Please use the parameters provided by your internet service provider (ISP) for
configuration. If the configuration is wrong, you will not be able to access the
Internet.
Using the Embedded PPP Dial-Up Software of the
HG520b to Get Online
Step 1 Configure the HG520b to enable the embedded dial-up function
1. Connect the HG520b with your computer by using the Ethernet cable.
2. Configure the IP address of your computer to be in the same network
segment as the HG520b. The default LAN IP address and subnet mask of
the HG520b is 192.168.1.1 and 255.255.255.0.
3. Start Internet Explorer on your computer and enter the Web address of the
HG520b in the address bar. The default address is http://192.168.1.1.
4. Enter the username and password in the displayed window.
5. Select Basic > WAN Setting from the navigation tree to display the
configuration page.
6. Set Mode to Routing.
7. Select PPPoE and configure the other parameters. Then click Submit.
Step 2 Configure your computer
Configure your network card (also called as network adapter) to make the computer to
automatically obtain information, such as the IP address, the gateway, and DNS.
If the embedded dial-up function of the HG520b is enabled, you need to
power off the HG520b when you do not want to access the Internet.
Otherwise, the ISP may calculate the fee for accessing the Internet even if you
have powered off your computer.
Using the PPP Dial-Up Software of the Computer to Get
Online
Step 1 Configure the HG520b to work in the bridge mode
Refer to steps for enabling the embedded dial-up function to configure the bridge mode.
The only difference is to select the Bridge mode not the Routing mode.
Step 2 Configure your computer
The PPP dial-up software is installed in your computer, and then you can get online.
