Electrolux EURO OVEN Manuel utilisateur

Edition:

SERVICE MANUAL

Muggenhofer Straße 135

D-90429 Nürnberg

Germany

Fax +49 (0)911 323 1420

TSE - N

Publ.-Nr.:

599 50 72 16

685

12.99

EURO OVEN

WOEC

Test program

- 2 -

TSE-N 12.99 A. B. 599 50 72 16 EN

Page

Contents 2

Safety instructions 3

1. General technical information 4

1.1 User technical data 4

Dimensions 4

1.2 Hot plate controls 5

Circuit diagram of energy regulator 1 5

Circuit diagram of energy regulator 2 5

1.3 Oven control 5

Circuit diagram of oven thermostat 5

Thermotronic (electronic oven control, WOEC) 5

1.4 WOEC test programmes and their application 6

Descriptions of programme 1 - 6 7 - 11

Fault-finding 12

2. Service instructions 13

Dismantling front glass oven door and door handle 13

Rubber gasket between air duct and switch panel 14

- 3 -

TSE-N 12.99 A. B. 599 50 72 16 EN

Attention

mPlease observe the applicable safety requirements according to DIN/VDE 0701

(concerning repairs) and VDE 0700/ICE 355 respectively VDE 0860/IEC 65 (concerning

type of product)!

mComponents to IEC or VDE guidelines! Only use components with the same

specification for replacement!

mControls with MOS components use only components with the same specification.

mObserve MOS components handling instructions when servicing!

Recommendation for service repairs

mUse only original spare parts.

With components or assemblies accompanied with the Safety Symbol only origi-

nal-spare parts are strictly to be used.

mUse only original fuse value.

mPay attention to ratings and power data of components and protective devices.

mSafety compliance, parts of the product must not be visually damaged or unsuitable.

This is valid especially for insulators and insulating parts.

mMains leads and connecting leads should be checked for external damage before

connection. Check the insulation!

mThe functional safety of the tension relief and bending protection bushes are to be

checked.

mThermally loaded solder pads are to be suck off and re-soldered.

mEnsure that the ventilation slots are not obstructed.

Safety instructions

- 4 -

TSE-N 12.99 A. B. 599 50 72 16 EN

1. General technical information

1.1 User technical data

Capacity / Voltage

Oven heater (heating element)

Heating element bottom 1000 W / 230 V

Heating element top 1000 W / 230 V

Heating element grill 1900 W / 230 V

Heating element circulating air 2400 W / 230 V

Fan

Motor circulating air 35 W / 230 V

Querstromlüfter 16 W / 230 V

Lighting

Oven lamp rear 25 W / 230 V

Oven lamp lateral 25 W / 230 V

Dimensions

appliances dimensions

Height mm 579

Width mm 592

Depth mm 566

Built in dimensions

Built in hight mm 579

Built in width mm 540

Built in depth mm 546

- 5 -

TSE-N 12.99 A. B. 599 50 72 16 EN

1.2 Hot plate controls

Circuit diagram of energy regulator 1

1.3 Oven control

Circuit diagram of oven thermostat

Some appliances are equipped with an electronic oven control (Thermotronic). See

Chapter 1.4 for further details.

Circuit diagram of energy regulator 2

Circuit diagram for “OFF” position

Can also be closed at left stop

- 6 -

TSE-N 12.99 A. B. 599 50 72 16 EN

1.4 WOEC test programmes and their application

The control is provided with various test programmes, some of which can be switched

on manually or run automatically in the background.

Safety cut-out

The appliance is equipped with a safety circuit which switches it off automatically if the

allocated time intervals are exceeded at various temperature settings without the

functions or temperature setting being changed. This time interval is smaller the higher

the selected temperature.

Examples: up to 250 °C 3 h

up to 230 °C 6 h

up to 120 °C 12 h

Self-test

The automatic test programme which runs permanently in the background carries out a

self-test at regular intervals to monitor for correct operation of the appliance. If any

deviation from the specified parameters is detected during this test, the service symbol

and a 3-digit service code are shown in the display.

In addition, the appliance is switched on via safety relay K60 and the cooling fan via

K61.

The cooling fan cannot be switched off on the appliance as long as the above-

mentioned self-test detects the fault. The only possibility of switching off the cooling fan

is to remove the fuse in the house electrical installation.

Service test

The manual test system for the control comprises 6 test programmes. Access to these

6 test programmes is only possible if the control is in a fault mode and displaying the

current fault or the time is flashing.

This is achieved directly after connecting a voltage. If the test programmes are to be

accessed during operation, the appliance must be disconnected from the mains for at

least 10 s.

- 7 -

TSE-N 12.99 A. B. 599 50 72 16 EN

Descriptions of programme 1 - 6

Basic setting

1 - Time flashes or current fault is displayed.

2 - Press quick timer button and button I simultaneously and keep pressed for 5 s.

3 - The programme number appears in the right of the display and can be set to

1-6 using the quick timer button.

If the programme number has been preselected and no entry made for 5 s, the

control switches to the preselected test programme.

4 - Once a test programme has been executed, this programme can be quit by

pressing the Off button.

5 - See 1 for switching on the test programme.

Programme 1

in red

048

Programme number

1 Block 048

2 Block 900

3 Block 210

white

The 9-digit code which appears in 3 successive blocks of 3 digits each is the version

number of the appliance. This code indicates the E number of the appliance.

Example: Version 048 900 210 Replace the first digit 0 with 9

948 900 210 Thermotronic JUNO JEH 5690 B

- 8 -

TSE-N 12.99 A. B. 599 50 72 16 EN

Programme 2

In this programme, the individual relays in the relay unit can be switched on and off by

pressing the quick timer button. The relevant relay can be selected by pressing the

Cooking time and End of cooking time buttons at the same time. Max. 10 or fewer

relays can be selected, depending on the assignment.

Attention! If the load is switched on, the switch-on time should be kept short as

neither the cooling fan nor the hot air ventilator are running and

excessively long switch-on times can cause damage.

Programme number

white

in red

Relay number

1 Cooling fan K 61 16 W 0.07 A

2 Ring heater element K 62 2400 W 10.43 A

3 Not equipped

4 Grill K 64 1900 W 8.26 A

5 Not equipped

6 Not equipped

7 Not equipped

8 Circulation fan motor K 68 35 W 0.15 A

9 Bottom heat K 69 1000 W 4.35 A

10 Top heat K 70 1000 W 4.35 A

- 9 -

TSE-N 12.99 A. B. 599 50 72 16 EN

Programme 3 - see basic setting 1 - 5

Programme number

white

Oven sensor

red

Food thermometer

white

Programme 3 shows the temperature of the oven sensor and the food thermometer (if

inserted).

Note! The two temperatures normally differ because different measuring points

are used.

Programme 4 - see basic setting 1 - 5

If the power supply is disconnected after detecting the fault, the information is deleted

and fault code 000 appears on executing test programme 4.

If a fault has been detected but the cause of the fault no longer exists (temporary fault)

because the temperature has dropped or the cooking thermometer has been

disconnected from the socket, the relevant fault code is stored in the memory and can

be read out via test programme 4 as long as the power supply is not disconnected.

Programme number

white

000

Fault code

red

- 10 -

TSE-N 12.99 A. B. 599 50 72 16 EN

Fault reports for programme 4

Functional description:

When this module is activated, it handles all the faults present and carries out an

EEPROM check. As soon as a fault occurs, a fault register has access to the main

processor control loop. This causes the control to switch from the current status to the

fault mode (except when in the test mode): If a new fault occurs which has a higher

priority than the preceding fault, only this higher fault code is displayed. The last fault

occurring with the highest priority is stored and can be displayed by Service Test Mode

4 at any time. The fault with the highest priority is the EEPROM control fault »F«.

Fault code Type of fault

000 No fault

001 Food thermometer open-circuit ∝ Ω

002 Fodd thermometer short-circuit Ω

003 Appers when an attempt is made to switch on

the appliance again in spite of fault code display

002 odr 003.

Fault in safety circuit.

004 Appers when the child safety system is to be

switched on but the circuit is faulty

005 Not used

006 The temperature measured by the oven sensor

exceeds the temperature set by the

programming unit

007 Other tests of the oven probe and display board

probe, excluding disconnection and short-circuit

(test fault)

008 Thermostat on the board has operated

009 Thermostat on the board is short-circuit

00 A Thermostat on the board is open-circuit

00 B Not used

00 C Not used

00 D Oven sensor is short-circuit

00 E Oven sensor is disconnected

00 F EEPROM fault (microprocessor)
