Ebyte E10-433MD-SMA Manuel utilisateur

E10-433MD-SMA User Manual

SI4463 433MHz 100mW DIP Wireless Module

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual
      Copyright ©2012–2018，Chengdu Ebyte Electronic  Technology Co.,Ltd.

目录
Overview.................................................................................................................................................................................................2
1 Brief introduction ......................................................................................................................................................................2
2 Feature.........................................................................................................................................................................................2
3 Application .................................................................................................................................................................................2
Specification and parameter ................................................................................................................................................................3
1 Limit parameter .........................................................................................................................................................................3
2 Operating para meter .................................................................................................................................................................3
Size and pin definit ion ..........................................................................................................................................................................4
Basic operation .....................................................................................................................................................................................5
1 Hardware design ................................................................................................................................................................5
2 So ftware ed iting ........................................................................................................................................................................5
Basic application .........................................................................................................................................................................6
1 Basic circuit diagram................................................................................................................................................................6
FA Q..........................................................................................................................................................................................................6
1 Communication range is too short .........................................................................................................................................6
2 Module is easy to damage........................................................................................................................................................7
3    BER(Bit Error Rate) is high .................................................................................................................................................7
Production guidance..............................................................................................................................................................................7
1 Reflow soldering temperature .................................................................................................................................................7
2 Reflow soldering curve ............................................................................................................................................................8
E10 Series ...............................................................................................................................................................................................8
Antenna guidance ..................................................................................................................................................................................9
1 Antenna recommendation ........................................................................................................................................................9
Package method for bulk order ...................................................................................................................................................... 10
Revision history ..................................................................................................................................................................................... 11
About us .................................................................................................................................................................................................. 11



Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

1 Overview

1.1 Brief introduction

E10-433MD-SMA is DIP wireless module working at

433MHz developed based on chip SI4463 from Silicon Labs.

Due to the use of the imported Si4463 as the core of the

module, its stability has been well received by users, and

compatibility is not a concern. The module is aimed at smart

home, wireless meter reading, scientific research and medical,

and medium and long distance wireless communicatio n

equipment. Since RF performance and component selection are in accordance with industrial standards, and the product

has obtained FCC, CE, RoHs and other international authoritative certification reports, users do not need to worry about

its performance. With its stable and reliable characteristics, it is favored by the majority of users. Compared with the old

products, it has made great progress in receiving current, receiving sensitivity, transmitting power, receiving rate range an d

anti-interference ability. High precision 26MHz crystal is used.

Since the module is a pure RF transceiver module, you need to use the MCU driver or a dedicated SPI debug tool.

1.2 Feature

Communication distance tested is up to 2km

Maximum transmission power of 100mW, software multi-level adjustable；

Support the global license-free ISM 433MHz band；

Support air date rate of 1.2kbps～1000kbps；

Support multiple modulation methods, (G)FSK, 4(G)FSK, (G)MSK，OOK ；

Support 64/128 byte Transceiver Data Register (FIFO);

Support 2.5V~3.6V power supply, power supply over 3.3 V can guarantee the best performance；

Industrial grade standard design, support -40 ~ 85 °C for working over a long time；

SMA connector, good for connecting external antenna.

1.3 Application

Home security alarm and remote keyless entry；

Smart home and industrial sensors；

Wireless alarm security system；

Building automation solutions；

Wireless industrial-grade remote control；

Health care products；

Advanced Meter Reading Architecture(AMI)；

Automotive industry applications .

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

2 Specification and parameter

2.1 Limit parameter

Main parameter

Performance

Remark

Min.

Max.

Power supply（V）

3.6

Voltage over 3.6V will cause permanent

damage to module

Blocking power（dBm）

Chances of burn is slim when modules are

used in short distance

Operatingtemperature（℃）

-40

2.2 Operating parameter

Main parameter

Performance

Remark

Min.

Typ.

Max.

Operatingvoltage（V）

1.8

3.3

3.6

≥3.3 V ensures output power

Communication level（V）

3.3

For 5V TTL,it may be at risk of burning

down

Operatingtemperature（℃）

-40

Industrial design

Operatingfrequency（MHz）

425

433

525

Support ISM band

Power

consumpti

TX current（mA）

Instant powerconsumption

RX current（mA）

Sleep current （μA）

0.6

Software is shut down

MaxTxpower（dBm）

Receiving sensitivity（dBm）

-124

-126

-128

Air data rate is 1kbps

Air data rate（bps）

0.123k

Controlled via user’s programming

Main parameter

Description

Remark

Distance for reference

2000m

Test condition：clear and open area, antenna gain: 5dBi，antenna

height: 2.5m，air data rate: 1kbps

FIFO

64Byte

Maxlength transmittedeach time

Crystalfrequency

26MHz

Modulation

GFSK

(recommended)

(G)FSK, 4(G)FSK,(G)MSK，OOK

Package

DIP

Connector

1.5mm

Communication interface

SPI

0-10Mbps

Size

16.6 *24mm

Antenna

SM A-K

50 ohm impedance

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

3 Size and pin definition

No.

Name

Direction

Function

GND

Ground

SDN

Shutdown Input Pin. It is low level when working

(See SI4463 manual for more details)

GPIO3

output

GPIO（seemore from SI4463 datasheet）•

GPIO2

output

GPIO（seemore from SI4463 datasheet）•

nSEL

input

SPI Chip select for starting SPI communication

MOSI

input

SPI master output slave input

MISO

output

SPI master input slave output

SCK

input

Serial Clock Input

IRQ

output

SPI interrupt request

GPIO1

output

GPIO（seemore from SI4463 datasheet）•

GPIO0

output

GPIO（seemore from SI4463 datasheet）•

VCC

Power supply ：1.8~ 3.6 V DC, 3.3V is recommended

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

4. Basic operation

4.1Hardware design

It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible, and

the module needs to be reliably grounded.；

Please pay attention to the correct connection of the positive and negative poles of the power supply. Reverse

connection may cause permanent damage to the module；

Please check the power supply to ensure it is within the recommended voltage otherwise when it exceeds the

maximu m value the module will be permanently damaged；

Please check the stability of the power supply, the voltage can not be fluctuated frequently ；

When designing the power supply circuit for the module, it is often recommended to reserve mo re than 30% of the

margin, so the whole machine is beneficial for long-term stable operation.；

The module should be as far away as possible from the power supply, transformers, high -frequency wiring and other

parts with large electromagnetic interference.；

High-frequency digital routing, high-frequency analog routing, and power routing must be avoided under the module.

If it is necessary to pass through the module, assume that the module is soldered to the Top Layer, and the copper is

spread on the Top Layer of the module contact part(well grounded), it must be close to the digital part of the module

and routed in the Bottom Layer；

Assuming the module is soldered or placed over the Top Layer, it is wrong to randomly route over the Bottom Layer

or other layers, which will affect the module's spurs and receiving sensitivity to varying degrees ；

It is assumed that there are devices with large electromagnetic interference around the module that will greatly affe ct

the performance. It is recommended to keep them away from the module according to the strength of the interference.

If necessary, appropriate isolation and shielding can be done；

Assume that there are traces with large electromagnetic interference (high-frequency digital, high-frequency analog,

power traces) around the module that will greatly affect the performance of the module. It is recommended to stay

away from the module according to the strength of the interference.If necessary, appropriate isolation and shielding

can be done.

If the communication line uses a 5V level, a 1k-5.1k resistor must be connected in series (not recommended, there is

still a risk of damage)；

Try to stay away from some physical layers such as TTL protocol at 2.4GHz , for example: USB3.0；

The mounting structure of antenna has a great influence on the performance of the module. It is necessary to ensure

that the antenna is exposed, preferably vertically upward. When the module is mounted inside the case, use a good

antenna extension cable to extend the antenna to the outside；

The antenna must not be installed inside the metal case, which will cause the transmission distance to be greatly

weakened.

4.2 Software editing

GPIO0 \ GPIO1 \ GPIO2 \ GPIO3 are configurable I/O ports for various application，see more in SI4463 datasheet.It

can be floated when not used.

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

IRQ pin can also be disconnected. The SPI query mode can be used to obtain the interrupt status. However, it is

recommended to use the external interrupt of the MCU.

SPI communication rate should not be set too high, usually around 1Mbps.

Please refer to “Operating Modes and Timing” for SI4463 status switch，the switch between TX and RX should be

through Ready, can not be switched directly.

Re-initialize register configuration when the chip is idle for higher stability.

For controlling GPIO2 ,GPIO3 externally，pin status is as follows ：

In tx mode：GPIO2 = 0; GPIO3 = 1;

In rx mode：GPIO2 = 1; GPIO3 = 0;

If the SI4463 is required to control itself, the mode of the configuration pins can be as follows when

the program is initialized:

SI44XX_GPIO_CONFIG( 0, 0, 32|0x40, 33|0x40, 0, 0, 0 );

5 Basic application

5.1 Basic circuit diagram

6 FAQ

6.1 Communication range is too short

The communication distance will be affected when obstacle exists.

Data lose rate will be affected by temperature, humidity and co-channel interference.

The ground will absorb and reflect wireless radio wave, so the performance will be poor when testing near groun d.

Sea water has great ability in absorbing wireless radio wave, so performance will be poor when testing near the sea.

The signal will be affected when the antenna is near metal object or put in a metal case.

Power register was set incorrectly, air data rate is set as too high (the higher the air data rate, the shorter the

distance).

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

The power supply low voltage under room temperature is lower than 2.5V, the lower the voltage, the lower the

transmitting power.

Due to antenna quality or poor matching between antenna and module.

6.2 Module is easy to damage

Please check the power supply source, ensure it is 2.0V~3.6V, voltage higher than 3.6V will damage the module.

Please check the stability of power source, the voltage cannot fluctuate too much.

Please make sure antistatic measure are taken when installing and using, high frequency devices have electrostatic

susceptibility.

Please ensure the humidity is within limited range, some parts are sensitive to humidity.

Please avoid using modules under too high or too low temperature.

6.3 BER(Bit Error Rate) is high

There are co-channel signal interference nearby, please be away from interference sources or modify frequency and

channel to avoid interference;

Poor power supply may cause messy code. Make sure that the power supply is reliable.

The extension line and feeder quality are poor or too long, so the bit error rate is high;

7 Production guidance

7.1 Reflow soldering temperature

Profile Feature

Curve characteristics

Sn-Pb Assembly

Pb-Free Assembly

Solder Paste

Solder paste

Sn63/Pb37

Sn96.5/Ag3/Cu0.5

Preheat Temperaturemin （Tsmin）

Minpreheating temp.

100℃

150℃

Preheat temperaturemax (Tsmax)

Mxpreheating temp.

150℃

200℃

Preheat Time (Tsmin toTsmax)(ts)

Preheating time

60-120 sec

Average ramp-up rate(Tsmaxto Tp)

Average ramp-up rate

3℃/second max

Liquidous Temperature(TL)

Liquid phasetemp.

183℃

217℃

Time（tL）Maintained Above（TL）

Time below liquid phaseline

60-90 sec

30-90 sec

Peak temperature（Tp）

Peak temp.

220-235℃

230-250℃

Aveage ramp-downrate（Tp toTsmax）

Aveage ramp-down rate

6℃/second max

Time 25℃ to peak temperature

Time to peaktemperature for

25℃

max 6 minutes

max 8 minutes

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

7.2 Reflow soldering curve

8 E10 Series

Model No.

Frequency

(Hz)

Tx power

(dBm)

Test distance

Package

Antenna

E10-868M S30

SI4463

868M

SMD

Stamp hole/IPEX

E10-915M S20

SI4463

915M

2.5

SMD

Stamp hole/IPEX

E10-868M S20

SI4463

868M

2.5

SMD

Stamp hole/IPEX

E10-433M S1W

SI4463

433M

SMD

Stamp hole

E10-433M D3

SI4438

433M

SMD

IPEX

E10-433M D-SM A

SI4463

433M

DIP

SMA-K

E10-433M S

SI4463

433M

SMD

Stamp hole

Chengdu Ebyte Electronic Technology Co., Ltd. E10-433MD-SMA User Manual

9 Antenna guidance

9.1 Antenna recommendation

The antenna is an important role in the communication process. A good antenna can largely improve the

communication system. Therefore, we recommend some antennas for wireless modules with excellent performance and

reasonable price.

Model No.

Type

Frequency

Interface

Gain

dBi

Height

Cable

Function feature

TX433-NP-4310

PCB

433M

SMA-J

43.8*9.5mm

Built-in FPC antenna

TX433-JW-5

Rubber

433M

SMA-J

50mm

Flexible &omnidirectional

TX433-JWG-7

Rubber

433M

SMA-J

2.5

75mm

Flexible &omnidirectional

TX433-JK-20

Rubber

433M

SMA-J

210mm

Flexible &omnidirectional

TX433-JK-11

Rubber

433M

SMA-J

2.5

110mm

Flexible &omnidirectional

TX433-XP-200

Sucker

433M

SMA-J

19cm

200cm

Sucker antenna, High gain

TX433-XP-100

Sucker

433M

SMA-J

3.5

18.5cm

100cm

Sucker antenna, High gain

TX433-XPH-300

Sucker

433M

SMA-J

96.5cm

300cm

Big sucker antenna，ultra

high gain

TX433-JZG-6

Rubber

433M

SMA-J

2.5

52mm

Short straight

&omnidirectional

TX433-JZ-5

Rubber

433M

SMA-J

52mm

Short straight

&omnidirectional

Table des matières

Autres manuels Ebyte Module sans fil

Ebyte

Ebyte E22-400T22DC Manuel utilisateur

Ebyte

Ebyte E07-400M10S Manuel utilisateur

Ebyte

Ebyte E30-780T20S Manuel utilisateur

Ebyte

Ebyte E72-2G4M05S1G Manuel utilisateur

Ebyte

Ebyte E32 Series Manuel utilisateur

Ebyte

Ebyte ESP32-C3-MINI-1U Manuel utilisateur

Ebyte

Ebyte E200-900A17S Manuel utilisateur

Ebyte

Ebyte E32-900T20D Manuel utilisateur

Ebyte

Ebyte E32(915T30S) Manuel utilisateur

Ebyte

Ebyte E19 Series Manuel utilisateur

Ebyte

Ebyte E30-900M20S Manuel utilisateur

Ebyte

Ebyte E28-2G4M12 Series Manuel utilisateur

Ebyte

Ebyte E49-400T20S Manuel utilisateur

Ebyte

Ebyte E70-433T14S2 Manuel utilisateur

Ebyte

Ebyte E104-BT12NSP-TB Manuel utilisateur

Ebyte

Ebyte EO01C-MLO1S Manuel utilisateur

Ebyte

Ebyte E22-400T30S Manuel utilisateur

Ebyte

Ebyte E49-400T30S Manuel utilisateur

Ebyte

Ebyte E07-900M10S Manuel utilisateur

Ebyte

Ebyte E49-400T20S Manuel utilisateur

Ebyte

Ebyte E22-230T30D Manuel utilisateur

Ebyte

Ebyte E22-400T22S1C Manuel utilisateur

Ebyte

Ebyte E32(915T30S) Manuel utilisateur

Ebyte

Ebyte E70-433T S Series Manuel utilisateur

Manuels Module sans fil populaires d'autres marques

Laird

Laird RM024 Manuel utilisateur

Laird

Laird BT830-SA Guide de configuration rapide

Fibocom

Fibocom FM101-NA-20 Instructions d'installation

Waldmann

Waldmann EnOcean TALK MODUL G2 Manuel utilisateur

Smartech

Smartech LBT-1.DO4 Manuel utilisateur

Cooper Wiring Devices

Cooper Wiring Devices ESPIRE RF RFAPM Manuel utilisateur

Yuga

Yuga CLM920 Manuel utilisateur

Waldmann

Waldmann TALK Bluetooth Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions UC864-G Manuel d'installation

Quectel

Quectel SC690A Series Supplément

Panasonic

Panasonic INDUSTRY PAN9028 Guide de configuration rapide

LongSung Technology

LongSung Technology U9507E Manuel utilisateur

Wistron NeWeb

Wistron NeWeb DNUR-S2 Manuel utilisateur

RF-Star

RF-Star SimpleLink RF-BM-2652P1 CC2652P Manuel utilisateur

CHIEF

CHIEF AVMW Manuel utilisateur

Huawei

Huawei EM701 Manuel utilisateur

SIYI

SIYI FTM30 Manuel utilisateur

RF-Star

RF-Star RF-BM-4055B1L Mode d’emploi
