Duerkopp Adler 550-767 Manuel utilisateur
550-767
Gestalteter Arbeitsplatz für
Seitenairbag - Sollreißnaht
Engineered work station for
side airbag tearing seam
Bedienanleitung / Operating instructions
Aufstellanleitung / Installation instructions
Postfach 17 03 51, D-33703 Bielefeld Potsdamer Straße 190, D-33719 Bielefeld Sprache: D/ GB
Telefon +49 (0) 5 21/ 9 25-00 Telefax+49(0)521/9252435www.duerkopp-adler.com
1
2
Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.:
10/2007 Rev. index: 01.0 Printed in Federal Republic of Germany 0791 550034
Alle Rechte vorbehalten.
Eigentum der Dürkopp Adler AG und urheberrechtlich geschützt. Jede, auch auszugsweise
Wiederverwendung dieser Inhalte ist ohne vorheriges schriftliches Einverständnis der Dürkopp Adler AG
verboten.
All rights reserved.
Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner,
even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited.
Copyright © Dürkopp Adler AG - 2007
Übersicht Summary
Bedienanleitung
Aufstellanleitung
Serviceanleitung (0791 767651)
Bauschaltplan
9890 550004 B
Operating Instructions
Installation Instructions
Service Instructions (0791 767651)
Interconnection-diagram
9890 550004 B
Foreword
This instruction manual is intended to help the user to become familiar
with the machine and take advantage of its application possibilities in
accordance with the recommendations.
The instruction manual contains important information on how to
operate the machine securely, properly and economically. Observation
of the instructions eliminates danger, reduces costs for repair and
down-times, and increases the reliability and life of the machine.
The instruction manual is intended to complement existing national
accident prevention and environment protection regulations.
The instruction manual must always be available at the machine/sewing
unit.
The instruction manual must be read and applied by any person that is
authorized to work on the machine/sewing unit. This means:
–Operation, including equipping, troubleshooting during the work
cycle, removing of fabric waste,
–Service (maintenance, inspection, repair) and/or
–Transport.
The user also has to assure that only authorized personnel work on the
machine.
The user is obliged to check the machine at least once per shift for
apparent damages and to immediatly report any changes (including the
performance in service), which impair the safety.
The user company must ensure that the machine is only operated in
perfect working order.
Never remove or disable any safety devices.
If safety devices need to be removed for equipping, repairing or
maintaining, the safety devices must be remounted directly after
completion of the maintenance and repair work.
Unauthorized modification of the machine rules out liability of the
manufacturer for damage resulting from this.
Observe all safety and danger recommendations on the machine/unit!
The yellow-and-black striped surfaces designate permanend danger
areas, eg danger of squashing, cutting, shearing or collision.
Besides the recommendations in this instruction manual also observe
the general safety and accident prevention regulations!
General safety instructions
The non-observance of the following safety instructions can cause
bodily injuries or damages to the machine.
1. The machine must only be commissioned in full knowledge of the
instruction book and operated by persons with appropriate training.
2. Before putting into service also read the safety rules and
instructions of the motor supplier.
3. The machine must be used only for the purpose intended. Use of
the machine without the safety devices is not permitted. Observe all
the relevant safety regulations.
4. When gauge parts are exchanged (e.g. needle, presser foot, needle
plate, feed dog and bobbin) when threading, when the workplace is
left, and during service work, the machine must be disconnected
from the mains by switching off the master switch or disconnecting
the mains plug.
5. Daily servicing work must be carried out only by appropriately
trained persons.
6. Repairs, conversion and special maintenance work must only be
carried out by technicians or persons with appropriate training.
7. For service or repair work on pneumatic systems, disconnect the
machine from the compressed air supply system (max. 7-10 bar).
Before disconnecting, reduce the pressure of the maintenance unit.
Exceptions to this are only adjustments and functions checks made
by appropriately trained technicians.
8. Work on the electrical equipment must be carried out only by
electricians or appropriately trained persons.
9. Work on parts and systems under electric current is not permitted,
except as specified in regulations DIN VDE 0105.
10. Conversion or changes to the machine must be authorized by us
and made only in adherence to all safety regulations.
11. For repairs, only replacement parts approved by us must be used.
12. Commissioning of the sewing head is prohibited until such time as
the entire sewing unit is found to comply with EC directives.
13. The line cord should be equipped with a country-specific mains
plug. This work must be carried out by appropriately trained
technicians (see paragraph 8).
It is absolutely necessary to respect the safety
instructions marked by these signs.
Danger of bodily injuries !
Please note also the general safety instructions.
Contents Page:
Part 2: Installation Instructions, Class 550-767
1. Items delivered ............................................... 2
2. General and transport packing
2.1 Transportpacking .............................................. 3
2.2 Connecting the control unit (PC)...................................... 3
2.2.1 Checkdateandtime............................................. 3
2.3 Transportwithincustomerpremises ................................... 4
2.4 V-belttension................................................. 4
2.5 Mounting the reel stand ........................................... 5
2.6 Adjustingworkingheight .......................................... 6
2.7 Pedal adjustment ............................................... 6
3. Electrical connection
3.1 Nominalvoltage................................................ 7
3.2 Checkingthedirectionofrotation..................................... 7
3.3 Checkingthepositioning .......................................... 8
3.4 Settingparameters.............................................. 9
4. Pneumatic connection ........................................... 10
5. Lubrication
5.1 Topping up with oil .............................................. 11
5.2 Adjusting hook lubrication.......................................... 11
5.3 Oilingwicksandfelt............................................. 12
6. Sewing test .................................................. 13
2
1. Items delivered
What items are supplied depends on your order. Before setting-up
please check that all the required components are present.
–Basic equipment
–maintenance unit 1
–Knee switch 2
–sewing lamp
–Additional equipment
–Minor components in the accessory pack
2
12
2. General and transport packing
CAUTION:
The sewing unit may only be set up by trained specialist personnel.
2.1 Transport packing
The transport packing must be removed before setting-up.
–Remove the safety straps and battens from the upper part of the
machine, table and frame.
–Remove the safety block and straps from the motor.
2.2 Connecting the control unit (PC)
–Connect plug connector 1.
–Screw on supply lead 2.
2.2.1 Check date and time
Attention:
After switching on the machine, check the system date 3 without fail!
–Check the date and correct it if necessary.
–Check the time (AM or PM) and correct it if necessary.
2
3
3
1
2
2.3 Transport within customer premises
For internal transport the sewing machine and the control unit (PC)
must be lifted and moved by a suitable vehicle (e.g. a fork-lift).
All connections between the sewing machine and the control unit
should be undone if appropriate.
2.4 V-belt tension
After the machine has been moved the pre-set V-belt tension must be
checked.
The tension in the V-belt 1 must be such that it can be depressed by
approx. 10 mm by applying finger pressure in the middle.
–Loosen nuts 2 and 3
–Swivel drive until V-belt tension is correct.
–Retighten nuts 2 and 3.
4
12
3
2.5 Mounting the reel stand
The structure and position of the reel stand 3 can be seen in the
illustration.
–Fit reel stand 3 in the hole of the table plate and secure it with
nuts 1 and washers 2 supplied.
–Fit the reel holders and take-up arms. The reel holder and take-up
arm of each reel must be vertically in line.
–If necessary adjust retaining pins 4 to the height of the
needle-thread cone.
Once the attachment 5 has been secured, the needle-thread cone
must press on the switch 6.
2
5
312 1
6
45 4
2.6 Adjusting working height
The working height is adjustable between 685 mm and 1085 mm
(measured to the upper edge of the table plate).
The working height is factory-set to 790 mm.
–Adjust the working height as required by pressing button 1.
2.7 Pedal adjustment The angle of the pedal 3 should be such that the operator can
comfortably move it forwards and backwards.
–Undo screw 2.
–Adjust pedal 3 as required.
–Retighten screw 2.
6
32
1
