Approval: ___________________________________________

K180 Vertical Cutter-Mixer

603302 (K180FU) K180 VCM (s/s bowl) 2 SPEED

208-240 V/3p/60Hz

Item No. ___________________________________

Unit to be Electrolux K180FU K180 Vertical Cutter-Mixer.

Electrical characteristics to be 208-240 V, Three-phase

operation with 2 speed at 1800 or 3600 rpm. Vertical Cutter-

Mixer designed for vertical cutting and mixing in 18.5 quart

quantities: puree, mix, chop, blend, mix and knead dough.

Short Form Specification

Electrolux Professional, Inc.

www.electroluxusa.com/professional

10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401

ITEM # _______________________________________________

MODEL # _____________________________________________

PROJECT NAME # ______________________________________

SIS # _________________________________________________

AIA # _________________________________________________

K180 Vertical Cutter-Mixer

Main features

• Power: 4-3/4 HP for Two Speed Model.

• 1800/3600 RPM for Two Speed Model.

• 3.6 kW for Two Speed Model.

• Red OFF, Green ON, and PULSE Buttons

• Compact Design

• Belt Drive

• All Stainless Steel Bowl

• Magnetic safety system and motor brake. Prevents machine from running

when bowl lid swings away from magnetic switch or is open.

• Delivered with :

• 18.5 Qt. Stainless Steel bowl with smooth edge “S” blade included.

• Complete selection of accessories available.

• Dimensions: (H×L×W): 23.75″× 16″× 25″

• Approx. shipping weight—150 lbs

• NEMA L15-20P for Two Speed Model

• 2 year parts warranty, 1 year labor.

Included Accessories:

• Smooth Blade Rotor - 18.5 Qt. VCM (PNC 653119)

• 18.5 Qt. Stainless Bowl (PNC 653272)

Optional Accessories:

• Smooth Blade Rotor - 18.5 Qt. VCM (PNC 653119)

• Serrated Blade Rotor - 18.5 Qt. VCM (PNC 653120)

• Equipped Scrapper for 18.5 Qt. VCM (PNC 653279)

• 18.5 Qt. Stainless Bowl (PNC 653272)

• Stainless Steel Mobile Stand (PNC 653017)

K180 Vertical Cutter-Mixer

With

L15-20P

(for Model

PNC 603302)

23.25

590 mm

48.94

1243 mm

16.38

416 mm

32.28

820 mm 28.58

726 mm

26.77

680 mm

16.93

430 mm

K180 Vertical Cutter-Mixer

Electric

The company reserves the right to make modifications to the products

without prior notice. All information correct at time of printing.

12-15-10

Front View

Top View

Key Information

K180Vertical Cutter-Mixer

Uses of Food Processor

MEAT

Rough mincing

Pates

Small sausages

Large sausages

Minced meat

Shellfish

Fine mincing

Stuffing

Mousses

PASTRY

Shortcrust

Cold water paste

Flan

POWDER

Almonds

Hazelnuts

FRUITS AND VEGETABLES

Purees

Mousses

Syrups

CHOPPING

Parsley

Onions

Side View

Supply voltage:

603302 (K180FU) 208-240 V/3p/60Hz – 13.9A

(Shown with

optional trolley.)
