M-TYPE DELTA
Additional Instructions
Remaining thread monitor (RFW)
All rights reserved.
Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,
including extracts, is prohibited without the prior written approval of Dürkopp Adler AG.
Copyright © Dürkopp Adler AG 2019
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Table of Contents
Additional Instructions M-TYPE DELTA - 00.0 - 08/2019 1
1 General information ................................................................... 3
1.1 Components of the kit 0867 594014
(RFW for 1-needle machines, large hook).................................... 4
1.2 Components of the kit 0867 594024
(RFW for 2-needle machines, large hook).................................... 5
1.3 Components of the kit 0867 594034
(RFW for 1-needle machines, extra-large hook)........................... 6
1.4 Components of the kit 0867 594044
(RFW for 2-needle machines, extra-large hook)........................... 7
2 Assembling the remaining thread monitor
(1-needle machines) ................................................................... 8
2.1 Assembling solenoid valve and RFW PCB................................... 8
2.2 Assembling the remaining thread monitor .................................. 12
3 Assembling the remaining thread monitor
(2-needle machines) ................................................................. 14
3.1 Assembling solenoid valve and RFW PCB................................. 14
3.2 Assembling the remaining thread monitor .................................. 18
4 Software settings...................................................................... 21
5 Appendix ................................................................................... 22
Table of Contents
2 Additional Instructions M-TYPE DELTA - 00.0 - 08/2019
General information
Additional Instructions M-TYPE DELTA - 00.0 - 08/2019 3
1 General information
Important
The machine is not equipped with compressed air.
If you want to assemble the remaining thread monitor to the machine, you
will need the following additional kits: (see Parts List):
•9780 000108: Compressed air maintenance unit
•0867 594304: Pneumatic small parts pack
•0797 003031: Pressure line K
Information
Fig. 1: General information, new bobbin
To use the remaining thread monitor, you will need to use the new bobbins
with flat.
New bobbins are included in the kit.
General information
4 Additional Instructions M-TYPE DELTA - 00.0 - 08/2019
1.1 Components of the kit 0867 594014
(RFW for 1-needle machines, large hook)
Check whether the scope of delivery for kit 0867 594014 is correct prior to
installation.
Part number Quantity Designation
0570 001847 1 Blanking plug
0667 155824 1 RFW carrier
0667 155840 1 Holder
0667 155930 1 Cover
0699 979265 1 Hose 0.9 m
0867 150170 1 Compression spring
0867 154570 3 Bobbin Ø 28 mm
9202 002077 1 Cylinder-head bolt
9204 201667 8 Pan-head screw
9710 063420 1 Solenoid valve
9790 201000 1 WI-E coupling
9815 925002 1 Light barrier
9830 501010 4 Spacer
9840 120025 2 Mounting clip
9840 120106 3 Cable holder
9840 121002 3 Cable tie
9850 755001 1 Circuit board
9874 867012 1 Cable
9874 867023 1 Cable
0791 867724 EN 1 Additional Instructions
General information
Additional Instructions M-TYPE DELTA - 00.0 - 08/2019 5
1.2 Components of the kit 0867 594024
(RFW for 2-needle machines, large hook)
Check whether the scope of delivery for kit 0867 594024 is correct prior to
installation.
Part number Quantity Designation
0570 001847 1 Blanking plug
0667 155824 2 RFW carrier
0667 155840 1 Holder
0667 155930 1 Cover
0699 979265 1 Hose
0867 150170 2 Compression spring
0867 154570 6 Bobbin Ø 28 mm
9202 002077 2 Cylinder-head bolt
9204 201667 9 Pan-head screw
9710 063420 1 Solenoid valve
9790 030020 1 Y-connection piece
9790 201000 1 WI-E coupling
9815 925002 2 Light barrier
9830 501010 4 Spacer
9840 120025 3 Mounting clip
9840 120106 3 Cable holder
9840 121002 3 Cable tie
9850 755001 1 Circuit board
9874 867012 1 Cable
9874 867023 1 Cable
0791 867724 EN 1 Additional Instructions
General information
6 Additional Instructions M-TYPE DELTA - 00.0 - 08/2019
1.3 Components of the kit 0867 594034
(RFW for 1-needle machines, extra-large hook)
Check whether the scope of delivery for kit 0867 594034 is correct prior to
installation.
Part number Quantity Designation
0570 001847 1 Blanking plug
0667 155824 1 RFW carrier
0667 155840 1 Holder
0667 155930 1 Cover
0699 979265 1 Hose 0.9 m
0867 150170 1 Compression spring
0867 150560 3 Bobbin Ø 32 mm
9202 002077 1 Cylinder-head bolt
9204 201667 8 Pan-head screw
9710 063420 1 Solenoid valve
9790 201000 1 WI-E coupling
9815 925002 1 Light barrier
9830 501010 4 Spacer
9840 120025 2 Mounting clip
9840 120106 3 Cable holder
9840 121002 3 Cable tie
9850 755001 1 Circuit board
9874 867012 1 Cable
9874 867023 1 Cable
0791 867724 EN 1 Additional Instructions
General information
Additional Instructions M-TYPE DELTA - 00.0 - 08/2019 7
1.4 Components of the kit 0867 594044
(RFW for 2-needle machines, extra-large hook)
Check whether the scope of delivery for kit 0867 594044 is correct prior to
installation.
Part number Quantity Designation
0570 001847 1 Blanking plug
0667 155824 2 RFW carrier
0667 155840 1 Holder
0667 155930 1 Cover
0699 979265 1 Hose
0867 150170 2 Compression spring
0867 150560 6 Bobbin Ø 32 mm
9202 002077 2 Cylinder-head bolt
9204 201667 9 Pan-head screw
9710 063420 1 Solenoid valve
9790 030020 1 Y-connection piece
9790 201000 1 WI-E coupling
9815 925002 2 Light barrier
9830 501010 4 Spacer
9840 120025 3 Mounting clip
9840 120106 3 Cable holder
9840 121002 3 Cable tie
9850 755001 1 Circuit board
9874 867012 1 Cable
9874 867023 1 Cable
0791 867724 EN 1 Additional Instructions
Assembling the remaining thread monitor (1-needle machines)
8 Additional Instructions M-TYPE DELTA - 00.0 - 08/2019
2 Assembling the remaining thread monitor
(1-needle machines)
2.1 Assembling solenoid valve and RFW PCB
Fig. 2: Assembling solenoid valve and RFW PCB (1)
To assemble solenoid valve and RFW PCB:
1. Screw the blanking plug (4) at valve output 2 onto the solenoid
valve (3).
2. Screw the elbow screw joint (5) at valve output 4 onto the solenoid
valve (3).
3. If not yet present, assemble the compressed air maintenance unit to
the stand (see Operating Instructions).
4. Disassemble the handwheel (1).
5. Disassemble the belt cover (2).
WARNING
Risk of injury from sharp and moving parts!
Puncture or crushing possible.
Switch off the machine before assembling the
remaining thread monitor (RFW).
(1) - Handwheel
(2) - Belt cover
(3) - Solenoid valve
(4) - Blanking plug
(5) - Elbow screw joint
①
②
④ ⑤③
