Approval: ___________________________________________

K45 Vertical Cutter-Mixer

603359 (K452VU) K45 VCM (s/s bowl) 2 SPEED

208-240 V/3p/60Hz

Item No. ___________________________________

Unit to be Electrolux K452VU K45 Vertical Cutter-Mixer.

Electrical characteristics to be 208-240 V, Three-phase

operation with 2 speed at 1800 or 3600 rpm. Vertical Cutter-

Mixer designed for vertical cutting and mixing in 4.7 quart

quantities: puree, mix, chop, blend, mix and knead dough. A

compact design for operator convenience the K45 occupies

minimal counter space. Housing constructed of Stainless steel

with rubber feet on base.

Short Form Specification

Electrolux Professional, Inc.

www.electroluxusa.com/professional

10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401

ITEM # _______________________________________________

MODEL # _____________________________________________

PROJECT NAME # ______________________________________

SIS # _________________________________________________

AIA # _________________________________________________

K45 Vertical Cutter-Mixer

Main features

• Power: 1-1/4HP for Two Speed Model.

• 1800/3600 RPM for Two Speed Model.

• 900 Watts for Two Speed Model.

• Red OFF, Green ON, and PULSE Buttons

• Compact Design

• Belt Drive

• All Stainless Steel Bowl

• Magnetic safety system and motor brake. Prevents machine from running

when bowl lid swings away from magnetic switch or is open.

• Delivered with :

• 4.7 Qt. Stainless Steel bowl with microtooth edge “S” blade included.

• Complete selection of accessories available.

• Dimensions: (H×L×W): 18.5″× 16.3″× 10″

• Approx. shipping weight—49 lbs

• NEMA L15-20P for Two Speed Model.

• 2 year parts warranty, 1 year labor.

Included Accessories:

• Microtooth Blade Rotor - 4.7 Qt. VCM (PNC 653580)

• Lid + Bowl Scrapper for 4.7 Qt. VCM (PNC 653588)

• 4.7 Qt. Stainless Bowl (PNC 653589)

Optional Accessories:

• Smooth Blade Rotor - 4.7 Qt. VCM (PNC 653579)

• Microtooth Blade Rotor - 4.7 Qt. VCM (PNC 653580)

• Lid + Bowl Scrapper for 4.7 Qt. VCM (PNC 653588)

• 4.7 Qt. Stainless Bowl (PNC 653589)

K45 Vertical Cutter-Mixer

With

L15-20P

(for Model

PNC 603359)

10.08

256 mm

7.95

202 mm

16.34

415 mm

18.50

470 mm

27.0

685 mm

K45 Vertical Cutter-Mixer

Electric

The company reserves the right to make modifications to the products

without prior notice. All information correct at time of printing.

12-15-10

Front View

Top View

Key Information

K45 Vertical Cutter-Mixer

Uses of Food Processor

MEAT

Rough mincing

Pates

Small sausages

Large sausages

Minced meat

Shellfish

Fine mincing

Stuffing

Mousses

PASTRY

Shortcrust

Cold water paste

Flan

POWDER

Almonds

Hazelnuts

FRUITS AND VEGETABLES

Purees

Mousses

Syrups

CHOPPING

Parsley

Onions

Side View

Supply voltage:

603359 (K452VU) 208-240 V/3p/60Hz – 3.8A
