Thank you for choosing a SunSplash® Series Overhead Projector. Dukane

SunSplash Overhead Projectors are available in rugged steel or durable ABS

plastic bases and a choice of 2000, 2200, 3000/2400 or 4000/3200 lumens.

Features of each model vary and can include a closed or open head; a single,

double or triple element lens; a wide angle lens and a lamp changer.

Because operation of all units is very similar, this manual covers all models

in the Dukane SunSplash Series.

IMPORTANT SAFETY INSTRUCTIONS

When using your overhead projector, basic safety precautions should

always be followed, including the following:

1. Read and understand all instructions before using.

2. Close supervision is necessary when any projector is used by or

near children. Do not leave projector unattended while in use.

3. Care must be taken as burns can occur from touching hot parts.

4. Do not operate projector with a damaged cord or if the pro-

jector has been dropped or damaged — until it has been

examined by a qualified service technician.

5. Position the cord so that it will not be tripped over, be pulled

or contact hot surfaces.

6. If an extension cord is necessary, a cord with a current rating

at least equal to that of the projector should be used. Cords

rated for less amperage than the projector may overheat.

7. Always unplug projector from electrical outlet before cleaning

and servicing and when not in use. Never yank cord to pull

plug from outlet. Grasp plug and pull to disconnect.

8. Let projector cool completely before putting away.

9. To protect against the risk of electric shock, do not immerse

this projector in water or other liquids.

10. To avoid the risk of electric shock, do not disassemble this

projector, but take it to a qualified service technician when

some service or repair work is required. Incorrect reassembly can

cause electric shock when the projector is used subsequently.

11. The use of an accessory attachment not recommended by

the manufacturer may cause a risk of fire, electric shock or

injury to persons.

12. Connect this projector to a grounded outlet.

13. Disconnect this unit from its source of supply before replacing

the projection lamp.

Additional lamp safeguards: never handle lamps with bare fingers;

periodically inspect lamps, when they’re turned off, for signs of

blistering or blackening; insure proper action of the cooling system;

turn off the projector immediately if the image becomes abnormally

dim; never operate a projector with the lamp housing open; and

make sure that the lamp itself is properly seated.

SAVE THESE INSTRUCTIONS

SPECIFICATIONS .................................................................. 1

ELECTRICAL SAFETY GROUNDING INSTRUCTIONS ........................ 1

INDEX OF FUNCTIONAL PARTS ................................................ 2

SETUP/ASSEMBLY................................................................. 3

OPERATION ......................................................................... 4

CLEANING ........................................................................... 4

SUNSPLASH SERIES OHP SELECTION CHART ...........................5/6

LAMP REPLACEMENT ............................................................. 7

For 2000 Lumen Models ................................................7/8

For 3000 & 4000 Lumen Models .....................................8/9

TROUBLESHOOTING .............................................................. 9

SERVICING ........................................................................ 10

Shipping Information .................................................... 10

Service........................................................................ 10

No Charge Warranty Repair............................................. 10

Information on Lamp Warranty ....................................... 10

OPTIONAL ACCESSORIES ...................................................... 10

STORAGE .......................................................................... 11

FRESNEL LENS REMOVAL ...................................................... 11

INTERNAL PARTS................................................................ 12

LIFETIME LIMITED WARRANTY ...................................Back Cover

TABLE OF CONTENTS Page

SPECIFICATIONS

This Dukane Overhead Projector is a transmissive (lamp under

stage) projector designed to project material on transparencies for

audience viewing.

Your Dukane projector is designed to incorporate rugged simplicity

with easy–to–use, efficient operation. With a minimum of routine

care and maintenance, it will provide you with many years of

dependable service.

Following are features common to all SunSplash Series Overhead

Projectors:

Focusing ... Rack and Pinion Focusing for Precise Image Adjustment

Dimensions .............. 13" (W) x 15" (D) x 36" (H) or 38" (H) Max.

Mounting Holes ........................... For Roll Film Feed Attachment

Aperture............................................................ 10.5" x 10.5"

Head Elevation .............................................. Up to 30 Degrees

Power .............................................................120V AC, 60 Hz

Power Cord ......................................... 3-Wire, Grounded, 10 Ft.

Safety Interlock.................. Cuts off power when stage is opened

Cooling ............. High efficiency fan and automatic thermal cutoff

to prevent overheating

Warranty ....................................................... Lifetime Limited

ELECTRICAL SAFETY

GROUNDING INSTRUCTIONS

This Class I product uses a three-wire power cord that grounds

the product for your protection. Do not

DEFEAT

REMOVE

the

grounding pin. If an extension cord is used, it must also be a

three-wire type with an ampere rating equal or greater than the

product’s rating. The plug must be connected to a properly

grounded three-terminal power receptacle. Connection to any

other type of receptacle should be done only by a qualified elec-

trician in accordance with local and/or national electrical codes.

A number of terms are used frequently in this instruction booklet.

The OVERHEAD PROJECTOR will be easier to operate if you become

familiar with the terms for the functional parts listed below:

1. OPEN HEAD

2. MAST

3. FOCUS KNOB

4. STAGE

5. STAGE OPENING LATCH TABS

6. BASE

7. CLOSED HEAD

8. POWER SWITCH

9. MAST MOUNT

INDEX OF FUNCTIONAL PARTS

PRIMARYLAMPRESERVE

In order to protect the optical head during shipment, it and the mast

have been packed apart from the base.

1. Remove the optical head/mast assembly and base from the

shipping carton.

2. On plastic models, depress stage opening latch tabs on front of

the stage and lift off stage (Step 1). Place stage aside.

3. Find the Allen head screw and the Allen wrench. (On plastic base

models, find the Allen head screw, washer, wing nut and Allen

wrench).

4. Take the mast and identify the lower end which has no plastic

cap.

5. Position the mast open end so the 3 holes fit over the two

alignment posts with the center hole being open (Step 2).

6. Insert the Allen screw from outside the unit into the mast. Turn

screw tight with fingers. Further tighten with the 1/8’ Allen

wrench. On plastic base models, use the wing nut and washer on

the inside of unit to tighten the Allen head screw (Step 3).

7. Replace stage on top of unit by aligning the rear edge. Push front

down to lock into place.

SETUP/ASSEMBLY

Open stage.

TEP

1 —

Fix Mast with

washer and

wing nut.

TEP

3 —

Position Mast

on posts.

TEP

2 —

Inside of Base

Washer and

wing nut

Allen screw

Place the projector on a firm level surface at a convenient operating

height. Be sure vent areas of unit are not blocked. Plug the power

cord into a 120V, 60 Hz AC outlet. Move power switch to ON position.

Place a transparency on the stage and turn focus knob until image

is in focus. Image elevation is adjusted by moving optical head up

or down.

Models equipped with a lamp changer system allow change of lamp

by sliding a lever.

OPERATION

1. Lamp Changer (2000 Lumen Series)

2. High/Low Lamp Switch (3000 or 4000 Lumen Series)

3. Lamp Changer (3000 or 4000 Lumen Series)

CLEANING

For best performance, keep your projector free of dust. Keep covered

when not in use.

Cleaning: Use a soft, lint-free cloth to remove dust from stage

glass and projection lens. Lens cleaner may be used on these

components.

Mirrors: Do not attempt to clean mirrors with cleaning

agents — use a soft lens brush to remove dirt.

Fresnel Lens: Use a soft, lint-free cloth or soft brush to remove

dust. The Fresnel lens may be removed by pressing the two plastic

latches.

TURN OFF POWER

BEFORE CHANGING LAMP!

Primary Reserve

Lamp

1 23

SP2123 2200 lumens Open, single element with wide angle EYB, 360W, 75 Hrs. / No Durable ABS

SP2223 2200 lumens Open, single element with wide angle EYB, 360W, 75 Hrs. / No Steel Constructed

SP2125 2200 lumens Open, single element EYB, 360W, 75 Hrs. / No Durable ABS

SP2225 2200 lumens Open, single element EYB, 360W, 75 Hrs. / No Steel Constructed

SP2226 2200 lumens Open, single element EYB, 360W, 75 Hrs. / Yes Rugged Steel Constructed

SP2127 2000 lumens Closed, single element with wide angle EYB, 360W, 75 Hrs. / No Durable ABS

SP2128 2000 lumens Closed, single element with wide angle EYB, 360W, 75 Hrs. / Yes Durable ABS

SP2227 2000 lumens Closed, single element with wide angle EYB, 360W, 75 Hrs. / No Steel Constructed

SP2133 2000 lumens Closed, double element EYB, 360W, 75 Hrs. / No Durable ABS

SP2134 2000 lumens Closed, double element EYB, 360W, 75 Hrs. / Yes Durable ABS

SP2233 2000 lumens Closed, double element EYB, 360W, 75 Hrs. / No Steel Constructed

SP2234 2000 lumens Closed, double element EYB, 360W, 75 Hrs. / Yes Steel Constructed

SP3123 3000/2400 lumens Open, single element with wide angle ENX, 360W, 75 Hrs. / No Durable ABS

SP3127 3000/2400 lumens Closed, single element with wide angle ENX, 360W, 75 Hrs. / No Durable ABS

SP3128 3000/2400 lumens Closed, single element with wide angle ENX, 360W, 75 Hrs. / Yes Durable ABS

SP3134 3000/2400 lumens Closed, double element ENX, 360W, 75 Hrs. / Yes Durable ABS

SP4123 4000/3200 lumens Open, single element with wide angle FXL, 410W, 50 Hrs. / No Durable ABS

SP4223 4000/3200 lumens Open, single element with wide angle FXL, 410W, 50 Hrs. / No Steel Constructed

SP4125 4000/3200 lumens Open, single element FXL, 410W, 50 Hrs. / No Durable ABS

SP4225 4000/3200 lumens Open, single element FXL, 410W, 50 Hrs. / No Steel Constructed

SP4127 4000/3200 lumens Closed, single element with wide angle FXL, 410W, 50 Hrs. / No Durable ABS

SP4128 4000/3200 lumens Closed, single element with wide angle FXL, 410W, 50 Hrs. / Yes Durable ABS

SP4233 4000/3200 lumens Closed, double element FXL, 410W, 50 Hrs. / No Rugged Steel Constructed

SP4134 4000/3200 lumens Closed, double element FXL, 410W, 50 Hrs. / Yes Durable ABS

SP4234 4000/3200 lumens Closed, double element FXL, 410W, 50 Hrs. / Yes Steel Constructed

SP4136 4000/3200 lumens Open, triple element FXL, 410W, 50 Hrs. / Yes Durable ABS

SP4236 4000/3200 lumens Open, triple element FXL, 410W, 50 Hrs. / Yes Steel Constructed

MODEL BRIGHTNESS LENS SYSTEM LAMP/LAMP CHANGER HOUSING

SUNSPLASH SERIES OHP SELECTION CHART

Lamp in projector:

SP2xxx — 2000 lumen, uses a 360 watt EYB lamp, Dukane Part

Number 456-186.

SP4xxx — 4000 lumen, uses a 410 watt FXL lamp, Dukane Part

Number 456-192.

SP3xxx — 3000 lumen, uses a 360 watt ENX lamp, Dukane Part

Number 458-188.

LAMP REPLACEMENT

WARNING

Lamp and adjacent metal parts are hot. Allow lamp to cool

before replacing. Glass components may shatter.

Handle carefully.

Lamp replacement, SP2xxx units:

1. Open unit stage by depressing the latch tabs on front of stage

and lifting (Step 1). Remove the stage.

2. Carefully pull out used lamp. Take caution since it may be hot.

Allow time to cool (Step 2).

3. Push new lamp in socket until firmly seated. Avoid skin oil on

bulb. Hold lamp with a cloth, tissue or gloved hand.

4. Replace stage by aligning rear edge and then pushing down the

front until it locks into place.

FOR 2000 LUMEN MODELS —

Open stage.

TEP

1 —

Lamp replacement, SP4xxx and SP3xxx units:

1. Open unit stage by depressing the latch tabs on front of stage

and lifting (Step 1). Remove the stage.

2. Pull up retainer clip wires and rotate lamp cover into open

position (Step 2).

Carefully pull out bulb.

TEP

2 —

FOR 2000 LUMEN MODELS —

FOR 3000 & 4000 LUMEN MODELS —

Pull up retainer clip and

rotate open the lamp cover.

TEP

2 —

Open stage.

TEP

1 —

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dukane Projecteur

Dukane

Dukane 8142WSS Manuel utilisateur

Dukane

Dukane 8952P Manuel utilisateur

Dukane

Dukane 8928C Manuel utilisateur

Dukane

Dukane 8964WUSS Manuel utilisateur

Dukane

Dukane ImagePro 8070 Manuel utilisateur

Dukane

Dukane 6233 Manuel utilisateur

Dukane

Dukane ImagePro 8065 Manuel utilisateur

Dukane

Dukane 8960WUSS Instructions d'installation et d'entretien

Dukane

Dukane ImagePro 8049B Manuel utilisateur

Dukane

Dukane ImagePro 8776-RJ Manuel utilisateur

Dukane

Dukane 8137W Manuel utilisateur

Dukane

Dukane ImagePro 9100HC Manuel utilisateur

Dukane

Dukane ImagePro 8888 Manuel utilisateur

Dukane

Dukane ImagePro 8742 Manuel utilisateur

Dukane

Dukane ImagePro 9060 Manuel utilisateur

Dukane

Dukane ImagePro 8038 Manuel utilisateur

Dukane

Dukane 8133WSS Document technique

Dukane

Dukane ImagePro 28A8801A Manuel utilisateur

Dukane

Dukane ImagePro 8066 Guide de démarrage rapide

Dukane

Dukane ImagePro 9017 Manuel utilisateur

Dukane

Dukane 6537WC Manuel utilisateur

Dukane

Dukane ImagePro 8805 Document technique

Dukane

Dukane 68100-4KSS Manuel utilisateur

Dukane

Dukane 7700 Series Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
