Elation DP-DMX20L Manuel utilisateur

4295 Charter Street Los Angeles, CA 90058 USA

Tel: 323-582-3322 Fax: 323-582-3311

Web: www.elationlighting.com

E-mail: [email protected]

Elation Professional R

DP-DMX20L

8888

DMX Signal

MODE

1432

Receive

Chase

4321

OUTPUT: 10A/CH , TOTAL 20A Max.

4 CHANNEL DMX DIMMER PACK

TOTAL DMX CHANNEL

DMX CHANNEL

CHASE PROGRAM

CHASE SPEED

CHASE DIMMER

MODE MENU DISPLAY

RECEIVE

CHASE

DIMMER / SWITCH

USER MANUAL

otes:

Power Input ...................................................... AC 120V~50-60Hz, 20 A max.

Channel Output ........................................... 10A per channel, Total 20 A max.

DMX OUT ........................................................................... 3-pin XLR female

DMX IN .................................................................................. 3-pin XLR male

External load fuse............................................................. F10A 250V 5x20mm

Dimensions ..........................................8.35L x 7.4W x 2.8H (212x188x71mm)

Weight ......................................................................................5.29lbs.(2.4 Kg)

Internal main fuse........................................................ F0.315A 250V 5x20mm

Technical Specifications

Table of Contents

General Instruction..........................................................................2

Warnings.........................................................................................2

Cautions......................................................................................... 2

Features ...........................................................................................1

Control and Functionss .................................................................. 3

Front Panel Layout ..................................................................3 & 4

Rear Panel Layout......................................................................... 4

Operation Guide.............................................................................. 5

Menu Options................................................................................. 5

Chase Mode..................................... ............................5 & 6

Receive (DMX) Mode................ ..............................7 & 8

............

.................

Installation Mounting & Connections.

Troubleshooting

, ......................................... 9

Installation / Mounting................................................................... 9

Connections...................................................................................9

............................................................................10

Troubleshooting........................................................................... 10

Fuse Replacement.......................................................................10

Technical Specifications...............................................................11

Features

Thank you for purchasing the DP-DMX20L hybrid dimmer/switch pack. This

product includes the following features:

Every effort has been made to design dependable and reliable products. New

products are constantly being designed to meet the needs of the

entertainment lighting industry. Your comments regarding our products and

services are welcome. Please send us an e-mail to [email protected]

and let us know how we can improve to better serve you.

It is both a privilege and a pleasure serving you.

4 channel hybrid pack with dual Edison sockets per channel.

All four channels are user assignable between Dimmer & Switch

modes.

Device can functions as a one, two or four channel pack.

16 built in chase programs with speed and intensity settings.

Power failure memory..

4 digit digital LED-display.

0-100% dimming capability.

Four 10A fuses. One per channel, AC120V, 5x20mm

4 channel LED’s indicate relevant channel activity.

Troubleshooting

Fuse Replacement

No Power to the pack:

No Channel output:

Undesired 100% channel switch output:

Disconnect the main power line cord. Reconnect the line cord to

ensure proper connection. If the problem still persists, check the building

service panel and make sure the circuit breakers are on.

Disconnect the main power line cord. Check the corresponding channel

fuse (see replacing fuses section). Replace if blown. Reconnect line cord.

If controlling via DMX, ensure that you are receiving DMX signal at the

pack. Indicator in the display should be flashing when signal is present. If

signal is not present, check the XLR connections from console or previous

fixture in line. If problem still persists, replace XLR cable between previous

device and pack and try again.

Check the “Dim/Switch” settings. Ensure all channels are set to dim. If problem

still persists, ensure that you are not receiving channel output from your

console by disconnecting the XLR input cable from the pack.

If you’ve tried the above and the unit continues to malfunction, please contact

ELATION customer service at (323) 582-3322, your unit will require service.

Once you describe your problem to the customer service representative, you

will be issued a return authorization number that must accompany the package

when sent in. Please write this RA# on the outside of the box with a black

marker and also write it on any packing list that may be included with the

package.

External Fuse Replacement: Disconnect the main power line cord.

Internal Fuse Replacement: Disconnect the main power line cord.

Use a flat head screwdriver to remove the fuse holder cap. Pull out the old fuse

and replace it with a new one of the exact same type. Replace the fuse cap with

the flat head screw driver. Do not over tighten as this may result in a broken and

unusable fuse holder.

Remove the six phillips head screws from the rear panel. Locate fuse on circuit

board, remove and replace with exact same type. Replace rear panel and six

screws.

The DP-DMX20L was designed to be mounted onto a truss rig or ceiling. It is

recommended that you use a suitable mounting clamp and safety cable when

mounting over head. There are several mounting holes on the DP-DMX20L in

place for the mounting in various configurations. The mounting bracket can be

reversed by removing the six phillips head screws on the rear- this design is

intended for hanging the pack ontoa2inpipe or truss without the need of clamps

or other means of hardware. For cooling purposes, it is necessary to mount the

pack so that air is free to circulate around the dimmer. There should be at least 12

inches of clearance between the pack and anything surrounding it.

The DP-DMX20L is supplied with a single 15 Amp Edison plug attached to a 14

gauge line cord. This cord should be connected to a service capable of suppling

20 amps to the pack and be protected by a properly sized circuit breaker.

Lamp loads should be plugged into to the dual 15 Amp Edison sockets which are

supplied on the face of the pack. 3 pin XLR’s are supplied for the DMX input and

output. Connect out of the DMX controller or previous fixture in line and into the

input of the DP-DMX20L. Connect out of the DP-DMX20L and into the input of

next pack or fixture in line. Continue to connect the remainder of your fixtures in a

daisy chain fashion. It is recommended that the last pack or fixture in line include

a DMX terminator into the output. A DMX terminator consists of a 120 ohm, 1/4

watt resistor soldered across pins2&3ofastandard 3 pin XLR connector.

Installation / Mounting

Connections

Installation, Mounting & Connections General Instructions

This is a 4 channel portable DMX dimmer/switch pack. Each channel can

individually be set to dim or switch and the pack can function as a one, two or

four channel device. Using the packs digital display, the pack is quick and easy

to set up. There are dual Edison sockets supplied so more than one par or

effect can be connected to each channel. 16 built in chase sequences, with

speed and intensity control, are available for your convenience. Four external

channel fuses allow for quick and easy field serviceability.

This unit must be earthed.

Do not allow for any flammable liquids to come in close contact with the unit.

Do not dismantle or modify this unit. There are no user serviceable parts

inside.

Handle this unit carefully, any strong shock or vibration may result in

malfunction.

When replacing fuses, always replace with the exact same type.

When unpacking, please check the unit for damages. Should you find

something wrong with the unit, please contact the dealer that you purchased

it from immediately.

by any means, without permission in writing from Elation Professional.

Specifications and improvements in the design of this product and this

manual are subject to change without prior notice.

Notice:

Do not operate this unit if the internal components are exposed.

Only use an AC source that complies with the local building and electrical

codes.

To optimize performance of this product, please read the instructions carefully to

familiarize yourself with the basic operations.

Keep the unit dry, do not expose it to water or high levels of humidity.

Warnings

Cautions

Controls & Functions

Front Panel Layout

8888

DMX Signal

MODE

1432

Receive

Chase

4321

OUTPUT: 10A/CH , TOTAL 20A Max.

4 CHANNEL DMX PACK

TOTAL DMX CHANNEL

DMX CHANNEL

CHASE PROGRAM

CHASE SPEED

CHASE DIMMER

MODE MENU DISPLAY

RECEIVE

CHASE

DIMMER / SWITCH

1. Edison Output Sockets (1-4):

These are dual 120V. Edison sockets. Each socket is labeled with the packs

relevant channel number. Up to 10 amps can be connected into each channel.

2. Channel LED’s (1-4): These LED’s display relevant channel intensity & activity.

3. LED Display: Shows the current DMX channel and function mode- including

a DMX signal indicator. All set up functions are accomplished through display.

4. Mode Button:

The mode button is used to select between receive and chase mode. When in

receive mode, the pack will respond to DMX. When in chase mode, the pack

can be set to chase any of the internal 16 chase programs.

5. Menu Button: The menu button is used to set up the packs characteristics.

MODE MENU

143

Operation Guide

Receive (DMX) Mode Cont.

4. Press the up or down buttons to

change the total DMX channel setting. Set to

“ if you wish to set the device as a one

channel pack- all four channels will activate via

the packs set DMX address channel. Set to

if you wish to set the device as a two

channel pack- channels1&2will activate via the

packs set DMX address channel and channels

3 & 4 will activate by the next DMX channel in

sequence. Set to if you wish to set the

device as a four channel pack- each of the packs

channels will individually be controlled via its own

DMX channel starting with the set DMX address

channel.

Ch:01”

“Ch:02”

“Ch:04”

CH:02

DMX Signal Receive

Chase

MODE MENU

143

25. Press the MENU button to access dimmer /

switch settings. The display will show “

C1-d”

“C1-S”. Note: All packs are set to dimmer

mode at the factory.

C1-d

DMX Signal Receive

Chase

MODE MENU

143

26. Press the up or down buttons to change

between dimmer / switch modes. Once set, press

the MENU button to confirm and advance to

the following channel settings. Repeat these steps

for all four channels. When complete, the DMX

channel address setting will show in the display.

C1-S

DMX Signal Receive

Chase

Operation Guide

Receive (DMX) Mode

MODE MENU

143

2. Tap the up or down buttons to set your

desired DMX channel address setting. Pressing

and holding the up or down buttons will change

the values in the display quickly. This is useful

when trying to achieve higher channel values.

MODE MENU

143

3. Press the MENU button to access the total

DMX channel option setting. The display will

show C , C or C .h:01 h:02 h:04

MODE MENU

143

21. Press the MODE button to access receive

(DMX) mode. An “A” in the display indicates

receive mode. There will also be a small

indicator illuminated on the top right side of

the display next to the “Receive” text. In

addition, if you’ve connected your DMX

console to the pack, there will be a flashing

indicator in the top left side of the display next

to the “DMX Signal” text indicating that DMX

signal is present.

A:001

DMX Signal Receive

Chase

A:025

DMX Signal Receive

Chase

CH:04

DMX Signal Receive

Chase

Controls & Functions

Front Panel Layout Cont.

This product must not be continuously used

for a long time under 20A total output load

Power input:

1234

1:Ground

2:Data-

3:Data+

DMX OUTDMX IN

Power

Risk of Electric Shock

DO NOT OPEN

CAUTION

FUSES:F10A 250V 5x20mm

Made in PRC 23-001-1568

AC 120V~ 50-60Hz, 20A max.

Fuses (internal):

F0.315A 250V 5x20mm

N'ouvrez pas..risque de choc electrique

Warning:This apparatus must be earthed

8911

6. Up Arrow Button: Pressing this button will increase any value listed in

the display by one. Pressing and holding this button

down will increase the displayed value quickly.

7. Down Arrow Button: Pressing this button will decrease any value

listed in the display by one. Pressing and holding

this button down will decrease the displayed

value quickly.

Rear Panel Layout

8. Power Switch:

This switch turns the device ON & OFF.

9. Power Input:

The line cord supplies power to the device. Plug into a 120V.-60Hz. Outlet.

10. Fuse Holders (1-4):

These fuse holders house one 10 amp, 120V, 5x20mm. fuse each. Each

channel fuse protects the corresponding internal components from getting

damaged if there were ever a short or voltage spike.

11. 3-pin XLR DMX Input Connector:

This input receives DMX signal from a DMX controller or previous device.

12. 3-pin XLR DMX Output Connector:

This output feeds DMX signal through to the next DMX device in line.

Operation Guide

Chase Mode

P:01

DMX Signal

MODE

Receive

Chase

1. Press the MODE button to access Chase

mode. The indicator next to the Chase text

will illuminate.

2. Tap the up or down buttons to scroll to

the chase that you desire. There are sixteen

built in chase programs to select from.

dS,PSP

Note: Abbreviations within the display represent the following: =Address,

=Channel, =Dimmer & Dim Level, =Switch =Program, =Speed.C&CH

When in receive mode, press the MENU button to navigate through the menu

options. Continually tapping the MENU button will loop through the following

options.

CH: 01, 02 or 04

A: 001 - 512 C1- dorS C2-dorS C3- dorS C4-dorS

DMX Address Total DMX channels Channel 1 Dim or Switch Channel 2 Dim or Switch Channel 4 Dim or Switch

Channel 3 Dim or Switch

Menu Options

When in chase mode, press the MODE button to enter pre-programmed chase

mode, continually tapping the MENU button will loop through the following options.

SP: 01 - 99

P: 01 - 16 d: 000 - 100 C2-dorS C3- dorS C4-dorS

Chase Speed Channel 1 Dim or Switch Channel 2 Dim or Switch Channel 4 Dim or Switch

Channel 3 Dim or Switch

Chase Programs Dim Level

C1-dorS

P:02

DMX Signal Receive

Chase

MODE

3. Press the MENU button to access

the chase speed option.

4. Tap the up or down buttons to set

your desired chase speed. The range is

from 01-99. The higher the value, the faster

the chase speed.

Operation Guide

Chase Mode

MODE

5. Press the MENU button to access the

chase dimmer option. The dim levels range

from 0 - 100%. A selected chases intensity will

reflect the dim setting level.

SP:89

DMX Signal Receive

Chase

SP:89

DMX Signal Receive

Chase

d:055

DMX Signal Receive

Chase

6. Tap the up or down buttons to set

your desired chase intensity. The higher the

value, the brighter the intensity during chase

playback.

d:064

DMX Signal Receive

Chase

Table des matières

Autres manuels Elation Matériel de DJ

Elation

Elation Artiste Monet Manuel utilisateur

Elation

Elation FSD 575 Manuel utilisateur

Elation

Elation DTW PAR 300 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Elation

Elation SIXBAR 1000 Manuel utilisateur

Elation

Elation PROTEUS RAYZOR 1960 Manuel utilisateur

Elation

Elation CHORUS LINE 16 Manuel utilisateur

Elation

Elation TVL551 Manuel utilisateur

Elation

Elation Active Scan 250 Manuel utilisateur

Elation

Elation DTW BLINDER 700 IP Manuel utilisateur

Elation

Elation FUZE WASH FR Manuel utilisateur

Elation

Elation KL Fresnel 6 PO Manuel utilisateur

Elation

Elation SMARTY HYBRID Manuel utilisateur

Elation

Elation Elation Professional Scene Setter Manuel utilisateur

Elation

Elation 5R SNIPER Manuel utilisateur

Elation

Elation PROTEUS RAYZOR 760 WMG Manuel utilisateur

Elation

Elation FUZE PAR Z120 IP Manuel utilisateur

Elation

Elation 70 Manuel utilisateur

Elation

Elation PLATINUM PROFILE LED Manuel utilisateur

Elation

Elation 1236100115 Manuel utilisateur

Elation

Elation DTW BLINDER 350 IP Manuel utilisateur

Elation

Elation ZCL BAR Z300 IP Manuel utilisateur

Elation

Elation ARTISTE DAVINCI Manuel utilisateur

Elation

Elation DMX Operator 192 Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur

KAM

KAM DMX Laser80 FScan Manuel utilisateur
