EKF Electronik SC8-FLUTE Manuel utilisateur

User Guide

SC8-FLUTE • CompactPCI® Serial CPU Card

Intel® Atom™x6000 Series Processor • Elkhart Lake SoC

Preliminary Edition

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

Contents

AboutthisManual........................................................................4

EditionHistory.....................................................................4

RelatedDocuments................................................................5

Nomenclature.....................................................................5

TradeMarks.......................................................................5

Legal Disclaimer - Liability Exclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Standards.........................................................................6

General..................................................................................7

FeatureSummary..................................................................8

CompactPCI®Serial............................................................... 14

MezzanineExpansion............................................................ 15

BlockDiagram................................................................... 19

FrontPanel...................................................................... 20

FrontPanelConnectors........................................................... 21

Front Panel Switches & Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 22

ComponentOrientation.......................................................... 23

Overview On-Board Connectors & Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 26

BackplaneResources............................................................. 27

RecommendedSystemSolutions.................................................. 30

System-on-Chip.................................................................. 32

Memory......................................................................... 33

MassStorage.................................................................... 34

Graphics......................................................................... 35

Networking...................................................................... 36

TrustedPlatformModule(TPM)................................................... 37

SerialATA(SATA)................................................................ 38

PCIExpress®..................................................................... 39

UniversalSerialBus(USB)......................................................... 40

SPIFlash......................................................................... 41

Real-TimeClock(RTC)............................................................ 42

ReplacementoftheBattery....................................................... 42

Warning.................................................................. 42

Watchdog....................................................................... 43

Reset............................................................................ 44

PowerRequirements............................................................. 46

Main Power Supply Control (PS_ON#) . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

PowerSupplyStatus(PWR_FAIL#)................................................. 46

ThermalConsiderations.......................................................... 47

PeripheralSlotOperation......................................................... 48

BoardHot-Plug.................................................................. 49

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

SupplementaryInformation...................................................... 50

TechnicalReference.................................................................... 51

LocalPCI®Devices................................................................ 51

Local SMB/I2CDevices............................................................ 52

HardwareMonitorNCT7491...................................................... 53

Board Control and Status Registers (BCSR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Write/ReadControlRegister0.............................................. 55

Read/ClearStatusRegister0............................................... 56

Read/ClearStatusRegister1............................................... 57

ReadPLDRevisionRegister................................................. 58

ConfigurationJumpers........................................................... 59

J-GP - Loading UEFI/BIOS Setup Defaults & IEEE 1588 Pulse per Second . . . . . . . 59

J-MFG - Manufacturer Mode Jumper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . 60

J-RTC-RTCReset.......................................................... 61

Connectors...................................................................... 62

MezzanineConnectors........................................................... 63

HSE1MezzanineConnector................................................ 65

HSE2MezzanineConnector................................................ 66

N-EXPMezzanineConnector............................................... 67

CompactPCI® Serial Backplane Connectors. . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

P1........................................................................ 69

P2........................................................................ 70

P3........................................................................ 71

P4........................................................................ 72

P5........................................................................ 73

PCBDimensions.................................................................. 74

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

About this Manual

ThismanualdescribesthetechnicalaspectsoftheSC8-FLUTE,requiredforinstallationandsystem

integration. It is intended for the experienced user only.

Edition History

Ed. Contents Author Date

1 User Manual SC8-FLUTE, english, preliminary edition (formal

structure and basic content), Text #10074, File: sc8_ug.wpd jj 8 June 2022

Pleasenote:IfanEKFproducthasbeenlabelledwith this special sign according to ISO 7010 M002, please

contact support@ekf.com for availability of additional documentation which may be important

for proper usage.

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

Related Documents

Related Information SC8-FLUTE

SC8-FLUTE Home www.ekf.com/s/sc8/sc8.html

SC8-FLUTE Product Information www.ekf.com/s/sc8/sc8_pi.pdf

Nomenclature

Signal names used herein with an attached '#' designate active low lines.

Trade Marks

Some terms used herein are property of their respective owners, e.g.

<XEON®, Core™: ® Intel

<CompactPCI, CompactPCI PlusIO, CompactPCI Serial: ® PICMG

<Windows: ® Microsoft

<EKF, ekf system: ® EKF

EKF does not claim this list to be complete.

Legal Disclaimer - Liability Exclusion

This manual has been edited as carefully as possible. We apologize for any potential mistake.

Information provided herein is designated exclusively to the proficient user (system integrator,

engineer). EKF can accept no responsibility for any damage caused by the use of this manual.

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

Standards

Reference Documents

Term Document Origin

CompactPCI®

Serial CompactPCI® Serial Specification, PICMG® CPCI-S.0 www.picmg.org

DisplayPort VESA DisplayPort Standard Version 1.4a,

DisplayPort Alt Mode on USB Type-C www.vesa.org

Ethernet IEEE Std 802.3

2.5GBASE-T, 1000BASE-T, 100BASE-TX, 10BASE-T

IEEE Std 1588-2008 Precision Time Protocol

standards.ieee.org

HD Audio High Definition Audio Specification Rev.1.0a www.intel.com

eSPI Intel Enhanced Serial Peripheral Interface Bus

Interface Base Specification Rev. 1.0 www.intel.com

M.2 PCI Express M.2 Specification Revision 4.0 www.pcisig.com

NVMe NVM Express 2.0 specification www.nvmexpress.org

PCI Express® PCI Express® Base Specification 3.1

PCI Express® Base Specification 4.0 www.pcisig.com

SATA Serial ATA 3.0 & 3.1 Specification www.sata-io.org

TPM Trusted Platform Module 2.0 www.trustedcomputinggroup.org

UEFI Unified Extensible Firmware Interface

UEFI Specification Version 2.9

UEFI Shell Specification Version 2.2

ACPI Specification Version 6.3

www.uefi.org

USB Universal Serial Bus 3.2 Specification Rev.1.0

Universal Serial Bus 4 Specification Version1.0

Type-C Cable and Connector Specification Rev. 2.1

Type-C Locking Connector Specification Rev. 1.0

Universal Serial Bus Power Delivery Specification Rev. 3.1

www.usb.org

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

General

The SC8-FLUTE is a low power CompactPCI®

Serial CPU board, based on an Intel® Atom™

x6000RE (Elkhart Lake Industrial) System-on-

Chip processor. The front panel is provided

with three 2.5Gbps RJ45 Ethernet jacks, and

three Type-C USB3/DisplayPort connectors.

The board is equipped with 16GB directly

soldered DDR4 IBECC RAM, and in addition a

DDR4 SODIMM socket for another 16GB.

High speed PCIe® x4 SSD mass storage is

available via low profile mezzanine modules

(4HP assembly), or multi-function side cards

(8HP). The SC8-FLUTE backplane connectors

comply with the CompactPCI® Serial system

board specification, suitable for reasonable

systemexpansionvia 3xPCIe®,4xSATA (two

ports configurable as hardware RAID 0/1),

and USB3.

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

Feature Summary

General

<CompactPCI® Serial (PICMG® CPCI-S.0) System Slot Controller

<Form factor single size Eurocard (board dimensions 100x160mm2)

<Mounting height 3U

<Front panel width 4HP (8HP/12HP assembly with optional mezzanine side card)

<Front panel I/O for versatile system configuration (3 x USB3/DisplayPort, 3 x 2.5Gbps Ethernet)

<Backplane communication via CompactPCI® Serial connectors

<On-board PCIe® mezzanine expansion option for mass storage modules or side cards

<Side cards and low profile mass storage modules available as COTS and also as custom specific

SoC (Processor)

<Intel® Atom® Industrial SoC x6000RE Series (Elkhart Lake)

<x6425RE • 4 Cores • 1.9GHz • 12W TDP • 400MHz/32EUs Gfx

<x6414RE • 4 Cores • 1.5GHz • 9W TDP • 400MHz/16EUs Gfx

<x6212RE • 2 Cores • 1.2GHz • 6W TDP • 350MHz/16EUs Gfx

all frequencies not final and subject to change

<Intel® Atom® Embedded SoC x6000E Series (Elkhart Lake)

<x6425E • 4 Cores • 2.0GHz • 12W TDP • 500MHz/32EUs Gfx

<x6413E • 4 Cores • 1.5GHz • 9W TDP • 500MHz/16EUs Gfx

<x6211E • 2 Cores • 1.3GHz • 6W TDP • 350MHz/16EUs Gfx

<Intel® Atom® Industrial FuSa SoC x6000FE Series (Elkhart Lake)

<x6427FE • 4 Cores • 1.9GHz • 12W TDP • 400MHz/32EUs Gfx • FuSa

<x6200FE • 2 Cores • 1.0GHz • 4.5W TDP • tbd MHz/tbd EUs Gfx • FuSa

italic grey: SKUs not plan of release

<In-band ECC

<Intel® Programmable Services Engine

<Intel® Time Coordinate Computing (Intel® TCC) and TSN

<Operating life 10 years up to 100% active

<Ta-40°C to 85°C

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

Feature Summary

Firmware

<Phoenix® UEFI (Unified Extensible Firmware Interface) with CSM*

<Fully customizable by EKF

<Secure Boot and Measured Boot supported

<Windows®, Linux and other (RT)OS' supported

* CSM (Compatibility Support Module) emulates a legacy BIOS environment, which allows to boot a

legacy operating system such as DOS, 32-bit Windows and some RTOS'

Main Memory

<Integrated memory controller fo up to 32GB DDR4 w. IBECC, 3200MT/s

<16GB Soldered memory for rugged applications

<16GB SODIMM socket

Mass Storage

<128Mbit SPI Flash (UEFI firmware and customer application data)

<Option e•MMC (embedded MMC 5.0 64GByte soldered)

<PCIe® based SSD module options via P-HSE1 & P-HSE2 mezzanine connectors

<M.2 socket(s) on low profile mezzanine modules (4HP) or side cards (8HP)

<Up to 2 x M.2 NVMe SSD size 2280, PCIe x4 (P-HSE1) and PCIe x1 (P-HSE2)

<Up to 2 x 1TB as of current

<Option custom specific mezzanine mass storage board design on request

Graphics

<Intel® UHD Graphics, 4kp60 (4096x2160@60Hz) on three simultaneous displays

<2D/3D Hardware acceleration

<H.265/HEVC Decode/Encode

<H.264 Decode/Encode

<MPEG2 Decode

<VC1/WMV9 Decode

<VP8 Decode

<VP9 Decode/Encode

<JPEG/MPEG Decode/Encode

<HDCP 2.3, PAVP

<3 x Type-C front panel connectors (DisplayPort Alternate Mode)

<DisplayPort™ 1.4 MST (multiple displays if monitor is equipped with bridge chip)

SC8-FLUTE • CompactPCI® Serial CPU Board • Intel® Atom™x6000RE Series SoC

Feature Summary

Networking

<Up to 11 Gigabit Ethernet networking interfaces in total

<3 x 2.5GBASE-T RJ45 front ports via integrated MACs & SGMII PHYs Marvell® AQR115C

<Option 8 x 1000BASE-T backplane w. S80-P6 mezzanine module - Marvell® Peridot switch

<Option 4 x 1000BASE-T backplane w. S82-P6 mezzanine module - 4 x Intel® I210-IT NIC

<Option 4 x 2.5GBASE-T RJ45 front w. SCJ-VEENA short side card - 4 x Intel® I226-IT NIC (8HP assy)

<Option 4 x 1000BASE-T M12-X front w. SCL-RHYTHM short side card - 4 x Intel® I210-IT NIC (8HP assy)

<TSN Precision time protocol (Time-Sensitive-Networking) as required for OPC UA and OpenAvnu

<Enables ultra-reliable low-latency communication (URLLC)

<Intel® Time Coordinated Computing (Intel® TCC) for time synchronisation and timeliness

EHL SoC I/O Usage

<3 x USB Type-C front panel connectors (DP Alt Mode)

<3 x 2.5GBASE-T SGMII PHYs to RJ45 front ports

<4 x PCIe® Gen3 to HSE1 mezzanine connector (configurable 1x4 or 4x1 links)

<4 x PCIe® Gen3 to HSE2 mezzanine connector (4x1 links via Gen3 switch)

<3 x PCIe® Gen3 to backplane connectors (x1 links, 1 derived from SoC, 2 x via Gen3 switch)

<1 x PCIe® Gen3 to 1:7 switch (1 x USB controller, 2 x backplane use, 4 x HSE2 mezzanine)

<e•MMC 5.1(ordering option, mass storage device up to 64GB)

<1 x SATA 3.2 for backplane usage

<eSPI, Audio, I2C, UART, CAN-FD, Time Sync to mezzanine expansion connector N-EXP

<TPM 2.0 module

Additional Building Blocks

<Additional on-board devices, PCIe® based

<PCIe® Gen3 packet switch PI7C9X3G808GP (8-port, 8-lane)

<Quad port PCIe® USB3 controller TUSB7340 (Type-C, backplane, HSE1, RAID controller)

<Option JMS562 USB to SATA RAID 0/1 controller (backplane SATA)

Security

<Trusted Platform Module

<TPM 2.0 for highest level of certified platform protection

<Infineon Optiga™ SLM9670 cryptographic processor

<Conforming to TCG 2.0 specification

<AES hardware acceleration support (Intel® AES-NI)

Table des matières

Autres manuels EKF Electronik Matériel informatique

EKF Electronik

EKF Electronik CompactPCI CC8-BLUES Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
