E10-915MS30 User Manual

SI4463 915MHz 1W SMD Wireless Module

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

Contents

Disclaimer.............................................................................................................................................................................. 2

1 Overview............................................................................................................................................................................. 3

1.1 Brief introduction........................................................................................................................................................... 3

1.2 Features.....................................................................................................................................................................3

1.3 Application................................................................................................................................................................3

2 Specification and parameter............................................................................................................................................. 4

2.1 Limit parameter.........................................................................................................................................................4

2.2 Operating parameter................................................................................................................................................. 4

3 Size and pin definition....................................................................................................................................................... 5

4. Basic operation..................................................................................................................................................................6

4.1 Hardware design....................................................................................................................................................... 6

4.2 Software editing........................................................................................................................................................7

5 Basic application..........................................................................................................................................................8

5.1 Basic circuit diagram................................................................................................................................................ 8

6 FAQ..................................................................................................................................................................................... 8

6.1 Communication range is too short............................................................................................................................ 8

6.2 Module is easy to damage.........................................................................................................................................9

6.3 BER(Bit Error Rate) is high...................................................................................................................................9

7 Production guidance.......................................................................................................................................................... 9

7.1 Reflow soldering temperature...................................................................................................................................9

7.2 Reflow soldering curve...........................................................................................................................................10

8 E10 Series..........................................................................................................................................................................10

9 Antenna guidance............................................................................................................................................................ 11

9.1 Antenna recommendation....................................................................................................................................... 11

9.2 Antenna selection....................................................................................................................................................11

Revision history...................................................................................................................................................................11

About us............................................................................................................................................................................... 12

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

Disclaimer

EBYTE reserves all rights to this document and the information contained herein.

Products, names, logos and designs described herein may in whole or in part be

subject to intellectual property rights. Reproduction, use, modification or disclosure to

third parties of this document or any part thereof without the express permission of

EBYTE is strictly prohibited.

The information contained herein is provided “as is” and EBYTE assumes no

liability for the use of the information. No warranty, either express or implied, is given,

including but not limited, with respect to the accuracy, correctness, reliability and

fitness for a particular purpose of the information. This document may be revised by

EBYTE at any time. For most recent documents, visit www.ebyte.com.

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

1 Overview

1.1 Brief introduction

E10-915MS30 is 1W SMD wireless module working at

915MHz, developed based on chip SI4463 from Silicon Labs.

Due to the use of the imported Si4463 as the core of the

module, with PA and LNA its sensitivity and stability are largely

improved when tx power is 1W. The module is aimed at smart

home, wireless meter reading, scientific research and medical,

and medium and long distance wireless communication

equipment. Since RF performance and component selection are in accordance with industrial standards, and the product

has obtained FCC, CE, RoHs and other international authoritative certification reports, users do not need to worry about

its performance. With its stable and reliable characteristics, it is favored by the majority of users. Compared with the old

products, it has made great progress in receiving current, receiving sensitivity, transmitting power, receiving rate range

and anti-interference ability. High precision 26MHz crystal is used.

Since the module is a pure RF transceiver module, you need to use the MCU driver or a dedicated SPI debug tool.

1.2 Features

Communication distance tested is up to 6km

Maximum transmission power of 1W, software multi-level adjustable；

Support the global license-free ISM 915MHz band；

Support air date rate of 1.2kbps～1000kbps；

Support multiple modulation methods, (G)FSK, 4(G)FSK, (G)MSK，OOK ；

Support 64/128 byte Transceiver Data Register (FIFO)

Support 2.5V~5.5V power supply, power supply over 5.0 V can guarantee the best performance；

Industrial grade standard design, support -40 ~ 85 °C for working over a long time；

IPEX and stamp hole optional, good for secondary development and integration.

1.3 Application

Home security alarm and remote keyless entry；

Smart home and industrial sensors；

Wireless alarm security system；

Building automation solutions；

Wireless industrial-grade remote control；

Health care products；

Advanced Meter Reading Architecture(AMI)；

Automotive industry applications.

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

2 Specification and parameter

2.1 Limit parameter

Main parameter

Performance

Remark

Min.

Max.

Power supply（V）

5.5

Voltage over 5.5V will cause permanent

damage to module

Blocking power（dBm）

Chances of burn is slim when modules are

used in short distance

Operating temperature（℃）

-40

2.2 Operating parameter

Main parameter

Performance

Remark

Min.

Typ.

Max.

Operating voltage（V）

4.8

5.0

5.5

≥5.0 V ensures output power

Communication level（V）

3.3

For 5V TTL, it may be at risk of burning

down

Operating temperature（℃）

-40

Industrial design

Operating frequency（MHz）

900

915

925.5

Support ISM band

Power

consumpti

TX current（mA）

753

Instant power consumption

RX current（mA）

Sleep current （μA）

5.0

Software is shut down

Max Tx power（dBm）

Receiving sensitivity（dBm）

-121

-122

-124

Air data rate is 1kbps

Air data rate（bps）

0.123k

Controlled via user’s programming

Main parameter

Description

Remark

Distance for reference

6000m

Test condition：clear and open area, antenna gain: 5dBi，

antenna height: 2.5m，air data rate: 1kbps

FIFO

64Byte

Max length transmitted each time

Crystal frequency

26MHz

Modulation

GFSK(recommended)

(G)FSK, 4(G)FSK, (G)MSK，OOK

Package

SMD

Connector

2.54mm

Communication interface

SPI

0-10Mbps

Size

25*40 mm

Antenna

IPEX/stamp hole

50 ohm impedance

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

3 Size and pin definition

Pin No.

Pin item

direction

Pin application

GND

Ground, connecting to power supply reference ground

SDN

Input

Module operation enabling control pin, low level in operation (refer to

SI4463 Datasheet for details)

GPIO3

Output

Connecting to the internal RF switch transmission, can be

disconnected, controlled by SI4463 intelligently

GPIO2

Output

Connecting to the internal RF switch receiving, can be disconnected,

controlled by SI4463 intelligently

CSN

Input

Module chip selection pin, used to start a SPI communication

MOSI

Input

Module SPI data input pin

MISO

Output

Module SPI data output pin

GND

Ground, connecting to power supply reference ground

SCK

Output

Module SPI clock pin

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

IRQ

Output

Module interrupt pin

GPIO1

Output

Module data output pin (refer to SI4463 datasheet)

GPIO0

Output

Module data output pin (refer to SI4463 datasheet)

VCC

Power supply must be 5.0 ~ 5.5V DC (voltage higher than 6V is

forbidden)

GND

Ground, connecting to power supply reference ground

GND

Ground, connecting to power supply reference ground

GND

Ground, connecting to power supply reference ground

GND

Ground, connecting to power supply reference ground

GND

Ground, connecting to power supply reference ground

GND

Ground, antenna port reference ground

ANT

Output

Antenna

4. Basic operation

4.1 Hardware design

It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible, and

the module needs to be reliably grounded.；

Please pay attention to the correct connection of the positive and negative poles of the power supply. Reverse

connection may cause permanent damage to the module；

Please check the power supply to ensure it is within the recommended voltage otherwise when it exceeds the

maximum value the module will be permanently damaged；

Please check the stability of the power supply, the voltage can not be fluctuated frequently；

When designing the power supply circuit for the module, it is often recommended to reserve more than 30% of the

margin, so the whole machine is beneficial for long-term stable operation.；

The module should be as far away as possible from the power supply, transformers, high-frequency wiring and other

parts with large electromagnetic interference.；

High-frequency digital routing, high-frequency analog routing, and power routing must be avoided under the

module. If it is necessary to pass through the module, assume that the module is soldered to the Top Layer, and the

copper is spread on the Top Layer of the module contact part(well grounded), it must be close to the digital part of

the module and routed in the Bottom Layer；

Assuming the module is soldered or placed over the Top Layer, it is wrong to randomly route over the Bottom Layer

or other layers, which will affect the module's spurs and receiving sensitivity to varying degrees；

It is assumed that there are devices with large electromagnetic interference around the module that will greatly

affect the performance. It is recommended to keep them away from the module according to the strength of the

interference. If necessary, appropriate isolation and shielding can be done；

Assume that there are traces with large electromagnetic interference (high-frequency digital, high-frequency analog,

power traces) around the module that will greatly affect the performance of the module. It is recommended to stay

away from the module according to the strength of the interference.If necessary, appropriate isolation and shielding

can be done.

If the communication line uses a 5V level, a 1k-5.1k resistor must be connected in series (not recommended, there is

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

still a risk of damage)；

Try to stay away from some physical layers such as TTL protocol at 2.4GHz , for example: USB3.0；

The mounting structure of antenna has a great influence on the performance of the module. It is necessary to ensure

that the antenna is exposed, preferably vertically upward. When the module is mounted inside the case, use a good

antenna extension cable to extend the antenna to the outside；

The antenna must not be installed inside the metal case, which will cause the transmission distance to be greatly

weakened.

4.2 Software editing

Si4463+PA+LNA，same drive way as SI4463，user can refer to SI4463 datasheet.

GPIO0 \ GPIO1 \ GPIO2 \ GPIO3 are configurable I/O ports for various application，see more in SI4463 datasheet.It can be

floated when not used.

IRQ pin can also be disconnected. The SPI query mode can be used to obtain the interrupt status. However, it is recommended to

use the external interrupt of the MCU.

SPI communication rate should not be set too high, usually around 1Mbps.

Please refer to “Operating Modes and Timing” for SI4463 status switch ，the switch between TX and RX should be through

Ready, can not be switched directly.

Re-initialize register configuration when the chip is idle for higher stability.

For controlling GPIO2 ,GPIO3 externally，pin status is as follows：

In tx mode：GPIO2 = 0; GPIO3 = 1;

In rx mode：GPIO2 = 1; GPIO3 = 0;

If the SI4463 is required to control itself, the mode of the configuration pins can be as follows when the program

is initialized:

SI44XX_GPIO_CONFIG( 0, 0, 32|0x40, 33|0x40, 0, 0, 0 );

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

5 Basic application

5.1 Basic circuit diagram

6 FAQ

6.1 Communication range is too short

The communication distance will be affected when obstacle exists.

Data lose rate will be affected by temperature, humidity and co-channel interference.

The ground will absorb and reflect wireless radio wave, so the performance will be poor when testing near ground.

Sea water has great ability in absorbing wireless radio wave, so performance will be poor when testing near the sea.

The signal will be affected when the antenna is near metal object or put in a metal case.

Power register was set incorrectly, air data rate is set as too high (the higher the air data rate, the shorter the

distance).

The power supply low voltage under room temperature is lower than 2.5V, the lower the voltage, the lower the

Chengdu Ebyte Electronic Technology Co., Ltd. E10-915MS30 User Manual

transmitting power.

Due to antenna quality or poor matching between antenna and module.

6.2 Module is easy to damage

Please check the power supply source, ensure it is 2.0V~3.6V, voltage higher than 3.6V will damage the module.

Please check the stability of power source, the voltage cannot fluctuate too much.

Please make sure antistatic measure are taken when installing and using, high frequency devices have electrostatic

susceptibility.

Please ensure the humidity is within limited range, some parts are sensitive to humidity.

Please avoid using modules under too high or too low temperature.

6.3 BER(Bit Error Rate) is high

There are co-channel signal interference nearby, please be away from interference sources or modify frequency and

channel to avoid interference;

Poor power supply may cause messy code. Make sure that the power supply is reliable.

The extension line and feeder quality are poor or too long, so the bit error rate is high;

7 Production guidance

7.1 Reflow soldering temperature

Profile Feature

Curve characteristics

Sn-Pb Assembly

Pb-Free Assembly

Solder Paste

Solder paste

Sn63/Pb37

Sn96.5/Ag3/Cu0.5

Preheat Temperature min （Tsmin）

Min preheating temp.

100℃

150℃

Preheat temperature max (Tsmax)

Mx preheating temp.

150℃

200℃

Preheat Time (Tsmin to Tsmax)(ts)

Preheating time

60-120 sec

Average ramp-up rate(Tsmax to Tp)

Average ramp-up rate

3℃/second max

Liquidous Temperature (TL)

Liquid phase temp.

183℃

217℃

Time（tL）Maintained Above（TL）

Time below liquid phase line

60-90 sec

30-90 sec

Peak temperature（Tp）

Peak temp.

220-235℃

230-250℃

Aveage ramp-down rate（Tp to Tsmax）

Aveage ramp-down rate

6℃/second max

Time 25℃ to peak temperature

Time to peak temperature for

25℃

max 6 minutes

max 8 minutes

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ebyte Module sans fil

Ebyte

Ebyte E220-400T30S Manuel utilisateur

Ebyte

Ebyte E70-915NW14S Manuel utilisateur

Ebyte

Ebyte E49-400T30S Manuel utilisateur

Ebyte

Ebyte E70-900T14S Manuel utilisateur

Ebyte

Ebyte E22-900T22S1C Manuel utilisateur

Ebyte

Ebyte E28-2G4M12S Manuel utilisateur

Ebyte

Ebyte E840-TTL-GPRS03 Manuel utilisateur

Ebyte

Ebyte E104-BT54S Manuel utilisateur

Ebyte

Ebyte E10-433MS Manuel utilisateur

Ebyte

Ebyte E610-433T S Series Manuel utilisateur

Ebyte

Ebyte E49-900T20S Manuel utilisateur

Ebyte

Ebyte E01-ML01D Manuel utilisateur

Ebyte

Ebyte E32-170T30D Manuel utilisateur

Ebyte

Ebyte E103-W11 Manuel utilisateur

Ebyte

Ebyte E07-400T10S Manuel utilisateur

Ebyte

Ebyte E22-900T30S1C Manuel utilisateur

Ebyte

Ebyte E10-433MD-SMA Manuel utilisateur

Ebyte

Ebyte E73-2GM08S1C Manuel utilisateur

Ebyte

Ebyte CC2541 Manuel utilisateur

Ebyte

Ebyte E73-2G4M04S1F Manuel utilisateur

Ebyte

Ebyte E62-433T20S Manuel utilisateur

Ebyte

Ebyte E70-433T30S Manuel utilisateur

Ebyte

Ebyte E32(915T30S) Manuel utilisateur

Ebyte

Ebyte E22 Series Manuel utilisateur

Manuels Module sans fil populaires d'autres marques

Laird

Laird RM024 Manuel utilisateur

Laird

Laird BT830-SA Guide de configuration rapide

Fibocom

Fibocom FM101-NA-20 Instructions d'installation

Waldmann

Waldmann EnOcean TALK MODUL G2 Manuel utilisateur

Smartech

Smartech LBT-1.DO4 Manuel utilisateur

Cooper Wiring Devices

Cooper Wiring Devices ESPIRE RF RFAPM Manuel utilisateur

Yuga

Yuga CLM920 Manuel utilisateur

Waldmann

Waldmann TALK Bluetooth Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions UC864-G Manuel d'installation

Quectel

Quectel SC690A Series Supplément

Panasonic

Panasonic INDUSTRY PAN9028 Guide de configuration rapide

LongSung Technology

LongSung Technology U9507E Manuel utilisateur

Wistron NeWeb

Wistron NeWeb DNUR-S2 Manuel utilisateur

RF-Star

RF-Star SimpleLink RF-BM-2652P1 CC2652P Manuel utilisateur

CHIEF

CHIEF AVMW Manuel utilisateur

Huawei

Huawei EM701 Manuel utilisateur

SIYI

SIYI FTM30 Manuel utilisateur

RF-Star

RF-Star RF-BM-4055B1L Mode d’emploi
