Effekta RMH 700 Manuel utilisateur

UPS

Uninterruptible Power Supply

RMH 700/1000/1500

Instruction Manual

Item number: R30 / 00700MH-000

R30 / 01000MH-000

R30 / 01500MH-000

Juli 2005

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 2 of 37

Contents

1Presentation 4

2Warranty conditions 5

2.1 Limitation of liability 6

3Safety 7

3.1 General safety instructions 7

3.2 Transportation and storage 7

3.3 Setup 7

3.4 Connection 8

3.5 Operation 8

3.6 Handling batteries 9

3.7 Maintenance, servicing and faults 9

4Introduction 11

5System description 12

6RMH700/1000/1500 – description of equipment 14

6.1 Display and operator control elements on the front panel 14

6.1.1 UPS operator control elements 14

6.1.2 UPS display elements 15

6.2 Equipment elements on the rear panel 15

6.3 UPS audible alarm signals 15

7Storage and unpacking 15

7.1 Storing the UPS 15

7.2 Unpacking the equipment 15

8Installing and connecting the UPS 15

8.1 Connecting the UPS 15

8.2 UPS communications connection 15

8.3 Connection sequence 15

9Running and operating the equipment 15

9.1 Operating the UPS equipment 15

9.1.1 Operating modes and signals 15

9.2 Instructions for using the UPS 15

9.2.1 Switching on and starting the UPS 15

9.2.2 Powering down and switching off the UPS 15

9.2.3 Activating the test operation 15

9.2.4 Communication 15

10 Starting up the UPS equipment 15

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 3 of 37

11 Troubleshooting 15

12 Software 15

13 Maintenance and servicing 15

13.1 Measuring the bridging time (support time) 15

13.2 Replacing the batteries 15

13.3 Service log 15

13.4 Service hotline: 15

13.5 Maintenance and service contracts 15

14 Technical Data 15

14.1 Equipment specifications 15

14.2 Accessories 15

14.3 List of wearing parts 15

15 Requirements for the declaration of conformity 15

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 4 of 37

1 Presentation

In this instruction manual, the abbreviation UPS stands for Uninterruptible

Power Supply.

The following icons are used in this instruction manual:

Denotes information which, if disregarded, poses a risk

to health, functionality or safety.

Warning about the handling of batteries.

Warning about dangerous electrical voltage.

Denotes additional information and tips.

Recycling symbol.

Denotes components which are governed by the

electronic scrap ordinance.

Denotes components or parts which are subject to

mandatory special waste disposal. Never throw these

components into the regular refuse.

This instruction manual is protected by copyright law.

The copyright owner is EFFEKTA Regeltechnik GmbH.

Trademarks:

All trademarks used are the property of their respective owners.

EFFEKTA®is a registered trademark of EFFEKTA Regeltechnik GmbH.

We reserve the right to make technical and visual changes, and we are not liable for typographical

errors.

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 5 of 37

2 Warranty conditions

The delivery receipt is considered to be the initial proof of purchase and should

be stored carefully. It is required for all warranty claims. If the product is

transferred to another user, then the latter is entitled to claim under the

warranty for the remainder of the warranty period. The purchase receipt,

together with this declaration, should be transferred to the possession of the

new owner.

We guarantee that this equipment is in a functional state and corresponds in

technical terms to the descriptions in the enclosed documentation.

The warranty period for special equipment corresponds to the minimum period

prescribed by legislation.

This warranty is not valid for the following cases:

oDefects due to: damage during transportation, accidents, natural

disasters, misuse, vandalism, inappropriate use, maintenance errors or

incorrect repairs by third parties.

oModifications, unauthorized tampering, incorrect operation, another

device or accessory, incorrect installation, or any modification not

approved by us.

oDisregard for the instructions in the supplied documentation.

oIncompatibility of the product as a result of technical innovations or

regulations which may come into effect after the purchase.

oIncompatibility or malfunction caused by product components not

installed by us.

oSigns associated with the normal ageing process of the product

(wearing parts).

oDefects caused by external appliances.

The warranty period for parts replaced and/or repaired within the scope of this

warranty expires with the original warranty for the product.

Equipment sent in without accessories will be replaced without accessories.

Equipment returned will only be accepted if it is returned in the original

packaging.

Incidental transportation costs are generally excluded from the scope of

services provided under the warranty.

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 6 of 37

EFFEKTA GmbH does not give any express or implied warranties in relation to

this equipment and its quality, performance, merchantability or suitability for a

specific purpose. In some countries, the exclusion of implied warranties is not

permitted by law. In this case, the validity of all express and implied warranties

is restricted to the warranty period. When this period expires, all warranties

cease to be valid. In some countries, a limitation of the validity period of implied

warranties is not permitted by law, in which case the above restriction is not

effective.

2.1 Limitation of liability

Compensation claims are excluded, unless they are based on the deliberate

acts or gross negligence of EFFEKTA GmbH or its employees. The liability

according to the Product Liability Act remains unaffected. Under no

circumstances will we be liable for:

oClaims for losses or damage made by third parties against you.

oLoss or damage of your records or data or the cost of their recovery.

oFinancial consequential damage (including loss of earnings or savings)

or incidental damage, even in the event that we had been informed of

the possibility of such damage.

Under no circumstances whatsoever will EFFEKTA GmbH be held responsible

for any coincidental, indirect, special, consequential or other damage of any

kind (including, without limitation, damage relating to loss of profit,

discontinuation of business, loss of business information or any other loss)

arising from use of the equipment or in any connection with the equipment,

whether based on a contract, compensation, negligence, strict liability, or other

claims, even if EFFEKTA GmbH has been informed in advance about the

possibility of such damage. This exclusion also applies for any liability arising

from claims of third parties made against the initial purchaser.

In some countries, the exclusion or limitation of coincidental or consequential

damage is not legally permitted, in which case the above declaration is not

effective.

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 7 of 37

3 Safety

3.1 General safety instructions

Read and observe the user manual and safety instructions in this chapter before

taking any further action (transportation, storage, connection, startup, etc.).

Since the UPS equipment uses mains voltage and incorporates an appropriate

energy accumulator (high-capacity batteries) either on the inside or outside of

the device, the instructions in this chapter are very important for all users and

personnel. For this reason, safety information on batteries and battery packs is

also provided here. When using external battery packs, you must also follow the

safety instructions in the accompanying manual.

Work on the UPS equipment may only be performed by authorized technical

personnel.

3.2 Transportation and storage

The UPS may only be transported to its destination in the original packaging.

The same applies for removals or returns.

The equipment may not be transported or stored upside down.

Position the equipment securely during transportation taking the centre of

gravity into account. Due to their weight, UPS equipment with built-in batteries

may drop suddenly if their position shifts slightly.

During storage, secure positioning of the equipment must also be ensured.

3.3 Setup

The UPS is intended for use in ventilated rooms.

During setup or installation, the installation location prescribed by the

manufacturer must be observed.

If the UPS is exposed to extreme and rapid temperature changes, there is a

risk of condensation. Before taking any further steps, the equipment should be

allowed to acclimatise for at least 2 hours.

Never set up or operate the equipment in a damp environment.

Keep fluids away from the equipment.

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 8 of 37

The UPS must not be set up near heat sources.

Ensure that the vents of the equipment are not blocked and that the air

circulation is not impeded.

3.4 Connection

Only connect the UPS to an earthed shock-proof socket or, where a terminal

clamp is used, connect the protective earth conductor without fail. Under no

circumstances should the equipment be operated without a protective earth

conductor.

The house installation socket must be easily accessible and located in the

vicinity of the UPS. In the case of a fixed connection, ensure that the shortest

possible cable lengths are used.

If a generator is used to operate the equipment, the correct poling must be

observed when connecting the UPS.

To connect the UPS to the house installation socket, only a VDE-tested and

CE-labelled mains cable may be used. In the case of a fixed connection, a

suitable cable must be used.

To connect the consumer to the UPS, only use VDE-tested and CE-labelled

electrical cables. In the case of a fixed connection to the consumer, a suitable

cable must be used.

The fuse protection for the consumer must always be installed directly in front

of it, and never centrally in front of the UPS.

Do not operate any household appliances and power tools, e.g. fan heaters,

vacuum cleaners, drills, hairdryers, toasters, etc., via the UPS.

Do not connect any consumers to the UPS which could overload the

equipment (e.g. laser printers).

The sum of the earth fault currents of all consumers connected to the UPS

must not exceed 3.5 mA.

Keep the connecting cables as short as possible and always lay these

correctly. Avoid the dangers associated with laying connecting cables where

they may be tripped over, crushed or torn open, etc.

3.5 Operation

The mains power cable must never be disconnected during the operation of

the UPS, otherwise the protective earthing of the UPS as well as the

connected consumers will be lost.

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 9 of 37

The UPS equipment contains an energy accumulator (batteries). This means

that the output of the UPS can be live even if it is not connected on the line

side.

To completely switch off the UPS, first press and hold the "ON/OFF" button for

more than 3 seconds, wait until the UPS switches off and only then disconnect

the equipment from the mains (remove input fuse or disconnect mains supply

cable from the equipment).

Make sure that no fluids or foreign bodies enter the UPS.

3.6 Handling batteries

Warning – danger of electric shocks and burns.

Batteries can cause electric shocks and are capable of producing high short-

circuit currents which can also inflict burns.

Unauthorized persons must be kept away from batteries.

Do not place batteries against heat sources and do not throw them into a fire.

They might explode!

Do not open or destroy batteries. The electrolyte released is extremely

dangerous to people and the environment (danger of chemical burning to skin

and eyes, toxic).

Defective batteries must be disposed of in an environmentally-friendly manner.

Never throw batteries into the household refuse.

The local waste disposal regulations must be observed.

3.7 Maintenance, servicing and faults

Warning – danger of electric shocks.

The UPS remains connected to the battery circuit even after it has been

disconnected from the mains power supply, and has a dangerous voltage

potential. Therefore always disconnect the battery circuit before carrying out

servicing or maintenance work and make sure that the equipment has been

disconnected from the supply.

Work on batteries may only be performed and monitored by personnel with

appropriate technical knowledge about the required precautions.

Unauthorized persons must be kept away from batteries.

When working on the UPS, the following precautions must be taken:

UPS RMH700/1000/1500 Instruction Manual

RMH Series Page 10 of 37

oRemove wristwatches, rings and other metallic objects

oOnly use electrically-insulated tools

The UPS must not be dismantled.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Effekta UPS

Effekta

Effekta USV MTX Series Manuel utilisateur

Effekta

Effekta MTD-XL Manuel utilisateur

Effekta

Effekta THOR II T50 Manuel utilisateur

Effekta

Effekta TRITON M3 Manuel utilisateur

Effekta

Effekta MKD 6 kVA RT Manuel utilisateur

Effekta

Effekta TRITON PF1 Manuel utilisateur

Effekta

Effekta PEGASUS II 10 KVA Manuel utilisateur

Effekta

Effekta MT 3200 Manuel utilisateur

Effekta

Effekta ME 400 Manuel utilisateur

Effekta

Effekta ACX11CIS70000000 Manuel utilisateur

Effekta

Effekta MKD 700 RT XL Manuel utilisateur

Effekta

Effekta MKD 700 XL Manuel utilisateur

Effekta

Effekta ACX11OFS40000000 Manuel utilisateur

Effekta

Effekta ADIRA T Manuel utilisateur

Effekta

Effekta ME 1000 Manuel utilisateur

Effekta

Effekta Triton Series Manuel utilisateur

Effekta

Effekta THOR RM Manuel utilisateur

Effekta

Effekta MKD 700 Manuel utilisateur

Effekta

Effekta MTD 2000 Manuel utilisateur

Effekta

Effekta THOR 31 Manuel utilisateur

Effekta

Effekta MI-Series Manuel de la liste des pièces

Effekta

Effekta MH6000 Manuel utilisateur

Effekta

Effekta ADIRA Series Manuel utilisateur

Effekta

Effekta ACX11MKR2K000000 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
