Elo TouchSystems Entuitive 1525/27L Series Manuel utilisateur

Elo Entuitive Touchmonitor

User Guide

15"LCD Desktop Touchmonitor

1525/27L-XXWC-X Series

Revision E

P/N 008520

Elo TouchSystems, Inc.

1-800-ELOTOUCH

www.elotouch.com

iii

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means, including, but not

limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written

permission of Elo TouchSystems.

Disclaimer

The information in this document is subject to change without notice. Elo TouchSystems makes no

representations or warranties with respect to the contents hereof, and specifically disclaims any

implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves

the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Elo TouchSystems to notify any person of such revisions or changes.

Trademark Acknowledgments

IntelliTouch, SecureTouch, AccuTouch, Entuitive, and MonitorMouse are trademarks of Elo

TouchSystems, Inc.

Other product names mentioned herein may be trademarks or registered trademarks of their

respective companies. Elo TouchSystems claims no interest in trademarks other than its own.

Chapter 1

Introduction 1

Precautions . . . . . . . . . . . . . . . . . . . . 1

About the Product . . . . . . . . . . . . . . . . . 1

Chapter 2

Installation and Setup 3

Unpacking Your Touchmonitor. . . . . . . . . . . 3

Product Overview . . . . . . . . . . . . . . . . . 4

Main Unit . . . . . . . . . . . . . . . . . . . . 4

Rear View . . . . . . . . . . . . . . . . . . . 4

Side View. . . . . . . . . . . . . . . . . . . . 5

Base Bottom View . . . . . . . . . . . . . . . 5

Touch Interface Connection . . . . . . . . . . . . 6

Serial Connection . . . . . . . . . . . . . . . 6

STEP 1-Removing the Back Cover . . . . . 7

STEP 2-Connecting the Video Cable . . . . 8

STEP 3-Connecting the Serial Touchscreen

Cable . . . . . . . . . . . . . . . . . . . . 9

STEP 4-Connecting the Speaker Cable . 10

STEP 5-Connecting the Power Cable. . . 11

STEP 6-Replacing the Back Cover . . . . 11

USB Connection . . . . . . . . . . . . . . . 12

STEP 1-Removing the Back Cover . . . . 13

STEP 2-Connecting the Video Cable . . . 14

STEP 3-Connecting the USB Touchscreen

Cable . . . . . . . . . . . . . . . . . . . 15

STEP 4-Connecting the Speaker Cable . 16

STEP 5-Connecting the Power Cable. . . 17

STEP 6-Replacing the Back Cover . . . . 17

Optimizing the LCD Display . . . . . . . . . . . 18

VESA Mount on Your Touchmonitor. . . . . . . 18

Accessing the VESA Mounting Interface. . . 19

Mounting the Base . . . . . . . . . . . . . . . 19

Installing the Driver Software . . . . . . . . . . 20

Installing the Serial Touch Driver . . . . . . . 21

Installing the Serial Touch Driver for Windows

XP, Windows 2000, Me, 95/98 and NT 4.0 21

Installing the Serial Touch Driver for MS-DOS

and Windows 3.1 . . . . . . . . . . . . . 22

Installing the USB Touch Driver . . . . . . . 23

Installing the USB Touch Driver for Windows

XP, Windows 2000, Me and 98 . . . . . . 23

Chapter 3

Operation 25

About Touchmonitor Adjustments. . . . . . . . 25

Using the On-Screen Display (OSD) Menus . . 25

Side Bezel Buttons . . . . . . . . . . . . . . . 26

OSD Menu Function . . . . . . . . . . . . . . 27

Chapter 4

Troubleshooting 29

Solutions to Common Problems . . . . . . . . 29

Appendix A

Native Resolution 31

Appendix B

Touchmonitor Safety 33

Care and Handling of Your Touchmonitor. . . . 34

Appendix C

Technical Specifications 35

Compatible Video Modes . . . . . . . . . . . . 35

Touchmonitor Specifications . . . . . . . . . . 36

15" LCD Touchmonitor (ET15XXL-XXWC-1)

Dimensions . . . . . . . . . . . . . . . . . . 40

Regulatory Information 43

Warranty 47

Index 49

Table of Contents

1-1

CHAPTER

HAPTER

NTRODUCTION

Congratulations on your purchase of an Elo TouchSystems Entuitive

touchmonitor. Your new touchmonitor combines the reliable performance of

Elo’s touch technology with the latest advances in LCD display design. This

combination of features creates a natural flow of information between a user

and your touchmonitor.

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s manual to maximize the life of your unit. See Appendix B for more

information on touchmonitor safety.

About the Product

Your LCD Desktop Touchmonitor is a 15.1” XGA TFT color display with the

following features:

• Direct analog RGB input

• 15.0” diagonal screen size

• 16.7 million displayable colors

• 1024 x 768 resolution

• XGA/ SVGA/ VGA/ VESA/ Mac compatible

• 30kHz~62 horizontal scan

• 56~75Hz refresh rate

1-2 Elo Entuitive Touchmonitor User Guide

• Auto adjustment capability

• High quality full screen re-scaling

• Multilingual OSD menus in four languages: English, French, German,

Spanish, and Japanese

• Serial or USB touch interface (USB requires Windows 98, 2000, Me and

XP.)

• Built in speakers

• Patented touch technology of Elo TouchSystems

• VESA DDC 1/2B data communication

• VESA DPMS power saving

• Stand with minimum 45° angle of tilt.

• Cable management device

• VESA flat panel monitor physical mounting interface (75mm)

• OSD and Power button lockouts

For full Product Specifications refer to Appendix C.

2-3

CHAPTER

HAPTER

NSTALLATION

AND

ETUP

This chapter discusses how to install your LCD touchmonitor and how to install

Elo TouchSystems driver software.

Unpacking Your Touchmonitor

Check that the following 8 items are present and in good condition:

LCD Display

User Guide-on CD,

Quick Install Guide and software CD

Speaker Cable

Monitor power cable

European monitor power cable Video cable

Serial touchscreenUSB touchscreen

cable cable

(US/Canada)

Software

Quick Install Guide

Speakercable

2-4 Elo Entuitive Touchmonitor User Guide

Product Overview

Main Unit

Rear View

LCD Display

Stand

2-5

Side View

Base Bottom View

User Controls
