Eaton Powerware 9125 Manuel utilisateur

Powerware 9125 Two-in-One UPS

5000/6000 VA

User’s Guide

Class A EMC Statements

FCC Part 15

NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

ICES-003

This Class A Interference Causing Equipment meets all requirements of the Canadian Interference Causing

Equipment Regulations ICES-003.

Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel brouilleur du

Canada.

EN 50091-2

Some configurations are classified under EN 50091-2 as “Class-A UPS for Unrestricted Sales Distribution.” For

these configurations, the following applies:

WARNING This is a Class A-UPS Product. In a domestic environment, this product may cause radio interference, in

which case, the user may be required to take additional measures.

Powerware, ABM, and FERRUPS are registered trademarks and X-Slot, ConnectUPS, and LanSafe are trademarks

of Eaton Power Quality Corporation. Greenlee is a registered trademark of Greenlee Textron. Modbus is a registered

trademark of Modicon.

reproduced in any way without the express written approval of Eaton Corporation.

Requesting a Declaration of Conformity

Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:

SHarmonized Standards: EN 50091-1-1 and EN 50091-2; IEC 60950 Third Edition

SEU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits

93/68/EEC, Amending Directive 73/23/EEC

89/336/EEC, Council Directive relating to electromagnetic compatibility

92/31/EEC, Amending Directive 89/336/EEC relating to EMC

The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC

Declaration of Conformity, contact:

Eaton Power Quality Oy

Koskelontie 13

FIN-02920 Espoo

Finland

Phone: +358-9-452 661

Fax: +358-9-452 665 68

Special Symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the

associated warning should be observed.

CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for

additional information, such as important operating and maintenance

instructions.

This symbol indicates that you should not discard the UPS or the UPS batteries

in the trash. This product contains sealed, lead-acid batteries and must be

disposed of properly. For more information, contact your local recycling/reuse or

hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic

equipment (WEEE) in the trash. For proper disposal, contact your local

recycling/reuse or hazardous waste center.

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B

www.powerware.com

Table of Contents

1 Introduction 1.........................................................

2 Safety Warnings 3.....................................................

3 Installation 15..........................................................

Inspecting the Equipment 15................................................................

UPS Setup 15..........................................................................

Installing the UPS Internal Batteries 16.....................................................

Tower Setup 17......................................................................

EBM Installation 19......................................................................

Plug-Receptacle UPS Installation 21..........................................................

Remote Emergency Power-off Installation 22....................................................

Hardwired UPS Installation 24..............................................................

4 Operation 29...........................................................

Turning the UPS On 29....................................................................

Starting the UPS on Battery 29..............................................................

Turning the UPS Off 30....................................................................

Initiating the Battery Test 30................................................................

Transferring the UPS to Bypass Mode 31.......................................................

Operating Modes 31.....................................................................

Normal Mode 32.....................................................................

Battery Mode 33.....................................................................

Bypass Mode 34......................................................................

Standby Mode 34.....................................................................

5 Configuration 35........................................................

6 Communication 37......................................................

USB Port 37............................................................................

DB-9 Communication Port 38...............................................................

X-Slot Cards 39.........................................................................

7 UPS Maintenance 41....................................................

UPS and Battery Care 41..................................................................

Storing the UPS and Batteries 41..........................................................

When to Replace Batteries 41...............................................................

TABLE OF CONTENTS

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B

www.powerware.com

Replacing Batteries 42....................................................................

How to Replace Extended Battery Modules 42................................................

How to Replace Internal Batteries 44.......................................................

Testing New Batteries 45..................................................................

Recycling the Used Battery or UPS 46.........................................................

8 Specifications 47.......................................................

9 Troubleshooting 51......................................................

Audible Alarms and UPS Conditions 51........................................................

Silencing an Audible Alarm 51............................................................

Service and Support 54...................................................................

10 Warranty 55...........................................................

Two-Year Limited Warranty (US and Canada) 55..................................................

Ten-Year Pro-Rated Limited Warranty (US and Canada) 57..........................................

Load Protection Guarantee (US and Canada) 59..................................................

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B

www.powerware.com

Chapter 1 Introduction

The Powerware®9125 uninterruptible power system (UPS) protects your

sensitive electronic equipment from the most common power problems

including power failures, power sags, power surges, brownouts, line

noise, high voltage spikes, frequency variations, switching transients,

and harmonic distortion.

Power outages can occur when you least expect it and power quality

can be erratic. These power problems have the potential to corrupt

critical data, destroy unsaved work sessions, and damage hardware —

causing hours of lost productivity and expensive repairs.

With the Powerware 9125, you can safely eliminate the effects of power

disturbances and guard the integrity of your equipment. Figure 1 shows

the Powerware 9125 UPS with an optional Extended Battery Module

(EBM).

Figure 1. The Powerware 9125 UPS with Optional EBM

INTRODUCTION

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B

www.powerware.com

Providing outstanding performance and reliability, the Powerware 9125’s

unique benefits include the following:

SOnline UPS design with pure sine wave output. The UPS filters and

regulates incoming AC power and provides consistent power to your

equipment without draining the battery.

S5U rack height with the highest power density for a 6000 VA UPS.

STwo-in-one form factor for using the UPS in a rack-mount

configuration or as a standalone cabinet.

SABM®technology that uses advanced battery management to

increase battery service life, optimize recharge time, and provide a

warning before the end of useful battery life.

SHours of extended runtime with up to four EBMs.

SStart-on-battery capability for powering up the UPS even if utility

power is not available.

SHot-swappable batteries that simplify maintenance by allowing you to

replace batteries safely without powering down the critical load.

SEmergency shutdown control through the remote emergency

power-off (REPO) port.

STwo standard communication options with a USB port and a DB-9

serial port.

SOptional X-Slottcards with enhanced communication capabilities for

increased power protection and control.

SAdvanced power management with the Software Suite CD for

graceful shutdowns and power monitoring.

SBacked by worldwide agency approvals.

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B

www.powerware.com

Chapter 2 Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions that you should follow during installation and

maintenance of the UPS and batteries. Please read all instructions before operating the

equipment and save this manual for future reference.

DANGER

This UPS contains LETHAL VOLTAGES. All repairs and service should be performed by

AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS

inside the UPS.

WARNING

SThis UPS contains its own energy source (batteries). The output receptacles may carry

live voltage even when the UPS is not connected to an AC supply.

SFor 208–240V models, the output receptacles may remain electrically live. If the input

power source in your application is wired line-to-neutral (as in most European

applications), the voltage to the output receptacles is 0V. With line-to-line input wiring,

the voltage to the output receptacles is 110–120V (measured from line-to-ground or

line-to-neutral, depending on the UPS wiring).

SDo not remove or unplug the input cord when the UPS is turned on. This removes the

safety ground from the UPS and the equipment connected to the UPS.

STo reduce the risk of fire or electric shock, install this UPS in a temperature and humidity

controlled, indoor environment, free of conductive contaminants. Ambient temperature

must not exceed 40°C (104°F). Do not operate near water or excessive humidity (95%

maximum).

SFor UPS models with hardwired outputs, overcurrent protection for the output AC

circuit(s) is to be provided by others.

SFor UPS models with hardwired outputs, suitably rated disconnect switches for the

output AC circuit(s) are to be provided by others.

SAFETY WARNINGS

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B

www.powerware.com

CAUTION

SBatteries can present a risk of electrical shock or burn from high short-circuit current.

Observe proper precautions. Servicing should be performed by qualified service

personnel knowledgeable of batteries and required precautions. Keep unauthorized

personnel away from batteries.

SProper disposal of batteries is required. Refer to your local codes for disposal

requirements.

SNever dispose of batteries in a fire. Batteries may explode when exposed to flame.

Sikkerhedsanvisninger

VIGTIGE SIKKERHEDSANVISNINGER

GEM DISSE ANVISNINGER

DENNE BRUGERVEJLEDNING INDEHOLDER VIGTIGE

SIKKERHEDSANVISNINGER

FARE

Denne UPS indeholder LIVSFARLIG HØJSPÆNDING. Alle reparationer og vedligeholdelse bør

kun udføres af en AUTORISERET SERVICETEKNIKER. Ingen af UPS’ens indvendige dele kan

repareres af brugeren.

ADVARSEL!

SDenne UPS indeholder egen energiforsyning (batterier). Udgangsnetstikkene kan lede

strøm, selv når UPS’en ikke er tilsat en AC-energikilde.

SNetledningen må ikke fjernes og stikket må ikke trækkes ud, mens UPS’en er tændt.

Dette fjerner sikkerhedsjorden fra UPS’en og fra det udstyr, der er sat til.

SInstallér denne UPS i et temperatur- og fugtighedskontrolleret indendørsmiljø, frit for

ledende forureningsstoffer for at formindske risikoen for brand og elektrisk stød.

Rumtemperaturen må ikke overstige 40°C. UPS’en bør ikke betjenes nær vand eller høj

fugtighed (maksimalt 95%).

SFor UPS systemer med hårdledningsudgange, skal overstrømsbeskyttelse for

vekslestrømmens udgangskredsløb forsynes af andre.

SFor UPS systemer med hårdledningsudgange, skal egnede, nominelle afbryderkontakter

for vekslestrømmens udgangskredsløb forsynes af andre.

Autres manuels pour Powerware 9125

Table des matières

Autres manuels Eaton UPS

Eaton

Eaton Tower 6KS Manuel utilisateur

Eaton

Eaton 9PX3K3U Manuel utilisateur

Eaton

Eaton 9390IT Manuel utilisateur

Eaton

Eaton Power Xpert Plus 1 Manuel utilisateur

Eaton

Eaton Power Xpert 9395 550/275 Manuel utilisateur

Eaton

Eaton Power Xpert 9395C Manuel utilisateur

Eaton

Eaton 5E650i Manuel utilisateur

Eaton

Eaton Power Xpert 9395 High Performance Manuel utilisateur

Eaton

Eaton 550VA 3S Manuel utilisateur

Eaton

Eaton Powerware 9390 Manuel utilisateur

Eaton

Eaton Aegis AGPHxxxxx series Manuel utilisateur

Eaton

Eaton BladeUPS none Manuel utilisateur

Eaton

Eaton POWERWARE Plus 18 Manuel utilisateur

Eaton

Eaton 93PM IBC-L Manuel utilisateur

Eaton

Eaton Pulsar Series 650 Manuel utilisateur

Eaton

Eaton Ellipse ECO 500 Manuel utilisateur

Eaton

Eaton Ellipse PRO 1200 FR Manuel utilisateur

Eaton

Eaton 93E XL Manuel utilisateur

Eaton

Eaton EX RT 5 Manuel utilisateur

Eaton

Eaton Powerware 9395 550 kVA MBM Manuel utilisateur

Eaton

Eaton 550i Manuel utilisateur

Eaton

Eaton 93PM 150 kW SIAC-B Three-Wire Manuel utilisateur

Eaton

Eaton Power Xpert 9395 Plus Manuel utilisateur

Eaton

Eaton 9E Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur

ZincFive

ZincFive BC Series Manuel utilisateur
