<Examples of Pictorial Symbols>
A circle with a line through it indicates a prohibited action.
The particular act prohibited is indicated by a picture inside the circle.
(In the example shown here, the prohibited act is disassembly.)
A black disc indicates an instruction, or sometimes a prohibited action.
The instruction itself is indicated by pictorial symbols drawn in white on the disc.
(In the example shown here, the instruction is “Remove the plug from the outlet”.)
●The precautions below are vital for safety and must be taken.
Warning Terminology
The following warning terminology is used in this installation manual.
Indicates a high degree of potential danger. Failure to heed the warning may lead to death or
serious injury.
Safety Precautions
WARNING
Indicates a medium degree of potential danger. Failure to heed the caution may lead to injury or
damage to property.
CAUTION
WARNING
●Use only the power cord that is provided among the accessories.
Insert the power cord plug firmly into the socket, so that proper electrical contact is effected.
→Use of any other power cord could result in imperfect grounding.
If grounding is imperfect and electrical leakage occurs, fire or electric shock could result.
●Do not use a source voltage other than that specified. Do not connect two or more loads to a
single outlet. →Doing so may result in fire or electric shock.
●Do not place the machine in a humid or dusty area. →Doing so may result in fire or electric
shock.
CAUTION
●Do not place the machine in an unstable position, such as on an unsteady support or sloping
area.
→If the machine is dropped or falls over, this could result in personal injury.
●Once the machine is in position, secure in place using the casters.
→If the machine falls over, this could result in personal injury.
2
WARNING
Use this machine correctly in accordance with the instructions. Great care must be taken to
ensure person safety while installing, operating, checking, and maintaining this machine.
The maintenance including dangerous work, transportation or installation should be carried out
by a person with sufficient knowledge and experience of this machine and system.
CAUTION
Never lay the machine on its side.
WARNING
This machine is heavy-weight equipment.
When moving it by using the casters, two or more persons are required. Pay extra attention to
slopes when transporting.
WARNING
Do not place the machine outside.
Rain drops, water, or dust may result in electric fire, electric shock or malfunction.
CAUTION
Horizontally place the machine on a flat hard floor that bears the weight of the machine, and
take actions for the machine not to fall over. Imperfect installation could result in dropping or
falling, causing personal injury .
WARNING
Do not touch the tools contained in each module.
Injury may result.
WARNING
Turn off the power before uninstalling, adjusting and installing the modules.
3
Operating temperature 10°C–30°C
Operating humidity 40%–70%
Storage temperature 0°C–50°C, no condensation
Storage humidity 10%–80%, no condensation
●Installation environment
Be sure to offer training in replacement of the tool, adjustment, and safety precautions to
customers who are in charge of maintenance when the machine is installed.
Instruct customers that replacement of the tool must be performed only by the trained person
in charge of maintenance.
Be sure to offer training in pressing and releasing the back-up rollers to customers who
are in charge of maintenance.
Procedures for contacting back-up rollers is described in this manual. Have customers keep
this manual at hand.
Duplo is not responsible for damage, injury, or any other troubles due to failure to observe
the description in this manual.
To All Dealers/Distributors
4
1. Unpacking Checks
1. Check the product name on the package.
Product name: DC-646
(The DC-646 includes 115V model, 230V model, ASIA model.)
2. Unpack the package.
Carry out unpacking in a place that is safe for the work.
3. Check the contents.
IMPORTANT
No. Name Part No. Q'ty Remarks
1 Power cord E1-8108* 1 115V model
2 Power cord L1-W126* 1 230V model , ASIAmodel
3 PC controller CD W5-Y198* 1
4 Card stacker 1
5 Support guide (for card stacker) W5-L232* 4
6 Guide assy (for card stacker) Y2-L208* 1
7 Side guide (for exit tray) 2
8 Side guide (for feed tray) 1
9 Upper guide 1
10 Back guide (for exit tray) 1
11 Back guide (for feed tray) 1
12 Back guide weight (for feed tray) 5
13 Plate (for PC) U7-M722* 1 115V (USA) model, 230V model
14 PC arm mount assy 1 115V (USA) model, 230V model
15 Screw (HSKW5×12) 7115V (USA) model, 230V model
16 Hexagon wrench XZ057 1
17 Shaft (tool) W5-G138* 1
18 Check sheet S2-Y104* 6
19 Coated paper
320×450 mm (230 gsm) 5
Used for pressure adjustment
when the driving roller and the
press roller are replaced. See the
service manual for adjustment
procedure.
20 Warning label K9-T140* 3 230V model
21 Warning label M7-T307* 2 230V model
22 Warning label sheet L8-T112* 4 230V model
23 Warning label W5-T135* 1 230V model
24 Warning label sheet P9-T301* 1 230V model
25 Label sheet U3-T114* 1 230V model
26 Label U3-T112* 1
27 Installation Manual W5-Y206* 1
28 Instruction Manual W5-Y204* 1
5
1
2
3
4
5
6
7
8
9
10
6
11
13
12
14
15
16
17
18
19
20
7
21
ACHTUNG
P9-T3010g
NOTA
P9-T3010s
ATTENTION
P9-T3010f
ATTENZIONE
P9-T3010i
P9-T3010r
P9-T3010
22
23
24
26
27
28
25
8
2510mm
2310mm
2570mm
1650mm
1110mm
(1745mm)
1540mm
1505mm
765mm
745mm
800mm800mm
2650mm
800mm
1000mm
(240mm)
800mm800mm
3250mm
800mm
2. Machine Dimensions and Required Space for Operation
Dimensions in ( ): DC-646 230V model,
DC-646 115V model
