Carton Contents

1 Ecotric ebike 1 lithium-ion battery

1 battery charger 1 kit box

2 pedals 1 saddle

2 keys 1 toolkit

2 reflectors 1 manual

Ecotric Electric Bikes

First, we would like to thank you for choosing the Ecotric electric bike purchased from Ebikes-

Canada.com. We believe this technology, with the benefits of electric power drive, will provide you with

the perfect vehicle to increase your personal mobility.

The brushless electric hub motor on your bike will allow you to run errands or commute to work while

saving money on gasoline and reducing your environmental impact on our world. Your ebike will also

give you the opportunity to pedal if you want to get exercise along the way. You can explore further,

climb hills with ease and see more of the world. All of this and it's just plain fun to ride!

If you have any concerns, questions, or suggestions about your Ecotric electric bike, please contact us

through our contact fort at Ebikes-Canada.com, we will always do our best to serve you. Again, thank

you for choosing Ecotric and Ebikes-Canada.com.

PLEASE NOTE: This manual is not intended as a detailed user, service, repair or maintenance manual.

Please seek assistance from a qualified technician for service repairs or maintenance.

Warning

Electric bikes can be dangerous to use. The user or consumer assumes all risks of personal injuries,

damage, or failure of the bicycle or system and all other losses or damages to themselves and others,

and to any property arising as a result of using the bicycle. It is after all an electric vehicle.

As with all mechanical components, the bicycle is subjected to wear and high stresses. Different

materials and components may react to wear or stress fatigue in different ways. If the design life of the

component has been exceeded, it may suddenly fail possibly causing injuries to the rider. Any form of

crack, scratches or change of colouring in highly stressed areas indicate that the life of the component

has been reached and it should be replaced. For replacement parts, technical information, and warranty

assistance, please feel free to contact us.

PLEASE NOTE: Your insurance policies may not provide coverage for accidents involving the use of this

ebike. To determine if coverage is provided, you should contact your insurance provider company or

agent.

DO NOT DISASSEMBLE, MODIFY

OR REPLACE ELECTRICAL PARTS

Assembly Instructions

Front Wheel Installation

CAUTION: Your electric bike is equipped with a front disc brake. Be careful not to damage the disc,

caliper or brake pads when reinserting the disc into the caliper. Never activate a disc brakes control

lever unless the disc is correctly inserted into the caliper.

1. Carefully take your bike out of the carton and gently rest it in place with the kickstand down as

in Figure 1.1

2. Remove all of the inside cardboard protection and bubble wrap on the ebike

3. Locate and set aside the kit box containing the battery charger pedals, tool kit, etc.

4. Remove the rubber pad and metal block from the front wheel and front fork (Figure 1.2)

5. The fork is curved, please make sure the concave of the fork is facing forward (Figure 1.3)

6. With the steering fork facing forward, insert the front wheel between the fork blades so that the

axle seats firmly at the top of the fork dropouts (Figure 1.4)

7. Push the wheel firmly to the top of the slots in the fork dropouts, and at the same time centring

the wheel rim in the fork

8. With a cam action system, move the cam lever upwards and swing it into the closed position

(Figure 1.5). The lever should now be parallel to the fork blade and curved toward the front

wheel. To apply enough clamping force, you should have to wrap your fingers around the fork

blade for leverage, and the lever should leave a clear imprint in the palm of your hand

PLEASE NOTE: If on a traditional camp action system, the lever cannot be pushed all the way to a

position parallel to the fork blade, return the lever to the open position. Turn the tension adjusting nut

counter-clockwise one-quarter turn and try tightening the lever again.

WARNING: Securely clamping the wheel with a cam action retention device takes considerable force. If

you can fully close the cam lever without wrapping your fingers around the fork blade for leverage, and

the lever does not leave a clear imprint in the palm of your hand, and the serrations on the wheel

fastener does not emboss the surfaces of the dropouts, the tension is insufficient. Open the lever; turn

the tension adjusting nut clockwise one-quarter turn and try again. Spin the wheel to make sure that it is

centred in the frame and clears the brake pads, then squeeze the brake lever and make sure that the

brakes are operating correctly.

Handlebar, Display and Front Reflector Installation

1. Loosen the bolt on top of the stem, then rotate the stem through 90 degrees (Figure 2.1).

2. Unscrew the four screws in front of the stem with a 5 mm hexagonal spanner, place the

handlebar on the stem, tighten the four screws slightly, and position the handlebar to your

desired comfort level, then tighten the four bolts in turn until fully tightened (Figure 2.2).

PLEASE NOTE: Before installing the handlebar, please pay attention to the wire harness that connects

to it. Make sure that the wire harness is are not twined together (Figure 2.3).

3. Once the handlebars are aligned and the top bolt is slightly secured, tighten the two side bolts

on the stem with a 6 mm hexagonal spanner firmly (Figure 2.4). After tightening the two side

bolts, tighten the top bolt with 5 mm hexagonal spanner firmly (Figure 2.5). After all three bolts

have been securely fastened, make sure there is no play in the headset.

4. Unscrew the two screws on the display, then install the display on the centre of the handlebar

(Figure 2.6).

5. Unscrew the bolt on the front of the fork, then install the front reflector.

Installation instructions can be found on YouTube at www.youtube.com/watch?v=AdTEu5iVJZA

WARNING: Do not overtighten the stem bolt. Overtightening the stem bolt can damage the steering

system and cause loss of control.

Seat Post Installation

1. Please pay attention to the vertical lines on the seat post, it is the minimum insert line or safety

line, please make sure the post is installed into the frame deeper than the minimum insertion

line. It is at the bottom of the seat post (Figure 3.1).

2. Unclamp the clamp on the seat tube, insert the seat post into the seat tube, adjusting the seat

to a comfortable height, tighten the tension adjusting nut, then press the clamp lever inwards

toward the seat tube (Figure 3.2).

PLEASE NOTE: If necessary, tighten the clamp by twisting the clamp handle clockwise while in the

unclamped position. Then, fold the handle in toward the seat post. This should require a fair amount of

force to ensure the seat post is held tightly. If necessary, the clamp can be further tightened with a

5 mm Allen wrench while in the clamped position.

Pedals Installation

1. Identify left versus right pedal

There is a letter L or R stamped into the axle (threaded part that looks like a screw) as in

Figure 4.1. There may also be labels on the pedals themselves. Please note they are not the

same. Apply a small amount of white grease if possible.

2. Install the left side pedal first

You will have to screw it in counter-clockwise because the threading is the reverse of a normal

screw. Do this by slowly pedalling the crank backwards. If the pedal feels stiff, stop and then

retry. It should feel like a smooth motion. Do not use a wrench until you are ready to tighten it

for the final few turns. Tighten it down until you can’t anymore (Figure 4.2).

PLEASE NOTE: Hand tightened is not sufficient. Use a wrench. Please ensure that your pedals are

properly tightened before your first ride. If after riding, the threads on your crank are stripped. You have

not followed these instructions. Your crank needs to be replaced and this would not be covered by the

warranty.

3. Install the right-side pedal

This pedal threads in clockwise, like a normal screw. Follow the same principle as discussed in

Step 2 for the left pedal (Figure 4.3).

4. Wipe off any excess grease from around the crank.

Torque Specification Table

Item

N.m

Handlebars

18 N.m (Trail Tracker 12 N.m)

Handlebar stem

12 N.m (Trail Tracker 8 N.m)

Seat post

Quick release

Seat

18 N.m

Front wheel

18 N.m (if applicable)

Rear wheel

30 N.m or above
