Ei Electronics EIB600MRF Manuel utilisateur
Instructions
Read and retain carefully for as long as the product is being used. It contains vital information on the operation
and installation of your Module. The leaflet should be regarded as part of the product.
If you are just installing this Module, the leaftet must be given to the householder. The leaflet is to be given to
any subsequent user.
EIB600MRF Module
(for use with EIB600 Series compatible Alarms only)
RadioLINK+Module EIB600MRF
for Battery Powered Smoke / Heat Alarms
EIB600 Series
2
Introduction .....................................................................................
Compatibility Table ..........................................................................
Installation and House Coding ........................................................
Additional Features .........................................................................
Indicator Summary ..........................................................................
System Examples ............................................................................
Testing the system ..........................................................................
Interconnected Smoke/Heat Alarms & Carbon Monoxide Alarms ...
RadioLINK+Troubleshooting ..........................................................
Technical Specifications ..................................................................
Guarantee .......................................................................................
Limitations of Radio Communications .............................................
Table of Contents
3
4
5
7
9
10
12
14
15
16
17
18
page
3
The EIB600MRF RadioLINK+ Module is the next generation RF module designed
to fit in the EIB650i series Smoke Alarms and EIB603TYC Heat Alarm. The
EIB600MRF RadioLINK+ Module has added features not previously seen before in
Brooks RadioLINK modules.
The primary function of the EIB600MRF is to interconnect all Brooks Alarms in
a system by the means of an RF signal i.e. when one Alarm senses a fire event, the
EIB600MRF module attached to that Alarm will transmit an RF signal that will
activate the sounders in all the other Alarms in the system.
The EIB600MRF module is plugged into the rear of the base of a Brooks compatible
Alarm (see Compatibility Table on page 4). RF communication through this module
eliminates the need to install long interconnect wires between all the Alarms on
different floors in different rooms. The EIB600MRF is powered from its own 3V
Lithium battery.
The module also has “multiple repeater” transmission – this provides multiple signal
paths to create a robust RF ‘mesh’ system and also increase the RF range.
Introduction
4
Model
1. Certain Alarms may be supplied (on request) with the appropriate RF module fitted
Intelligent Smoke Alarms
EIB650iC
EIB650iW
Yes
No
Hardwired
Interconnect
Yes
Yes
Compatible
with EIB600MRF
Ye
sY
esYes
Yes
Yes
1
RF
Capability
Model
Heat Alarms
Hardwired
Interconnect
Compatible
with EIB600MRF
1
RF
Capability
EIB603TYC
Standard Smoke Alarms
Compatibility Table
5
To fit the EIB600MRF module, plug it into the base of the compatible Alarm while
being careful to align the pins and insert the flexible antenna into the antenna hole
(See Fig 1). N.B. Ensure that the EIB600MRF is fully inserted.
House Coding the Unit
Power supply to the EIB600MRF will be confirmed
by an initial flash of the red, blue and green LED
on the cover (see Fig 2).
Press and hold the House Code button on the
module until the blue light illuminates on the
cover. (see Fig 2).
Immediately release the button, the blue light will
flash rapidly and then stop. Now attach the Alarm
to its mounting plate. (see ‘Installation’ section in
the EIB650i Series booklet).
The flashing will repeat every 5 seconds
thereafter. Repeat this procedure for all RF
devices in the system.
Check to ensure all RF devices have been successfully House Coded. This can
be done by counting the number of blue flashes on each RF Module. The number
of flashes should correspond to the number of RF devices in the system. (i.e. 4
flashes if there are 4 RF devices in the system).
Installation and House Coding
Figure 1
N.B. We recommend, for ease of installation and RF communication, that up
to 12 RF devices can be installed in any one RF coded system. Please contact
us for further advise if additional RF devices are required.
You can exit this mode by pressing the House Code button on one of the RF Alarms.
Keep the button pressed until the blue light comes on solid and then release.
The Alarm will now send a signal to all the other RF devices in the system to exit
House Code. Alternatively, the RF devices will automatically exit the House Code
mode after 30 minutes. Note: Some RadioLINK devices do not support the on
demand exit House Code feature. You may allow them to automatically exit House
Code after the time period or if you wish, you can do it manually. Consult the
individual RadioLINK device manual for further instructions.
To check the system, press the test button on any Alarm. After a few seconds all
Alarms should now sound. All Alarms in the system should be checked similarly.
6
House Code Button
Red / Blue / Green LED
Figure 2
7
Caution: Do not House Code another group (e.g. adjacent apartment) until the
current House Code has been completed.
Factory Reset
Sometimes in order to resolve an RF communication issue it may be necessary to
reset (factory reset) and House Code the system again. To do so, press and hold the
House Code button until you see a flashing blue light on the Alarm cover (approx. 7
seconds), release immediately. Repeat this procedure on all other Alarms.
The EIB600MRF RadioLINK+Module provides additional features not available
with Brooks RadioLINK products. The following features will only work with
RadioLINK+devices.
1. Remote House Coding (required if you want to add an Alarm to an installed system)
2. Data Extraction
*Note these functions will not be available unless you have completed House Code Entry
1. Remote House Coding
If it is necessary to extend an RF system or you find that you want to add an extra
Alarm to a system you can now do so quite simply via the ‘Remote House Coding’
feature. Firstly using a screwdriver, press and hold the House Code button of one of
the previously installed Alarms until you see all colours flashing (red, blue, green).
Immediately release the button. This Alarm will now send an RF message to all the
previously installed (compatible) devices to re-enter House Code mode.
Additional Features
Similarly, install and put the new Alarm you wish to add to the system into House
Code mode (see “Installation and House Coding” section). As before, allow
sufficient time so that all Alarms are now house coded correctly (this can be
confirmed by counting the number of flashes on each Alarm). You can then exit
House Code mode manually or let it exit automatically after 30 minutes. (N.B. for
this feature to work all devices in the system must be RadioLINK+).
2. Data Extraction
The EIB600MRF RadioLINK+ Module allows for the extraction of information from
a Brooks Compatible Alarm, using a Brooks download device. Once the system
has been set up, information can be accessed securely from within or outside a
property if access is an issue The event log can contain very useful information
about any recorded events in the history of the Alarm such as: Fire Events, Alarm
Head removals, Button Tests, and so on.
Event logs can be retrieved as many times as necessary.
8
9
Blue LEDButton Action Red LEDGreen LEDSounder
House Code EnterPress & Release on Solid Blue
Press & Release on Flashing Blue
Flashes briefly & stops
In House code
Factory Reset
Mode-Enter / Exit
OffOff Off
(1 flash per unit) every 5 Sec
**
OffOff Off
Rapid flashing followed by single flash OffOff Off
Press & Release on Solid Blue
House code Exit 3.5 Sec flash OffOff Off
Remote House Coding Press & Release on Multi- Colour Flashing Rapid flashing followed by 3.5 Sec flash OffOff Off
Power Up
Blue LED Red LEDGreen LEDSounder
Alarm
Head Removal
Full Sound
Normal Operation
Standby
1 flash1flash
3.5 Sec flash followed by flash every 10 Sec
3.5 Sec flash every 6 mins for 4 hrs
OffOff
Off
Off
1 flash
OffOff
Off
Off
Off
Off
Low Battery (EIB603TYC)
*
Low Battery
(EIB650iC / iW)
*
OffOff
Off
Off
Flash every 60 Sec
Flash every 60 Sec
1 beep with
flash
Off
EIB600MRF Indicator Summary
*
EIB600MRF Low Battery indicators when installed in these Alarms
**
See ‘Installation and House Coding’ section for further details
10
RF System (RadioLINK & RadioLINK+)
RadioLINK
Smoke Alarm
RadioLINK
Heat Alarm
RadioLINK
Smoke Alarm
RadioLINK
Smoke Alarm
Note: Remote House Coding / Monitoring / Data Extraction only available on RadioLINK+Alarms
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RFTo ol
Data Extraction
RFTool
Data Extraction
RadioLINK+System
System Examples
