electrolux ceramic cooktops before installation 5

Before installation

Before installing the cooktop, read these points carefully.

caution

Damage resulting from incorrect installation WILL NOT be

covered by warranty.

It is the responsibility of the installer to make sure that:

• Thecabinetisconstructedcorrectly

• Thecooktopisinstalledaccordingtothe

speciﬁcations in this leaﬂet

Electrical connection

• Electricalconnectionis220volts,AC50Hz16Amps

Preparing the bench

• Choosewhereyouwanttoplacethecooktop

• Checktheopeningdimensionsforthemodelandmark

it out on the bench (refer to back page)

• Ifabarrierisnotrequired(seenotebelow),a

minimumgapof30mmisneededunderthecooktop

• Makesurethatnothing(eg.atimbermember)

interfereswiththesespacerequirements

• Cuttheopeninginthebenchtop

• Anywallsaroundthecooktoparetobeheatresistantup

to90°C,upto150mmhighi.e.ceramictiles

• NOTE:Thecooktopisdesignedfortheglasstositon

top of the bench. The glass must not be recessed into

the bench

Barrier installation

• Ifthebaseofthecooktopcanbetouchedfrominside

acupboardordrawer,abarrierMUSTbeinstalledto

prevent contact

• Makesurethematerialforthebarrieriscapableof

sustainedheatupto70°Ceg.woodormetal.

DO NOT use plastic or plastic-coated wood

• Makesureitisatleast50mm,andnotmorethan75mm

below the base of the cooktop

• Makesureitishasventilationholesthatareopentofree

air and evenly spaced (see diagrams on back)

• Checkthenumberofholesfromthislist:

Twentyveholes:25mmdiameter

Fifteen holes: 35mm diameter

Sixholes:50mmdiameter

warning

Safety instructions

It is important to use your cooktop safely, check these

safety points before using your cooktop.

• Thiscooktopmustbeconnectedtoa16Ampsocket

• DONOTbendthemainscableorputanyheavyobjects

on top of it

• Ifthemainscableisdamaged,onlytrainedservice

technicians should replace it

• Thisapplianceisnotintendedforusebyyoung

children or inﬁrm persons unless they have been

adequatelysupervisedbyaresponsiblepersonto

ensure that they can use the appliance safely

• PutONLYcookwareonthecookingsurface

• DONOTcookdirectlyontheceramicsurfaceasfood

will stick to the surface and will cause problems

• Iftheceramiccooktopcracks,IMMEDIATELYswitchoff

the cooktop at the power supply

• Keepanythingwhichwillmeltawayfromthesurfaceeg.

plastic, foil and sugar

• DONOTtouchthecooktopwhileitisstillhot

• Youngchildrenshouldbesupervisedtoensurethatthey

do not play with the appliance

Cooktop structure

Safetyinstructions

1A-bigcookingarea

3A-controlknobA

3B - control knob B

1B-smallcookingarea

4 - bottom plate

6-light

2-ceramicglass

5 - mains cable

electrolux ceramic cooktops operation 7

GOOD UNDERSIZED

OVERSIZED

RECESSED BASE

MOISTURE ON

SURFACE

NO POT OR PAN

CONVEX BASE

caution

• DONOTusethecooktopasaworksurfaceasthismay

scratch the surface

• DONOTcutorchopfoodontheceramicsurface

Choosing and using pots and pans

warning

• DONOToperateanelementwithoutacookingpotor

pan on it

• Usepotsandpanswithat,heavybases.Potsand

pans with uneven or thin bases will take longer to cook

• DONOTusepotsandpanswhichoverhangthe

elementsmorethan50mm.Oversizedpotsand

pans can cause ﬁne cracks on the cooktop

(see illustration below)

• Checkthebaseofpotsandpansarelevelwitharuler

• Checkthebottomofpotsandpansarefreefromgrit,

as this can scratch the ceramic surface

• Cookwithlidsonpotsandpansasthiswillsavetime

and electricity

• DONOTslidethepotsorpansasthismayscratchthe

surface

• DONOTplacesteamyorwetutensilsonthecooktop

Cleaning instructions

• Cleanthecooktopregularlywhileitisstillwarmwitha

suitablenon-abrasiveliquidceramiccooktopcleaner

• RemovemeltedmaterialIMMEDIATELYwhilethe

surface is still hot by:

-usingarazorbladescrapertoremovematerial;or

- using a ceramic glass scraper; or

- rinsing and wiping dry with a clean cloth or paper

towel

caution

• DONOTleavefoodonceramicsurfaceascooktopmay

become stained

• DONOTuseabrasiveorcorrosivecleaners,scouring

pads, steam cleaners, wire wool or oven cleaners

• Becarefulnottoscratchthesurfacewithbracelets

or rings

Operating instructions
