Emerson Micro Motion TA Series Manuel utilisateur
Installation Manual
MMI-20040393, Rev AE
May 2021
Micro Motion™ TA-Series Flow and Density
Meters
Safety messages
Safety messages are provided throughout this manual to protect personnel and equipment. Read each safety message carefully
before proceeding to the next step.
Safety and approval information
This Micro Motion product complies with all applicable European directives when properly installed in accordance with the
instructions in this manual. Refer to the EU declaration of conformity for directives that apply to this product. The EU declaration
of conformity, with all applicable European directives, the complete ATEX Installation Drawings and Instructions, the IECEx
Installation Instructions for installations outside of the European Union, and the CSA Installation Instructions for installations in
North America are available on the internet at www.emerson.com or through your local Micro Motion support center.
Information affixed to equipment that complies with the Pressure Equipment Directive, can be found on the internet at
www.emerson.com.
For hazardous installations in Europe, refer to standard EN 60079-14 if national standards do not apply.
Other information
Full product specifications can be found in the product data sheet. Troubleshooting information can be found in the configuration
manual. Product data sheets and manuals are available from the Micro Motion web site at www.emerson.com.
Return policy
Follow Micro Motion procedures when returning equipment. These procedures ensure legal compliance with government
transportation agencies and help provide a safe working environment for Micro Motion employees. Micro Motion will not accept
your returned equipment if you fail to follow Micro Motion procedures.
Return procedures and forms are available on our web support site at www.emerson.com, or by phoning the Micro Motion
Customer Service department.
Emerson Flow customer service
Email:
•Worldwide: [email protected]
•Asia-Pacific: [email protected]
Telephone:
North and South America Europe and Middle East Asia Pacific
United States 800-522-6277 U.K. and Ireland 0870 240 1978 Australia 800 158 727
Canada +1 303-527-5200 The Netherlands +31 (0) 70 413
6666
New Zealand 099 128 804
Mexico +52 55 5809 5010 France +33 (0) 800 917
901
India 800 440 1468
Argentina +54 11 4809 2700 Germany 0800 182 5347 Pakistan 888 550 2682
Brazil +55 15 3413 8000 Italy +39 8008 77334 China +86 21 2892 9000
Chile +56 2 2928 4800 Central & Eastern +41 (0) 41 7686
111
Japan +81 3 5769 6803
Peru +51 15190130 Russia/CIS +7 495 995 9559 South Korea +82 2 3438 4600
Egypt 0800 000 0015 Singapore +65 6 777 8211
Oman 800 70101 Thailand 001 800 441 6426
Qatar 431 0044 Malaysia 800 814 008
Kuwait 663 299 01
South Africa 800 991 390
Saudi Arabia 800 844 9564
UAE 800 0444 0684
2
Contents
Chapter 1 Before you begin........................................................................................................5
1.1 About this document...................................................................................................................5
1.2 Hazard messages.........................................................................................................................5
1.3 Related documentation............................................................................................................... 6
Chapter 2 Planning.................................................................................................................... 7
2.1 About this document...................................................................................................................7
2.2 Installation checklist.................................................................................................................... 7
2.3 Best practices.............................................................................................................................. 8
2.4 Temperature limits...................................................................................................................... 9
Chapter 3 Mounting.................................................................................................................11
3.1 Mount the meter....................................................................................................................... 11
Chapter 4 Wiring..................................................................................................................... 13
4.1 Tantalum wiring.........................................................................................................................13
Chapter 5 Grounding................................................................................................................15
Chapter 6 Purge the sensor case .............................................................................................. 17
Installation Manual Contents
MMI-20040393 May 2021
Installation Manual 3
Contents Installation Manual
May 2021 MMI-20040393
4 Micro Motion TA Series
1 Before you begin
1.1 About this document
This document provides information on planning, mounting, wiring, and grounding the
TA-Series sensor.
The information in this document assumes that users understand basic transmitter and
sensor installation, configuration, and maintenance concepts and procedures.
1.2 Hazard messages
This document uses the following criteria for hazard messages based on ANSI standards
Z535.6-2011 (R2017).
DANGER
Serious injury or death will occur if a hazardous situation is not avoided.
WARNING
Serious injury or death could occur if a hazardous situation is not avoided.
CAUTION
Minor or moderate injury will or could occur if a hazardous situation is not avoided.
NOTICE
Data loss, property damage, hardware damage, or software damage can occur if a
situation is not avoided. There is no credible risk of physical injury.
Physical access
NOTICE
Unauthorized personnel can potentially cause significant damage and/or misconfiguration
of end users' equipment. Protect against all intentional or unintentional unauthorized use.
Physical security is an important part of any security program and fundamental to
protecting your system. Restrict physical access to protect users' assets. This is true for all
systems used within the facility.
Installation Manual Before you begin
MMI-20040393 May 2021
Installation Manual 5
1.3 Related documentation
You can find all product documentation on the product documentation DVD shipped with
the product or at www.emerson.com.
See any of the following documents for more information:
•The hazardous area approvals documentation shipped with the sensor or available at
www.emerson.com/flowmeasurement.
•Micro Motion TA-Series Flow and Density Meters Product Data Sheet
•Micro Motion 9-Wire Flow Meter Cable Preparation and Installation Guide
•The transmitter installation and configuration and use guides
Before you begin Installation Manual
May 2021 MMI-20040393
6 Micro Motion TA Series
2 Planning
2.1 About this document
This manual provides information on planning, mounting, and grounding the meter. For
information on full configuration, maintenance, troubleshooting, or service of the
transmitter, see the configuration and use manual.
The information in this document assumes that users understand:
•Basic transmitter and sensor installation, configuration, and maintenance concepts
and procedures
•All corporate, local government, and national government safety standards and
requirements that guard against injuries and death
2.2 Installation checklist
□If possible, install the meter in a location that will prevent direct exposure to sunlight.
The environmental limits for the meter may be further restricted by hazardous area
approvals.
□If you plan to mount the meter in a hazardous area:
WARNING
—Verify that the meter has the appropriate hazardous area approval. Each meter
has a hazardous area approval tag attached to the meter housing.
—For ATEX/IECEx installations, strictly adhere to the safety instructions
documented in the ATEX/IECEx approvals documentation available on the
Product Documentation DVD shipped with the product or at www.emerson.com.
Be sure to reference this documentation in addition to the information shown in
this guide.
□Verify that the local ambient and process temperatures are within the limits of the
meter.
□Follow the wiring instructions in the Model 5700 installation manual for signal and
power wiring.
□Mount the meter in a location and orientation that allows sufficient clearance to open
the housing cover. Allow 8 in (203 mm) to 10 in (254 mm) clearance at the wiring
access points.
□Install the meter so that the flow direction arrow on the sensor case matches the actual
forward flow of the process. Flow direction is also software-selectable.
Installation Manual Planning
MMI-20040393 May 2021
Installation Manual 7
2.2.1 Orientation options
You can mount the meter in any orientation as long as the conduit openings or display do
not point upward. Keep the sensor tubes full of process fluid to achieve best performance.
CAUTION
Installing the meter with the conduit openings or display facing upward risks moisture
entering the housing, which could damage the meter.
Table 2-1: Preferred sensor orientation
Type TA010T - TA200T Models TA300T Model
Liquids
Slurries
2.3 Best practices
•There are no pipe run requirements for Emerson meters. Straight runs of pipe
upstream or downstream are unnecessary.
•If the meter is installed in a vertical pipeline, liquids and slurries should flow upward
through the meters. Gases should flow downward.
•Keep the meter tubes full of process fluid.
•For halting flow through the meter with a single valve, install the valve downstream
from the meter.
•Minimize bending and torsional stress on the meter. Do not use the meter to align
misaligned piping.
•The meter does not require external supports. The flanges will support the sensor in
any orientation.
•Do not use the junction box to pick up the meter.
•Do not use the junction box as a step.
•Do not unscrew and rotate the junction box as this will break the wires.
•Do not install the meter in suspended pipes.
•Do not adjust the meter position by pulling or grasping the meter.
Planning Installation Manual
May 2021 MMI-20040393
8 Micro Motion TA Series
2.4 Temperature limits
Temperature type Min Max
Process temperature -40 °F (-40.0 °C) 356 °F (180.0 °C)
Ambient temperature -40 °F (-40.0 °C) 176 °F (80.0 °C)
Use the extended mount junction box (electronic interface code H) for process
temperatures above 176 °F (80.0 °C).
Installation Manual Planning
MMI-20040393 May 2021
Installation Manual 9
Planning Installation Manual
May 2021 MMI-20040393
10 Micro Motion TA Series
