Elcon HiD 2000 Series Manuel de l'opérateur

SERIES HiD 2000

INTRINSIC SAFETY ISOLATORS

User Instruction Manual

ELCON INSTRUMENTS

I/O Interface, Intrinsic Safety and Solutions

This manual may not be copied, in whole or in part, without the written

consent of Elcon Instruments.

Elcon Instruments reserves the right to make changes of this manual

without notice.

• RD-ZIP-004

DOC.TECN. Ins.Man. IM-ENG-111/GB-A2-PN991169

SERIES HiD 2000 INTRINSIC SAFETY ISOLATORS

User Instruction Manual

ELCON INSTRUMENTS

I/O Interface, Intrinsic Safety and Solutions

Table of contents

1Introduction..................................................................................................................................................1-1

1.1 Overview ..............................................................................................................................................1-1

1.2 Explanation of Contents........................................................................................................................1-1

1.3 Key Features ........................................................................................................................................ 1-2

1.4 Hazardous Area Interfacing...................................................................................................................1-2

2Specifications ..............................................................................................................................................2-1

2.1 Product Selection..................................................................................................................................2-1

2.2 Ordering Information.............................................................................................................................2-2

2.3 Mechanical Specifications.....................................................................................................................2-3

2.4 Safety Specifications ............................................................................................................................ 2-4

2.5 Approvals and Markings........................................................................................................................2-5

2.6 Electrical Specifications - general .........................................................................................................2-6

2.7 Electrical Specifications - modules........................................................................................................2-7

2.7.1 HiD 2025/2026 Repeater Power Supply, Smart Transmitter........................................................... 2-7

2.7.2 HiD 2025SK/2026SK Repeater Power Supply, Smart Transmitter..................................................2-8

2.7.3 HiD 2029/2030 Repeater Power Supply, Smart Tx, Fully Floating..................................................2-9

2.7.4 HiD 2029SK/2030SK Repeater Power Supply, Smart Tx, Fully Floating................................................ 2-10

2.7.5 HiD 2031/2032 I/P Driver, Bus Powered....................................................................................... 2-11

2.7.6 HiD 2033/2034 I/P Driver, Loop Powered..................................................................................... 2-12

2.7.7 HiD 2035/2036 Loop powered Isolator for Fire and Smoke Detectors........................................... 2-13

2.7.8 HiD 2037/2038 I/P Driver, Bus Powered, Smart ........................................................................... 2-14

2.7.9 HiD 2061/2062 Temperature Converter, mV/TC........................................................................... 2-15

2.7.10 HiD 2071/2072 RTD/Potentiometer Converter.............................................................................. 2-16

2.7.11 HiD 2822/2824 Switch/Proximity Detector Repeater, Relay Output .............................................. 2-17

2.7.12 HiD 2842/2844 Switch/Proximity Detector Repeater, Open Coll. Output............................................ 2-18

2.7.13 HiD 2871/2872 Solenoid/Alarm Driver, Loop or Bus Powered ...................................................... 2-19

2.7.14 HiD 2873/2874 Solenoid/Alarm Driver, Bus Powered................................................................... 2-20

2.7.15 HiD 2875/2876 Solenoid/Alarm Driver, Loop or Bus Powered ...................................................... 2-21

2.7.16 HiD 2877/2878 Solenoid/Alarm Driver, Bus Powered................................................................... 2-22

2.7.17 HiD 2881 Solenoid/Alarm Driver, Loop or Bus Powered, IIB Output ............................................. 2-23

3System Operation........................................................................................................................................ 3-1

3.1 General description of the system......................................................................................................... 3-1

3.2 System design considerations...............................................................................................................3-1

3.3 Wiring of intrinsically safe circuits......................................................................................................... 3-1

3.4 Grounding information ..........................................................................................................................3-2

4Installation and Configuration.......................................................................................................................4-1

4.1 Unpacking.............................................................................................................................................4-1

4.2 Storage.................................................................................................................................................4-1

4.3 Operating environment .........................................................................................................................4-1

4.4 Installation ............................................................................................................................................4-2

4.5 Board polarisation................................................................................................................................. 4-2

4.6 Configuration ........................................................................................................................................4-2

4.7 Electrical Connections...........................................................................................................................4-3

4.8 EMC Guidelines....................................................................................................................................4-3

4.9 Heat Dissipation and Thermal Behaviour ..............................................................................................4-3

4.10 Cabinet Heat-Dissipation....................................................................................................................... 4-5

5Unit Operation ............................................................................................................................................. 5-1

5.1 HiD 2025/2026......................................................................................................................................5-1

5.2 HiD 2025SK/2026SK............................................................................................................................. 5-3

5.3 HiD 2029/2030......................................................................................................................................5-5

5.4 HiD 2029SK/2030SK............................................................................................................................. 5-7

5.5 HiD 2031/2032......................................................................................................................................5-9

5.6 HiD 2033/2034.................................................................................................................................... 5-11

5.7 HiD 2035/2036.................................................................................................................................... 5-13

5.8 HiD 2037/2038.................................................................................................................................... 5-15

5.9 HiD 2061/2062.................................................................................................................................... 5-17

5.10 HiD 2071/2072.................................................................................................................................... 5-20

5.11 HiD 2822/2824.................................................................................................................................... 5-23

5.12 HiD 2842/2844.................................................................................................................................... 5-26

5.13 HiD 2871/2872.................................................................................................................................... 5-29

5.14 HiD 2873/2874.................................................................................................................................... 5-32

5.15 HiD 2875/2876.................................................................................................................................... 5-35

5.16 HiD 2877/2878.................................................................................................................................... 5-38

5.17 HiD 2881............................................................................................................................................. 5-41

6Servicing .....................................................................................................................................................6-1

6.1 Maintenance......................................................................................................................................... 6-1

6.2 Functional Check & Troubleshooting.....................................................................................................6-1

6.2.1 HiD 2025/2026............................................................................................................................... 6-3

6.2.2 HiD 2025SK/2026SK......................................................................................................................6-4

6.2.3 HiD 2029/2030............................................................................................................................... 6-5

6.2.4 HiD 2029SK/2030SK......................................................................................................................6-6

6.2.5 HiD 2031/2032............................................................................................................................... 6-7

6.2.6 HiD 2033/2034............................................................................................................................... 6-8

6.2.7 HiD 2035/2036............................................................................................................................... 6-9

6.2.8 HiD 2037/2038............................................................................................................................. 6-10

6.2.9 HiD 2822/2824............................................................................................................................. 6-11

6.2.10 HiD 2842/2844............................................................................................................................. 6-13

6.2.11 HiD 2871/2872............................................................................................................................. 6-15

6.2.12 HiD 2873/2874............................................................................................................................. 6-17

6.2.13 HiD 2875/2876............................................................................................................................. 6-19

6.2.14 HiD 2877/2878............................................................................................................................. 6-21

6.2.15 HiD 2881...................................................................................................................................... 6-23

6.3 Warranty............................................................................................................................................. 6-25

7Glossary ......................................................................................................................................................7-1

8Index ...........................................................................................................................................................8-1

9Appendix A..................................................................................................................................................9-1

9.1 HiD 2061/HiD 2062 Input Range Configurations....................................................................................9-1

9.1.1 Input type “mV”.............................................................................................................................. 9-1

9.1.2 Input type thermocouple “B”........................................................................................................... 9-2

9.1.3 Input type thermocouple “E”........................................................................................................... 9-3

9.1.4 Input type thermocouple “J”............................................................................................................ 9-4

9.1.5 Input type thermocouple “K”........................................................................................................... 9-5

9.1.6 Input type thermocouple “N”...........................................................................................................9-6

9.1.7 Input type thermocouple “R”...........................................................................................................9-7

9.1.8 Input type thermocouple “S”........................................................................................................... 9-7

9.1.9 Input type thermocouple “T”........................................................................................................... 9-8

9.1.10 Input type thermocouple “L” ........................................................................................................... 9-9

9.2 Thermocouple / mV Calibration........................................................................................................... 9-10

9.2.1 Equipment required...................................................................................................................... 9-10

9.2.2 Thermocouple or mV Input range modification............................................................................. 9-10

9.2.3 Thermocouple Input Range Calibration........................................................................................ 9-10

9.2.3.1 Copper Wires Calibration.......................................................................................................... 9-11

9.2.3.2 Compensating Wires Calibration .............................................................................................. 9-11

9.2.3.3 0 °C Reference Junction Calibration......................................................................................... 9-11

9.2.3.4 TC Calibrator with auto internal RJ compensation Calibration................................................... 9-12

9.2.3.5 TC Calibrator with auto remote RJ compensation Calibration ................................................... 9-12

9.2.4 mV Input Range Calibration......................................................................................................... 9-12

10 Appendix B................................................................................................................................................ 10-1

10.1 HiD 2071/HiD 2072 Input Range Configurations.................................................................................. 10-1

10.1.1 Input type RTD Pt100 Ω............................................................................................................... 10-1

10.1.2 Input type Potentiometer.............................................................................................................. 10-2

10.2 RTD / POT Calibration........................................................................................................................ 10-3

10.2.1 Equipment required...................................................................................................................... 10-3

10.2.2 RTD or POT Input range modification.......................................................................................... 10-3

10.2.3 Pt 100 ΩRTD Input range calibration........................................................................................... 10-3

10.2.4 Other types of RTD (to be specified when ordering)..................................................................... 10-3

10.2.5 POT Input range calibration ......................................................................................................... 10-4

1-1

1Introduction

This manual is intended to provide guidance for the installation, operation and maintenance of the HiD 2000 range

of intrinsic safety isolators.

To avoid damage, failure or improper operation, carefully read this manual before installing and operating the unit.

This manual and the related equipment should not be used by untrained personnel unless they are fully acquainted

with the principles of intrinsically safe system.

Elcon Instruments has published a complete tutorial entitled “Guide to Intrinsic Safety” covering most aspect of

intrinsic safety. The book can be obtained from Elcon Instruments free of charge.

1.1 Overview

The Elcon HiD 2000 Series is designed to be used in connection with process instrumentation system and consist

of a range of compact I.S. isolating interface modules to handle the input and output signals of a process plant.

Moreover a range of standard and custom made Termination Boards are available where the modules can be

plugged and quickly secured.

With this new full line of modular plug-in I.S. isolator a significant cost reduction is achieved in project planning,

plant design commissioning and service.

The module pack one, two or four isolated channels into a compact housing which can be inserted or removed

from the Termination Board without disturbing any of the wiring, no specialist knowledge is required, thereby

eliminating a frequent source of errors. The new “Quick Lok” method of fixing the module without the need for

tools reduces installation time and is very ease to operate. Pushing down a tab on each side of the module rotates

a securing foot which locks the unit to the Termination Board; to remove the modules simply lift the tabs. For

servicing, only the defective module needs to be removed and the replacement module plugged into the

Termination Board and locked by the quick mechanism. No special knowledge is required, the signal cables don’t

need to be detached and re-connected, eliminating a frequent source of errors.

Polarisation on the Board securely prevents modules from being swapped inadvertently.

The HiD 2000 Series product range has:

•high packing density, due to innovative circuit design using advanced surface mount components

•high performance, with high signal transfer accuracy and repeatability, low consumption, low heat

dissipation

•wide functionality, with a wide range of I/O signals, galvanic isolation, line fault alarm

•HiD 2000 Series products are Intrinsic Safety Certified according to CENELEC, CSA, FM, GOST, SEV,

SABS, SAA and other world-wide standards. Moreover, they meet European directives on EMC, and all

modules carry the CE marking.

1.2 Explanation of Contents

This instruction manual describes how to install, connect, check and maintain the HiD range of intrinsic safety

isolators:

•section 2 supplies the technical specifications of the units in a concise form

•section 3 describes system operation.

•section 4 describes how to install and configure the HiD modules

•section 5 shows how to operate the units

•section 6 deals with maintenance and troubleshooting issues

A Glossary and an Analytical Index for easy reference to topics complete the document.

This isolators manual is intended to be read and used in conjunction with the Termination Board User

Instruction Manual (IM-ENG 112/GB).

1-2

1.3 Key Features

•high channel density results from innovative circuit design using surface mounted components

•high packing density, with ultra slim 4 channels 18 mm wide plug-in mounting modules, 4.5 mm per

channel

•single, dual and quadruple channels models

•high signal transfer accuracy and repeatability

•low power consumption and heat dissipation

•wide operating temperature range

•wide range of digital switches and analog I/O, including 4-20 mA, signal conversion, loop powered and

external supply configurations

•galvanic isolation to eliminate noise, ground loop problems and to provide Intrinsic Safety without a

high integrity safety earth connection

•line fault alarm detects open or short circuit of field cables

•sink or source outputs available on analog models

•configure using DIP switch located on side cover for easy field set up

•LED indication for power, signal status and line fault condition

•“Quick Lok” mechanism for easy and quickly mounting

•loop identification, coding and tagging

•accept DC power supply over a wide range (24V, -15% +25%)

1.4 Hazardous Area Interfacing

Correct and safe operation of Elcon HiD 2000 Series calls for expert installation and commissioning as well as

correct operation and meticulous maintenance.

Only those persons conversant with the installation commissioning, operation and maintenance of similar

apparatus and who has the necessary qualifications are allowed to work on HiD 2000 Series.

Make sure installation is carried out observing the safety regulations pertaining to the installation and operation of

electrical system and the directives and guidelines on explosion protection (Hazardous Area equipment should

comply with the descriptive system document).

The installation must be performed by qualified personnel, it must comply with the relevant national/international

standards (e.g. IEC 79-14, CEI 64-2, BS 5345 Pt. 4, DIN VDE 165) and in line with the established installation

rules and recommended practice (e.g. CEI 64-8, ANSI/ISA RP-12.6).

The conformity of hazardous area devices with the related system documentation must always be checked. This

instrumentation IS NOT intended for hazardous area installation, unless it is included in a proper explosion proof

enclosure which conforms to the applicable standards.

For I.S. applications, the maximum limit for AC power supply is 250 Vrms.

For more information on request Elcon will provide the manual “Guide to Intrinsic Safety”, a comprehensive

tutorial about the constraints imposed by the I.S. regulations.

2-1

2Specifications

This section lists the relevant specifications for all HiD modules. For a detailed description of unit functions and

operation, please refer to Section 5.

2.1 Product Selection

The following table shows the standard isolators available and their main features.

Field

Device Model N° of

Ch. Hazardous Area Signal Safe Area Signal Fault Bus

Output

HiD 2025

HiD 2026

4-20 mA (15.5 V) floating supply to Smart

or non Smart two wire Transmitters 4-20 mA (or 1-5 V) output isolated from

input, Smart compatible

HiD 2025/SK

HiD 2026/SK

4-20 mA (15.5 V) floating supply to Smart

or non Smart two wire Transmitters 4-20 mA load sink, isolated from input,

Smart compatible

HiD 2029

HiD 2030

4-20 mA (15.5 V) floating supply to Smart

or non Smart two or three wire Transmitters 4-20 mA (or 1-5 V) output isolated from

input and power supply, Smart compatible,

Line Fault Detection

√√

HiD 2029/SK

HiD 2030/SK

4-20 mA (15.5 V) floating supply to Smart

or non Smart two or three wire Transmitters 4-20 mA load sink, isolated from input and

power supply, Smart compatible, Line Fault

Detection

√√

HiD 2031

HiD 2032

4-20 mA to I/P converters, electrovalve

actuators and displays Bus powered, 4-20 mA signal from DCS,

PLC or other control device

HiD 2033

HiD 2034

4-20 mA to I/P converters, electrovalve

actuators and displays Loop Powered, 4-20 mA signal from DCS,

PLC or other control device

HiD 2035

HiD 2036

Fire and Smoke Detectors or I/P Converter Loop Powered, 1.5 to 50 mA signal from

DCS, PLC or other control device

HiD 2037

HiD 2038

4-20 mA and Smart signal to I/P

converters, electrovalve actuators and

displays

Bus powered, 4-20 mA signal from DCS,

PLC or other control device, Line Fault

Detection, Smart compatible

√√

HiD 2061

HiD 2062

Thermocouple or mV 4-20 mA (or 1-5 V) output isolated from

input

HiD 2071

HiD 2072

RTD or Potentiometer 4-20 mA (or 1-5 V) output isolated from

input

HiD 2822

HiD 2824

Dry Contact or Proximity Switch DPST relay per channel, Line Fault

Detection

SPST relay per channel, Line Fault

Detection

√√

HiD 2842

HiD 2844

Dry Contact or Proximity Switch 2 open-collector outputs per channel, Line

Fault Detection

1 open-collector output per channel, Line

Fault Detection

√√

2-2

Field

Device Model N° of

Ch. Hazardous Area Signal Safe Area Signal Fault Bus

Output

HiD 2871

HiD 2872

40 mA at 12 V to drive solenoid valve,

audible or visual alarm (LED) Bus powered and/or loop powered,

controlled by external contact from DCS or

control device

HiD 2873

HiD 2874

40 mA at 12 V to drive solenoid valve,

audible or visual alarm (LED) Bus powered, controlled by external contact

or logic level from DCS or control device,

Line Fault Detection

√√

HiD 2875

HiD 2876

40 mA at 11.2 V to drive solenoid valve,

audible or visual alarm (LED) Bus powered and/or loop powered,

controlled by external contact from DCS or

control device

HiD 2877

HiD 2878

40 mA at 11.2 V to drive solenoid valve,

audible or visual alarm (LED) Bus powered, controlled by external contact

or logic level from DCS or control device,

Line Fault Detection

√√

HiD 2881 1

60 mA at 13 V to drive solenoid valve, IIB

Gas Group Bus powered and/or loop powered,

controlled by external contact or logic level

from DCS or control device, Line Fault

Detection

√√

2.2 Ordering Information

The ELCON family of HiD Intrinsic Safety Isolators are designed for simple ordering, you simply have to specify

the Model Number from the product selection table.

All user configurable units are delivered with a “default” configuration as specified in Section 2.7. For an additional

charge, Elcon can deliver units configured as specified by the customer.

Each unit is delivered with a detailed Installation Sheet containing all the information required to set up the isolator

on site.

2-3

2.3 Mechanical Specifications

Mounting Plug-in on Termination Board

Dimensions Width 18 mm

Depth 106 mm

Height 128 mm

Case material Policarbonate

Flame retardant compliant to UL 94 V2

Unit weight about 140 gr

Blister packing size Width 30 mm

Depth 145 mm

Height 165 mm

Dimensional Drawing

2-4

2.4 Safety Specifications

Terminal Safety Description Maximum External Parameters

HiD2025/2026 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

HiD2025SK/2026SK Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

HiD2029/2030 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

Uo = 1.2 V II C A-B

4-7 Io = 50 mA II B C-E Non energy storing apparatus connection

5-6 Po = 25 mW II A D-F-G

HiD2029SK/2030SK Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

Uo = 1.2 V II C A-B

4-7 Io = 50 mA II B C-E Non energy storing apparatus connection

5-6 Po = 25 mW II A D-F-G

HiD2031/2032 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

HiD2033/2034 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

HiD2035/2036 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

HiD2037/2038 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 26.25 V II C A-B 0.097 4.1 58

1-4 Io = 93 mA II B C-E 0.74 16.5 230

2-5 Po = 610 mW II A D-F-G 2.51 33 470

HiD2061/2062 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 13.1 V II C A-B 1.97 70 520

1-4, 7-8 Io = 22 mA II B C-E 13.8 250 1860

2-3, 5-6 Po = 72 mW II A D-F-G 60 580 4300

HiD2071/2072 Cenelec (groups) USA Co (µµF) Lo (mH) L/R (µµH/ΩΩ)

Uo = 13.1 V II C A-B 1.97 70 520

7-1-4-8 Io = 22 mA II B C-E 13.8 250 1860

3-2-5-6 Po = 72 mW II A D-F-G 60 580 4300

Table des matières

Autres manuels Elcon Équipements de sécurité

Elcon

Elcon EL-34 Manuel utilisateur

Manuels Équipements de sécurité populaires d'autres marques

Innova

Innova Xtirpa Mode d’emploi

bolle SAFETY

bolle SAFETY B810 Manuel utilisateur

SHENZHEN FANHAI SANJIANG ELECTRONICS

SHENZHEN FANHAI SANJIANG ELECTRONICS A9060T Manuel utilisateur

Hiltron security

Hiltron security POWER8E Mode d’emploi

Hatco

Hatco B-950P Manuel utilisateur

Sitec

Sitec TX MATIC Manuel utilisateur

TEUFELBERGER

TEUFELBERGER GRIP 12 Manuel utilisateur

MSA

MSA PremAire System Manuel utilisateur

AMC

AMC 1022M Series Manuel utilisateur

Trinity

Trinity CASS S3 Manuel utilisateur

CMC

CMC Helitack HotSeat Manuel utilisateur

Force

Force P-35 Manuel utilisateur

ACM

ACM SAFETY D200 Manuel du produit

Honeywell

Honeywell Miller H-Design DuraFlex Manuel de l'opérateur

ROCK

ROCK P-451 AS Manuel utilisateur

Power first

Power first 2XYR7A Manuel de service

SCHUBERTH

SCHUBERTH SHP 28-C Manuel utilisateur

Trango

Trango CINCH Manuel utilisateur
