Easypix W508 Manuel utilisateur

English Manual......................... P1

German Manual ........................ P18

Spanish Manual ........................ P37

French Manual.......................... P55

Portuguese Manual .................. P73

Instruction Manual

Table of content

Introduction .......................................................................................................................... 2

Key Features........................................................................................................................ 2

What Your Camera Includes ................................................................................................ 2

Computer System Requirement for Windows 2000/XP ....................................................... 2

Computer System Requirement for Windows Vista ............................................................. 2

Computer System Requirements for Macintosh................................................................... 2

Quick Look at Your Camera ................................................................................................. 3

Main Icons on the LCD ........................................................................................................ 3

Prepare Your Camera for use .............................................................................................. 4

Install battery........................................................................................................................ 4

Install SD memory card........................................................................................................ 4

Starting Your Digital Camera................................................................................................ 5

Camera mode ...................................................................................................................... 5

Video mode.......................................................................................................................... 8

Playback mode .................................................................................................................... 8

Camera setup ....................................................................................................................11

Transferring photos to your PC / Executing PC camera..................................................... 13

Install PhoTags Express Software...................................................................................... 13

Everything you need to get the most from your photos...................................................... 15

Download photos to your PC ............................................................................................. 15

Photags Express software owner manual.......................................................................... 17

Viewing Videos on Your Computer..................................................................................... 17

Maintenance of Your Digital Camera.................................................................................. 17

Appendix A: Technical Specifications ................................................................................. 17

Introduction

Thank you for purchasing this kind of Digital Camera. Not only can you take good quality digital

photos and videos but you can also use your camera as a removable disk. Everything you need to

take quality photos and videos is included with your camera. Please read this manual carefully

before using.

Key Features

yDigital Video resolutions-640x480 Pixels (VGA), 320x240 Pixels (QVGA)

5 mega pixels camera with choice of 6 digital camera resolutions-4032X3024Pixels (12M by

interpolation), 3456X2580Pixels (9M by interpolation), 2560X1920Pixels (5M), 2048X1536Pixels

(3M), 1208X960Pixels (1.3M), 640X480Pixels (VGA)

y2.4 inch TFT LCD

y8x Digital Zoom function

yImage Stabilization function

ySD memory card slot accepts SD compatible memory card up to 8GB

yBuilt in Flash

yPhoTags Express software for managing and enhancing your photos, printing, sending photos

by e-mails and much more.

What Your Camera Includes

yPhoTags Express software installation CD

yUSB cable

yUser’s manual

yStrap

yPouch

Computer System Requirement for Windows 2000/XP

To be able to download photos and videos to your PC, you will need the following minimum

configuration:

yPentium processor or above with Windows 2000, XP

y128 MB RAM, more than 125MB free disk space.

yAvailable USB Interface

yCD-ROM Driver

yRecommended screen resolution 1024 X 768 pixels or higher.

y16-bit color or higher display adaptor.

Computer System Requirement for Windows Vista

To be able to download photos or videos to your PC you will need the following minimum

configuration:

yWindows Vista

y800MHz processor and 512 MB of system memory

y20GB hard driver with at least 15GB of available space

ySupport for Super VGA graphics

yAvailable USB Interface

yCD-ROM Driver

Computer System Requirements for Macintosh

yPower Macintosh G3 500 MHz or higher

yMac OS X version 10.2.6 or later

y128 MB or more available system RAM (256 MB recommended), 150 MB free disk

yspace

y800 x 600 or higher-resolution monitor displaying millions of colors

Note: This hardware is plug and play compatible when used on a Mac, however, the included

software can be used on Windows operating systems only.

Quick Look at Your Camera

Main Icons on the LCD

Prepare Your Camera for use

Install battery

Please insert the battery correctly as the correct polarity facing up with the battery cover.

Note:

1. “Low battery” will show on the LCD when battery is insufficient and your camera will be off.

2. Please uninstall your battery when you don’t intend to use your camera for a long time to

forbid them leakage and corrosion.

3. Your digital camera will be off when the battery is insufficient.

4. The photos will be lost when the camera off or open the battery door, transfer the test

photos/videos to PC as often as possible.

5. Do not mix old and new batteries.

6. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium metal hydride)

batteries.

Install SD memory card

This camera supports any compatible SD memory card up to 8GB. Limited internal memory is only

for you to take test photos, these photos will be lost when you turn off your camera or remove the

batteries. Please refer to the below diagram for correct installation method:

Locate the SD memory card slot, and insert an SD memory card as above, until you feel and hear a

“Click” sound. When the icon appears on the LCD screen this indicates that your SD card is

installed correctly.

Note:

1. After the SD memory is inserted successful, “Move to SD card” will appear on the screen, the

photos you have taken will be stored on the SD memory card.

2. Formatting will delete all data on the SD memory card including protected data.

3. Don’t remove the SD card during formatting as this may damage the card and render it

unusable.

4. Download the photos/videos to your PC and delete the photos and videos from your SD Card

in order to continue using your camera.

Starting Your Digital Camera

There are 3 modes on your camera.

Camera Mode: Take still photos

•Video Mode: Capture video files

Playback Mode: View, print, edit photos and view videos

Power on

Press the Power button once to turn on your camera. The LCD will light up and it will sound a “beep”,

this indicates your camera is turned on and ready for use.

Power off

Press the Power button once to turn off your camera. When there is insufficient battery power, your

camera will be off automatically after a moment.

Camera Mode

Taking Photos

After each photo is shot (when the camera returns to icon mode) the numbers of photos left to shoot

at this resolution is displayed on the top right of the LCD screen.

When the camera's memory (photo capacity) is full, the LCD screen will display a message “ Card

Full ”

Digital Zoom function

Use the T and W buttons to adjust the zoom. The icon will show on your LCD screen. Press

the T button to zoom in on your subject. Push the Wbutton to zoom back out.

Macro shooting

slide the Macro/Far switch to position which is on the left side of the camera, until

icon appears on the LCD screen, it indicates the macro shooting is on.

Far shooting

slide the Macro/Far switch to position which is on the left side of the camera, until icon

appears on the LCD screen, it indicates that the far shooting is on.

Flash

Press the Up button repeatedly until the icon shows on the LCD screen. This will activate the

automatic flash.

Press the Up button repeatedly until the icon appears on the LCD screen. This means the

flash function has been "forced on" (manual flash). If the flash is not ready, a LED will light up and

the icon will flash repeatedly - wait until the flash is ready before taking a photo.

Press the Up button repeatedly until the icon shows on the LCD screen. The red eye reduction

is open.

Press the Up button repeatedly until the icon appears. This will turn off the flash function.

Self-Timer :

You can include yourself in a photo by using this feature to delay the time between your pressing the

shutter and when the photo is actually taken. It is recommended that you use a tripod when you use

the self-timer.

1. Press Down button repeatedly to select or seconds self timer or 3 pictures

continuous shooting.

2. Press the shutter button to start a 2 or 10 or 3 pictures continuous shooting to count down,

and the photo will automatically be taken.

Delete :

You can delete the last photo you take on Camera Mode.

1. Please press Right button to enter into the menu, and press Up/Down button to select it.

2. Press OK button to confirm the selection, and press OK button to confirm the cancellation. Or,

select Left button to exit.

OK button

ÎÎÎÎÎ

Menu:

You can set photo/video quality and change other setting.

Photo setting :

Press Menu/Left button to enter into the menu, and press

Up/Down button to select the setting. There are Resolution,

Scene, Image stabilization, Quality , Sharpness , Exposure,

White Balance , ISO and Face Detection.

Resolution :

1. Enter into MENU, and press Up/Down button to select ”

Resolution”.

2. Press OK button, and then press Up/Down button to

select the resolution.

12M , 9M , 5M , 3M , 1.3M , VGA

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return back.

Scene :

1. Enter into MENU, and press Up/Down button to select

“Scene”.

2. Press OK button, and then press Up/Down button to

select the scenes, Auto, Night Scene, Night Portrait,

Portrait, Scenery, Sports, Party, Beach, High

Sensitivity.

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Image Stabilization :

1. Enter into MENU, and press Up/Down button to select

“ Image Stabilization”.

2. Press OK button, and then press Up/Down button to

select On/Off.

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Quality :

1. Enter into MENU, and press Up/Down button to

select” Quality”.

2. Press OK button, and then press Up/Down button to

select the quality, Super Fine , Fine , Normal

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Sharpness :

1. Enter into MENU, and press Up/Down button to select”

Sharpness”.

2. Press OK button, and then press Up/Down button to

select sharpness, Strong , Normal , Soft

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Exposure :

1. Enter into MENU, and press Up/Down button to select”

Exposure”.

2. Press OK button, and then press Up/Down button to

select exposure,-2.0 , -5/3 , -4/3 , -1.0 , -2/3 , -1/3 ,

+0.0 , +1/3 , +2/3 , +1.0 , +4/3 , +5/3 , +2.0

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

White Balance :

1. Enter into MENU, and press Up/Down button to select ”

White Balance”.

2. Press OK button, and then press Up/Down button to

select white balance, Auto / Daylight / Cloudy /

Tungsten / Fluorescent

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

ISO :

1. Enter into MENU, and press Up/Down button to select ”

ISO”.

2. Press OK button, and then press Up/Down button to

select ISO, Auto , 50 , 100 , 200 , 400

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Face Detection :

1. Enter into MENU, and press Up/Down button to select ”

Face Detection”.

2. Press OK button, and then press Up/Down button to

select Face Detection Off / On

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Video Mode:

Under Video mode, please press Menu/Left button to enter

into the menu, and press Up/Down button to select the

setting. There are Resolution, White Balance, and

Exposure

Resolution:

1. Enter into MENU, and press Up/Down button to select”

Resolution”.

2. Press OK button, and then press Up/Down button to

select the resolution, VGA , QVGA

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

White Balance :

1. Enter into MENU, and press Up/Down button to select ”

White Balance”.

2. Press OK button, and then press Up/Down button to

select white balance, Auto / Daylight / Cloudy /

Tungsten / Fluorescent

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Exposure :

1. Enter into MENU, and press Up/Down button to select ”

Exposure”.

2. Press OK button , and then press Up/Down button to

select Exposure, -2.0 , -5/3 , -4/3 , -1.0 , -2/3 , -1/3 ,

+0.0 , +1/3 , +2/3 , +1.0 , +4/3 , +5/3 , +2.0

3. After selection, please press OK button to confirm, and

press Left button to exit. Or, select Right button to

return.

Playback Mode

Under Camera mode, please press Mode Button twice

quickly to enter into Playback Mode.

Press WButton to enter into Photo Mode, and press

Up/Down/ Left/ Right button to select the photo you would

like to view. After selection, please press OK button to view

the photo.

When viewing the photo, you can press T Button to zoom in

the photo, and press Up/Down/ Left/ Right button to adjust

the viewing angle.

Table des matières

Langues :

Autres manuels Easypix Appareil photo numérique

Easypix

Easypix GoXtreme BLACK HAWK+ 4K Manuel utilisateur

Easypix

Easypix LCD Manuel utilisateur

Easypix

Easypix GoXtreme Phantom 4K Manuel utilisateur

Easypix

Easypix GoXtreme Enduro Black Manuel utilisateur

Easypix

Easypix Octonauts Manuel utilisateur

Easypix

Easypix DVX5233 OPTIMUS Manuel utilisateur

Easypix

Easypix V130 Manuel utilisateur

Easypix

Easypix V500 Diamond Manuel utilisateur

Easypix

Easypix AQUAPIX W2024 Splash Manuel utilisateur

Easypix

Easypix GOXTREME VISION+ Manuel utilisateur

Easypix

Easypix Streetvision SV5 Manuel utilisateur

Easypix

Easypix KIDDYPIX ROBOZZ Manuel utilisateur

Easypix

Easypix easypix Clip Tube Manuel d'instructions

Easypix

Easypix VX 1400 HD Manuel utilisateur

Easypix

Easypix KIDDYPIX BLIZZ Manuel utilisateur

Easypix

Easypix Megxon S320 Manuel utilisateur

Easypix

Easypix DV 5211 HD Manuel utilisateur

Easypix

Easypix GoXtreme Reef Manuel utilisateur

Easypix

Easypix goxtreme user manual Manuel utilisateur

Easypix

Easypix GOXTREMELIVE 360 Manuel utilisateur

Easypix

Easypix aquapix W1400 Manuel utilisateur

Easypix

Easypix Jelly Body t514 Manuel utilisateur

Easypix

Easypix v515 duo Manuel utilisateur

Easypix

Easypix V130 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
