Brief Operating Instructions

Levelflex FMP53

PROFIBUS PA

Guided wave radar

These Instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Detailed information about the device can be found in the

Operating Instructions and the other documentation:

Available for all device versions via:

– Internet: www.endress.com/deviceviewer

– Smart phone/tablet: Endress+Hauser Operations App

KA01080F/00/EN/16.18

71396569

2018-04-12

Levelflex FMP53 PROFIBUS PA

2 Endress+Hauser

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

Levelflex FMP53 PROFIBUS PA Table of contents

Endress+Hauser 3

Table of contents

1 Important document information ................................................. 4

1.1 Symbols ............................................................................. 4

1.2 Terms and abbreviations ................................................................. 6

1.3 Registered trademarks .................................................................. 7

2 Basic safety instructions .......................................................... 8

2.1 Requirements for the personnel ............................................................ 8

2.2 Designated use ........................................................................ 8

2.3 Workplace safety ...................................................................... 9

2.4 Operational safety ......................................................................9

2.5 Product safety ......................................................................... 9

3 Product description .............................................................. 10

3.1 Product design ....................................................................... 10

4 Incoming acceptance and product identification ................................. 11

4.1 Incoming acceptance ................................................................... 11

4.2 Product identification .................................................................. 11

5 Storage, Transport ............................................................... 12

5.1 Storage conditions .................................................................... 12

5.2 Transport product to the measuring point ................................................... 12

6 Mounting ....................................................................... 13

6.1 Mounting requirements ................................................................ 13

6.2 Mounting the device ................................................................... 14

6.3 Post-installation check ................................................................. 19

7 Electrical connection ............................................................ 20

7.1 Connection conditions .................................................................. 20

7.2 Connecting the measuring device ......................................................... 26

7.3 Post-connection check ..................................................................29

8 Integration into a PROFIBUS network ............................................ 29

8.1 Overview of the device database files (GSD) .................................................. 29

8.2 Set device address ..................................................................... 30

9 Commissioning via wizard ....................................................... 32

10 Commissioning (via operating menu) ............................................ 33

10.1 Display and operating module ............................................................ 33

10.2 Operating menu ...................................................................... 36

10.3 Unlock the device ..................................................................... 37

10.4 Setting the operating language ........................................................... 37

10.5 Configuration of a level measurement ...................................................... 38

10.6 User-specific applications ............................................................... 39

Important document information Levelflex FMP53 PROFIBUS PA

4 Endress+Hauser

1 Important document information

1.1 Symbols

1.1.1 Safety symbols

Symbol Meaning

DANGER

DANGER!

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

WARNING!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

CAUTION!

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

NOTE!

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.1.2 Electrical symbols

Symbol Meaning Symbol Meaning

Direct current Alternating current

Direct current and alternating current Ground connection

A grounded terminal which, as far as

the operator is concerned, is grounded

via a grounding system.

Symbol Meaning

Protective Earth (PE)

A terminal which must be connected to ground prior to establishing any other connections.

The ground terminals are situated inside and outside the device:

• Inner ground terminal: Connects the protectiv earth to the mains supply.

• Outer ground terminal: Connects the device to the plant grounding system.

1.1.3 Tool symbols

A0011219 A0011220 A0013442 A0011221 A0011222

Cross-head

screwdriver

Flat blade

screwdriver Torx screwdriver Allen key Hexagon wrench

Levelflex FMP53 PROFIBUS PA Important document information

Endress+Hauser 5

1.1.4 Symbols for certain types of information

Symbol Meaning Symbol Meaning

Permitted

Procedures, processes or actions that

are permitted.

Preferred

Procedures, processes or actions that

are preferred.

Forbidden

Procedures, processes or actions that

are forbidden.

Tip

Indicates additional information.

Reference to documentation.

Reference to page.

Reference to graphic.

… Series of steps.

Result of a step. Visual inspection.

1.1.5 Symbols in graphics

Symbol Meaning

1, 2, 3 ... Item numbers

… Series of steps

A, B, C, ... Views

A-A, B-B, C-C, ... Sections

Hazardous area

Indicates a hazardous area.

Safe area (non-hazardous area)

Indicates the non-hazardous area.

1.1.6 Symbols at the device

Symbol Meaning

Safety instructions

Observe the safety instructions contained in the associated Operating Instructions.

Temperature resistance of the connection cables

Specifies the minimum value of the temperature resistance of the connection cables.

Important document information Levelflex FMP53 PROFIBUS PA

6 Endress+Hauser

1.2 Terms and abbreviations

Term/abbreviation Explanation

BA Document type "Operating Instructions"

KA Document type "Brief Operating Instructions"

TI Document type "Technical Information"

SD Document type "Special Documentation"

XA Document type "Safety Instructions"

PN Nominal pressure

MWP Maximum Working Pressure

The MWP can also be found on the nameplate.

ToF Time of Flight

FieldCare Scalable software tool for device configuration and integrated plant asset management solutions

DeviceCare Universal configuration software for Endress+Hauser HART, PROFIBUS, FOUNDATION Fieldbus

and Ethernet field devices

DTM Device Type Manager

DD Device Description for HART communication protocol

εr (DC value) Relative dielectric constant

Operating tool The term "operating tool" is used in place of the following operating software:

• FieldCare / DeviceCare, for operation via HART communication and PC

• SmartBlue (app), for operation using an Android or iOS smartphone or tablet.

BD Blocking Distance; no signals are analyzed within the BD.

PLC Programmable Logic Controller

CDI Common Data Interface

PFS Pulse Frequence Status (Switching output)

Levelflex FMP53 PROFIBUS PA Important document information

Endress+Hauser 7

1.3 Registered trademarks

PROFIBUS®

Registered trademark of the PROFIBUS User Organization, Karlsruhe, Germany

Bluetooth®

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG,

Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and

trade names are those of their respective owners.

Apple®

Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the

U.S.and other countries. App Store is a service mark of Apple Inc.

Android®

Android, Google Play and the Google Play logo are trademarks of Google Inc.

KALREZ®, VITON®

Registered trademark of DuPont Performance Elastomers L.L.C., Wilmington, USA

TEFLON®

Registered trademark of E.I. DuPont de Nemours & Co., Wilmington, USA

TRI CLAMP®

Registered trademark of Alfa Laval Inc., Kenosha, USA

Basic safety instructions Levelflex FMP53 PROFIBUS PA

8 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for the personnel

The personnel must fulfill the following requirements for its tasks:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task.

‣Are authorized by the plant owner/operator.

‣Are familiar with federal/national regulations.

‣Before starting work, read and understand the instructions in the manual and

supplementary documentation as well as the certificates (depending on the application).

‣Follow instructions and comply with basic conditions.

2.2 Designated use

Application and measured materials

The measuring device described in these Operating Instructions is intended only for level

measurement of liquids. Depending on the version ordered the device can also measure

potentially explosive, flammable, poisonous and oxidizing materials.

Observing the limit values specified in the "Technical data" and listed in the Operating

Instructions and supplementary documentation, the measuring device may be used for the

following measurements only:

‣Measured process variables: level

‣Calculated process variables: Volume or mass in arbitrarily shaped vessels (calculated from

the level by the linearization functionality)

To ensure that the measuring device remains in proper condition for the operation time:

‣Use the measuring device only for measured materials against which the process-wetted

materials are adequately resistant.

‣Observe the limit values in "Technical data".

Incorrect use

The manufacturer is not liable for damage caused by improper or non-designated use.

Verification for borderline cases:

‣For special measured materials and cleaning agents, Endress+Hauser is glad to provide

assistance in verifying the corrosion resistance of wetted materials, but does not accept any

warranty or liability.

Residual risk

The electronics housing and its built-in components such as display module, main electronics

module and I/O electronics module may heat to 80 °C (176 °F) during operation through heat

transfer from the process as well as power dissipation within the electronics. During operation

the sensor may assume a temperature near the temperature of the measured material.

Danger of burns due to heated surfaces!

‣For high process temperatures: Install protection against contact in order to prevent burns.

Levelflex FMP53 PROFIBUS PA Basic safety instructions

Endress+Hauser 9

2.3 Workplace safety

For work on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

With divisible probe rods, medium may penetrate into the joints between the indivual parts of

the rod. This medium may escape when loosening the joints. In the case of dangerous (e.g.

aggressive or toxic) media this may cause injuries.

‣When loosening the joints between the individual parts of the probe rod: Wear appropriate

protective equipment according to the medium.

2.4 Operational safety

Risk of injury.

‣Operate the device in proper technical condition and fail-safe condition only.

‣The operator is responsible for interference-free operation of the device.

Conversions to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers.

‣If, despite this, modifications are required, consult with the manufacturer.

Repair

To ensure continued operational safety and reliability,

‣Carry out repairs on the device only if they are expressly permitted.

‣Observe federal/national regulations pertaining to repair of an electrical device.

‣Use original spare parts and accessories from the manufacturer only.

Hazardous area

To eliminate a danger for persons or for the facility when the device is used in the hazardous

area (e.g. explosion protection, pressure vessel safety):

‣Based on the nameplate, check whether the ordered device is permitted for the intended

use in the hazardous area.

‣Observe the specifications in the separate supplementary documentation that is an integral

part of these Instructions.

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which it

is safe to operate. It meets general safety standards and legal requirements.

NOTICE

Loss of degree of protection by opening of the device in humid environments

‣If the device is opened in a humid environment, the degree of protection indicated on the

nameplate is no longer valid. This may also impair the safe operation of the device.

Product description Levelflex FMP53 PROFIBUS PA

10 Endress+Hauser

2.5.1 CE mark

The measuring system meets the legal requirements of the applicable EC guidelines. These are

listed in the corresponding EC Declaration of Conformity together with the standards applied.

Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.

2.5.2 EAC conformity

The measuring system meets the legal requirements of the applicable EAC guidelines. These

are listed in the corresponding EAC Declaration of Conformity together with the standards

applied.

Endress+Hauser confirms successful testing of the device by affixing to it the EAC mark.

3 Product description

3.1 Product design

3.1.1 Levelflex FMP53

A0013421

 1 Design of the Levelflex

1 Electronics housing

2 Process connection

3 Rod probe

Autres manuels pour Levelflex FMP53

Table des matières

Autres manuels Endress+Hauser Instrument de mesure

Endress+Hauser

Endress+Hauser Waterpilot FMX167 Manuel utilisateur

Endress+Hauser

Endress+Hauser DipFit W CPA 111 Manuel utilisateur

Endress+Hauser

Endress+Hauser Levelflex FMP50 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Tank Side Monitor NRF590 Manuel

Endress+Hauser

Endress+Hauser Proline t-mass A 150 Manuel

Endress+Hauser

Endress+Hauser Proline Promass E 200 Manuel

Endress+Hauser

Endress+Hauser Deltapilot S FMB70 Manuel utilisateur

Endress+Hauser

Endress+Hauser Teqwave F Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass 83 Manuel utilisateur

Endress+Hauser

Endress+Hauser promag 50 PROFIBUS-PA Caractéristiques techniques

Endress+Hauser

Endress+Hauser Memocheck CYP02D Manuel utilisateur

Endress+Hauser

Endress+Hauser Levelflex M FMP45 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promass A 100 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 10D Manuel

Endress+Hauser

Endress+Hauser Levelflex FMP50 Manuel utilisateur

Endress+Hauser

Endress+Hauser Hart Micropilot FMR60B Manuel utilisateur

Endress+Hauser

Endress+Hauser Levelflex M FMP40 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Cleanfit W CPA450 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline 500 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Micropilot M FMR250 Manuel utilisateur

Endress+Hauser

Endress+Hauser Cerabar M PMC51? Cerabar M PMP51 Manuel utilisateur

Endress+Hauser

Endress+Hauser Levelflex FMP53 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag L 800 Caractéristiques techniques

Endress+Hauser

Endress+Hauser Proline Promass O 500 PROFIBUS DP Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur

Acterna

Acterna MS1400 Manuel utilisateur

R&S

R&S ZPH Manuel utilisateur
