Edge-Core AS4600-54T Manuel utilisateur

Installation Guide

www.edge-core.com.au

AS4600-54T

48 GE port with 4*10G SFP+

with 2 Expansion Slots

Data Center Switch

Installation Guide

AS4600-54T

48 GE port with 4*10G SFP+ with 2 Expansion Slots Data Center Switch

with 48 10/100/1000BASE-T (RJ-45) Ports,

4 10GBASE SFP+ Ports,

2 Slots for Optional Single-Port 40GBASE QSFP+ Modules

2 Power Supply Units,

and 2 Fan Trays (F2B or B2F Airflow)

AS4600-54T

E122013-AP-R01

150200000566A

– 3 –

How to Use This Guide

This guide includes detailed information on the switch hardware, including

network ports, power, cabling requirements, as well as plug-in modules and

transceivers. This guide also provides general installation guidelines and

recommended procedures. To deploy this switch effectively and ensure trouble-

free operation, you should first read the relevant sections in this guide so that you

are familiar with all its hardware components.

Who Should Read This

Guide?

This guide is for network administrators and support personnel that install, operate,

and maintain network equipment. The guide assumes a basic working knowledge

of LANs (Local Area Networks) and can be read by those that are new to network

equipment, or those with more experience.

How This Guide is

Organized

The organization of this guide is based on the switch’s main hardware components.

Each chapter includes information about a specific component with relevant

specifications and installation procedures. A switch overview section is also

provided.

For Users New to Switches

—If you are new to network switches, it is

recommended that you first read all chapters in this guide before installing the

switch.

For Experienced Users

—If you are already familiar with installing and operating

network switches, the Switch Description and Installation Overview chapters

provide you with enough information to install the switch. Other chapters can be

left for reference, when needed.

The guide includes these chapters:

◆Chapter 1 - Switch Description—Includes a switch overview, key component

identification, key technical specifications, and switch deployment information.

◆Chapter 2 - Installation Overview—Includes details of the package contents

and an outline of switch installation tasks.

◆Chapter 3 - Switch Chassis—Includes switch chassis rack installaion, and system

cooling requirements.

◆Chapter 4 - Power and Grounding—Includes information on AC power supply

unit installation, switch grounding, and powering on the switch.

How to Use This Guide

– 4 –

◆Chapter 5 - Port Connections—Includes information on network interfaces,

installing optional transceivers, and cabling specifications.

◆Chapter 6 - Switch Management—Connecting to the switch for management,

and information on the system status LEDs.

◆Appendix A - Troubleshooting—Information for troubleshooting switch

installation and operation.

Documentation

This guide focuses on switch hardware and installation, it does not cover software

configuration of the switch. For specific information on how to operate and use the

management functions of the switch, see the following guides:

CLI Command Reference

Administrator’s Guide

For all safety information and regulatory statements, see the following document:

Quick Start Guide

Safety and Regulatory Information

Conventions The following conventions are used throughout this guide to show information:

Note:

Emphasizes important information or calls your attention to related features

or instructions.

Caution:

Alerts you to a potential hazard that could cause loss of data, or damage

the system or equipment.

Warning:

Alerts you to a potential hazard that could cause personal injury.

Revision History This section summarizes the changes in each revision of this guide.

December 2013 Revision

This is the first revision of this guide.

– 5 –

Contents

How to Use This Guide 3

Contents 5

Figures 7

Tables 9

1 Switch Description 10

Overview 10

Key Hardware Components 11

Key Technical Specifications 13

Data Center Deployment 14

Rack Cooling 15

2 Installation Overview 17

Package Contents 17

Switch Installation Tasks 17

3 Switch Chassis 24

General Installation Guidelines 24

How to Install the Switch in a Rack 25

Rack-Mounting Items 25

Rack-Mount Procedure 25

Switch Cooling Requirements 27

Rack Cooling 28

Fan Trays 28

How to Replace a Fan Tray 29

Optional Expansion Module 30

How to Install an Optional Expansion Module 30

4 Power and Grounding 32

Power Supply Units 32

Contents

– 6 –

Grounding the Chassis 34

How to Connect to AC Power 35

5 Port Connections 37

Cable Labeling and Connection Records 38

Understanding the Port Status LEDs 39

How to Install an SFP/SFP+/QSFP+ Transceiver 40

How to Connect to Twisted-Pair Copper Ports 41

Copper Cabling Guidelines 42

10/100BASE-TX Pin Assignments 42

1000BASE-T Pin Assignments 43

Connection Procedure 44

How to Connect to SFP/SFP+ Fiber Optic Ports 44

Connection Procedure 45

How to Connect to QSFP+ Fiber Optic Ports 47

Connection Procedure 47

DAC Connections 49

Making DAC Connections 49

6 Switch Management 51

Understanding the System Status LEDs 52

How to Connect to the Console Port 53

How to Connect to the Mgmt Port 55

A Troubleshooting 56

Diagnosing LED Indicators 56

System Self-Diagnostic Test Failure 56

Power and Cooling Problems 57

Installation 57

In-Band Access 57

Index 58

– 7 –

Figures

Figure 1: Front Panel 11

Figure 2: Rear Panel 12

Figure 3: Cloud Data Center Deployment 14

Figure 4: Converged Ethernet Data Center Deployment 15

Figure 5: F2B Airflow Cooling 16

Figure 6: B2F Airflow Cooling 16

Figure 7: Installing the Switch in a Rack 18

Figure 8: Grounding Terminal 19

Figure 9: Connecting AC Power 20

Figure 10: System LEDs 21

Figure 11: Console Port 21

Figure 12: Making a Connection to an SFP+ Port 22

Figure 13: Making a Connection to an QSFP+ Port 23

Figure 14: Attaching the Brackets 26

Figure 15: Installing the Switch in a Rack 26

Figure 16: Switch Cooling 27

Figure 17: Fan Tray 29

Figure 18: Expansion Modules 30

Figure 19: Installing an Optional Module 31

Figure 20: AC Power Supply Unit 33

Figure 21: Grounding Terminal 34

Figure 22: AC PSU and Power Socket 35

Figure 23: Port Status LEDs 39

Figure 24: RJ-45 Connector 42

Figure 25: Making Twisted-Pair Connections 44

Figure 26: Making Connections to an SFP+ Transceiver 46

Figure 27: Connecting to a QSFP+ Transceiver 48

Figure 28: Making DAC Connections (10G) 50

Figure 29: Making DAC Connections (40G) 50

Figures

– 8 –

Figure 30: System Status LEDs 52

Figure 31: Console Port 53

Figure 32: Console Port Connection 54

Figure 33: Management Port 55

– 9 –

Tables

Table 1: Key Technical Specifications 13

Table 2: AC Power Supply Unit Specifications 33

Table 3: Power Supply Unit LED 33

Table 4: Port Status LEDs 39

Table 5: Maximum Twisted-Pair Copper Cable Lengths 41

Table 6: 10/100BASE-TX MDI and MDI-X Port Pinouts 43

Table 7: 1000BASE-T MDI and MDI-X Port Pinouts 43

Table 8: Maximum 10 Gigabit Ethernet Fiber Cable Lengths 44

Table 9: Maximum Gigabit Ethernet Fiber Cable Lengths 45

Table 10: Maximum 40 Gigabit Ethernet Fiber Cable Lengths 47

Table 11: Maximum 10GBASE-CR 10 Gigabit Ethernet Cable Lengths 49

Table 12: Maximum 40GBASE-CR4 40 Gigabit Ethernet Cable Lengths 49

Table 13: System Status LEDs 52

Table 14: Console Cable Wiring 53

Table 15: Troubleshooting Chart 56

– 10 –

1Switch Description

This chapter includes these sections:

◆“Overview” on page 10

◆“Key Technical Specifications” on page 13

◆“Data Center Deployment” on page 14

Overview

Thank you for choosing the AS4600-54T switch system. This switch is built with

leading-edge technology to deliver reliable high-performance connectivity for

your data network.

The AS4600-54T switch is a high-performance top-of-rack switch, designed for data

center operating environments. The switch provides 48 10/100/1000BASE-T RJ-45

ports, four 10 Gigabit Small Form Factor Pluggable Plus (SFP+) ports, and two

expansion slots for optional single-port 40G Quad-SFP+ (QSFP+) modules. The

switch can also be configured with two hot-swappable power supply units (PSUs)

that operate in a dual load-sharing mode.

The switch supports a full set of Layer 2 switching, data center bridging, and Layer 3

routing features. The switch can be deployed as a top-of-rack (TOR) or distributed

spine switch to form a network fabric that can reduce infrastructure expenses and

power consumption in the data center. This network fabric can be used to

interconnect tens of thousands of servers delivering cloud computing services.

The switch further offers an option of front-to-back (F2B) or back-to-front (B2F)

airflow cooling for rack deployment with either blade servers or other switches,

allowing cool aisles to be maintained without creating “hot loops.”
