Electrolux Dito 601860 Manuel utilisateur

Item

Model

ProjectName

Planetary mixers

XBM20 Floor Model

with Hub

Universal 20 litre kitchen and

pastry making planetary mixer.

XBM20 is the beater-mixer for

medium size restaurants. It has a

mechanical range drive, with belt

variator system that protects

against overloading and makes the

machine extremely versatile.

FEATURES

V Powerful motor that provides all the

basic mixer functions faultlessly:

kneading of all sort of pastes, mixing of

semiliquid products, emulsions and

various sauces.

V With a 750 W rating, the XBM20 can

handle hard, low hydration kneadings

for speciality breads.

V Used with the recommended

quantities, it can also be used to

produce pizza dough.

V The motor is sufficiently dimensioned

for all kitchen work.

V Body in non-corrosive material.

V 18/8 Stainless steel bowl - 3 tools:

hook, paddle and whisk.

V A kit of wheels is available as optional

accessory for easier movement.

V Accessory drive hub for extra

functions: vegetable cutter, meat

mincer, puree strainer, sharpening

grindstone.

Specifications

MODEL

XBMF20AS5

601860

XBMF20AS35

601861

XBMF20AS36

601863

Bowl Capacity lt 20 20 20

External dimensions - mm

width 521 521 521

depth 685 685 685

height 1230 1230 1230

Working capacity - kg of flour

Choux pastry 3 3 3

Shortcrust pastry 5 5 5

Cold water paste 6 6 6

Sweet pastry 4 4 4

Croissant 5 5 5

Brioche 5 5 5

Meat kg 10 10 10

Puree - kg of potatoes 10 10 10

Power - kW

installed-electric 0.75 0.75 0.75

Net weight - kg. 95 95 95

Supply voltage 220...240 V, 1N, 50 200...240/380...415

V, 3, 50

200...220/380...440

V, 3, 60

V Splash proof planetary system to avoid

water from entering the mechanism.

V Removable safety guard for easy

cleaning.

V Adjustable feet for stability.

V Touch button control panel improves the

ergonomics and the reliability against the

humidity or water jets.

V Control panel equipped with 0-59 minute

timer.

V Pivoting and removable safety screen is

fitted with a chute for adding products

while working.

Included accessories

CODE DESCRIPTION

XBMF20AS5

601860

XBMF20AS35

601861

XBMF20AS36

601863

653426 BOWL FOR 20LT MIXER 1 1 1

653114 DOUGH HOOK FOR 20LT MIXER 1 1 1

653116 PADDLE FOR 20LT MIXER 1 1 1

653109 WHISK FOR 20LT MIXER 1 1 1

Optional accessories

CODE DESCRIPTION

XBMF20AS5

601860

XBMF20AS35

601861

XBMF20AS36

601863

653064 10L BOWL,HOOK,PADDLE,WHISK FOR 20L

MIXER ✓✓✓

653426 BOWL FOR 20LT MIXER ✓✓✓

653562 BOWL TROLLEY FOR 20/30 LT

PLANET.MIXERS ✓✓✓

653114 DOUGH HOOK FOR 20LT MIXER ✓✓✓

654041 ELECTRIC HEATING-20/30L

PLAN.MIXER-FLOOR ✓✓✓

653552 KIT WHEELS FOR (XB)20/30/40L

PLAN.MIXERS ✓✓✓

653016 MEATMINCER 70MM-H

HUB-ENTERPR.CUT+3DISCS ✓✓✓

653116 PADDLE FOR 20LT MIXER ✓✓✓

653226 PLANETARY MIXER 10L-H

HUB-DISCONN.DRIVE ✓✓✓

653187 PUREE STRAINER FOR H HUB WITH 3

GRIDS ✓✓✓

653254 REINFORCED WHISK FOR 20LT MIXER ✓✓✓

653435 S/S DISH SHELF FOR 20L/30L PLANET.

MIXER ✓✓✓

653062 SHARPENING GRINDSTONE FOR H HUB ✓✓✓

653225 VEGETAB.CUTTER H

HUB+EJECTOR-DISCONNECT. ✓✓✓

653015 VEGETABLE CUTTER H HUB WITH EJECTOR ✓✓✓

653109 WHISK FOR 20LT MIXER ✓✓✓

ADAC060

www.dito-electrolux.com

Planetary mixers

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.

Installation drawings

XXX

I - Electrical connection 220...240 V, 1N, 50 200...240/380...415

V, 3, 50

200...220/380...440

V, 3, 60

MODEL

XBMF20AS5

601860

XBMF20AS35

601861

XBMF20AS36

601863

601860, 601863, 601861

1230

1208

685

521

190
