The Light pack contains:

IP44 rated floor standing light.

The following tools may be required:

Selection of cross and flat head screwdrivers.

Electric drill and assorted drill bits.

Wire strippers.

Electrical insulation tape.

INSTRUCTION MANUAL

These products are only suitable for connection to a 240V~50Hz supply.

It is recommended that these floor standing lights are installed by a qualified electrician in accordance with

current IEE Wiring Regulations and local Building Regulations and are for the Domestic environment only.

These light fittings should be connected to a lighting circuit protected by a 5 amp fuse (or a 6 amp miniature

circuit breaker).

These lights have an IP44 (splash proof) rating suitable for use outdoors.

Run supply wire from a 5-amp electrical supply using double insulated 3-core cable of type H05RN-F 1.0mm2

(not supplied) to selected site, ensuring it is adequately protected through the full length of the cable run, it

must come out of the mounting surface in line with the entry to the fitting and should be at least 250mm in

length.

Except where installed in a conduit or duct , which provides equivalent protection against mechanical damage,

a cable buried in the ground shall incorporate an earthed armour or metal sheath or both, suitable for use as a

protective conductor, or be of insulated concentric construction. Buried cables shall be marked by cable

covers or a suitable marking tape. Buried conduits and ducts shall be suitably identified. Buried cables,

conduits and ducts shall be at a sufficient depth to avoid being damaged by any reasonably foreseeable

disturbance of the ground.

This product contains breakable parts – be careful during handling and maintenance to avoid breakage.

The shade can become hot in use. Switch off and allow 10 minutes to cool before cleaning.

If any part of the bulb housing is broken or cracked then it must be replaced immediately to preserve the water

ingress protection, please consult your retailer. This is represented by the symbol

These products contain breakable parts – be careful during handling and maintenance to avoid breakage.

If any modification is made it will invalidate the warranty and may render the products unsafe.

Before you start

Please read these instructions carefully before fitting your new light and retain for reference.

Switch off the mains supply and remove the appropriate fuse or switch off the appropriate circuit breaker

before commencing installation.

Ensure that no one else has access that would enable the supply to be inadvertently reconnected.

Ensure that there are no cables / pipes beneath the surface (other than the supply cable for this fitting).

The mounting surface must be secure and able to accommodate the weight / height of the fitting. If installing on an

existing secure (concrete) base, use the holes in the post base as a template to drill suitable fixing holes and prepare

with suitable ground fixing bolts (not supplied).The supply cable (at least 250mm) must come out of the mounting

surface and directly into the terminal block in the base/post of the fitting.

Check the packaging and make sure that you have all the required parts.

Follow each assembly step in order to prevent incorrect assembly

Make sure all screws / nuts, including electrical connections etc are fully tightened before use.

67699/67700 - Canillo Outdoor post/bollard fittings.

Safety Warnings

1. Diagram A. Determine the

position of your light fitting.

Ensure there is sufficient power

cable to connect to the fitting –

we recommend at least 250mm.

Ensure that the mounting surface

is solid. If you are using anchor

bolts (not supplied) prepare the

mounting surface as appropriate

(and ensure that there are no

other cables or pipes beneath the

surface).

2. Place the base of the light fitting

over the cable and use it as a

template to mark the mounting

hole positions. Drill and plug the

holes ready to mount the fitting

later.

3. Diagram B. Pull the terminal

block assembly out of the base of

the fitting. Remove the cable

clamp and take the lid off the

terminal block housing to expose

the internal terminal block.

4. Connect the house wiring to the

internal terminal block. NOTE:

This is a Class I fitting and

must be earthed. Connect the

incoming mains as per the

WIRING DETAILS diagram

5. Re-fit the terminal block into its

housing and secure – ensuring

that all seals are correctly

located.

6. Secure the cable clamp over the

incoming cable and then push the

terminal block assembly fully

inside the base / stem.

7. Secure the post (screws / bolts

etc not supplied) to the mounting

surface making sure that all

cables are contained inside the

fitting.

8. Unscrew the lid and fit the bulb.

Max. 3.5W GU10. When

changing a bulb, always switch

off at the mains and allow the

bulb to cool before handling.

Dispose of used bulbs carefully.

Do not exceed the wattage stated

or use a different shape bulb from

that indicated on the fitting.

9. Re-fit the lid. Ensure the rubber

seal is in place for ingress

protection. Do not overtighten.

10. Turn on the

power and test.

These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.

Assembly / user instructions

Endon Lighting

Leeds

LS9 0SE

67699_67700 Canillo-FL-20151222

Diagram A

Diagram B

WIRING DETAILS
