CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 6
4. CONTROL PANEL............................................................................................. 7
5. PROGRAMMES................................................................................................. 8
6. SETTINGS........................................................................................................10
7. OPTIONS..........................................................................................................12
8. BEFORE FIRST USE....................................................................................... 13
9. DAILY USE....................................................................................................... 13
10. HINTS AND TIPS........................................................................................... 15
11. CARE AND CLEANING..................................................................................16
12. TROUBLESHOOTING....................................................................................18
13. TECHNICAL INFORMATION......................................................................... 22
14. INSTALLATION.............................................................................................. 22
15. WARRANTY .................................................................................................. 24
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged 8 years
and above and by persons with reduced capabilities
provided that they have been given instruction and/or
supervision regarding the safe use of the appliance
and understand the potential hazards involved.
•Do not let children play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–farm houses; staff kitchen areas in shops, offices
and other working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and
maximum) must be between 0.5 (50) / 8 (800) bar
(kPa)
•Obey the maximum number of 14 place settings.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or a
similarly qualified persons in order to avoid a hazard.
ENGLISH 3
•Put knives and cutlery with sharp points in the cutlery
basket with the points down or in a horizontal position.
•Do not keep the appliance door open without
supervision to prevent to fall on it.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
•The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
•Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed. Avoid
contact with the skin and eyes and keep children away
from the dishwasher when the door is open.
•Check that the detergent receptacle is empty after
completion of the wash cycle.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• Follow the installation instruction
supplied with the appliance.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• Do not cause damage to the water
hoses.
www.electrolux.com4
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• The water inlet hose has a safety
valve and a sheath with an inner
mains cable.
WARNING!
Dangerous voltage.
• If the water inlet hose is damaged,
immediately disconnect the mains
plug from the mains socket. Contact
the Authorised Service Centre to
replace the water inlet hose.
2.4 Use
• Do not sit or stand on the open door.
• Dishwasher detergents are
dangerous. Obey the safety
instructions on the detergent
packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the
appliance until the programme is
completed. There can be detergent on
the dishes.
• The appliance can release hot steam
if you open the door while a
programme operates.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
2.5 Service
• Contact the Authorised Service
Centre to repair the appliance. We
recommend only the use of original
spare parts.
• When you contact the Authorised
Service Centre, ensure that you have
the following information that is
available on the rating plate.
Model :
PNC :
Serial Number :
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
ENGLISH 5
3. PRODUCT DESCRIPTION
12
65
8
9
34
21
10 711
1Work-top
2Top spray arm
3Upper spray arm
4Lower spray arm
5Filters
6Rating plate
7Air vent
8Rinse aid dispenser
9Detergent dispenser
10 Cutlery basket
11 Lower basket
12 Upper basket
www.electrolux.com6
4. CONTROL PANEL
1
2 3 6 7
9813 1214
4 5
11 10
1
2 3 6 7
9 813 1214
4 5
11 10
1On/off button
2Program touchpad
3MyFavourite touchpad
4Programme indicators
5Indicators
6Delay touchpad
7Option touchpad
8Start touchpad
9XtraDry touchpad
10 Display
11 Programme bar
12 Indicators
13 TimeManager touchpad
14 Reset touchpad
4.1 Indicators
Indicator Description
XtraDry indicator.
Rinse aid indicator. It is always off while the programme operates.
TimeManager indicator.
Delay indicator.
XtraPower indicator.
Door indicator. It comes on when the appliance door is open or is not
correctly closed.
Turbidity Sensor indicator. It comes on when the sensor for the
programme operates. When the sensor operates, only this
indicator is on. All the other indicators, the display and the programme
bar go off. They come on again when the Turbidity Sensor indicator
goes off.
ENGLISH 7
4.2 Programme bar
The programme bar shows information
related to the programme and to the
option TimeManager.
Start and progress of the programme
When the programme starts, the 2 lateral
segments of the programme bar flash.
As the programme is in progress, the
middle segments come on with fixed
light , while the 2 lateral segments contin‐
ue to flash.
When the programme is completed, all
the segments come on with fixed light.
Programme bar and TimeManager option
When you set a programme, that is appli‐
cable to the TimeManager option, all the
segments of the programme bar come on
with fixed light.
When you set the TimeManager option,
only the middle segment stays on with
fixed light.
5. PROGRAMMES
Programme Degree of soil
Type of load
Programme pha‐
ses
Options
1) • Normal soil
• Crockery and
cutlery
• Prewash
• Wash 50 °C
• Rinses
• Dry
• TimeManager
• XtraDry
2) • All
• Crockery, cut‐
lery, pots and
pans
• Prewash
• Wash from 45 °C
to 70 °C
• Rinses
• Dry
• XtraDry
3) • Mixed soil
• Crockery, cut‐
lery, pots and
pans
• Prewash
• Wash 50 °C and
65 °C
• Rinses
• Dry
• TimeManager
• XtraDry
www.electrolux.com8
Programme Degree of soil
Type of load
Programme pha‐
ses
Options
4) • Heavy soil
• Crockery, cut‐
lery, pots and
pans
• Prewash
• Wash 70 °C
• Rinses
• Dry
• XtraPower
• TimeManager
• XtraDry
• Normal or light
soil
• Delicate crock‐
ery and glass‐
ware
• Wash 45 °C
• Rinses
• Dry
• XtraDry
• Light soil
• Crockery and
cutlery
• Wash 55 °C
• Rinses
• XtraDry
5) • Fresh soil
• Crockery and
cutlery
• Wash 60 °C
• Rinses
• XtraDry
1) With this programme you have the most efficient use of water and energy consumption
for crockery and cutlery with normal soil. (This is the standard programme for test institutes).
2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto‐
matically adjusts the temperature and the quantity of water, the energy consumption and the
programme duration.
3) With this programme you can wash a load with mixed soil. Very heavy soil in the lower
basket and normal soil in the upper basket. The pressure and the temperature of the water
in the lower basket are higher than in the upper basket.
4) This programme has a high temperature rinsing phase for better hygiene results. During
the rinsing phase, the temperature stays at 70 °C for at least 10 minutes.
5) With this programme you can wash a load with fresh soil. It gives good washing results in
a short time.
5.1 Consumption values
Programme 1) Water
(l)
Energy
(kWh)
Duration
(min)
11.5 0.86 160
7.0 - 14 0.6 - 1.4 40 - 150
13.5 - 15 1.2 - 1.5 139 - 149
13.5 - 14.5 1.4 - 1.6 150 - 164
13 - 13.5 0.7 - 0.9 60 - 70
9.5 - 10 0.9 - 1.0 55 - 65
ENGLISH 9
Programme 1) Water
(l)
Energy
(kWh)
Duration
(min)
9 0.8 30
1) The pressure and the temperature of the water, the variations of the mains supply, the
options and the quantity of dishes can change the values.
5.2 Information for test
institutes
For all the necessary information for test
performance, send an email to:
Write down the product number (PNC)
that is on the rating plate.
6. SETTINGS
6.1 Programme selection mode
and user mode
When the appliance is in programme
selection mode it is possible to set a
programme and to enter the user mode.
In user mode, the following settings
can be changed:
• The activation or the deactivation of
the acoustic signal for end of
programme.
• The activation or deactivation of the
rinse aid empty notification.
• The level of rinse aid according to the
required dosage.
These settings will be saved until you
change them again.
How to set the programme
selection mode
The appliance is in programme selection
mode when the programme indicator
is on and the display shows the
programme duration.
When you activate the appliance, usually
it is in programme selection mode.
However, if this does not happen, you
can set the programme selection mode
in the following way:
Press and hold Reset until the appliance
is in programme selection mode.
6.2 The rinse aid dispenser
The rinse aid helps to dry the dishes
without streaks and stains.
The rinse aid is automatically released
during the hot rinse phase.
You can set the released quantity of
rinse aid between level 1 (minimum
quantity) and level 6 (maximum quantity).
Level 0 will deactivate the rinse aid
dispenser and no rinse aid will be
released.
Factory setting: level 4.
How to set the rinse aid level
The appliance must be in programme
selection mode.
1. To enter the user mode, press and
hold simultaneously Delay and
XtraDry until the indicators ,
and start to flash and
the display is blank.
2. Press TimeManager.
• The indicators and go
off.
• The indicator
continues to flash.
• The display shows the current
setting: e.g. = level 4.
– The levels of rinse aid are
from 0A to 6A.
www.electrolux.com10
Table des matières
Autres manuels Electrolux Lave-vaisselle
Electrolux
Electrolux GA60IEEVWE Manuel utilisateur
Electrolux
Electrolux EUC1G 400063 Manuel d'instructions
Electrolux
Electrolux ESI 66050X Manuel utilisateur
Electrolux
Electrolux NHT8 Comment utiliser
Electrolux
Electrolux U04306 ANC 822 Manuel utilisateur
Electrolux
Electrolux AEG FAVORIT 64080 VIL Manuel utilisateur
Electrolux
Electrolux ESF 6241 Manuel utilisateur
Electrolux
Electrolux GA60SLVS Manuel utilisateur
Electrolux
Electrolux EIDW6305GB - Semi-Integrated Dishwasher Manuel utilisateur
Electrolux
Electrolux ESL 6115 Manuel utilisateur
Electrolux
Electrolux GA45SLV Manuel utilisateur
Electrolux
Electrolux ESF 6610ROW Manuel utilisateur
Electrolux
Electrolux ESF 4510ROW Manuel utilisateur
Electrolux
Electrolux GA45SLVCN Manuel utilisateur
Electrolux
Electrolux GA60KVSW Manuel utilisateur
Electrolux
Electrolux ESI 662 Manuel utilisateur
Electrolux
Electrolux WT730 TCW Manuel utilisateur
Electrolux
Electrolux ESA47205SX Manuel utilisateur
Electrolux
Electrolux ESF 640 Mode d’emploi
Electrolux
Electrolux ESF4520LOW Manuel utilisateur
