Brief Operating Instructions

Levelflex FMP51, FMP52,

FMP54

HART

Guided wave radar

These Instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Detailed information about the device can be found in the

Operating Instructions and the other documentation:

Available for all device versions via:

– Internet: www.endress.com/deviceviewer

– Smart phone/tablet: Endress+Hauser Operations App

KA01077F/00/EN/17.17

71385688

Levelflex FMP51, FMP52, FMP54 HART

2 Endress+Hauser

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

Levelflex FMP51, FMP52, FMP54 HART Table of contents

Endress+Hauser 3

Table of contents

1 Important document information ................................................. 4

1.1 Symbols ............................................................................. 4

2 Basic safety instructions .......................................................... 6

2.1 Requirements for the personnel ............................................................ 6

2.2 Designated use ........................................................................ 6

2.3 Workplace safety ...................................................................... 7

2.4 Operational safety ......................................................................7

2.5 Product safety ......................................................................... 7

3 Product description ............................................................... 9

3.1 Product design ........................................................................ 9

4 Incoming acceptance and product identification ................................. 10

4.1 Incoming acceptance ................................................................... 10

4.2 Product identification .................................................................. 10

5 Storage, Transport ............................................................... 12

5.1 Storage conditions .................................................................... 12

5.2 Transport product to the measuring point ................................................... 12

6 Mounting ....................................................................... 13

6.1 Mounting requirements ................................................................ 13

6.2 Mounting the device ................................................................... 19

6.3 Post-installation check ................................................................. 27

7 Electrical connection ............................................................ 28

7.1 Connection conditions .................................................................. 28

7.2 Connecting the measuring device ......................................................... 41

7.3 Post-connection check ..................................................................44

8 Commissioning via wizard ....................................................... 45

9 Commissioning (via operating menu) ............................................ 46

9.1 Display and operating module ............................................................ 46

9.2 Operating menu ...................................................................... 49

9.3 Unlock the device ..................................................................... 50

9.4 Setting the operating language ........................................................... 50

9.5 Configuration of a level measurement ...................................................... 51

9.6 Configuration of an interface measurement .................................................. 53

9.7 User-specific applications ............................................................... 54

Important document information Levelflex FMP51, FMP52, FMP54 HART

4 Endress+Hauser

1 Important document information

1.1 Symbols

1.1.1 Safety symbols

Symbol Meaning

DANGER

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

NOTE!

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.1.2 Electrical symbols

Symbol Meaning Symbol Meaning

Direct current Alternating current

Direct current and alternating current Ground connection

A grounded terminal which, as far as

the operator is concerned, is grounded

via a grounding system.

Symbol Meaning

Protective Earth (PE)

A terminal which must be connected to ground prior to establishing any other connections.

The ground terminals are situated inside and outside the device:

• Inner ground terminal: Connects the protectiv earth to the mains supply.

• Outer ground terminal: Connects the device to the plant grounding system.

1.1.3 Tool symbols

A0011219 A0011220 A0013442 A0011221 A0011222

Cross-head

screwdriver

Flat blade

screwdriver Torx screwdriver Allen key Hexagon wrench

Levelflex FMP51, FMP52, FMP54 HART Important document information

Endress+Hauser 5

1.1.4 Symbols for certain types of information

Symbol Meaning Symbol Meaning

Permitted

Procedures, processes or actions that

are permitted.

Preferred

Procedures, processes or actions that

are preferred.

Forbidden

Procedures, processes or actions that

are forbidden.

Tip

Indicates additional information.

Reference to documentation.

Reference to page.

Reference to graphic.

… Series of steps.

Result of a step. Visual inspection.

1.1.5 Symbols in graphics

Symbol Meaning

1, 2, 3 ... Item numbers

… Series of steps

A, B, C, ... Views

A-A, B-B, C-C, ... Sections

Hazardous area

Indicates a hazardous area.

Safe area (non-hazardous area)

Indicates the non-hazardous area.

1.1.6 Symbols at the device

Symbol Meaning

Safety instructions

Observe the safety instructions contained in the associated Operating Instructions.

Temperature resistance of the connection cables

Specifies the minimum value of the temperature resistance of the connection cables.

Basic safety instructions Levelflex FMP51, FMP52, FMP54 HART

6 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for the personnel

The personnel must fulfill the following requirements for its tasks:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task.

‣Are authorized by the plant owner/operator.

‣Are familiar with federal/national regulations.

‣Before starting work, read and understand the instructions in the manual and

supplementary documentation as well as the certificates (depending on the application).

‣Follow instructions and comply with basic conditions.

2.2 Designated use

Application and measured materials

The measuring device described in these Operating Instructions is intended only for level and

interface measurement of liquids. Depending on the version ordered the device can also

measure potentially explosive, flammable, poisonous and oxidizing materials.

Observing the limit values specified in the "Technical data" and listed in the Operating

Instructions and supplementary documentation, the measuring device may be used for the

following measurements only:

‣Measured process variable: Level and/or interface

‣Calculated process variable: Volume oder mass in arbitrarily shaped vessels (calculated

from the level by the linearization functionality)

To ensure that the measuring device remains in proper condition for the operation time:

‣Use the measuring device only for measured materials against which the process-wetted

materials are adequately resistant.

‣Observe the limit values in "Technical data".

Incorrect use

The manufacturer is not liable for damage caused by improper or non-designated use.

Verification for borderline cases:

‣For special measured materials and cleaning agents, Endress+Hauser is glad to provide

assistance in verifying the corrosion resistance of wetted materials, but does not accept any

warranty or liability.

Residual risk

The electronics housing and its built-in components such as display module, main electronics

module and I/O electronics module may heat to 80 °C (176 °F) during operation through heat

transfer from the process as well as power dissipation within the electronics. During operation

the sensor may assume a temperature near the temperature of the measured material.

Danger of burns due to heated surfaces!

‣For high process temperatures: Install protection against contact in order to prevent burns.

Levelflex FMP51, FMP52, FMP54 HART Basic safety instructions

Endress+Hauser 7

2.3 Workplace safety

For work on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

With divisible probe rods, medium may penetrate into the joints between the indivual parts of

the rod. This medium may escape when loosening the joints. In the case of dangerous (e.g.

aggressive or toxic) media this may cause injuries.

‣When loosening the joints between the individual parts of the probe rod: Wear appropriate

protective equipment according to the medium.

2.4 Operational safety

Risk of injury.

‣Operate the device in proper technical condition and fail-safe condition only.

‣The operator is responsible for interference-free operation of the device.

Conversions to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers.

‣If, despite this, modifications are required, consult with the manufacturer.

Repair

To ensure continued operational safety and reliability,

‣Carry out repairs on the device only if they are expressly permitted.

‣Observe federal/national regulations pertaining to repair of an electrical device.

‣Use original spare parts and accessories from the manufacturer only.

Hazardous area

To eliminate a danger for persons or for the facility when the device is used in the hazardous

area (e.g. explosion protection, pressure vessel safety):

‣Based on the nameplate, check whether the ordered device is permitted for the intended

use in the hazardous area.

‣Observe the specifications in the separate supplementary documentation that is an integral

part of these Instructions.

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which it

is safe to operate. It meets general safety standards and legal requirements.

NOTICE

Loss of degree of protection by opening of the device in humid environments

‣If the device is opened in a humid environment, the degree of protection indicated on the

nameplate is no longer valid. This may also impair the safe operation of the device.

Basic safety instructions Levelflex FMP51, FMP52, FMP54 HART

8 Endress+Hauser

2.5.1 CE mark

The measuring system meets the legal requirements of the applicable EC guidelines. These are

listed in the corresponding EC Declaration of Conformity together with the standards applied.

Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.

2.5.2 EAC conformity

The measuring system meets the legal requirements of the applicable EAC guidelines. These

are listed in the corresponding EAC Declaration of Conformity together with the standards

applied.

Endress+Hauser confirms successful testing of the device by affixing to it the EAC mark.

Levelflex FMP51, FMP52, FMP54 HART Product description

Endress+Hauser 9

3 Product description

3.1 Product design

3.1.1 Levelflex FMP51/FMP52/FMP54/FMP55

A0012399

 1 Design of the Levelflex

1 Electronics housing

2 Process connection (here as an example: flange)

3 Rope probe

4 End-of-probe weight

5 Rod probe

6 Coax probe

Incoming acceptance and product identification Levelflex FMP51, FMP52, FMP54 HART

10 Endress+Hauser

4 Incoming acceptance and product identification

4.1 Incoming acceptance

Upon receipt of the goods check the following:

• Are the order codes on the delivery note and the product sticker identical?

• Are the goods undamaged?

• Do the nameplate data match the ordering information on the delivery note?

• Is the DVD with the operating tool present?

If required (see nameplate): Are the Safety Instructions (XA) present?

If one of these conditions is not satisfied, contact your Endress+Hauser Sales Center.

4.2 Product identification

The following options are available for identification of the measuring device:

• Nameplate specifications

• Order code with breakdown of the device features on the delivery note

• Enter serial numbers from nameplates in W@M Device Viewer

( www.endress.com/deviceviewer ): All information about the measuring device is

displayed.

• Enter the serial number from the nameplates into the Endress+Hauser Operations App or

scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations

App: all the information for the measuring device is displayed.

Autres manuels pour Levelflex FMP51

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Endress+Hauser Radar

Endress+Hauser

Endress+Hauser Micropilot FMR50 Instructions d'utilisation et d'installation

Endress+Hauser

Endress+Hauser Micropilot M FMR245 Manuel utilisateur

Endress+Hauser

Endress+Hauser Levelflex FMP53 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR66B PROFINET with Ethernet-APL Caractéristiques techniques

Endress+Hauser

Endress+Hauser Levelflex M FMP40 Manuel de la liste des pièces

Endress+Hauser

Endress+Hauser micropilot M FMR 230 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR67B PROFINET with Ethernet-APL Caractéristiques techniques

Endress+Hauser

Endress+Hauser Micropilot M FMR244 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR51 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Micropilot FMR51 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR63B PROFIBUS PA Manuel

Endress+Hauser

Endress+Hauser Micropilot FMR50 Caractéristiques techniques

Endress+Hauser

Endress+Hauser levelflex M FMP 40 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot M FMR244 Manuel utilisateur

Endress+Hauser

Endress+Hauser FOUNDATION Fieldbus Levelflex FMP51 Caractéristiques techniques

Endress+Hauser

Endress+Hauser PROFIBUS PA Levelflex FMP50 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR62B PROFINET with Ethernet-APL Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR63B Caractéristiques techniques

Endress+Hauser

Endress+Hauser Levelflex FMP53 FOUNDATION Fieldbus Caractéristiques techniques

Endress+Hauser

Endress+Hauser Levelflex FMP56 Manuel utilisateur

Endress+Hauser

Endress+Hauser Micropilot FMR66B Caractéristiques techniques

Endress+Hauser

Endress+Hauser micropilot M FMR 231 Manuel utilisateur

Endress+Hauser

Endress+Hauser Levelflex FMP56 Manuel utilisateur

Endress+Hauser

Endress+Hauser PROFIBUS PA Micropilot FMR53 Caractéristiques techniques

Manuels Radar populaires d'autres marques

SAW D2L

SAW D2L Valentine One Gen2 Manuel utilisateur

Raymarine

Raymarine Raytheon R20X Manuel utilisateur

Simrad

Simrad CA34 Manuel utilisateur

ECHOMAX

ECHOMAX Active-X-Band Manuel utilisateur

AGD

AGD 340 Manuel utilisateur

Kustom Signals

Kustom Signals Eagle 3 Manuel utilisateur

SYMEO

SYMEO STU Manuel utilisateur

Axis

Axis D2110-VE Manuel utilisateur

MALA

MALA MIRA Manuel utilisateur

Emerson

Emerson ROSEMOUNT 5300 Manuel utilisateur

Rosemount

Rosemount 5300 Series Manuel utilisateur

TERMA

TERMA SCANTER 5102 Manuel utilisateur

GSSI

GSSI UtilityScan Manuel utilisateur

Acconeer

Acconeer A111 Manuel utilisateur

Crosley

Crosley CR37 Manuel utilisateur

AGD

AGD 318 Manuel utilisateur

Cobra

Cobra SLR 650G Manuel utilisateur

Faselase

Faselase D10 Manuel utilisateur
