PLEASE READ AND SAVE THIS GUIDE

Thank you for choosing Electrolux, the new premium brand in home appliances.

This

Use & Care Guide

is part of our commitment to customer satisfaction and

product quality throughout the service life of your new downdraft vent.

We view your purchase as the beginning of a relationship. To ensure our ability to

continue serving you, please use this page to record key product information.

Once you have your unit installed, we suggest you keep this manual in a safe

place for future reference. Should any problems occur, refer to the

Troubleshooting section of this manual. This information will help you quickly

identify a problem and get it remedied. In the event you require assistance, please

contact the dealer where you purchased your unit.

MAKE A RECORD FOR QUICK REFERENCE

Whenever you call to request information or service, you will need to know your

model number and serial number. You can find this information on the serial plate

located on the inside wall of your unit and on the product registration card.

Post Office Box 212378, Augusta, Georgia 30917, USA

Attach your sales

receipt to this

page for future

reference.

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

PLEASE READ all instructions completely before attempting to install or operate the

unit.

Finding Information

NONO

NOTETE

TETE

Registering your product with Electrolux enhances our ability to serve you. You can

Card in the mail. Complete and mail the Product Registration Card as soon as possible

to validate the registration date.

PRODUCT REGISTRATION INFORMATION

The package containing this manual also includes your product registration

information. Warranty coverage begins at the time your Electrolux retractable

ventilation system was purchased.

If you received a damaged product, immediately contact your dealer or builder. Do

not install or use a damaged appliance.

Please record the purchase date of your Electrolux unit and your dealer’s name,

address and telephone number.

________________________________________________

Purchase Date

________________________________________________

Electrolux Model Number

________________________________________________

Electrolux Serial Number

________________________________________________

Dealer Name

________________________________________________

Dealer Address

________________________________________________

Dealer Telephone

Keep this manual and the sales receipt together in a safe place for further

reference.

QUESTIONS?

For toll-free telephone support in the U.S. and Canada:

1-877- 4ELECTROLUX (1-877-435-3287)

For online support and Internet product information:

www.electroluxusa.com

TABLE OF CONTENTS

Finding Information ........................................... 2

Please Read And Save This Guide ................... 2

Make ARecord For Quick Reference ................ 2

Questions .......................................................... 3

Table Of Contents .............................................. 4

Safety ................................................................... 5

Important Safety Instructions .............................. 5

General Precautions .......................................... 6

Getting Started ................................................... 7

Operating Your Retractable

Ventilation System .............................................. 7

Maintenance ........................................................ 9

Maintaining Your Retractable

Ventilation System .............................................. 9

Top Cap Cleaning ............................................. 9

Filter Cleaning ................................................... 9

Intake Panel Cleaning ..................................... 10

Troubleshooting ............................................... 10

If Service is Required ...................................... 10

Troubleshooting Guide ..................................... 11

Warranty Information ....................................... 12

Finding Information

Safety

IMPORTANT SAFETY INSTRUCTIONS

Safety Precautions

Do not attempt to install or operate your unit until you have read the safety

precautions in this manual. Safety items throughout this manual are labeled with a

Warning or Caution based on the risk type.

Definitions

This is the safety alert symbol. It is used to alert you to potential personal injury

hazards. Obey all safety messages that follow this symbol to avoid possible injury

or death.

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

Indicates installation, operation or maintenance information which is important but

not hazard related.

WARNINGWARNING

WARNING

WARNING indicates a potentially hazardous situation which, if not avoided, could

result in death or serious injury.

CACA

CAUTIONUTION

UTIONUTION

UTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result

in minor or moderate injury.

CACA

CAUTIONUTION

UTIONUTION

UTION

CAUTION used without the safety alert symbol indicates a potentially hazardous

situation which, if not avoided, may result in property damage.

6Safety

General Precautions

WARNINGWARNING

WARNING

• To reduce the risk of a range top grease fire:

a) Never leave surface units unattended at high settings. Boilovers cause

smoking and greasy spillovers that may ignite. Heat oils slowly on low or

medium settings.

b) Always turn hood ON when cooking at high heat or when flambeing food (i.e.

Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambe’).

c) Clean ventilating fans frequently. Grease should not be allowed

toaccumulate on fan or filter.

d) Use proper pan size. Always use cookware appropriate for the size of the

surface element.

• To reduce the risk of injury to persons in the event of a range top grease fire,

observe the following:

a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then

turn off the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not

go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.

b) NEVER PICK UP A FLAMING PAN - You may be burned.

c) DO NOT USE WATER, including wet dishcloths or towels - a violent steam

explosion will result.

d) Use an extinguisher ONLY if:

1)You know you have a Class ABC extinguisher, and you already know how

to operate it.

2)The fire is small and contained in the area where it started.

3)The fire department is being called.

4)You can fight the fire with your back to an exit.

• To reduce the risk of fire, electric shock, or injury to persons, observe the

following:

a) Use this unit only in the manner intended by the manufacturer. If you have

questions, contact the manufacturer.

• Unplug or disconnect this appliance from the power supply before servicing.

CACA

CAUTIONUTION

UTIONUTION

UTION

For general ventilating use only. Do not use to exhaust hazardous or explosive

materials and vapors.

WARNINGWARNING

WARNING

If the vent intake becomes jammed while being raised or lowered, immediately press the

Up/Down switch once to stop the intake motion, then disconnect the power supply.

Remove the obstruction, then restore power and press the Up/Down switch to continue

raising or lowering the intake.

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

The direction of travel of the vent intake cannot be reversed while it is moving. The

intake must complete a full up or down cycle before changing directions.

Variable

Speed Control

Countertop

Top Cap

Filter

Screen

Up/Down Switch

Getting Started

OPERATING YOUR DOWNDRAFT VENT

To operate the downdraft vent system, press the Up/Down switch, located on the

top cap, once while the vent intake is in the down position (see Figure 1). The

intake will take approximately 10 seconds to reach its uppermost position where it

will stop.

The blower will then turn on to the last position

the variable speed control was set when the

intake was lowered last. The blower speed may

be adjusted by turning the variable speed

control. Blower speed may be adjusted

whenever desired, as long as the vent intake is

in the fully raised position. The blower will not

operate if the intake is in any other position.

The blower may be turned off by pressing the

Up/Down switch once, which shuts off the

blower and also lowers the vent intake.

Figure 1

8Getting Started

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

• Activate the blower a few minutes before starting to cook to establish an airflow

pattern in the room.

•Adjust the fan speed according to the volume and weight of the cooking exhaust.

•Reduce the fan speed if the flame on a gas cooktop is being drawn by the vent

system. Drawing of the flame is a normal occurrence with these powerful vent

systems, especially when installed with short duct runs.

•Always raise the vent intake and activate the blower whenever using the cooktop.

•Eliminate air currents in the vent vicinity by shutting nearby windows and doors,

turning off ceiling fans and closing adjacent heating and air conditioning

outlets.

•Place your largest frying pans, skillets and stock pots on the rear burners

whenever possible, as the draft is strongest closest to the vent intake.

WARNINGWARNING

WARNING

• Do not operate the vent system without the grill and filters in place or with dirty,

grease-laden filters.

•Do not raise or lower the vent without first verifying that pot handles or other

objects will not interfere with the moving vent intake.

•Do not set hot cookware, utensils or any other objects on the vent top cap.

•Do not leave the vent intake in the down position when using the cooktop.

Maintenance

MAINTAINING YOUR DOWNDRAFT VENT

No maintenance, other than the instructions that follow should be attempted by

the owner/operator. All other maintenance and service must be performed by a

qualified appliance technician

TOP CAP CLEANING

The top cap and end caps feature finishes that will scratch if cleaned with abrasive

materials or harsh chemicals. Gently wipe them with a sponge or soft cloth

moistened in a mild detergent solution whenever they becomes soiled. Avoid

introduction of moisture into the up/down switch area.

FILTER CLEANING

To remove the intake filter, gently grasp the filter on both ends and push down, then

pull the top of the filter out of the upper groove. The filter should be cleaned

regularly by hand-washing in hot water with mild detergent solution. After

thoroughly rinsing, filters can also be washed in the top rack of the dishwasher.

Dry the filters completely before using them again.

After cleaning, carefully reinstall the filters.

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

The top cap should be cleaned while the vent intake is in the lowered position.

IMPORIMPOR

IMPORTT

TANTANT

ANTANT

ANT

The vent intake must be in the up position to allow for filter cleaning.

10 Troubleshooting

IF SERVICE IS REQUIRED

First, review the recommended checks listed in the Troubleshooting Guide.

Then, be certain that the appliance has been installed properly and is being

operated correctly. Familiarize yourself with the warranty terms and conditions

listed in the Warranty section.

If the above checks have been completed and the problem has not yet been

remedied, contact the dealer where you purchased the unit. State the Model and

Serial number and explain the problem. The Model and Serial number plate is

located inside the unit at upper right hand corner.

If you do not know the name of the selling dealer or local service company, you can

check online at www.electroluxusa.com.

Autres manuels pour ICON E30DD75ESS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Electrolux hotte de ventilation

Electrolux

Electrolux EFV60380BX Manuel utilisateur

Electrolux

Electrolux EFP 6411 Manuel utilisateur

Electrolux

Electrolux DVK5510SW Manuel utilisateur

Electrolux

Electrolux EFI 60011 Manuel utilisateur

Electrolux

Electrolux LFG235S Manuel utilisateur

Electrolux

Electrolux EFG 535 Manuel utilisateur

Electrolux

Electrolux REHR6 Series Manuel utilisateur

Electrolux

Electrolux EFC 9510 Manuel utilisateur

Electrolux

Electrolux EFT 535X Manuel utilisateur

Electrolux

Electrolux EFC 9440 Manuel utilisateur

Electrolux

Electrolux DBGL1031CN Manuel utilisateur

Electrolux

Electrolux ICON RH36WC60GS Manuel utilisateur

Electrolux

Electrolux EFP 629 Manuel utilisateur

Electrolux

Electrolux LFT419X Manuel utilisateur

Electrolux

Electrolux EFP 662 Fiche technique

Electrolux

Electrolux EFC90245X Manuel utilisateur

Electrolux

Electrolux EFP129X Manuel utilisateur

Electrolux

Electrolux EFP6500X Manuel utilisateur

Electrolux

Electrolux SL series Mode d'emploi

Electrolux

Electrolux EFP 646 Manuel utilisateur

Electrolux

Electrolux ICON RH36WCT6GS Manuel utilisateur

Electrolux

Electrolux EFT 540-640-740 Manuel utilisateur

Electrolux

Electrolux LFV619K Manuel utilisateur

Electrolux

Electrolux U24211 EFT 530 Manuel utilisateur

Manuels hotte de ventilation populaires d'autres marques

emmeti

emmeti RECUPA MED A-140 Mode d’emploi

Nibe

Nibe F135 Manuel utilisateur

Kuppersberg

Kuppersberg INTRO 60 Instructions d'installation et d'entretien

Zephyr

Zephyr Spruce AK9834BS Guide d'installation

Hisense

Hisense MH6INBG Manuel utilisateur

Miele

Miele DA 1255 Manuel utilisateur

Broan

Broan 46000 Manuel utilisateur

GE Profile PV977 Instructions originales

FALMEC

FALMEC FFRIA24W5FS Manuel utilisateur

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuel utilisateur

Küppersbusch

Küppersbusch DX ISLA Manuel utilisateur

ETNA

ETNA AV360RVS Manuel utilisateur

JUNO

JUNO JDF603E6 Manuel utilisateur

Miele

Miele DA 6708 D Manuel utilisateur

Tricity Bendix

Tricity Bendix LE 150 Manuel

AEG

AEG X68163BV1 Manuel utilisateur

AEG

AEG 125 D Manuel utilisateur

Smeg

Smeg KSEV97X Manuel utilisateur
