Electrolux ICON E36GC75DSS Manuel utilisateur

2Finding Information

MAKE A RECORD FOR FUTURE USE

Brand_______________________________________________________________

Purchase Date______________________________________________________

Model Number______________________________________________________

Serial Number______________________________________________________

QUESTIONS?

For toll-free telephone support in the U.S. and Canada:

1-877-4ELECTROLUX (1-877-435-3287)

For online support and internet product information:

www.electrolux.com

Post Office Box 212378, Au usta, Geor ia 30917, USA

All ri hts reserved. Printed in the USA

NOTE

The serial plate is located under the burner box.

Finding Information

TABLE OF CONTENTS

Finding Information ........................................... 2

Make a Record for Future use .......................... 2

Questions? ........................................................ 2

Safety ................................................................... 4

Important Safety Instructions .............................. 4

Getting Start ........................................................ 7

Grounding Instructions ....................................... 7

Li uefied Petroleum (Propane)

Gas Conversion ................................................ 7

Surface Cooking ................................................. 8

Flame Size ........................................................ 8

Proper Burner Adjustments ................................ 8

Locations of the Burners .................................... 8

Placement of Burner Heads and Caps ............... 9

Placement of Burner Grates ............................... 9

Surface Cooking Utensils ................................. 10

Using the Griddle............................................. 10

Using the Wok Stand ........................................ 11

Using the Simmer Plate .................................... 12

Setting Surface Controls ................................... 13

General Care & Cleaning .................................. 14

Care & Cleaning Table .................................... 14

Cleaning the Burner Grates, Burner Caps,

Burner Heads, Simmer plate and Griddle ........ 15

Cooktop Cleaning and Maintenance ................ 16

Cleaning Recommendations for the

Ceramic Glass Cooktop ................................... 16

Care & Cleaning of Stainless Steel ................... 17

Solutions to Common Pro lems ..................... 18

Surface Burner Do Not Light ........................... 18

Burner Flame Only Lights Half

Way Around Burner ........................................ 18

Burner Flame is Orange .................................. 18

Scratches or Abrasions on Ceramic

Glass Cooktop Surface .................................... 19

Metal Marks on Ceramic Glass

Cooktop Surface .............................................. 19

Brown Streaks and Specks on Ceramic Glass

Cooktop Surface .............................................. 19

Areas of Discoloration on Ceramic

Glass Cooktop Surface .................................... 19

Warranty Information ....................................... 20

4Safety

IMPORTANT SAFETY INSTRUCTIONS

Please read all safety instructions before using your new Electrolux cooktop.

 Remove all tape and packaging before using the Cooktop. Destroy the carton and plastic ba s

after unpackin the cooktop. Never allow children to play with packa in material. Do not remove

the model/serial plate attached to the cooktop.

 Proper Installation-Be sure your appliance is properly installed and grounded by a qualified

technician in accordance ith the National Fuel Gas Code ANSI Z223.1latest edition in the

United States, or in Canada CAN/CGA B149.1, and CAN/CGA B149.2, and the National Electrical

Code ANSI/NFPA No. 70latest edition in United States, or in Canada CSA Standard C22.1,

Canadian Electrical Code, Part 1, and local code requirements. Install and/or adjust only per

installation instructions provided in the literature packa e for this cooktop.

Ask your dealer to recommend a qualified technician and an authorized repair service. Know how to shut

off as supply at the meter and disconnect the electrical power to the cooktop at the circuit breaker or

fuse box in case of an emer ency.

 User servicingDo not repair or replace any part of the appliance unless specifically recommended

in the manuals. All other servicin should be done only by a qualified technician, This may reduce the

risk of personal injury and dama e to the cooktop.

 Never modify or alter the construction of a cooktop by removing panels, ire covers or any other

part of the product.

WARNING

To reduce the risk of fire, electrical shock, or injury when using your gas cooktop, follow asic

precautions including the following:

WARNING

If the information in this manual is not followed exactly, a fire or explosion may result

causing property damage, personal injury or death.

FOR YO R SAFETY:

 Do not store or use gasoline or other flammable vapors and liquids in the vicinity

of this or any other appliance.

 WHAT TO DO IF YO SMELL GAS:

 Do not try to light any appliance.

 Do not touch any electrical switch; do not use any phone in your building.

 Immediately call your gas supplier from a neighbor's phone. Follow the gas

supplier's instructions.

 If you cannot reach your gas supplier, call the fire department.

 Installation and service must be performed by a qualified installer, servicer or the

gas supplier.

CAUTION

Do not store items of interest to children in the cabinets above the cooktop. Children climbin

on the cooktop to reach items could be seriously injured.

Safety

 Storage on ApplianceFlammable materials should not be stored on the cooktop or near

surface units. This includes paper, plastic and cloth items, such as cookbooks, plasticware and

towels, as well as flammable liquids. Do not store explosives, such as aerosol cans, on or near

the cooktop. Flammable materials may explode and result in fire or property dama e.

 Do Not Leave Children AloneChildren should not be left alone or unattended in the area here

appliance is in use. They should never be allowed to sit or stand on any part of the appliance.

 DO NOT TOUCH SURFACE BURNERS/UNIT, GRATES OR AREAS NEAR THESE BURNERS/UNIT.

Surface burners/unit may be hot even thou h flames are not visible/ unit is dark in color. Areas near

surface burners/unit may become hot enou h to cause burns. Durin and after use, do not touch,

or let clothin or other flammable materials touch these areas until they have had sufficient time to

cool. Amon these areas are the cooktop and surfaces facin the cooktop.

 Wear Proper ApparelLoose-fitting or hanging garments should never be orn hile using the

appliance. Do not let clothin or other flammable materials contact hot surfaces.

 Do Not Use Water or Flour on Grease FiresSmother the fire ith a pan lid, or use baking soda,

a dry chemical or foam-type extinguisher.

 When heating fat or grease, atch it closely. Fat or rease may catch fire if allowed to become too hot.

 Use Only Dry PotholdersMoist or damp potholders on hot surfaces may result in burns from

steam. Do not let potholders touch hot heatin elements, the flame or burners. Do not use a towel

or other bulky cloth instead of a potholder.

 Do Not Heat Unopened Food ContainersBuildup of pressure may cause container to burst and

result in injury.

I PORTANT SAFETY INSTRUCTIONS FOR USING YOUR COOKTOP

 Kno hich knob controls each surface burner/surface unit. Place a pan of food on the burner

before turnin it on, and turn the burner off before removin the pan.

 Al ays turn knob to the full LITE position hen igniting top burners. Visually check that burner has

lit. Then adjust the flame so it does not extend beyond the ed e of the utensil.

 Use proper pan size. This cooktop can be equipped with one or more surface units of different sizes.

Select utensils havin flat bottoms lar e enou h to cover the surface unit. The use of

undersized utensils will expose a portion of the surface heatin unit to direct contact and may result

in i nition of clothin . Proper relationship of utensil to the surface unit will also improve efficiency.

WARNING

Stepping, leaning or sitting on this cooktop can result in serious injuries and also cause damage

to the cooktop. Do not allow children to clim or play around the cooktop.

Never use your appliance for warming or heating the room.

WARNING

Use Proper Flame SizeAdjust flame size so it does not extend eyond the edge of the utensil. The use

of undersized utensils will expose a portion of the burner flame to direct contact and may result in ignition of clothing.

Proper relationship of utensil to flame will also improve efficiency.

6Safety

 Utensil Handles Should Be Turned In ard and Not Extend Over Adjacent Surface Burners/Unit

To reduce the risk of burns, i nition of flammable materials, and spilla e due to unintentional

contact with the utensil, the handle of the utensil should be positioned so that it is turned inward,

and does not extend over adjacent surface burners.

 Never Leave Surface Burners/Unit Unattended at High Heat SettingsBoilovers cause smokin

and reasy spillovers that may i nite, or a pan that has boiled dry may melt.

 Protective LinersDo not use aluminum foil to line any part of the cooktop, use aluminum foil only

to cover food durin cookin . Improper installation of these liners may result in risk of electric shock,

or fire.

 Glazed Cooking UtensilsOnly certain types of lass, lass/ceramic, ceramic, earthenware, or

other lazed utensils are suitable for cooktop service without breakin due to the sudden chan e

in temperature. Check the manufacturers recommendations for cooktop use.

 Do not use Searin Grill on the cooktop. The Searin Grill is not desi ned for use on the cooktop.

Doin so may result in a fire.

Do Not Use Decorative Surface Burner/Unit Covers. If a burner/unit is accidentally turned on, the

decorative cover will become hot and possibly melt. You will not be able to see that the burner/unit

is on. Burns will occur if the hot covers are touched. Dama e may also be done to the cooktop or

burners/unit because the covers may cause overheatin . Air will blocked from the burner/unit and

cause combustion problems.

IMPORTANT INSTRUCTIONS FOR USING YOUR GLASS COOKTOP

 Do Not Operate or Clean a Broken Cooktop Glass.If lass top should break, cleanin solutions

and spillovers may penetrate the broken cooktop and create a risk of electric shock. Contact a

qualified technician immediately.

 Clean Cooktop Glass ith Caution.If a wet spon e or cloth is used to wipe spills on a hot cookin

area, be careful to avoid a steam burn. Some cleaners can produce harmful fumes if applied to a

hot surface.

 Avoid Scratching the Cooktop Glass ith Sharp Objects.

WARNING

Do Not Use Stove Top Grills on Your Sealed Gas BurnersIf you use a stove top grill on a sealed gas burner, it will cause

incomplete combustion and can result in exposure to carbon monoxide levels above allowable current standards. This can be

hazardous to your health.

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to

pu lish a list of su stances known to the state to cause cancer, irth defects or other reproductive

harm, and requires usinesses to warn customers of potential exposure to such su stances.

NOTE

Save these important safety instructions for future reference.

Getting Start

GROUNDING INSTRUCTIONS

For personal safety, the cooktop must be properly grounded. For

maximum safety, the power cord must be plugged into an

electrical outlet that is correctly polarized and properly grounded.

DO NOT operate the cooktop using a 2-prong adapter or an

extension cord. f a 2-prong wall receptacle is the only available

outlet, it is the personal responsibility of the consumer to have it

replaced with a properly grounded 3-prong wall receptacle installed

by a qualified electrician.

See the INSTALLATION INSTRUCTIONS packaged with this

cooktop for complete installation and grounding instructions.

LIQUEFIED PETROLEUM (PROPANE) GAS CONVERSION

This appliance can be used with Natural Gas and Propane Gas. t is shipped from the

factory for use with natural gas.

A kit for converting to LP gas is supplied with your cooktop. The kit is marked FOR LP/

PROPANE GAS CONVERS ON. Follow the installation instructions which are inside the

envelope.

The conversion must be performed by a qualified service technician in accordance with the

kit instructions and all local codes and requirements. Failure to follow instructions could

result in serious injury or property damage. The qualified agency performing this work

assumes responsibility for the conversion.

Do not, under any

circumstances, cut,

remove, or ypass the

grounding prong.

Power supply cord with

3-prong grounding plug

Grounding

type wall

receptacle

WARNING

This appliance is e uipped with a 3-prong grounding plug for your protection

against shock hazard and should be plugged directly into a properly grounded

receptacle. DO NOT cut or remove the grounding prong from this plug.

Avoid fire hazard or electrical shock. DO NOT use an adapter plug, an

extension cord, or remove grounding prong from electrical power cord. Failure

to follow this warning can cause serious injury, fire or death.

WARNING

Severe shock, or damage to the cooktop may occur if the cooktop is not installed by a ualified installer or electrician.

CAUTION

Any additions, changes or conversions re uired in order for this appliance to satisfactorily meet the application

needs must be made by a ualified service technician in accordance with the manufacturers instructions and all

codes and re uirements of the authority having jurisdiction. Failure to follow the instructions could result in

serious injury or property damage. The ualified agency performing this work assumes responsibility for the

conversion.

8Surface Cooking

FLAME SIZE

For most cooking, start on the highest control setting and then turn to a lower one to

complete the process. Use the chart below as a guide for determining proper flame size for

various types of cooking. The size and type of utensil used and the amount of food being

cooked will influence the setting needed for cooking.

For deep fat frying, use a thermometer and adjust the surface control knob accordingly. f

the fat is too cool, the food will absorb the fat and be greasy. f the fat is too hot, the food

will brown so quickly that the center will be undercooked. Do not attempt to deep fat fry too

much food at once as the food will neither brown nor cook properly.

*Flame Size Type of Cooking

High Flame Start most foods; bring water to a boil; pan broiling

Medium Flame Maintain a slow boil; thicken sauces, gravies; steam

Low Flame Keep foods cooking; poach; stew

*These settings a e based on using medium-weight aluminum pans with

lids. Settings may va y when using othe types of pans.

Never extend the flame beyond the outer edge of the utensil. A higher flame

simply wastes heat and energy, and increases your risk of being burned by the

flame.

PROPER BURNER ADJUSTMENTS

The color of the flame is the key to proper burner adjustment. A good flame is clear, blue

and hardly visible in a well-lighted room. Each cone of flame should be steady and sharply

defined. Adjust or clean burner if flame is yellow-orange. To clean burner, see instructions

under Gene al Ca e & Cleaning.

LOCATIONS OF THE BURNERS

Your cooktop is equipped with 5 different sized burners.

The surface burners are located on the cooktop as follows (See Figure):

-a 5 000 BTU (natural gas) burner located at the right rear position;

- two 9 500 BTU (natural gas) burners located at the left and center rear

positions;

-a 12 000 BTU (natural gas) burner located at the left front position;

-a 14 000 BTU (natural gas) burner located at the center front position;

-and a 17 000 BTU (natural gas) burner located at the right front position.

RIGHT

WRONG

Surface Cooking

PLACEMENT OF BURNER HEADS AND CAPS

Place burner head over each gas orifice, matching the head with the

orifice size. Be ca eful not to damage the elect ode while placing

the head ove the o ifice. Make sure electrode fits correctly into slot in

burner head. Place a burner cap on each burner head, matching the cap

size to the head size. The cap for each burner has an inner locating ring

which centers the cap correctly on the burner head. Be sure that all the

burner caps and burner heads are correctly placed BEFORE using your

appliance.

Make sure each burner cap is properly aligned and level.

Turn the burner on to determine if it will light. f the burner does not light,

contact a Service Center. Do not service the sealed burner yourself.

PLACEMENT OF BURNER GRATES

Place grates on the Ceramic Glass Cooktop. Be sure they

are right located inside the stainless steel frame.

ATTENT ON: Do not slide the grates on the stainless steel

frame, doing so can damage the surface.

Burner Cap

Burner

Head

Electrode

Gas

Opening

10 Surface Cooking

SURFACE COOKING UTENSILS

Note: Always use a utensil for its intended purpose. Follow manufacturer's instructions.

Some utensils were not made to be used in the oven or on the cooktop.

*GOOD

 Flat bottom and straight sides.

 Tight fitting lids.

 Weight of handle does not tilt pan.

Pan is well balanced.

 Pan sizes match the amount of

food to be prepared and the size of

burner.

 Made of material that conducts

heat well.

 Easy to clean.

POOR

 Curved and warped pan bottoms.

 Pan overhangs unit by more than

2.5 cm (1).

 Heavy handle tilts pan.

 Flame extends beyond unit.

Pans should have flat bottoms.

Check for flatness by rotating a

ruler across the bottom. There

should be no gaps between the

pan and ruler.

*Specialty pans such as lob-

ster pots, griddles and pressure

cookers may be used but must

conform to the above recom-

mended cookware require-

ments.

USING THE GRIDDLE

Figure 1

Figure 2

Side with grooves

The griddle is intended for direct food cooking and can be used on both

sides (Figures 2 and 3). Do not use pans or other cookware on the griddle.

Doing so could damage the finish. With the grate in position over the

burner, set the griddle on top of the grate positioning the notches in the

griddle over the grate fingers(Figures 1 and 2).

CAUTION

Always place the griddle on the grate efore to turn on the urner.

Always use potholders to remove the griddle from the grate. Allow the griddle to cool efore removing. Do not

set hot griddle on surfaces that cannot withstand high heat; such as countertops.

Be sure the griddle is positioned correctly and sta le efore use to prevent hot spills and possi le urns.

Figure 3

Flat Side

Table des matières

Autres manuels Electrolux plaque de cuisson

Electrolux

Electrolux EW30IC60LB Instructions d'installation

Electrolux

Electrolux EI30EF35JS Manuel utilisateur

Electrolux

Electrolux E36EC65ESS - Icon 36"Drop-in Electric... Manuel utilisateur

Electrolux

Electrolux E48GC76EPS - 48" Sealed Burner Slide-In Gas... Guide de démarrage rapide

Electrolux

Electrolux FPIC3695MS Manuel utilisateur

Electrolux

Electrolux E36EC75HSS3 Manuel utilisateur

Electrolux

Electrolux E30IC80ISS1 Manuel utilisateur

Electrolux

Electrolux E36GC76PRS Manuel utilisateur

Electrolux

Electrolux CHC645BA Manuel d'utilisation

Electrolux

Electrolux Electric Cooktop Manuel utilisateur

Electrolux

Electrolux E36EC65ESS - Icon 36"Drop-in Electric... Manuel utilisateur

Electrolux

Electrolux GHC607S Manuel d'utilisation

Electrolux

Electrolux EW30IC60LB Guide de démarrage rapide

Electrolux

Electrolux 36" Ceramic Manuel utilisateur

Electrolux

Electrolux EW36IC60I - 36 in. Induction Cooktop Manuel utilisateur

Electrolux

Electrolux E36EC75HSS - 36" Pro-Style Slide-In Electric... Manuel utilisateur

Electrolux

Electrolux EHD90LLUM Manuel utilisateur

Electrolux

Electrolux EW36CC55GW Manuel utilisateur

Electrolux

Electrolux ICON Designer E30EC65ESS Manuel utilisateur

Electrolux

Electrolux ECCI3668AS Manuel utilisateur

Electrolux

Electrolux E36EC70FSS - 36" Drop-In Electric Cooktop Instructions d'utilisation

Electrolux

Electrolux EW36EC55G S Manuel utilisateur

Electrolux

Electrolux E36GC75GSS - Icon 36 Inch Slide-In Gas... Manuel utilisateur

Electrolux

Electrolux E36GC75GSS - Icon 36 Inch Slide-In Gas... Manuel utilisateur

Manuels plaque de cuisson populaires d'autres marques

Bonnet

Bonnet OPTIMUM 700 Manuel du propriétaire

Jenn-Air

Jenn-Air JGCP430 Manuel utilisateur

Frigidaire

Frigidaire FES367FCC Guide de démarrage rapide

Ztove

Ztove EZ2 DUO Manuel utilisateur

Kleenmaid

Kleenmaid cooking GCTK9011 Guide d'installation

Casselin

Casselin CSASRE24 Manuel utilisateur

Jenn-Air

Jenn-Air JGC2536EB00 Manuel utilisateur

Waldorf

Waldorf RN8603E-B Mode d’emploi

Whirlpool

Whirlpool SMP658CNEIXL Manuel utilisateur

Wolf

Wolf CI243C/B Manuel utilisateur

Fulgor Milano

Fulgor Milano F5PGK305S1 Manuel utilisateur

GE JP389 Manuel utilisateur

Wells

Wells WV-2HFG Manuel utilisateur

IKEA

IKEA Lagan HGA4K Manuel utilisateur

Samsung

Samsung NA36N9755 Manuel utilisateur

Miele

Miele KM 404 Manuel utilisateur

Lacor

Lacor 69562 Fiche technique

Keating Of Chicago

Keating Of Chicago MG-2 Manuel utilisateur
