Easypix DVX5233 OPTIMUS Manuel utilisateur

User,s Manual

Read This Before Using the Camera

SAFETY INSTRUCTIONS

Do not drop, puncture or disassemble the camera.•

Use the camera with care. Rough handling may damage the internal components.•

Do not expose the camera to high temperature. Avoid contact with water.•

Please notice that the camera body may become warm when operating it for an extended period.•

Test for proper operation before using the camera.•

Only use accessories supplied by the manufacturer.•

Use only the type of battery that came with your camera.•

Remove the battery if the camera is not going to be used for long periods.•

Product Information

Designsandspecicationsofthecameraaresubjecttochangewithoutnotice.Thisincludesprimary•

productspecications,software,andthisuser’smanual.

ThisUser’sManualisageneralreferenceguideforthecamera.•

The illustrations in this manual may not be the same as the actual design of your camera and those•

you see on the LCD screen.

Contents

Read This Before Using the Camera ................................................... 2

Section 1 Getting to Know Your Camera........................................... 4

Section 2 Getting Started.................................................................... 7

Section 3 Enjoying the Record Mode ................................................ 9

Section 4 Enjoying the Playback Mode........................................... 21

Section 5 Setting Your Camera ....................................................... 26

Section 6 Viewing Photos and Videos on TV.................................. 30

Section 7 Viewing Video & Photo on PC ......................................... 31

Section 8 Uploading Files to Internet .............................................. 32

Section 9 Specications and System Requirements..................... 35

Section 10 Troubleshooting ............................................................... 37

Section 1

Getting to Know Your Camera

Overview

Thecameraequippeda5MegaPixelsensorthatcantakeH.264formatvideos.TheH.264technology

allowsforextandedvideorecordingwithlessmemory.Highqualityimagesupto16mega-pixelscan

also be delivered smoothly. With a color LCD monitor, you can view and examine the videos and photos

easily.

The camera features 3” (16:9) LCD touch panel which is an ideal platform for you to operate your

camera. Themenu optionsare accessiblewith yournger.With thetouch panel,you canselect the

optionsdirectlyandquickly.

ThecameraalsofeaturesvideorecordingatanHDresolutionof1920x1080.Youcanalsoconnectitto

anHDTVviaanHDMIcable,andeasilyplaybacktherecordedhigh-denitionvideosonthewidescreen

HDTV.

Moreover,thecamerahasanadvanceduploadingfeature.Withtheexclusivebuilt-inInternet Direct

application, you can upload the videos captured by the camera to the web site more effortlessly .

ISOsensitivityandcolorbalance can either beadjustedautomaticallyorchanged manually.A 120x

digitalzoomhelpsyoutocontroloverthevideosandphotosyoutake.

Thevariedeffectoptions,suchasTimeLapseandSlowMotion,makerecordingmorefun.

Thebuilt-inmemoryallowsyoutotakephotosandtorecordvideoswithoutamemorycard.Thememory

card slot allows users to increase the storage capacity.

Note

Partial memory of the built-in memory is used for the camera’s Firmware code• and software.

Install the bundled software application on the CD, ArcSoft MediaImpression, for viewing the•

videos correctly on a PC.

Standard Accessories

Unpackthepackageandmakesureallstandardaccessorieslistedareincluded:

Camera•

USBCable•

AVCable•

HDMICable•

Adaptor•

Lithium-ionRechargeableBattery•

QuickGuide•

CD-ROM(Software,User’sManual)•

Pouch•

LensCoverSet(LenscoverandStrap)•

Front View

Rear View

Lens

Microphone

Photo Button

Tele/Wide Button

Flash

Self-timer LED

LCD Touch Panel

HDMI Port

Mini USB 2.0 Port

Video Button

TV Port

Record LED

Indicator

Playback LED

Indicator

Side View

Bottom View

Speaker

Power Button

Playback Button

Stabilization ButtonDigital Light Button

Pause Button

Tripod Socket Battery/SD card Cover

Section 2

Getting Started

Loading the Battery

Beforeusingthecamera,youmustloadtheLithium-ion

rechargeablebatterycomewithinthepackage.

Insertthebatteryaccordingtothecorrectpolaritymarks(+or1.

-).

Closethebatterycoverrmly.2.

Charge your battery

YoumustusethesuppliedACchargerortheUSBcable.Thecameramustbe

turnedOFF.Theblinkinglightconrmsthecameraiscurrentlycharging,and

thelightbecomesconstantafterthechargingiscompleted.InACcharging

Mode,thelightwillturnitself offautomaticallyafter3~5minutes. Thefull

chargetimeisabout4to5hours.(Actualchargingtimemayvary.Itdepends

onthebatteryconditions.)

Inserting and Removing an SD Card (Optional)

The camera comes with an internal memory that allows you to store

photosandvideos.Youcanexpandthememorycapacitybyusingan

optionalSDmemorycard.

Insertthe memorycard intothe slot.Please referto thegure on1.

the right side.

ToremovetheinstalledSDcard,pressthecardinwardtorelease2.

it.

When the card pops out, gently remove it from its slot.3.

Recommendedmemorycapacity:1GBorabove.4.

Note

When a memory card is tted, videos/photos are saved to the card rather than the built-in•

memory.

Protecting Data on an SD Card: SD Card is read-only•

when it is locked. No photos or videos can be recorded

when the SD card is locked. Make sure the lock is on

the writeable position before recording any media.

Writeable

position

Write-Protected

Position

Turning the Camera On

Toturnonthecamera:•

Flip out the LCD panel; the camera will turn on automatically.1.

Orpress[PowerButton2. ] for approximately one second to turn it on.

Conguring the Initial Date and Time Setup

Thetimesettingscreenappearstoallowyoutosetupdateandtime:•

Operation Display Screen

TouchYear,Month,Day,Hour,Minute,andAM/PMtoset.1.

Adjustthenumericvaluebytouching2. /

Touch the [OK] icon to validate the setting.3.

Touch the Exit icon4. ( )to exit.

Getting Started

Torecordvideo:• Press [VideoButton] to record video. To stop recording, press it again.

To pause recording:• Press [Pause Button] to pause recording. To continue the recording, press it

again.

Totakeaphotoduringvideorecording:Whenrecordingvideo,press[PhotoButton]tocapturethe•

image. The Dual record icon ( )appearsontheLCDmonitor.

Totakea• photo:Press[PhotoButton] halfway down until the focusing frame turns from white to green.

Then,pressitfullydowntotakephoto.

FocusingFrame:White FocusingFrame:Green

Toviewstoredvideosandphotos:Press[PlaybackButton]ortouch• on the screen to switch to

thePlaybackmode.

Turning the Camera Off

Toturnoffthecamera:Youcaneitherpress[PowerButton]foronesecond,oryoucanplacetheLCD•

panelbacktoitsoriginalposition.

Section 3

Enjoying the Record Mode

Button Function

Video Button:

Presstotakevideo.1.

To stop recording, press it again.2.

Photo Button:

Presstotakephoto.1.

When recording video, press to capture the image.2.

Tele Button:

ZoomIn.1.

Wide Button

Zoom out.1.

Power Button:

Press down for one second to turn on or turn off the camera.1.

Playback Button:

SwitchbetweenRecord/PlaybackMode.1.

Forquickreview,pressitafterrecording.2.

Pause Button:

Press to pause the recording.1.

To continue the recording, press it again.2.

Digital Light Button:

DigitalLightOn/Off.

Stabilization Button:

StabilizationOn/Off.

LCD Monitor Information

TheindicatorsshownbelowmaydisplayonLCDwhenvideosandphotosarerecorded:

(1)

VideoResolution

FullHD(1080p30fps)

HD(720p60fps)

HD(720p30fps)

VGA(640X480)

SlowMotion(Recordvideoat432x240(QVGA)resolution.)

Photo Resolution

16MP

5MP

3MP

(2)

00:05:30

Recordingtimeofthevideothatcanstillbetakenatcurrent

resolution

Numberofimagesthatcanstillbetakenatcurrentresolution

(3)

Self-timerenabled

Dual Record

(4) PlaybackModeOn

(5) MenuOn

(6) InformationbarOn

(7) SDCardInserted
