Dual XDMA350 Mode d'emploi
INSTALLATION/OWNER'S MANUAL
AM/FM/CD Receiver with Detachable Face
XDMA350
AUX
Front Panel Input
Made
for
~
~iPod CliPhone
~
Ill
2
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Removal Keys
Mounting Sleeve
Dashboard or
Mounting Kit
Head Unit
XDMA350 INSTALLATION
Preparation
Please read entire manual before installation.
Before You Start
•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.
•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom
directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.
Getting Started
•Removetrimringfromunit.
•Remove2transitscrewslocatedontopoftheunit.
•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting
sleeve.
•Installmountingsleeveintoopening,bendingtabstosecure.
•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.
•Certainvehiclesmayrequireaninstallationkitand/or
wiringharnessadapter(soldseparately).
•Testforcorrectoperationandslideinto
mountingsleevetosecure.
•Snaptrimringintoplace.
In
3
XDMA350 INSTALLATION
Wiring Diagram
Rear Preamp Output
Connect to amplifier RCA input
Antenna Connector
RCA Cable
(sold separately)
AMP
BLUE
BLACK
RED
YELLOW
Remote Turn-On
Connect to amplifier or power
antenna. Insulate wire if not used.
Ground
Connect to vehicle
chassis ground.
Accessory
Connect to ignition
circuit or switched 12 volt source.
Memory
Connect to battery
circuit or constant 12 volt source.
Right Front
Gray/Black (-)
Gray (+)
Left Front
White/Black (-)
White (+)
Right Rear
Violet/Black (-)
Violet (+)
Left Rear
Green/Black (-)
Green (+)
10 AMP
AGC Fuse
FUSE
Whenreplacingthe
fuse,makesurenew
fuseisthecorrecttype
andamperage.Using
anincorrectfusecould
damagetheradio.
TheXDMA350usesone
10ampAGCfuselocated
in-lineonthewiring
connector.
In
4
XDMA350 OPERATION
Control Locations - Receiver
Release
Volume
Mute/Power
Tune/TrackDown
Source
Tune/TrackUp
Eject
USBPort
AuxiliaryInput
Preset6/FolderUp
Preset5/FolderDown
Preset4/Play/Pause
Preset3/Intro
Preset2/Random
Preset1/Repeat
Band/Select
Display/Escape
Audio/Menu
1 2 3 4 6 7
16 9
8
15 14 13 12 11 101718
5
110
2 11
3 12
4 13
514
615
7 16
8 17
9 18
In
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
5
XDMA350 OPERATION
Control Locations - Remote
Display/ESC
Tune/TrackDown
Band/Select
Mute/Power
VolumeUp
Source
Tune/TrackUp
VolumeDown
Audio/Menu
1 6
2 7
3 8
4 9
5
2
3
1
8
7
9
456
0
0
0
0
0
0
0
0
0
In
6
XDMA350 OPERATION
Press oranyotherbutton(exceptEJECT)toturntheunit
on. Press toturntheunitoff.
Press SOURCE toselectbetweenAM/FM,CDplayer,
auxiliaryinput,USBandoperationofiPod®/iPhone®.Modes
ofoperationareshowninthedisplay.
NOTE:CD,USBandoperationofiPodmodeswillnotappear
unlessaCDisinsertedorUSB/iPoddevicesareconnected.
TheXDMA350offersa3.5mmportonthefrontpanel.Using
a3.5mmmale-to-malecable,connectaudiodevice,MP3
player,etc.totheauxilaryinput.PressSOURCE toselect
AUX-INmode.
Adjustvolumeusingvolumeknob(00-46).
Press DISPtoselectbetweenclockanddifferenttypesof
information,suchasradiofrequency,CDtrack/elapsedtime
orMP3/WMAsonginformation.
Press RESETuponinitialinstallationorifabnormal
operationoccurs.Resetbuttonislocatedbehindthefront
panel.
Withtheuniton,pressandholdDISPuntiltheclockbegins
toflash,thenrelease.PressTUNE
nn
toadjustthehours
and TUNE
ll
toadjusttheminutes.PressDISP momen-
tarilytosavetheselectedtime.
Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency
spacingmode(10:00PM).InEuropeanfrequencyspacing
mode,theclockwilldisplay24-hourtime(22:00).
PressandholdAUDIO/MENUformorethan3secondsto
accessthesetupmenu.PressAUDIO/MENUmomentarily
toselectbetweenthemenufunctionsandrotatethevolume
knobleft/righttoadjustoractivatethedesiredfunction.
Power On/Off
Changing Modes
Auxiliary Input
Volume
Display
Reset
Set the Clock
12/24-hour Clock
Setup Menu
General Operation
In
7
XDMA350 OPERATION
General Operation - Setup Menu
Menu Function Options Action
Auto Station
Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe
currentband.(Tuner mode only)
Local/Distance
Tuning
LOCALOFF Activatesdistancetuning(Tuner mode only).
LOCALON Activateslocaltuningforstrongstationreceptiononly(Tuner
mode only).
Tuner
Frequency
Spacing
FREQUSA ProgramstheunittoUSAtunerspacing.
(200kHzforFMand10kHzforAM).(Tuner mode only)
FREQEURO ProgramstheunittoEuropeantunerspacing.
(50kHzforFMand9kHzforAM).(Tuner mode only)
Selectable iPod
Control
IPODFULL ProgramstheheadunittoadvancedcontroloftheiPod/
iPhonedevice.(Operation of iPod mode only)
IPODBASIC
ProgramstheheadunittomanualcontroloftheiPod/iPhone
deviceandallowsmusictobecontrolledfromtheiPod/
iPhonedevice.(Operation of iPod mode only)
Clock
Display
CLOCKOFF Programsunittonotdisplaytheclockwhenthepowerisoff.
CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.
Auxiliary Input AUXON Enablesthefrontpanel3.5mmauxiliaryinput.
AUXOFF Disablesthefrontpanel3.5mmauxiliaryinput.
Beep
Confirmation
BEEPOFF Disablestheconfirmationbeep.
BEEPON Enablestheconfirmationbeep.
Programmable
Turn On Volume PRO-VOL# Programsunittoalwaysturnonataspecificvolume
(defaultisOFF).Anyvolumelevel1-46canbeselected.
Power on
Message
MSGOFF Disablespoweronmessage.(example:GOODMORNING)
MSGON Enablespoweronmessagetobedisplayed.
Scrolling
Option
SCROLL15S Programsunittoscrollinformationonceevery15seconds
(default).
SCROLLONCE Programsunittoscrollonce,thenshowthefirst10
charactersondisplay.
SCROLLON Programsunittoscrollcontinuously.
SCROLLOFF Programsunittoshowthefirst10charactersonthedisplay.
Illumination
Dimmer
DIMMERHI Programsunittothebrightestilluminationlevel.
DIMMERMED Programsunittothemiddleilluminationlevel.
DIMMERLOW Programsunittothedimmestilluminationlevel.
Demonstration
Mode
DEMOOFF Disablesthedemonstrationmode.
DEMOON Enablesthedemonstrationmessage.
In
8
XDMA350 OPERATION
Press AUDIOmomentarilytoselectbetweenBass,Treble,
Balance,Fader,EqualizerandSourceVolumeLevel.
Press AUDIO until BASSappearsthenrotatevolumeknob
left/righttoadjust(-6minimum/+6maximum).
Press AUDIO until TREBLEappearsthenrotatevolumeknob
left/righttoadjust(-6minimum/+6maximum).
Press AUDIO until BALappearsthenrotatevolumeknob
left/righttoadjust(BALL12-BALR12).
BALEVENrepresentsequalbalance
Press AUDIO until FADERappearsthenrotatevolumeknob
left/righttoadjust(FADERF12-FADERR12).
FADEVENrepresentsequalfader
Press AUDIO until EQappearsthenturnthevolume knob
tocyclethroughthefollowingequalizationcurves:FLAT
(default),POP,JAZZ,CLASSIC,BEAT,ROCKandUSER.
AnymanualadjustmenttotheBassorTreblesettingsare
automaticallysavedasUSER.
Thesourcevolumelevelcontrolallowsagainadjustment
foreachaudiosource:AM,FM,CD,AUX,operationofiPod
andUSB.Setthesourcevolumelevelforeachmode,
dependingontherelativevolumeofeachaudiosource.
Tosetthesourcevolumelevel,pressAUDIOuntilSRC
LEVELappears.Afteronesecond,thecurrentmodewill
appearonthedisplay.Turnthevolumeknobtoadjust
theaudiolevelofthecurrentsource(-6minimum/+6
maximum).
Note: Onlythecurrentmodewillbeavailablefor
adjustment.Toadjustanothermodeofoperation,press
SOURCE untilthedesiredmodeisselected,thensetthe
sourcevolumelevelforthatmode.
Audio
Bass
Treble
Balance
Fader
Equalizer
Source Volume Level
General Operation
BASS TREBLE BALANCE FADER EQUALIZER SOURCE LEVEL
IIJ
+ + J
9
XDMA350 OPERATION
Seek Tuning
Manual Tuning
Band
Storing and Recalling
Station Presets
Press TUNE
nn
or TUNE
ll
formorethanonesecond
toseektothenextstrongstation.
Press TUNE
nn
or TUNE
ll
momentarilytochange
radiofrequencyupordownonestepatatime.Pressand
holdtoadvancequickly.
Press BANDtoselectbetweenFM1,FM2,FM3,AM1and
AM2bands.
Upto18FMstationsand12AMstationscanbestored.To
storeastation,selectthedesiredbandandstation.Press
andholdthedesiredpresetbutton(1-6)formorethan
2seconds.Whenstored,thepresetnumberwillappearin
thedisplay.Thestationcanberecalledanytimebypressing
thecorrespondingpresetbutton.
AM/FM Tuner Operation
In
10
XDMA350 OPERATION
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Intro
Repeat
Random
CD-R/CD-RW Compatibility
Withthelabelfacingup,insertastandardsizeCDintothe
CDslot.TheCDwillautomaticallybeginplayback.
Press EJECTtoejecttheCD.Theunitwillchangeto
previousmodeofoperation.Ifthediscisnotremoved
within10seconds,theunitwillreloadthedisc.Theunit
doesnothavetobeturnedontoejectCD.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
tofastforward
orreverseatrack.
Press
l
/
II
totemporarilystopCDplayback.
Press
l
/
II
againtoresumeplayback.
Press INT toentertheIntromenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsthefirst10secondsofeachtrack.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•ALL-PlaysalltracksonCD.
•TRACK-Continuouslyrepeatsselectedtrack.
Press RDM toentertheRandommenu,thenturnthe
volumeknobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
SomeCD-RsandCD-RWsmaybeincompatiblewiththis
unit,dependingonmediatypeandrecordingmethod.In
addition,thefollowingCDsmaybeincompatiblewiththis
unit:
CDsexposedtoextremetemperaturesordirectsunlight
forextendedperiodsoftime,CDsrecordedinwhicha
recordingsessionfailedorare-recordingwasattempted
and,orencryptedorcopy-protectedCDswhichdonot
conformtotheaudioCD-DAredbookrecordingstandard.
CD Player Operation
