Duerkopp Adler 530 Manuel utilisateur

530

CNC Knopfannähautomat

CNC Automat for Button Sewing

Bedienanleitung / Operating Instructions

Aufstellanleitung / Installation Instructions

Serviceanleitung / Service Instructions

Postfach 17 03 51, D-33703 Bielefeld Potsdamer Straße 190, D-33719 Bielefeld

Telefon +49 (0) 5 21/ 9 25-00 Telefax+49(0)521/9252435www.duerkopp-adler.com

Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:

06/2008 Rev. index: 01.0 Printed in Federal Republic of Germany 0791 530001

Anleitung, komplett

Manual, complete

530

Eigentum der Dürkopp Adler AG und urheberrechtlich geschützt. Jede, auch auszugsweise

Wiederverwendung dieser Inhalte ist ohne vorheriges schriftliches Einverständnis der Dürkopp Adler AG

verboten.

Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner,

even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.

Übersicht Summary

Bedienanleitung

Aufstellanleitung

Serviceanleitung

Bauschaltplan

9890 510001 B

Operating Instructions

Installation Instructions

Service Instructions

Interconnection-diagram

9890 510001 B

Foreword

This instruction manual is intended to help the user to become familiar

with the machine and take advantage of its application possibilities in

accordance with the recommendations.

The instruction manual contains important information on how to

operate the machine securely, properly and economically. Observation

of the instructions eliminates danger, reduces costs for repair and

down-times, and increases the reliability and life of the machine.

The instruction manual is intended to complement existing national

accident prevention and environment protection regulations.

The instruction manual must always be available at the machine/sewing

unit.

The instruction manual must be read and applied by any person that is

authorized to work on the machine/sewing unit. This means:

–Operation, including equipping, troubleshooting during the work

cycle, removing of fabric waste,

–Service (maintenance, inspection, repair) and/or

–Transport.

The user also has to assure that only authorized personnel work on the

machine.

The user is obliged to check the machine at least once per shift for

apparent damages and to immediatly report any changes (including the

performance in service), which impair the safety.

The user company must ensure that the machine is only operated in

perfect working order.

Never remove or disable any safety devices.

If safety devices need to be removed for equipping, repairing or

maintaining, the safety devices must be remounted directly after

completion of the maintenance and repair work.

Unauthorized modification of the machine rules out liability of the

manufacturer for damage resulting from this.

Observe all safety and danger recommendations on the machine/unit!

The yellow-and-black striped surfaces designate permanend danger

areas, eg danger of squashing, cutting, shearing or collision.

Besides the recommendations in this instruction manual also observe

the general safety and accident prevention regulations!

General safety instructions

The non-observance of the following safety instructions can cause

bodily injuries or damages to the machine.

1. The machine must only be commissioned in full knowledge of the

instruction book and operated by persons with appropriate training.

2. Before putting into service also read the safety rules and

instructions of the motor supplier.

3. The machine must be used only for the purpose intended. Use of

the machine without the safety devices is not permitted. Observe all

the relevant safety regulations.

4. When gauge parts are exchanged (e.g. needle, presser foot, needle

plate, feed dog and bobbin) when threading, when the workplace is

left, and during service work, the machine must be disconnected

from the mains by switching off the master switch or disconnecting

the mains plug.

5. Daily servicing work must be carried out only by appropriately

trained persons.

6. Repairs, conversion and special maintenance work must only be

carried out by technicians or persons with appropriate training.

7. For service or repair work on pneumatic systems, disconnect the

machine from the compressed air supply system (max. 7-10 bar).

Before disconnecting, reduce the pressure of the maintenance unit.

Exceptions to this are only adjustments and functions checks made

by appropriately trained technicians.

8. Work on the electrical equipment must be carried out only by

electricians or appropriately trained persons.

9. Work on parts and systems under electric current is not permitted,

except as specified in regulations DIN VDE 0105.

10. Conversion or changes to the machine must be authorized by us

and made only in adherence to all safety regulations.

11. For repairs, only replacement parts approved by us must be used.

12. Commissioning of the sewing head is prohibited until such time as

the entire sewing unit is found to comply with EC directives.

13. The line cord should be equipped with a country-specific mains

plug. This work must be carried out by appropriately trained

technicians (see paragraph 8).

It is absolutely necessary to respect the safety

instructions marked by these signs.

Danger of bodily injuries !

Please note also the general safety instructions.

Index Page:

Preface and general safety hints

Part 1: Operating Instructions Class 530

(Edition 06/2008)

1. Description of product .......................................... 5

2. Description of proper use ....................................... 6

3. Subclasses ................................................. 6

4. Optional equipment ............................................ 7

5. Stands .................................................... 7

6. Technical data

6.1 Technicaldataofthesubclasses..................................... 8

7. Operating

7.1 Threading needle thread.......................................... 9

7.2 Adjust needle thread tension ....................................... 10

7.3 Open needle thread tension ....................................... 10

7.4 Adjust thread regulator........................................... 11

7.5 Wind on bobbin thread ........................................... 12

7.6 Change hook thread bobbin........................................ 13

7.7 Adjust bobbin thread tension ....................................... 14

7.8 Change needle ............................................... 15

7.9 Button shank shaper ............................................ 16

7.10 Setting the hook feet of button clamp .................................. 17

8. Operating the control of class 530

8.1 The control panel .............................................. 18

8.1.1 Thekeys................................................... 18

8.2 Userinterface................................................ 20

8.2.1 Structureofmenu.............................................. 20

8.3 Alternumericalvalues,parametervalues,selectionofalternatives................ 21

8.3.1 Alternumericalvalues........................................... 21

8.3.2 Selectionofaparameter.......................................... 22

8.3.3 Selectionofalternatives.......................................... 22

8.4 Sewingpatterns............................................... 23

8.5 Mainmenu.................................................. 24

8.5.1 Sewing pattern operation ......................................... 24

Index Page:

8.5.2 Programmingmode............................................. 29

8.5.3 Sewing pattern sequences ........................................ 31

8.5.3.1 Switching the sequence programming mode on/off ......................... 31

8.5.3.2 Sequence programming mode ...................................... 34

8.5.4 Technicianmode .............................................. 35

8.5.4.1 Machine configuration ........................................... 38

8.5.4.2 User configuration ............................................. 45

8.5.4.3 Service functions .............................................. 49

8.5.4.4 Free contours ................................................ 63

8.5.4.5 Memory dongle ............................................... 71

8.6 Error messages ............................................... 78

8.6.1 Error categories ............................................... 78

8.6.2 Application messages ........................................... 79

8.6.3 Machineerrors ............................................... 81

9. Sewing .................................................... 86

10. Maintenance

10.1 Cleaning and checking........................................... 87

10.2 Oillubrication................................................ 88

11. Standard sewing patterns ........................................ 89

12. Clamping feet................................................ 92

13. Numbering of menu items ........................................ 93

1. Description of product

The Dürkopp Adler 530 is a CNC double lockstitch automat for button

sewing. The available button patterns are adjustable in length, width

and speed and can be memorized in their modified form. It is also

possible to create “free” sewing patterns (by programming).

The button sewing automat is equipped with automatic sewing foot

lifts, thread trimmer, thread retractor and integrated DC direct drive.

Technical features

–The control is executed by the DAC III, that is operated by the user

with the control panel BF2B.

–The fabric drive or the clamp drive is effectuated by two step

motors.

–The oil wick lubrication is central for head and hook, but there exist

two separated oil reservoirs that are both supplied through one

upper reservoir. So there is only one reservoir to be refilled.

–A maximum of 50 standard button patterns is available.

These standard patterns can temporarily be modified (as regards

length, width and speed). When switching off the automat the

modified data of the last sewing pattern are maintained.

–40 modified sewing patterns can additionally be memorized.

–Additionally there are a maximum of 9 free seam contours with a

total of 5000 dynamically controlled stitches at the users

disposition. Thus it is possible to sew f. e. free button patterns. The

coordinates of free sewing patterns are entered at the control

panel. There is no need for further devices.

–25 sewing pattern sequence programs each with up to 20 sewing

patterns per sewing pattern sequence program can be created and

memorized.

–The exactitude of the entered coordinates comes to 0.1 mm.

–It is possible to lock certain button programs or button sequence

programs and/or the modification so that an unauthorized use or

modification can be prohibited by the technicians.

–An in between cut without releasing the button clamp is possible,

so as to avoid a continued thread.

–It comes with a bobbin thread counter and a daily production

counter.

–The arm shaft of the button sewing automat is directly powered by

a brushless direct current motor.

–Fabric drive by two step motors.

–The speed can be altered between 0 rpm (manual operation with

full operability of the x-y drive) and 2700 rpm in 100 rpm steps.

–Service and maintenance work is backed up by comprehensive test

programs, that allow a separate testing of single functions.

2. Description of proper use

Class 530 is an button sewing automat determined for processing light

to medium-weight material, i.e. fabrics made of textile fibres or leather.

Such sewing materials are used in the clothing industry and for the

production of home and car upholstery.

Furthermore, this button sewing automat can also sew so-called

technical seams. However, in this case the user has to estimate the

possible risks (preferably in cooperation with DÜRKOPP ADLER AG)

because on the one hand such fields of application are comparatively

rare and on the other hand there is an immense variety of possibilities.

According to the result of this estimation suitable safety measures may

have to be taken.

Generally only dry fabrics must be processed on this button sewing

automat. The material must not be thicker than 10 mm when

compressed by the lowered sewing feet. It must not include any hard

objects. The eye protection must be mounted when working with the

automat.

In general the seam is produced with sewing threads made of textile

fibres (cotton threads, synthetic threads or core threads) with the

following dimensions:

Class 530-211 threads of the dimension 50/3 - 120/3

If other threads are to be used, it is indispensable also in this case to

consider the possible risks and to take corresponding safety

measures, if necessary.

This button sewing automat must only be installed and operated in dry

and well-kept rooms. In case it is operated in other rooms which are

not dry and well-kept further measures can become necessary which

have to be agreed upon (see EN 60204-31: 1999).

We as manufacturers of industrial sewing machines take it for granted

that at least semi-skilled operators are working with our products so

that we can assume that all usual operations and their risks are known

to them.

3. Subclasses

Cl. 530-211 Single needle double lockstitch button sewing automat with thread

trimmer and thread wiper.

Equipped with a special button clamp for general button attaching

operations in outer garments and linen. The standard equipment of the

button clamp consists of a clamp insert that can sew buttons of a

diameter from 10 to 20 mm and standard thickness.

4. Optional equipment

The following optional equipment is available for the button sewing

automat 530:

Order No. Optional equipment

9822 51 002 6 Sewing light

9822 51 002 7 Table clamp

9870 00 102 1 Cable assembly (add-on kit socket for sewing light)

0510 59 004 4 Laser marking lights (3 lights)

0510 59 003 4 Supplementary laser light

0510 59 005 4 Push button

0531 36 074 4 Shank button clamp

Further optional equipments are available. Please contact our application centre (APC).

E-mail: marketing@duerkopp-adler.com

5. Stands

The following stand is available for the button sewing automat 530:

MG55 40 029 4 Stand package

Table top size 600 x 1060 mm

Stand height 1160 to 1305 mm

6. Technical data

Noise: Lc = 78 dB (A)

Emission value per work place according to DIN 45635-48-A-1-KL-2

Speed: 2.700 min-1

Fabric: G1 DIN 23328 two-ply

6.1 Technical data of the subclasses

Subclass: 211

Stitch type: 301

Hook type: oscillating hook

Needle system: DPx17 (135x17)

Needle size: [Nm] 80 - 110

Needle size [Nm] 90

standard:

Thread size: 50/3 - 120/3

Stitch length: [mm] dependent on seam pattern

Max. speed [min-1] 2700

Clamp stroke [mm] 9

Delivery

maximum 13

Sewing field size [mm]

max. in X-direction: dependent on clamp

max. in Y-direction:

Number of standard sewing 50

patterns

Number of storable

modifiable sewing patterns 40

Number of sewing pattern

sequence programs 25

Number of sewing patterns per

sewing pattern sequence program 20

Soft start: on / off option

Sewing drive: DC-Motor

Rated voltage: [V] 1 ~ 230V/ 50/60 Hz

Rated load: [kW] 0,45

Autres manuels pour 530

Table des matières

Autres manuels Duerkopp Adler Machine à coudre

Duerkopp Adler

Duerkopp Adler 742-115 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 550-8-2 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 1280i-6 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 2180-1 Guide de dépannage

Duerkopp Adler

Duerkopp Adler 609 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 550-16-23 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 523i Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 1230i-6 Guide de dépannage

Duerkopp Adler

Duerkopp Adler 580 Mode d'emploi

Duerkopp Adler

Duerkopp Adler 550-16-26 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 550-767 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 506-3 Mode d'emploi

Duerkopp Adler

Duerkopp Adler 524-101 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 739-23 Caractéristiques techniques

Duerkopp Adler

Duerkopp Adler 4220i-6 Guide de dépannage

Duerkopp Adler

Duerkopp Adler 291 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 669 Premium Mode d'emploi

Duerkopp Adler

Duerkopp Adler 739-1201 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 867-70 ECO Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 272-160362 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler 512/532 Manuel utilisateur

Duerkopp Adler

Duerkopp Adler SP 460 Mode d’emploi

Duerkopp Adler

Duerkopp Adler 743-105 s Instructions d'installation

Duerkopp Adler

Duerkopp Adler 525 Manuel utilisateur

Manuels Machine à coudre populaires d'autres marques

Riccar

Riccar RL634DE Manuel utilisateur

Singer

Singer 2517 Manuel utilisateur

Pfaff

Pfaff 3307-1 SERIES Manuel utilisateur

Janome

Janome Quilt Maker Pro 18 VERSA Manuel utilisateur

Siruba

Siruba C007JP Manuel utilisateur

Husqvarna Viking

Husqvarna Viking Designer SE Manuel utilisateur

Singer

Singer 148-5 Manuel utilisateur

IKEA

IKEA SY Manuel utilisateur

Pfaff

Pfaff 571 Manuel utilisateur

Singer

Singer 15-91 Manuel utilisateur

Brother

Brother BB370 Manuel utilisateur

Pegasus

Pegasus WT100 Series Manuel utilisateur

Reliable

Reliable 7100DB Manuel utilisateur

Pfaff

Pfaff 937 Manuel utilisateur

Singer

Singer 6038 Manuel utilisateur

Singer

Singer 413K Manuel utilisateur

Pfaff

Pfaff 1471 E1 Manuel utilisateur

Kenmore

Kenmore 16677 - Serger Sewing Machine Manuel utilisateur
