EN User Manual Tumble Dryer

CAUTION: Read the instructions before

using the appliance.

Original Instructions.

CONTENTS

1. SAFETY INFORMATION...................................................................................... 2

2. PRODUCT DESCRIPTION................................................................................... 8

3. ACCESSORIES....................................................................................................9

4. CONTROL PANEL............................................................................................. 10

5. COIN OPERATED MACHINES...........................................................................11

6. PROGRAMME TABLE....................................................................................... 11

7. OPTIONS...........................................................................................................12

8. BEFORE FIRST USE..........................................................................................13

9. DAILY USE........................................................................................................ 13

10. HINTS AND TIPS............................................................................................. 15

11. CARE AND CLEANING....................................................................................15

12. TROUBLESHOOTING......................................................................................18

13. TECHNICAL DATA...........................................................................................20

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Read the instructions before using the appliance

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

www.electrolux.com2

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Children of less than 3 years should be kept away

unless continuously supervised.

•Keep all packaging away from children.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•If the appliance has a child safety device, we

recommend you activate it.

•Cleaning and user maintenance shall not be made by

children without supervision.

1.2 Installation

•Follow the installation instruction supplied with the

appliance.

•Make sure that the appliance is stable during

transportation.

•Remove all the packaging.

•Do not install or use a damaged appliance.

•Always be careful when you move the appliance

because it is heavy. Always wear safety gloves.

•Always move the appliance vertically.

•The appliance can be installed as freestanding or below

the kitchen counter with correct space (Refer to the

Installation leaflet).

•If the tumble dryer is put on top of a washing machine,

use the stacking kit. The stacking kit, available from

your authorized vendor, can be used only with the

ENGLISH 3

appliance specified in the instructions, supplied with the

accessory. Read it carefully before installation (Refer to

the Installation leaflet).

•Do not install or use the appliance where the

temperature is less than 5°C or higher than 35°C.

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite side,

where the appliance door can not be fully opened.

•Make sure that the floor where you install the appliance

is flat, stable, heat resistant and clean.

•Make sure that there is air circulation between the

appliance and the floor.

•The rear surface of the appliance must be put against

the wall.

•When the appliance is put in its permanent position,

check if it is fully level with the aid of a spirit level. If it is

not, adjust the feet until it is.

•Make sure that the appliance is disconnected from the

electricity supply during installation, maintenance and

repairs and cannot be reconnected until all work has

been carried out.

•Connect the mains plug to the mains socket only at the

end of the installation. Make sure that there is access to

the mains plug after the installation.

•Ensure you have good ventilation in the installation room

to avoid the back flow of gases into the room from

appliances burning other fuels, including open fires.

•Exhaust air must not be discharged into a flue which is

used for exhausting fumes from appliances burning gas

or other fuels. (if applicable)

•The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

1.3 Electrical connection

WARNING!

Risk of fire and electrical shock.

www.electrolux.com4

•The appliance must be correctly earthed. The

manufacturer is not responsible for the consequences

of an inadequate earthing system.

•Make sure that the electrical information on the rating

plate agrees with the power supply. If not, contact an

electrician.

•Always use a correctly installed shockproof socket.

•Do not use multi-plug adapters and extension cables.

•Do not pull the mains cable to disconnect the appliance.

Always pull the mains plug.

•Do not touch the mains cable or the mains plug with

wet hands.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Only for UK and Ireland. The appliance has a 13 amp

mains plug. If it is necessary to change the fuse in the

mains plug, use a 13 amp ASTA (BS 1362) fuse.

•This appliance complies with the E.E.C. Directives.

1.4 Use

WARNING!

Risk of injury, electrical shock, fire, burns or

damage to the appliance.

•Obey the maximum load volume of 8kg (refer to the

“Programme chart” chapter).

•Do not use the appliance if industrial chemicals have

been used for cleaning.

•Wipe away lint that has accumulated around the

appliance.

•Do not run the appliance without a filter. Clean the lint

filter before or after each use.

•Do not dry unwashed items in the tumble dryer.

•Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should

ENGLISH 5

be washed in hot water with an extra amount of

detergent before being dried in the tumble dryer.

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes

or pillows fitted with foam rubber pads should not be

dried in the tumble dryer.

•Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

•Remove all objects from pockets such as lighters and

matches.

•Never stop a tumble dryer before the end of the drying

cycle unless all items are quickly removed and spread

out so that the heat is dissipated.

•The final part of a tumble dryer cycle occurs without

heat (cool down cycle) to ensure that the items are left

at a temperature that ensures that the items will not be

damaged.

•Do not dry the damaged items which contain padding

or fillings.

•Only dry fabrics which are applicable to dry in the

tumble dryer. Follow the instructions on the fabric label.

•If you have washed your laundry with a stain remover

start an extra rinse cycle before you start the dryer.

•Do not drink or prepare food with the condensed water/

distilled water. It can cause health problems to people

and pets.

•Do not sit or stand on the open door.

•Do not dry dripping wet clothes in the tumble dryer.

1.5 Internal light

WARNING!

Risk of injury.

•Visible LED radiation, do not look directly into the beam.

•The type of light bulb or halogen lap used in this

appliance is not suitable for house lighting.

•To replace the internal light, contact the Authorised

Service Centre.

www.electrolux.com6

1.6 Care and cleaning

WARNING!

Risk of injury or damage to the appliance.

•Do not use water spray and steam to clean the

appliance.

•Clean the appliance with a moist soft cloth. Only use

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

1.7 Disposal

WARNING!

Risk of injury or suffocation.

•Disconnect the appliance from the mains supply.

•Cut off the mains cable and discard it.

•Remove the door catch to prevent children and pets to

get closed in the appliance.

1.8 Service

•Only original spare parts can ensure the safety

standards of the appliance.

•Only repairs undertaken by an Electrolux approved

service technician are covered by the guarantee.

ENGLISH 7

2. PRODUCT DESCRIPTION

1 2

1Water container

2Control panel

3Internal light

4Appliance door

5Filter

6Button for condenser door

7Airflow slots

8Adjustable feet

9Condenser door

10 Condenser cover

11 Locks for condenser cover

12 Rating plate

The load door can be

installed by the user in the

opposite side. It can help to

easily put and remove the

laundry or if there is a limit to

install the appliance (see

separate leaflet).

www.electrolux.com8

3. ACCESSORIES

3.1 Stacking kit

Available from your author-

ized vendor.

Stacking kit can be used

only with the washing ma-

chines specified in the leaf-

let. See the leaflet attached.

Read carefully the instruc-

tions supplied with the ac-

cessory.

3.2 Draining kit

It is available from your authorized vendor

(can be attached to some types of the

tumble dryers)

The accessory for through draining of the

condensed water into a basin, siphon,

gully, etc. After the installation, the water

container is drained automatically. The

water container must stay in the

appliance.

The installed hose must be on the height

from minimum of 50 cm to maximum of 1

m from floor level. The hose cannot be in

loop. Decrease the length of the hose if

necessary.

Read carefully the instructions supplied

with the accessory.

3.3 Pedestal with the drawer

It is available from your authorized vendor.

To put the appliance higher at the level

what helps to easy load and remove the

laundry.

The drawer can be used for laundry

storage e.g. : towels, cleaning products

and more.

Read carefully the instructions supplied

with the accessory.

ENGLISH 9

3.4 Coin operated machine If the appliance is set in a public place, it

can be connected to a coin operated

machine.

4. CONTROL PANEL

1 2

356 4

1Programme dial

2Display

3 Start/Pause button

4Options buttons

5Programme indicators

6 ON/OFF button with the Auto Off

function

4.1 Display

www.electrolux.com10

Autres manuels pour TE1120

Table des matières

Autres manuels Electrolux Séchoir

Electrolux

Electrolux EDR1000NEW Manuel utilisateur

Electrolux

Electrolux TW L4 E Manuel utilisateur

Electrolux

Electrolux TWSL4E303 Manuel utilisateur

Electrolux

Electrolux WT252 Mode d’emploi

Electrolux

Electrolux EDE 425 M Manuel utilisateur

Electrolux

Electrolux EDC 3150 Manuel utilisateur

Electrolux

Electrolux EDV5051 Manuel utilisateur

Electrolux

Electrolux FRWADREW4 Manuel utilisateur

Electrolux

Electrolux MKR62GWTWB Manuel utilisateur

Electrolux

Electrolux W455H Manuel utilisateur

Electrolux

Electrolux EWMGD65H Manuel utilisateur

Electrolux

Electrolux LAVATHERM 56840L Manuel utilisateur

Electrolux

Electrolux EDC 5371 Manuel d'utilisation

Electrolux

Electrolux EDH3497TDS Manuel utilisateur

Electrolux

Electrolux EDV705H3WB Manuel utilisateur

Electrolux

Electrolux EDE56150W Manuel utilisateur

Electrolux

Electrolux EDC2086PDW Manuel utilisateur

Electrolux

Electrolux FGQ332ES Manuel utilisateur

Electrolux

Electrolux EIMGD55I Manuel utilisateur

Electrolux

Electrolux EW6C4723SC Manuel utilisateur

Electrolux

Electrolux EDI 96150 W Manuel utilisateur

Electrolux

Electrolux EIED55HIW - 8.0 cu. Ft. Electric Dryer Manuel de service

Electrolux

Electrolux EDE 425 M Guide rapide

Electrolux

Electrolux EFDE210TIW Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire

Bosch

Bosch WTX8HKM9SN Manuel utilisateur
