Quick Start Guide

TK3/TK4 Cooling System and

Fan Shroud Assemblies

Models TK3-2932, TK4-2932 and SO4-2932

This quick start guide is effective for consumer installations of the part numbers listed in

System Part Numbers. OEM installers must contact EMP for production requirements.

Product Overview

The information contained in this manual is updated periodically. While great care is taken in compiling the information contained in this manual, Engineered

Machined Products, Inc. cannot assume liability for losses of any nature arising from any errors and/or omissions.

The information and specifications contained throughout this manual are up to date at the time of publication. Engineered Machined Products, Inc. reserves

the right to change the content of this manual at any time without notice.

Engineered Machined Products Inc.

2701 North 30th Street

Escanaba, MI, USA 49829

Phone: +1 (906) 789-7497

www.emp-corp.com

Service@emp-corp.com

Product Overview

The EMP TK3/TK4 Thermal System Assembly is a revolutionary advanced thermal product designed for

applications requiring cooling of natural gas engine water jacket circuits, power electronic components or any

other general cooling application using water/ethylene glycol or similar coolant. Benefits include lower energy

consumption, reduced noise, individual fan diagnostics and improved temperature control.

Service parts and the full service manual for this product can be obtained at http://www.emp-

corp.com/support/documents by searching for the system part number.
