Approval: ____________________________________________

K70 Vertical Cutter-Mixer

603361 (K702VU) K70 VCM (s/s bowl) 2 SPEED

208-240 V/3p/60Hz

Item No. ____________________________________

Unit to be Electrolux K702VU K70 Vertical Cutter-Mixer. Electrical

characteristics to be 208-240 V, Three-phase operation with

2 speed at 1800 or 3600 rpm. Vertical Cutter-Mixer designed

for vertical cutting and mixing in 7.4 quart quantities: puree,

mix, chop, blend, mix and knead dough. A compact design for

operator convenience the K70 occupies minimal counter space.

Housing constructed of Stainless steel with rubber feet on

base.

Short Form Specification

Electrolux Professional, Inc.

www.electroluxusa.com/professional

10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401

ITEM # ________________________________________________

MODEL # ______________________________________________

PROJECT NAME # ______________________________________

SIS # __________________________________________________

AIA # __________________________________________________

K70 Vertical Cutter-Mixer

Main features

• Power: 1-2/3HP for Two Speed Model.

• 1800/3600 RPM for Two Speed Model.

• 1.2 kW for Two Speed Model.

• Red OFF, Green ON, and PULSE Buttons

• Compact Design

• Belt Drive

• All Stainless Steel Bowl

• Magnetic safety system and motor brake. Prevents machine from running

when bowl lid swings away from magnetic switch or is open.

• Delivered with :

• 7.4 Qt. Stainless Steel bowl with microtooth, edge “S” blade included.

• Complete selection of accessories available.

• Dimensions: (H×L×W): 18.5″× 16.3″× 10″

• Approx. shipping weight—53 lbs

• NEMA L15-20P for Two Speed Model.

• 2 year parts warranty, 1 year labor.

Included Accessories:

• Microtooth Blade Rotor - 7.4 Qt. VCM (PNC 653584)

• Lid + Bowl Scrapper for 7.4 Qt. VCM (PNC 653592)

• 7.4 Qt. Stainless Bowl (PNC 653593)

Optional Accessories:

• Smooth Blade Rotor - 7.4 Qt. VCM (PNC 653583)

• Microtooth Blade Rotor - 7.4 Qt. VCM (PNC 653584)

• Lid + Bowl Scrapper for 7.4 Qt. VCM (PNC 653592)

• 7.4 Qt. Stainless Bowl (PNC 653593)

K70 Vertical Cutter-Mixer

With

L15-20P

(for Model

PNC 603361)

10.08

256 mm

7.95

202 mm

20.08

510 mm

16.61

422 mm

27.20

691 mm

K70 Vertical Cutter-Mixer

Electric

The company reserves the right to make modifications to the products

without prior notice. All information correct at time of printing.

12-15-10

Front View

Top View

Key Information

K70 Vertical Cutter-Mixer

Uses of Food Processor

MEAT

Rough mincing

Pates

Small sausages

Large sausages

Minced meat

Shellfish

Fine mincing

Stuffing

Mousses

PASTRY

Shortcrust

Cold water paste

Flan

POWDER

Almonds

Hazelnuts

FRUITS AND VEGETABLES

Purees

Mousses

Syrups

CHOPPING

Parsley

Onions

Side View

Supply voltage:

603361 (K702VU) 208-240 V/3p/60Hz – 15A
