Electrolux ESI5206LOX Manuel utilisateur
CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 6
4. CONTROL PANEL............................................................................................. 7
5. PROGRAMMES................................................................................................. 8
6. SETTINGS..........................................................................................................8
7. BEFORE FIRST USE....................................................................................... 10
8. DAILY USE....................................................................................................... 12
9. HINTS AND TIPS............................................................................................. 13
10. CARE AND CLEANING..................................................................................15
11. TROUBLESHOOTING....................................................................................16
12. TECHNICAL INFORMATION......................................................................... 20
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
www.electrolux.com2
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
•Children of less than 3 years of age should be kept
away unless continuously supervised.
•Do not let children play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–farm houses; staff kitchen areas in shops, offices
and other working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and
maximum) must be between 0.5 (0.05) / 8 (0.8) bar
(MPa)
•Obey the maximum number of 13 place settings.
ENGLISH 3
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
•Put the cutlery in the cutlery basket with the sharp
ends pointing down or put them in the cutlery drawer
in a horizontal position with the sharp edges down.
•Do not leave the appliance with the open door
unattended to avoid stepping accidentally onto it.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•If the appliance has ventilation openings in the base,
they must not be covered e.g. by a carpet.
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure that the appliance is
installed below and adjacent to safe
structures.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
www.electrolux.com4
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the
E.E.C. Directives.
• UK and Ireland only. This appliance is
fitted with a 13 A mains plug. If it is
necessary to change the mains plug
fuse, use only a 13 A ASTA (BS
1362) fuse.
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the
mains socket. Contact the Authorised
Service Centre to replace the water
inlet hose.
2.4 Use
• Do not sit or stand on the open door.
• Dishwasher detergents are
dangerous. Obey the safety
instructions on the detergent
packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the
appliance until the programme is
complete. Some detergent may
remain on the dishes.
• The appliance can release hot steam
if you open the door while a
programme operates.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
ENGLISH 5
3. PRODUCT DESCRIPTION
43
7
9 8
10 56
11
12
1Upper spray arm
2Lower spray arm
3Filters
4Rating plate
5Salt container
6Air vent
7Rinse aid dispenser
8Detergent dispenser
9Cutlery basket
10 Lower basket
11 Upper basket
www.electrolux.com6
4. CONTROL PANEL
1 2 3
456
1On/off indicator
2Programme marker
3Indicators
4Delay button
5Start button
6Programme knob
4.1 Indicators
Indicator Description
Washing phase. It comes on when the washing phase operates.
Drying phase. It comes on when the drying phase operates.
End indicator.
Rinse aid indicator. It is always off while the programme operates.
Salt indicator. It is always off while the programme operates.
ENGLISH 7
5. PROGRAMMES
Programme Degree of soil
Type of load Programme
phases Consumption values
1)
Duration
(min) Energy
(kWh) Water
(l)
2) Normal soil
Crockery and
cutlery
• Pre-wash
• Wash 50 °C
• Rinses
• Dry
227 1.039 11
Heavy soil
Crockery, cut‐
lery, pots and
pans
• Pre-wash
• Wash 70 °C
• Rinses
• Dry
155 - 170 1.5 - 1.7 14 - 15
Normal soil
Crockery and
cutlery
• Pre-wash
• Wash 65 °C
• Rinses
• Dry
130 - 140 1.4 - 1.6 15 - 17
3) Fresh soil
Crockery and
cutlery
• Wash 60 °C
or 65 °C
• Rinses
30 0.8 10
4) All • Pre-wash 14 0.1 5
1) The pressure and the temperature of the water, the variations of the mains supply, the
options and the quantity of dishes can change the values.
2) With this programme you have the most efficient use of water and energy consumption
for crockery and cutlery with normal soil. (Also, it is a standard programme for test insti‐
tutes).
3) With this programme you can wash a load with fresh soil. It gives good washing results in
a short period of time.
4) Use this programme to quickly rinse the dishes and to prevent the food remains from dry‐
ing out on the dishes and to reduce bad odour coming out from the appliance. Do not use
detergent with this programme.
5.1 Information for test
institutes
For all the necessary information for test
performance, send an email to:
Write down the product number (PNC)
that is on the rating plate.
6. SETTINGS
6.1 Programme selection mode
and user mode
When the appliance is in programme
selection mode it is possible to set a
programme and to enter the user mode.
Settings available in the user mode:
• The level of water softener according
to the water hardness.
• Activation or deactivation of AirDry.
As the appliance stores the saved
settings, there is no need to configure
it before every cycle.
www.electrolux.com8
How to set the programme
selection mode
The appliance is in programme selection
mode when the on/off indicator is on and
Start indicator flashes.
After activation, the appliance is in
programme selection mode by default. If
not, set the programme selection mode
the following way:
Press and hold simultaneously Start and
Delay until the appliance is in
programme selection mode.
6.2 The water softener
The water softener removes minerals
from the water supply, which would have
a detrimental effect on the washing
results and on the appliance.
The higher the content of these minerals,
the harder your water is. Water hardness
is measured in equivalent scales.
The water softener should be adjusted
according to the hardness of the water in
your area. Your local water authority can
advise you on the hardness of the water
in your area. It is important to set the
right level of the water softener to assure
good washing results.
Water hardness
German de‐
grees (°dH) French de‐
grees (°fH) mmol/l Clarke de‐
grees Water softener
level
47 - 50 84 - 90 8.4 - 9.0 58 - 63 10
43 - 46 76 - 83 7.6 - 8.3 53 - 57 9
37 - 42 65 - 75 6.5 - 7.5 46 - 52 8
29 - 36 51 - 64 5.1 - 6.4 36 - 45 7
23 - 28 40 - 50 4.0 - 5.0 28 - 35 6
19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)
15 - 18 26 - 32 2.6 - 3.2 18 - 22 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 2
<4 <7 <0.7 < 5 1 2)
1) Factory setting.
2) Do not use salt at this level.
Whether you use a standard detergent
or multi-tabs (with or without salt), set
the proper water hardness level to
keep the salt refill notification active.
Multi-tabs containing salt are
not effective enough to
soften hard water.
How to set the water softener
level
The appliance must be in programme
selection mode.
1. Make sure that the programme
marker on the knob is in on/off
position.
ENGLISH 9
2. To enter the user mode, press and
hold Delay. At the same time turn the
knob counterclockwise until the
programme marker indicates the first
programme. Release the Delay when
the indicators Start and on/off start
flashing.
• The intermittent flashing of
shows the current setting, e.g. 5
flashes + pause + 5 flashes =
level 5.
3. Press Delay repeatedly to change
the setting. Each pressing of Delay
increases the level number. After
reaching level 10, the count starts
again from level 1.
4. To confirm the setting, turn the
programme knob until the
programme marker is again in on/off
position
6.3 AirDry
AirDry improves the drying results with
less energy consumption.
During the drying phase, the
door opens automatically
and remains ajar.
CAUTION!
Do not try to close the
appliance door within 2
minutes after automatic
opening. This can cause
damage to the appliance.
AirDry is automatically activated with all
programmes excluding (if
applicable).
CAUTION!
If children have access to
the appliance, it is advised to
deactivate AirDry as opening
the door may pose a danger.
How to deactivate AirDry
The appliance must be in programme
selection mode.
Make sure that the programme marker
on the knob is set to on/off position.
1. To enter the user mode, press and
hold Delay. At the same time turn the
knob counterclockwise until the
programme marker indicates the first
programme. Release Delay when the
indicators Start and on/off start
flashing.
2. Turn the knob counterclockwise until
the programme marker indicates the
second programme.
• The indicator shows the
current setting: on = AirDry is
activated.
3. Press Delay to change the setting.
• If the indicator is off = AirDry
is deactivated.
4. To confirm the setting, keep turning
the programme knob until the
programme marker is back in the
on/off position.
7. BEFORE FIRST USE
1. Make sure that the current level of
the water softener agrees with the
www.electrolux.com10
Table des matières
Langues :
Autres manuels Electrolux Lave-vaisselle
Electrolux
Electrolux GA60LI221 Manuel utilisateur
Electrolux
Electrolux ESF8725ROX Manuel utilisateur
Electrolux
Electrolux 9JEDQU Manuel utilisateur
Electrolux
Electrolux ESF 6162 Manuel utilisateur
Electrolux
Electrolux EES27100L Manuel utilisateur
Electrolux
Electrolux GA55SLI302 Manuel utilisateur
Electrolux
Electrolux ESI 600 Manuel utilisateur
Electrolux
Electrolux 6919941 Manuel utilisateur
Electrolux
Electrolux ESL 8510RO Manuel utilisateur
Electrolux
Electrolux ESL 47030 Manuel utilisateur
Electrolux
Electrolux 402070 Manuel utilisateur
Electrolux
Electrolux GA45GLVCN Manuel utilisateur
Electrolux
Electrolux EWDW6505G S Mode d’emploi
Electrolux
Electrolux ESG89400UX Manuel utilisateur
Electrolux
Electrolux ESL 7310RA Manuel utilisateur
Electrolux
Electrolux ei24id50qs0b Manuel utilisateur
Electrolux
Electrolux GA556IFWE Manuel utilisateur
Electrolux
Electrolux 534178 Manuel utilisateur
Electrolux
Electrolux ESL5340LO Manuel utilisateur
Electrolux
Electrolux ESM48310SX Manuel utilisateur
