Glass touch controller - 2 buttons, SHARP RFGB-20/W, RFGB-20/B
Glass touch controller - 4 buttons, SHARP RFGB-40/W, RFGB-40/B
Package
Switch unit, 1-channel RFSAI-11B-SL
The individual elements in the iNELS kit are paired and their functions are preset.
iNELS kit wireless switch enables the basic function of controlling electrical appliances - ON / OFF.
The settings of the wall controllers can be changed - see. detailed manuals of iNELS elements.
Schema
ON function of
switching unit no. 1
OFF function of
switching unit no. 1
ON function of
switching unit no. 2
OFF function of
switching unit no. 2
EAN 8595188182928 (Glass touch controller - 4 buttons, WHITE SHARP + 1 switch unit, 1-channel)
EAN 8595188182942 (Glass touch controller - 4 buttons, WHITE ROUND + 1 switch unit, 1-channel)
EAN 8595188182959 (Glass touch controller - 4 buttons, WHITE SHARP + 2 switch units, 1-channel)
EAN 8595188182973 (Glass touch controller - 4 buttons, WHITE ROUND + 2 switch units, 1-channel)
EAN 8595188182898 (Glass touch controller - 4 buttons, BLACK SHARP + 1 switch unit, 1-channel)
EAN 8595188182935 (Glass touch controller - 4 buttons, BLACK ROUND + 1 switch unit, 1-channel)
EAN 8595188182904 (Glass touch controller - 4 buttons, BLACK SHARP + 2 switch units, 1-channel)
EAN 8595188182966 (Glass touch controller - 4 buttons, BLACK ROUND + 2 switch units, 1-channel)
Glass touch controller - 2 buttons, ROUND RFGB-220/W, RFGB-220/B
Glass touch controller - 4 buttons, ROUND RFGB-240/W, RFGB-240/B
ON
switch unit
OFF
switch unit
RFGB
Glass touch controller,
SHARP / ROUND - 2,4 buttons
Characteristics
• The wireless control - used to control, lights, gate, garage door, shutters, etc.
• Thickness only 8 mm.
• 2/4 capacitive buttons allows you to control 2/4 components.
• Fast installation on any surface - the rear base allows screwing to the walls, gluing with doublesided tape or
just laying on the table
RFGB-20/W – Glass touch controller - 2 buttons, WHITE SHARP
RFGB-220/W – Glass touch controller - 2 buttons, WHITE ROUND
RFGB-40/W – Glass touch controller - 4 buttons, WHITE SHARP
RFGB-240/W – Glass touch controller - 4 buttons, WHITE ROUND
RFGB-20/B – Glass touch controller - 2 buttons, BLACK SHARP
RFGB-220/B – Glass touch controller - 2 buttons, BLACK ROUND
RFGB-40/B – Glass touch controller - 4 buttons, BLACK SHARP
RFGB-240/B – Glass touch controller - 4 buttons, BLACK ROUND
Replacement of a battery in 3 steps
Insert the CR2032 battery into Battery
holder. Watch out for polarity.
Press to open the plug-in battery holder
(you can use a flat-blade screwdriver
to open it)..
Insert the holder into
the device.
Detailed manual
Assembly
Peel o one protective
layer on the doublesided
adhesive sheets and stick them
to the marked places on the
controller.
If the device is installed on
glass, cover it with
a cover foil
Peel o the second protective
layer on the doublesided
adhesive sheets and place the
control in the prepared place.
Adhesive
Place the mounting jig on the
box and screw it on
In the installation box or on the wall
Snap on the controller.Mount the snap bar on the
controller into the installation
box or on the wall
RFGB-40/RFGB-240RFGB-20/RFGB-220
Technical parameters
Power voltage:
Battery life:
Transmission indication
Number of capacitive buttons:
Communication Protocol:
Frequency:
Signal transmission method:
Range:
Material:
Other data
Operating Temperature:
Working Position
Mounting:
Protection
Pollution degree:
Dimension:
Weight:
Related standards:
2x 3 V battery CR 2032
about 2 years depending on the frequency of use
Red LED
2 4
RFIO2
868,5 MHz
one-way addressed message
in the open up to 200 m
Glass
-10 ... +50 °C (14 ... 122 °F)
any
adhesive, screw
IP20
2
SHARP 94 x 94 x 8 mm (3.7“ x 3.7“x 0.3“)
ROUND 100 x 100 x 8 mm (3.9“ x 3.9“ x 0.3“)
SHARP 107 g/ ROUND 108 g
EN 60669, EN 300 220, EN 301 489,
NVč. 426/2000Sb
RFSAI-11B-SL
Characteristics
• The switching unit with 1 output channel is used to control appliances, lights, etc.
• The BOX design lets you mount it right in an installation box, a ceiling or a controlled appliance cover.
• The switched load up to 8A (2.000 W).
• Single-function design - switch on/o .
• The output on the switching unit can be controlled by up to 25 channels (1 channel represents one button on
the controller).
• The programming button on the unit is also used for manual control of the output.
• Memory status can be pre-set in the event of a power failure.
• For components labeled as iNELS RF Control2 (RFIO2), it is possible to set the repeater function via the
RFAF/USB service device.
• Communication frequency with bidirectional protocol iNELS RF Control2(RFIO2).
Installation options
In to the installation box into the ceiling light cover under ceiling mounted
Detailed manual
Switch unit, 1-channel
RFSAI-11B-SL
RFSAI-11B-SL
230 V AC
50-60 Hz
7 VA / cos φ = 0.1 / 0.7 W
1x switching contacts (AgSnO2)
8 A / AC1 / 2000 VA
10 A / <3 s
250 V AC1
button PROG (ON/OFF)
868.5 MHz
-15 ... + 50 °C (5 ... 122 °F)
free at lead-in wires
IP40
III.
43 x 44 x 22 mm (1.9“ x 1.97“ x 0.8“)
31 g
EN 60730, EN 63044, EN 300 220, EN 301 489
Supply voltage:
Supply voltage frequency:
Power apparent / dissipated:
Output:
Number of contacts:
Rated current: / switching power
Peak current:
Max. switching voltage:
Communation:
Manual:
Frequency:
Other data:
Operating temperature:
Mounting:
Protection:
Overvoltage category:
Dimensions:
Weight:
Related standards:
Technical parameters
RFSAI-11B-SL
8 mm
20~16 AWG
0.2 ~1.5 mm2
Compatibility
The device can be combined with devices of iNELS RF Control2 with RFIO2 protocol.
Connection
The screw-less terminal
S - external input
N - neutral wire
L - phase wire
V - output
i- programing button
- manual controll
- output status indication
SLIDE IN
PUSH IN
RELEASE
Solid conductor
60 - 90 % 80 - 95 % 20 - 60 % 0 - 10 %
x
RFRP-20
80- 90 %
Radiofrequency signal penetration through various construction materials
Range up to 200 m in open space, if the signal is insucient between the controller and unit, use the signal
repeater RFRP-20 or protocol component RFIO2that supports this feature.
brick walls wooden structures
with plaster boards reinforced concrete metal partitions common glass
Warning
Instruction manual is designated for mounting and also for the usage of the device. It is always a part of its pac-
king. Installation and connection can be carried out only by a person with adequate professional qualification
with understanding this instruction manual and functions of the device, and while observing all valid regulations.
Trouble-free function of the device also depends on transportation, storing and handling. In case you notice any
sign of damage, deformation, malfunction or missing part, do not install this device and return it to its seller.
It is necessary to treat this product and its parts as electronic waste after its lifetime is terminated. Before
starting installation, make sure that all wires, connected parts or terminals are de-energized. While mounting
and servicing observe safety regulations, norms, directives and professional, and export regulations for working
with electrical devices. Do not touch parts of the device that are energized – life threat. Due to transmissivity
of RF signal, observe correct location of RF components in a building where the installation is taking place. RF
Control is designated only for mounting in interiors. Devices are not designated for installation into exteriors
and humid spaces. The must not be installed into metal switchboards and into plastic switchboards with metal
door – transmissivity of RF signal is then impossible. RF Control is not recommended for pulleys etc. – radio-
frequency signal can be shielded by an obstruction, interfered, battery of the transceiver can get flat etc. and
thus disable remote control.
