Dymo LabelWriter 450 Manuel utilisateur

H-1265

PAGE 1 OF 10 1013 IH-1265

Quick Start Guide

H-1265

PAGE 2 OF 10 1013 IH-1265

English

Quick Start Guide

Follow these steps to install the LabelWriter printer and print your first label.

1. Unpacking your LabelWriter Printer

NOTE Do not plug the printer into your computer until asked to do so during the

software installation.

1Unpack your printer and save the packing materials.

2Make sure you have all the items shown in Figure 1. (Labels included in the

package may vary.)

LabelWriter

Quick Start

Figure 1

Power adapter

LabelWriter printer

CD-ROM

Roll of Address labels

Power cable

Quick Start Guide

USB cable

H-1265

PAGE 3 OF 10 1013 IH-1265

Becomefamiliar with theprinter’s majorcomponents. See Figure 2.

LabelWriter Printer Features

Your LabelWriter printer is adirect thermal printer anddoes notuseinkortoner.

Instead, theprinter uses heat from athermal printhead to printon specially

treated labels. Labels are theonly supplies youwill ever need to buy.

Theform-feed button on thefrontof theprinter advances asinglelabel. Thelabel

eject button is used to removelabels from theprinter when changing rolls.

TheLED status lightvisually shows thecurrentstate of theprinter:

•Solid blue - power is on andtheprinter is ready.

•Flashing blue - labels are notloaded properly orlabel spool is empty.

Figure 2

Form-feed

Label feed path

andtear bar

Top

cover

USB

connectorDC power

connector

button andLED

Cable

channelLabel eject

button

Platen

Label roll

Label

spool

release

H-1265

PAGE 4 OF 10 1013 IH-1265

2. Installing the Software

NOTE Do not connect the printer to your computer until instructed to do so during

the software installation.

To install the software on a Windows system

1Insert theLabelWriter CD into your CD-ROM drive. After afew seconds, the

installation screen appears.

If theinstallation screen does notappear:

a. Click Start, then Run on theWindows taskbar. TheRun dialog box

appears.

b. Enter D:\install.exe (where D is theletter assigned to theCD-ROM drive)

andclick OK.

2Click Install andfollow theinstructions in theinstaller.

To install the software on a Mac OS system

1Insert theDYMO LabelWriter CD into theCD-ROM drive.

After afew seconds, theDYMO Label Software Installer

icon appears. See Figure 3.

2Double-click theInstaller icon andfollow theinstructions.

If youdo notsee your printer in theprinter listwhen theinstallation is

complete, refer to theReadMefileforinstructions on how to add theprinter.

DYMO Label

Figure 3

H-1265

PAGE 5 OF 10 1013 IH-1265

3. Connecting your LabelWriter Printer

OTE Do not connect the printer to your computer

unt

il instructed to do so during the software

installat

ion.

o connect the power

1Plug the power cord into the power adapter.

See Figure 4.

2Plug the power adapter into the power connector

on the bottom of the printer. See Figure 5.

3Plug the other end of the power cord into a

power outlet.

4Plug the USB cable into the USB port on the

bottom of the printer. See Figure 5.

5Insert the power and USB cables through the

cable channel and set the printer down.

NOTE DO NOT CONNECT the other end of the USB cable to

your computer until asked to do so during the software

installation.

6When prompted by the software installer, plug the USB

cable into a USB port. See Figure 6.

SwitchingAdapter

SHOCKHAZARD

RISKOFELECTRICSHOCK

DRYLOCATIONUSEONLY

NON-SERVICEABLEPARTSINSIDE.

FORUSEWITHITEONLY.

ENDASTFORKONTORSMASKINER.

CAUTION

Testedtocomply

withFCCstandards

FORHOMEOR

OFFICEUSE

I.T.E.POWERSUPPLY

ModelNo.:TESA2-2401000

U.S.P/N:90819

EuropeP/N:924883

INPUT:100-240V-50/60HzMax0.64A

OUTPUT:24V---0-1.0A

MADEINCHINA

LISTED

15WM

E198850

ULUL

N10926

Power adapter

Power cord

Figure 4

USB

24VDC

Figure 5

USB Power

Cable

channel

Figure 6

H-1265

PAGE 6 OF 10 1013 IH-1265

4. Loading Labels

To load a label roll

1Press the form-feed button to eject the labels that

protected the printer during shipment.

2Open the top cover and remove any packing

material inside the label compartment.

3Remove the label spool from inside the cover.

4Hold the spool spindle in your left hand and place the

label roll on the spindle so that the labels feed from

underneath and the left edge of the label roll is flush

against the side of the spool. See Figure 7.

5Place the spool guide onto the right side of the spool

and press the guide tightly against the side of the

label roll, leaving no gap between the roll and the spool. See Figure 7.

NOTE The label roll must fit snugly against both sides of the

label spool, with no gaps, to avoid drifting as the labels feed

through the printer.

6Insert the label spool into the slot in the printer cover with

the labels extending from underneath the roll. See Figure 8.

Figure 7

Spool

spindle

Spool

guide

Figure 8

H-1265

PAGE 7 OF 10 1013 IH-1265

7Align the left edge of the label with the left edge of the

label feed slot and insert the label into the slot. See

Figure 9.

The printer feeds the labels, stopping at the beginning

of the first label. If the printer does not feed the labels,

make sure the first label is fully inserted and then press

the form-feed button.

8Close the top cover.

You are now ready to print your first label.

5. Printing your First Label

To print your first label

1Start DYMO Label Software by doing one of the following:

•For Windows, click Start, then Programs>DYMO Label>DYMO Label.

•For Macintosh, double-click in the DYMO Label folder.

The first time you open the application, you are asked to register the

software. Registering the software ensures that you will be informed of any

software updates. You are also asked to enter your default return address.

2At the main window, click once on the label and type some text.

3Choose a font and a justification setting from the Formatting toolbar.

4Click to print the label.

Figure 9

H-1265

PAGE 8 OF 10 1013 IH-1265

Figure 10 highlights some of the major features available in DYMO Label

Software.

For complete details on using the software, refer to the DYMO Label Software User

Guide, located on the DYMO Label Software CD-ROM, and the online Help.

Insert text,

addresses, pictures,

rectangles, lines,

barcodes, dates, or

counters.

Insert text you’ve

copied to the

Clipboard.

Store your favorite

addresses in the

Address Book;

automatically insert

them on your label.

If you also have a tape

printer, two buttons

allow you to easily

switch between the

Label and Tape Editors.

Verify and correct addresses

as you add them to the

Address Book.

Figure 10

H-1265

PAGE 9 OF 10 1013 IH-1265

Printing Postage with

DYMO Stamps™

Youcan now printpostagerightfrom your desktop using your LabelWriter 400

Turbo label printer. All youneed is DYMO Stamps™software, your LabelWriter

printer, DYMO Stamps labels, andan Internet connection.

To install DYMO Stamps and print postage

1Sign up foryour USPSaccountwith Endicia. Go to:

www.endicia.com/dymostamps

2Attheendof thesign up process, download andinstall theDYMO Stamps

software.

DYMO Stamps software is availableforboth Windows andMac OSX.

NOTE You must have DYMO Label Software and your LabelWriter printer

installed before installing the DYMO Stamps software.

Thefirsttimeyoustart theDYMO

Stamps software, youare prompted

to enter thepostageaccount

number assigned andthepass

phraseyoucreated during thesign-

up process.

3Enter your accountnumber and

pass phrase, andthen click OK.

PAGE 10 OF 10 1013 IH-1265

4Select Buy Postagefrom the

Account menu and purchase

postage for your account.

5Select DYMO LabelWriter 450

Turbo from the Printer drop-

down list underPrinter

Selection.

6Click Test Print to print a

voided postage label.

You are now ready to start printing

actual postage whenever you need

it. Refer to the DYMO Stamps online

Help for more information about

using the software.

You can add postage, buy DYMO Stamps postage labels, and order supplies

directly from within the DYMO Stamps software.
