.8 JuiceBox with control board in Italy and in Holland 132

2.9 EV ready Installation 133

2.10 JuiceBox with Load Optimization Pro (without photovoltaics) 133

2.11 JuiceBox with Load Optimization Pro (with photovoltaics) 134

2.12 Customer's vehicle not available during installation 134

2.13 Renault Zoe, Sma 22 kW, Twingo Electric 135

2.14 Load Optimization Pro with transformer 135

H. JuiceBox Pro & JuiceBox Plus - Installer checklist 136

1 Installer checklist example 137

REV. 1

Purpose of this document

The purpose of this manual is to provide the installer with all the information necessary for

the correct installation and commissioning of the JuiceBox Pro and JuiceBox Plus charging

stations.

Installation Process

The following process is recommended to carry out the installation operations:

1. Please read this Installer Manual.

2. Carry out a feasibility inspection at the installation site by lling out a checklist provided

for this purpose by Enel X (see Installer Checklist example). This checklist allows you to

nd out whether you can proceed with standard installation (see Standard Installation)

or whether you need to follow the special installation procedures (see What-if Manual);

3. Obtain tools, materials, apps, and everything needed for installation (see Tools Needed);

4. Proceed with installation, commissioning, congurations, testing, and acceptance test.

Document Structure

The manuals that comprise this document are listed below.

DOCUMENT

SECTION MANUAL TOPIC

Section A JuiceBox Pro & JuiceBox Plus

Installation Manual

Physical installation of the JuiceBox,

introduction to congurations,

commissioning via JuicePass app,

and charging test

Section B JuiceMeter Installation

Manual

Physical installation of single-phase

and three-phase JuiceMeter device

to enable Load Optimization Pro

feature (available only with JuiceBox

Pro)

REV. 1

Section C JuiceBox4Installer App

Manual

Guide for the use of the

"JuiceBox4Installer" app, necessary

to carry out the JuiceBox

conguration activities (if not carried

out with the JuicePass app) and

JuiceMeter

Section D JuiceBox Web Manager

Manual

Guide for the use of the "JuiceBox

Web Manager" web app, which can

be used by all users to carry out the

JuiceBox conguration activities (if

not carried out with the JuicePass

app) and JuiceMeter

Section E

Procedure for installing the

external protection release

solution for JuiceBox with

control board

Guide to install protection

components for JuiceBox equipped

with control board

Section F HW GPD Deactivation

Procedure

Guide to disable the Ground

Presence Detector in the JuiceBox

to be followed in the cases indicated

in this manual

Section G What-if Manual - Special

installation cases

Procedures to be followed after

verication of a non-standard

installation case

Section H Installer checklist example

Checklist to be lled in during

the inspection to determine the

JuiceBox installation method

(standard or procedures for special

cases)

REV. 1

A. JuiceBox Pro & JuiceBox Plus -

Installation Manual

REV. 1

1 JuiceBox

JuiceBox Pro and JuiceBox Plus charging stations are available in two versions.

JUICEBOX CABLE VERSION (1):

1Cable

2RFID reader

3LED indicator

4Connector

1RFID reader

2LED indicator

3Socket

JUICEBOX SOCKET VERSION (2):

The JuiceBox Pro diers from the JuiceBox Plus by the possibility to enable the Load

Optimization Pro feature, which allows the Customer to always charge at the maximum

available power without triggering the meter. The activation of this function requires the

installation of an additional device, the JuiceMeter.

>JuiceBox Pro installation: hardware installation of the JuiceBox, hardware installation of

the JuiceMeter, conguration, testing and acceptance test

>JuiceBox Plus installation: hardware installation of the JuiceBox, conguration, testing

and acceptance test

REV. 1

1.1 Features

Output power

Single-phase

Up to 3.7 kW, 16 A

Up to 7.4 kW, 32 A

Three-phase Up to 22 kW, 32 A

Input voltage

Single-phase 230 VCA

Three-phase 400 VCA

Charging mode Mode 3

LED Dynamic LEDs indicating charging status

Protezione

IP55, IK08

The JuiceBox has an internal detector for DC fault

currents above 6 mA.

The following external protections are required:

>Type A residual current device (RCD)

>Curve C Miniature Circuit Breaker (MCB)

NOTE:

Some countries may require the installation of a Type B

RCD instead of the type A.

Operating temperature From -40 °C to +60 °C

Standards and

ceications

IEC 61851-1

CE Ceication

JuiceBox with control board: The cable version JuiceBox to be installed in Italy and Holland

has the control board.

JuiceBox to be installed according to EV ready requirements also are equipped with the

control board.
