Elkay DSWH160UVPC Manuel

Table of Contents

Declaraon of Conformity 2

Associaon 2

Recommendaons for Safeguarding the

Environment 3

Explanaon of Warning/Safety Icons 3

Introducon 4

Components Guide 5

Product Specicaons 6

Before You Begin – Requirements for

Installaon 7

Mounng Dimensions 7

Operang Environment 8

Water 8

Electrical 8

Tools You Will Need 9

Unpacking the Kit 9

What’s in the Kit 10

Installing the Machine 11

Operang the Keypad 17

Roune Maintenance 18

Troubleshoong 21

Replacement Parts 24

NOTICE: Read the instrucons in this manual and retain for future reference.

Installaon and

Maintenance

Manual

ENERGY

SAVING

DSWH160UVPC

Installaon and Maintenance Manual

Declaraon of Conformity

D.M. 174

rosso 032 c

Materials compliant for contact with drinking water

This unit is intended for the dispensing of drinking water, and so the materials that enter into direct contact with

water meet the criteria for food-grade components pursuant to the current legislaon. In addion, the unit is

manufactured in compliance with Italian Ministerial Decrees 174 of 04/06/2004 and 25 of 02/07/2012.

Electrical safety

This water cooler is designed, manufactured and marketed in compliance with:

 the safety objecves of the Low Voltage Direcve 2006/95/EC;

 the protecon requirements of the Electromagnec Compability Direcve 2004/108/EC.

The electrical safety of the product is ensured only when it is properly connected to an ecient, legally

compliant grounding circuit.

UL standard for safety of drinking water coolers, ANSI/UL 399, Issued: 2008/08/22, Ed: 7, Rev: 2013/10/18

CSA standard for refrigeraon equipment, CSA C22.2 No. 120, Issued: 2013/03/01, Ed: 4

Associaon

D.M. 174

rosso 032 c

Internaonal Awards

2015 - BEST PROMOTION OF HEALTH AND HYDRATION

EUROPEAN AQUA AWARDS 2015, ROME

2015 - BEST ENVIRONMENTAL PRACTICE

EUROPEAN AQUA AWARDS 2015, ROME

2014 – BEST PROMOTION OF HEALTH AND HYDRATION

EUROPEAN AQUA AWARDS 2014, BUDAPEST

2013 – BEST PRODUCT INNOVATION

EUROPEAN AQUA AWARDS 2013, BERLIN

2012 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE

EUROPEAN AQUA AWARDS 2012, ISTANBUL

1000003740 (Rev. A - 02/2017)

Recommendaons for Safeguarding the Environment

Packaging materials

D.M. 174

rosso032 c

The packaging materials are 100% recyclable. Please follow the local guidelines on waste disposal.

For safety reasons keep the packaging material out of the reach and sight of children.

Scrappage

D.M. 174

rosso 032 c

The DSWH160UVPC water cooler is made using recyclable material.

This unit is marked in compliance with European Direcve 2002/96/EC on Waste Electrical and

Electronic Equipment (WEEE). By ensuring that the product is scrapped correctly, you will help to

prevent potenal negave consequences for the environment and for health. This symbol indicates

that the product should not be treated as domesc waste but should be taken to a dedicated recycling

center for electrical and electronic equipment. Immediately prior to scrapping, cut o the power cable.

For more informaon on the treatment, recovery and recycling of this product, please contact

the appropriate local oce, the waste disposal service or the reseller from which the product was

purchased.

This product contains no CFCs or HFCs, which contribute to global warming.

This is the rst water cooler on the American market to use natural refrigerant.

The refrigerang system is lled with R134a: a natural gas that does not contribute to global warming

and that allows for substanal Energy Savings.

Explanaon of Warning/Safety Icons

NOTICE: Indicates an instrucon which, if not followed, could result in damage to product or property

or poor product performance.

CAUTION: Indicates an instrucon which, if not followed, could result in minor or moderate injury.

WARNING: Indicates an instrucon which, if not followed, could result in serious injury or death.

DSWH160UVPC

Installaon and Maintenance Manual

Introducon

The DSWH160UVPC cooler brings contemporary style and state-of-the-art technology to commercial water

dispensers. DSWH160UVPC oer the highest level of quality and modern design.

 Mulple dispensing opons: cold sll water, cold sparkling water, and hot water

 Natural materials throughout: stainless steel

 Internal components made enrely of stainless steel

 High-insulaon ice bank ensures a high output of cold water, sll and sparkling

 Self-diagnosis and alarm system responds to lile or no water ow, an accidental water leak or the need for

CO2 cylinder replacement

 Energy Saving command: when selected, this feature enables standby funconality of the unit, with

consumpon reduced by 75% compared to full funconality

NOTICE: Due to rigorous tesng, product may reasonably be expected to contain traces of sanizing

soluon.

1000003740 (Rev. A - 02/2017)

Components Guide

ENERGY

SAVING

Removable top cover

Front door

Keypad

Drip tray

Water inlet

CO2inlet

Front Panel lock

LED alarms

Energy Saving

No/low H20/CO2 pressure

Cold sparkling

dispenser

Hot dispensers

Energy Saving

buon

Cold sll

dispenser

DSWH160UVPC

DSWH160UVPC Keypad

ENERGY

SAVING

ENERGY

SAVING

Power cord

DSWH160UVPC

Installaon and Maintenance Manual

Product Specicaons

Specicaon DSWH160UVPC

Cooling capacity gal/h (lt/h) 4 (15)

85 6 oz. cups/h

Cold water temperature 42°F – 48°F

(5.5°C – 8.8°C)

Ice bank capacity gal (lt) 2 (7)

Ice bank lb (kg) 6.6 (3.5)

Cooling technology ICE BANK single stainless steel coil

Condensaon Venlated

Adjustable cooling thermostat Yes

Refrigerant gas HFC R134a

Pump Professional booster pump

Max hot water temperature 185°F (85°C)

Hot water tank capacity gal (lt) 0.265 (1)

Heater waage 1000W

Inlet water pipe ø 3/8"

Power 110V - 60Hz

Power consumpon 1350 W - 11 A

Working room temperature Min 41°F – Max 107.6°F

(Min 5°C – Max 42°C)

UNIT WEIGHT lb (kg) 71.65

(32.5)

SHIPPING WEIGHT lb (kg) 80

(36.3)

Dimensions W x D x H

in (mm)

13 x 19.48 x 18.41

(330 x 494.9 x 467.5)

Dispensing area height in (mm)

10.67 (271)

Packaging dimensions

W x D x H

in (mm)

15.23 x 21.54 x 27.38

(387 x 547 x 695.5)

Dispensing Supply opon (sparkling, cold and hot water)

Push buons Stainless steel push buons

Energy Saving device Included, dedicated push buons

Display Alarms No/low water, No/low CO2

Materials All robust stainless steel parts

* rated at a room temp. of 77°F and inlet water temp. of 68°F

1000003740 (Rev. A - 02/2017)

Before You Begin – Requirements for Installaon

Mounng Dimensions

Width

20.9” (531mm)

Depth

23.2” (589mm)

Height

22.4” (569mm)

Height

28" (711mm)

Height

12.75"

(324mm)

Depth

3.88" (99mm)

Diameter

8" (203mm)

Width

3.25" (83mm)

Footprint:

12.9” wide x 19.2” deep

330mm x 489mm

Over counter (includes 4" clearance on sides and back)

Under counter

Water lter

CO2 cylinder (typical, 20 pound)

DSWH160UVPC

Installaon and Maintenance Manual

Operang Environment

 Install the machine in a clean, dry, well-venlated room. It is designed to funcon correctly in environments

with a temperature of 16°C to 32°C – Climac Class N, (between 61°F and 90°F).

 Check that the water cooler is level, that it is on a surface that can support its weight and in an environment

suitable for its size and use.

 Do not place the machine near a source of heat.

 To guarantee adequate venlaon, leave at least 4" (100 mm) of space around the unit.

 Take care not to damage the cooling uid circuit. It is essenal to ensure that the tubes of the refrigerant

circuit are not damaged.

 The unit is not intended for use by children.

 Keep the areas surrounding the unit dry to avoid the risk of people slipping.

 The unit must not be cleaned with a water jet.

Water

 Always connect the water cooler to a water main that supplies drinking water only.

 Use of 3/8" diameter connecons for DSWH160UVPC is recommended.

 Turn o the main water inlet tap if the unit is not to be used for a long period.

Electrical

 Check that the voltage shown on the serial number plate corresponds to the voltage being

supplied at the installaon site.

 Do not use extension cables or mulple-power sockets. The machine must be located

close enough to a standard power socket that the supplied power cable reaches without

stretching.

 Aer installaon, check that the machine is not standing on its power supply cable.

 Ensure that it is possible to disconnect the power supply either by removing the plug or via a two-pole circuit

breaker placed upstream of the plug.

 Before any maintenance or cleaning operaon is carried out, remove the plug from the socket or disconnect

the power supply.

 If the power cable is damaged, it must be replaced by the manufacturer, by its technical support service or by

a qualied technician.

 Do not posion other electrical equipment in the immediate vicinity of the water cooler.

1000003740 (Rev. A - 02/2017)

Tools You Will Need

Unpacking the Kit

Remove the front panel (labeled FRONT) and cover of the

wooden packing case.

Remove the cardboard box and the internal protecve

packaging by sliding them up and over the top.

Once you have unpacked the machine, check all components

to ensure that they are not damaged. Contact the carrier

immediately if there has been any damage during shipping.

NOTICE: Ensure that your machine is installed by a

qualied technician in compliance with the

manufacturer’s instrucons and the local safety

guidelines.

NOTICE: Only qualied technicians should access the internal components of your machine, other than

to ll the ice bank.

(2) 8" adjustable wrenches

(1) 10" adjustable pliers

(1) 12" adjustable wrench

(1) universal screwdriver

(1) 12" pipe cuer

(1) wire cung pliers

DSWH160UVPC

Installaon and Maintenance Manual

What’s in the Kit

NOTICE: CO2 source is not included and must be supplied separately.

(1) DSWH160UVPC water cooler

(1) CO2

regulator

(1) external

water lter

(2) 3/8"–quick

connect connector

(1) supply hose 1/2 ips x 3/8

tube x 12” long

(1) 3/8” x

3/8” 90° quick

connect elbow

(1) water

pressure

regulator

(1) 10' coil CO2 tubing (natural)

1/4” OD

(1) 3/8” x 1/4”

quick connect

connector

(1) 4” piece of

1/4” OD tubing

(1) 10' coil water 3/8” OD

tubing (blue)

PLUS

Front panel

keys

Table des matières

Autres manuels Elkay Distributeur d'eau

Elkay

Elkay EFA8 1J Series Manuel d'installation

Elkay

Elkay Soft Sides FLEXI-GUARD EDFP217C Manuel d'installation

Elkay

Elkay EZSG8WS 1C Series Instructions d'utilisation

Elkay

Elkay EZSTLDWS 1G Series Instructions d'utilisation

Elkay

Elkay EZ Series Manuel d'installation

Elkay

Elkay LMABF8*1A Manuel d'installation

Elkay

Elkay EMABFDTLxC Series Manuel d'installation

Elkay

Elkay ezH2O Liv Pro Manuel utilisateur

Elkay

Elkay LFAEH8F 2LJO CCC Series Manuel d'installation

Elkay

Elkay EFY8 Series Manuel d'installation

Elkay

Elkay EMASMB Mode d’emploi

Elkay

Elkay EZOOTL Series Mode d’emploi

Elkay

Elkay ESWA8 1F Series Manuel utilisateur

Elkay

Elkay EZTL EZSTL8 1D Series Manuel d'installation

Elkay

Elkay FLEXI-GUARD EMABFDTL C Series Manuel d'installation

Elkay

Elkay EZTL Series Manuel d'installation

Elkay

Elkay EZ Series Instructions d'utilisation

Elkay

Elkay Space-ette FD700-3 1J Series Manuel d'installation

Elkay

Elkay VRCTLFR Series Manuel d'installation

Elkay

Elkay Backsplash FLEXI-GUARD EHFSAD H Series Manuel d'installation

Elkay

Elkay LVRCGRN8 Series Manuel d'installation

Elkay

Elkay EZS8WS 2G Series Instructions d'utilisation

Elkay

Elkay Space-ette With FLEXI-GUARD WD701-8 1G... Manuel d'installation

Elkay

Elkay ezH2O Liv LBWD00 C Series Manuel d'installation

Manuels Distributeur d'eau populaires d'autres marques

Monarch Water

Monarch Water ULTIMATE MINI AQUA HE Manuel utilisateur

Haier

Haier HLM-109B Manuel utilisateur

abc

abc Fleck 5600SXT Manuel utilisateur

GE GXOF18G Mode d'emploi

Kenmore

Kenmore 625.385560 UltraFilter 650 Manuel utilisateur

Innova

Innova CEV+ Guide de démarrage rapide

Aries

Aries Hydra DI Manuel

GE GNCF02H Manuel utilisateur

ProFlo

ProFlo PFB Series Manuel utilisateur

Hydrotech

Hydrotech 89DF HIM Manuel utilisateur

A.O. Smith

A.O. Smith FREZYA 300S Manuel utilisateur

Frakco

Frakco Travelsoft RV 2400HD Manuel utilisateur

GE GXSF30V Mode d'emploi

Avanti

Avanti WD31EC Manuel utilisateur

Avanti

Avanti WD360 Manuel utilisateur

BRIO

BRIO CLCTTL520 Guide de l'utilisateur

3M HCD-1 Manuel utilisateur

Coway

Coway CHP-671L Manuel utilisateur
