Dukane 8933B Manuel utilisateur
1
Features
This projector has the network function that brings you the following main features.
WARNING
• The information in this manual is subject to change without notice.
• The illustrations in this manual are for illustrative purposes. They may differ
slightly from your projector.
• The manufacturer assumes no responsibility for any errors that may appear in
this manual.
• The reproduction, transfer or copy of all or any part of this document is not
permitted without express written consent.
NOTE
9 Web Control : allows you to monitor and control the projector through a network from a
computer, smartphone and tablet device. (35)
9 Network Presentation : allows the projector to project computer, images transmitted
through a network. (76)
9 My Image : allows the projector to store up to four still images and project them. (80)
9 Messenger : allows the projector to display text sent from a computer through a network.
(81)
9 Network Bridge : allows you to control an external device through the projector from a
computer. (84)
LCD Projector
8932WB/8933B/8937B/
8938WB/8945B/8940WB
User's Manual (detailed) Network Guide
Thank you for purchasing this product.
This manual is intended to explain only the network function. For proper use of this
product, please refer to this manual and the other manuals for this product.
►Before using this product, be sure to read all manuals for this
product. After reading them, store them in a safe place for future reference.
8932WB-8933B-8937B-8938WB-8945B-8940WB-Network-Guide-00
Note: The Dukane models described in this document are manufactured by Hitachi and uses the
same firmware, software programs, control code, and accessory parts. The equivalent Dukane to
Hitachi models are 8932WB (CP-EW3051WN), 8933B (CP-EX3051WN), 8937WB (CP-EX3551WN),
8938WB (CP-EW3551WN), 8945B (CP-EX4551WN) and 8940WB (CP-EW4051).
2
Contents
Contents
Caution .......................................................................................... 5
1. Network Function ..................................................................... 6
1.1 Web Control ................................................................................................ 6
1.2 Network Presentation . ................................................................................ 7
1.3 My Image Function ..................................................................................... 8
1.4 Messenger Function ................................................................................... 9
1.5 Network Bridge Function ........................................................................... 10
1.6 Other Functions ......................................................................................... 11
1.6.1 E-mail Alerts ................................................................................................................... 11
1.6.2 Projector Management using SNMP .............................................................................. 11
1.6.3 Event Scheduling ........................................................................................................... 11
1.6.4 Command Control via the Network ................................................................................ 11
2. Connection to the network .................................................... 12
2.1 Connection via wireless LAN .................................................................... 13
2.1.1 Connection in Simple Access Point Mode ..................................................................... 15
2.1.2 Connection in Infrastructure Mode ................................................................................. 16
2.2 Connection via wired LAN ......................................................................... 18
2.3 Applications .............................................................................................. 20
2.4 NETWORK Menu . .................................................................................... 21
3. Web Control ............................................................................ 35
3.1 Projector Web Control ............................................................................... 38
3.1.1 Login .............................................................................................................................. 38
3.1.2 Network Information ....................................................................................................... 40
3.1.3 Network Settings ............................................................................................................ 41
3.1.3.1 Common Setup ......................................................................................................... 41
3.1.3.2 Wireless Setup ......................................................................................................... 43
3.1.3.3 Wired Setup .............................................................................................................. 46
3.1.3.4 Other Setup .............................................................................................................. 47
3.1.4 Port Settings .................................................................................................................. 48
3.1.5 Mail Settings .................................................................................................................. 49
3.1.6 Alert Settings .................................................................................................................. 51
3.1.7 Schedule Settings .......................................................................................................... 52
3.1.7.1 Schedule Management ............................................................................................ 52
3.1.7.2 Program List ............................................................................................................. 53
3.1.7.3 Program Edit ............................................................................................................. 54
3.1.7.4 Program Copy .......................................................................................................... 55
3
Contents
3.1.8 Date/Time Settings ......................................................................................................... 56
3.1.9 Security Settings ............................................................................................................ 58
3.1.9.1 User Account ............................................................................................................ 58
3.1.9.2 Network Control ........................................................................................................ 59
3.1.9.3 Network Presentation ............................................................................................... 60
3.1.9.4 SNMP ....................................................................................................................... 61
3.1.10 Projector Control .......................................................................................................... 62
3.1.11 Remote Control ............................................................................................................ 63
3.1.12 Projector Status ........................................................................................................... 64
3.1.13 Connection Test ........................................................................................................... 65
3.1.14 Network Restart ........................................................................................................... 66
3.2 Crestron e-Control® .................................................................................. 67
3.2.1 Main window .................................................................................................................... 69
3.2.2 Tools window ................................................................................................................... 71
3.2.3 Info window ..................................................................................................................... 73
3.2.4 Help Desk window ........................................................................................................... 74
3.2.5 Emergency Alert .............................................................................................................. 75
4. Network Presentation ............................................................. 76
4.1 Outline ...................................................................................................... 76
4.2 Display Mode . ........................................................................................... 77
4.2.1 Single PC mode ............................................................................................................. 77
4.2.2 Multi PC mode ............................................................................................................... 77
4.3 Multi Projector Mode . ............................................................................... 78
4.4 Moderator Control Mode . ......................................................................... 78
4.5 Port Number . ............................................................................................ 79
5. My Image Function ................................................................. 80
6. Messenger Function ............................................................... 81
6.1 Outline ...................................................................................................... 81
6.2 Display Style ............................................................................................. 82
7. Network Bridge Function ....................................................... 84
7.1 Connecting devices .................................................................................. 84
7.2 Communication setup ............................................................................... 85
7.3 Communication port ................................................................................. 85
7.4 Transmission method ............................................................................... 86
7.4.1 HALF-DUPLEX .............................................................................................................. 86
7.4.2 FULL-DUPLEX ............................................................................................................... 87
4
Contents
8. Other Functions ...................................................................... 88
8.1 E-mail Alerts ............................................................................................. 88
8.2 Projector Management using SNMP ........................................................ 91
8.3 Event Scheduling ..................................................................................... 93
8.4 Command Control via the Network .......................................................... 97
8.5 Crestron ConnectedTM ............................................................................ 102
9. Troubleshooting ................................................................... 103
10. Warranty and after-sales service ...................................... 112
5
Caution
Caution
• Be sure to confirm that the projector has been installed and connected safely
even if it is turned on automatically.
•
If you connect the projector to an existing network, consult a network
administrator before setting server addresses.
•
Attaching an optional wireless adapter to the projector enables wireless
connection. Follow the cautions below when you use the wireless adapter.
[Restriction on plugging and unplugging the wireless adapter (option)]
Before you insert or pull out the wireless adapter from the projector, turn off the
power of the projector and pull out the power cord’s plug from the outlet. Do not
touch the wireless adapter that is connected to the projector while the projector is
receiving AC power. Do not use any extension cable or device when connecting
the adapter to the projector.
[Security precautions when using wireless LAN (option)]
It is recommended that security settings, such as SSID and ENCRYPTION, are
specified when using wireless LAN communication. If the security settings are not
specified, the contents may be intercepted or it may cause unauthorized access
to the system. For details on wireless LAN security settings, refer to 3.1 Projector
Web Control. Although the projector has security functions, they do not always
guarantee prevention of the risks mentioned above.
►You do not need a radio license to use the adapter, but you
should be aware of the following:
• DO NOT USE NEAR THE FOLLOWING!
- Microwave ovens
- Industrial, scientific or medical devices
- Designated low power radio stations
- Premises radio stations
- Using this projector near the above may cause radio interference, which would
result in a decrease in transmission speed or interruption, and even lead to
malfunctioning of devices such as pacemakers.
•
Depending on the location where this projector is used, radio wave interference
may occur, which may result in a decrease in transmission speed or interruption
in communication. In particular, please be aware that using the wireless adapter
at locations where there is reinforced steel, other types of metals or concrete is
likely to cause radio wave interference.
• Available Channels
This projector uses the 5 GHz and 2.4 GHz radio frequency band, but
depending on the country or region you are in, the channels that you can use
might be limited. Please consult your dealer for information on the usable
channels.
• Bringing this projector out of the country or region you reside in and using it
there could lead to a violation of the radio laws of that country or region.
• The W52 is for indoor use only. Outdoor use is prohibited.
CAUTION
6
1. Network Function
1. Network Function
This chapter describes the outline of network function.
Connecting the projector and the computer via the network, remote control and
status monitoring of the projector can be performed by Web browser.
Two types of interface, “Projector Web Control” and “Crestron e-Control®” are
available for this projector. (35)
1.1 Web Control㻌
Projector Web Control
Crestron e-Control®
7
1.2 Network Presentation
1. Network Function
The projector can display or play back the computer screen images and audio
data that are transmitted through the network.
To use Network Presentation, an exclusive application, "LiveViewer" is required.
The following application is required to use Network Presentation.
OS Application
Windows®LiveViewer
Mac OS X®LiveViewer
iOS(iPhone/iPad) Projector Quick Connection
Android Projector Quick Connection
8
1.3 My Image Function
1. Network Function
The projector can display still images transferred via the network.
It is possible to allocate up to 4 image files.
MY IMAGE transmission requires an exclusive application for your computer.
Use the application to transfer the image data.
1
43
2
Transfer image data
Display image data (ex. )
9
1.4 Messenger Function
1. Network Function
The projector can display text data transferred via the network on the screen and
play back audio data inside the projector.
Up to 12 text data can be stored.
Transfer text data
Display text data (ex. )
1
4
3
2
12
10
1.5 Network Bridge Function
1. Network Function
This projector is equipped with the NETWORK BRIDGE function to perform
mutual conversion of a network protocol and a serial interface.
By making use of the NETWORK BRIDGE function, a computer connected to the
projector via wireless or wired LAN is able to control an external device via
RS-232C communication using the projector as a network device.
RS-232C
RS-232C cable
CONTROL port
LAN port
External device
Wired LAN
LAN cable
Computer
Protocol change
TCP/IP data Serial data
USB TYPE A port
(Wireless adapter)
Wireless
LAN
Ce manuel convient aux modèles suivants
5
Autres manuels Dukane Projecteur
Dukane
Dukane 6235W Manuel utilisateur
Dukane
Dukane 6650HDA Manuel utilisateur
Dukane
Dukane ImagePro 8918 Manuel utilisateur
Dukane
Dukane 6640W Manuel utilisateur
Dukane
Dukane ImagePro 8935 Manuel utilisateur
Dukane
Dukane ImagePro 8956H-RJ Manuel d'installation et d'exploitation
Dukane
Dukane ImagePro 8066 Manuel utilisateur
Dukane
Dukane ImagePro 8783 Manuel utilisateur
Dukane
Dukane 9005 Manuel utilisateur
Dukane
Dukane ImagePro 8913 Manuel utilisateur
Dukane
Dukane ImagePro 8935 Manuel d'utilisation et d'entretien
Dukane
Dukane ImagePro 8746A Manuel utilisateur
Dukane
Dukane 6230WA Manuel utilisateur
Dukane
Dukane 8934B Manuel utilisateur
Dukane
Dukane 6650HDSS Manuel utilisateur
Dukane
Dukane ImagePro 8913-W Manuel utilisateur
Dukane
Dukane ImagePro 8742 Manuel utilisateur
Dukane
Dukane ImagePro 8935 Manuel utilisateur
Dukane
Dukane ImagePro 8077A Manuel utilisateur
Dukane
Dukane 28A680 Manuel utilisateur
Manuels Projecteur populaires d'autres marques
Panasonic
Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur
NEC
NEC NP600S EDU Manuel utilisateur
BenQ
BenQ SH753P Manuel utilisateur
Eiki
Eiki EK-623U series Manuel utilisateur
Epson
Epson PowerLite Pro Cinema 6020UB Manuel utilisateur
Epson
Epson PowerLite Home Cinema 705HD Manuel utilisateur
