DSPPA MP 1500 Manuel utilisateur

P.A.SERIES

Public Address Amplifiers MP1500

MP2000

MP2500

Operation Instructions

Welcome to use the public address system manufactured by DSPPA Company. For the better application of this

equipment, please read the operation instruction carefully prior to use.

Guangzhou DSPPA Audio Co., Ltd.

http://www.DSPPA.com

Public Address Amplifier

POWER CLIP SIGNAL PROT TEMP

VOLUME

010

MP2500

PROFESSIONAL AMPLIFIER

FEATURES

Transformer isolated 100V, 70V and P1 outputs.

5 LED indicator for status display.

XLR socket and 6.35mm jack for link convenient.

Output circuit shorting protection & display.

Series amplifiers of high output power available.

AMPLIFIER FRONT VIEW

1. AC power switch(1 is power on and the “power LED” is on )

2. POWER LED indicator

3. CLIP LED indicator (Please reduce the gain to prevent severely clipped waveforms reaching the

loudspeakers)

4. SIGNAL LED indicator (Output level)

5. PROT LED indicator (DC or output circuit shorted indicator)

6. TEMP LED indicator

(high temperature indicator)

7. Unit’s fan exhaust window

8. Volume (input attenuator)

Public Address Amplifier

POWER CLIP SIGNAL PROT TEMP

VOLUME

010

MP2500

1 2 3 4 5 678

PROFESSIONAL AMPLIFIER

AMPLIFIER REAR VIEW and CONNECTIONS

COM

INPUT LINK

AUDIO OUTPUTS

P1 70V

~220 Hz/10A

100V

F A

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION!

1 3

246

Pre-amp.

MP9811P Another Amp.

MP series

1110

7or or

SER.

NO.

TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK,DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR

MOISTURE.

为了减少火灾或触电的危险,

不要将设备放在能被雨淋或潮湿的地方.

广州市迪士普音响科技有限公司

Guangzhou DSPPA Audio Co.,Ltd.

MP1500.2000.2500 SERIES

PROFESSIONAL AMPLIFIER

纯后级广播功放

MP1500

F4AL F6AL

MP2000 F8AL

MP2500

DSPPA

F A 38V 43V 51V

1. fan intake window

2. COM. output

3. P1 output

4. 70V output

5. 100V output

6. 220V AC fuse

7. XLR input

8. 6.35mm socket input

9. 6.35mm socket link

10. XLR link

11. 220VAC power cord

Pre-amp.

MP9811P

Another Amp.

MP series

OPERATING PRECAUTIONS

1. Make sure the AC mains voltage is correct and is the same as that printed on the rear of the amplifier.

Damage caused by connecting the amplifier to improper AC voltage is not covered by the three-year US

warranty.

2. Make sure the power switch is off before making any input or output connections. It is always a good

idea to have the gain controls turned down during power-up to prevent speaker damage if there is a high

signal level at the inputs.

3. If the PROT Led goes on steadily while power has been turned on and signal has been fed, there must a

trouble of output shorted. Please turn it off and correct the trouble then turn it on again.

CONNECTING INPUTS

Input connections are made via either the 3-pin XLR-type

connectors (Figure1/2 ) or 6.35mm sockets on the rear side of the

amplifier.

CONNECTING OUTPUTS

Output terminals are on the rear panel. Load can be

connected using banana plugs or spade lugs. A black binding post

is considered “COM”, while the three red binding posts are

considered “hot”.

Usually make use of “fixed voltage” (70V or 100V) output,

while the each loudspeaker should use a separate transformer and

the total power of connecting loudspeakers should be less than rated power of amplifier.

Loudspeaker which close to the amplifier also make use of P1 output, while the total resistance of connecting

loudspeakers should accord with 4Ω.

Note:

When connecting loudspeakers, it is better to use one pair of output terminals only.

Never connect the “hot” terminals together.

ground signal

Figure 1 3-pin XLR-male connectors

signal ground

Figure2 3-pin XLR-female connectors

SPECIFICATIONS

MODEL MP1500 MP2000 MP2500

Rated output power

350W 450W 650W

Input sensitivity ≤1000mV

S/N Ratio ≥77dB

Frequency Response 80Hz—16kHz (±3dB)

distortion ≤1% （1kHz，normal operating status）

Indicators “power”, “clip”, “signal”, “prot”, and “temp” LEDs.

Protection High temperature, DC voltage & Output Circuit Shorting.

Power Requirements AC220-240V/50-60Hz

Rated power Consumption 700W 850W 1000W

Outer Packing Size (L×W×H mm) 530×440×195

Unit Size (L×W×H mm) 483×380×88

Gross Weight 17kg 19.5kg 20.5kg

Net Weight 14.5kg 17kg 18kg

Specifications are subject to change without notice.

CAUTION

When the “Power switcher” is off, please pull out the power cord from the socket. Please keep the

equipment out of water.

To reduce the risk of electric shock, do not remove the cover.

No user parts inside. Refer servicing to qualified service personnel.

The symbol on rear panel indicates hazardous live. The connection of these terminals must be operated

by the instructed person.

The unit connects

to the mains by the plug. Pull out the plug when the unit is in fault or danger status. So the

socket for the unit plugging must be set in the place can be easy to plug into and pull out the plug.

Guangzhou DSPPA Audio Co. Ltd.

公共广播系统.

纯后级广播功放 MP1500

MP2000

MP2500

使用说明书

欢迎使用 DSPPA 公共广播系统。为了您能更好的使用本设备，使用前请仔细阅读本说明书。

广州市迪士普音响科技有限公司

http：//www.DSPPA.com

Public Address Amplifier

POWER CLIP SIGNAL PROT TEMP

VOLUME

010

MP2500

PROFESSIONAL AMPLIFIER

性能特点

100V、70V 定压输出和 P1 输出（平衡、不接地）。

5 单位 LED 显示器，作状态显示。

6.35mm 插口和 XLR 插口可方便地实现环接。

输出短路保护并示警。

一系列大功率纯后级可供选择。

前面板

1. 交流电源开关（按下 1为电源接通状态且电源指示灯亮）

2. 电源指示灯

3. 削顶指示灯(为避免严重削顶请适当降低增益)

4. 信号指示灯(输出电平)

5. 保护指示灯(直流或短路保护 )

6. 温度指示灯(超温指示)

7. 通风散热窗

8. 音量控制旋钮

Public Address Amplifier

POWER CLIP SIGNAL PROT TEMP

VOLUME

010

MP2500

1 2 3 4 5 678

PROFESSIONAL AMPLIFIER

后面板及连接

COM

INPUT LINK

AUDIO OUTPUTS

P1 70V

~220 Hz/10A

100V

F A

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION!

1 32 46

Pre-amp.

MP9811P Another Amp.

MP series

1110

7or or

SER.

NO.

TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK,DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR

MOISTURE.

为了减少火灾或触电的危险,

不要将设备放在能被雨淋或潮湿的地方.

广州市迪士普音响科技有限公司

Guangzhou DSPPA Audio Co.,Ltd.

MP1500.2000.2500 SERIES

PROFESSIONAL AMPLIFIER

纯后级广播功放

MP1500

F4AL F6AL

MP2000 F8AL

MP2500

DSPPA

F A 38V 43V 51V

1. 风扇口

2. 输出公共端

3. P1 输出

4. 70V 输出

5. 100V 输出

6. 220V 交流保险丝

7. 卡隆输入口

8. 6.35mm 输入插口

9. 6.35mm 环接插口

10. 卡隆环接插口

11．220V 交流电源线

前置放大器

MP9811P 其他功放

MP series

操作注意事项

1. 请确认电源电压与本机相符，由电压不符造成的损坏不在保修的范围。

2. 所有输入输出线连接好之前，请不要通电；通电前请把音量调至最小以防损坏扬声器。

3. 当通电并输入信号后，如果保护指示灯(PROT)点亮，说明有输出短路故障。此时应立即切断电源，

排除故障后再重新通电。

输入连接

所有输入均应连接于机器后面板的卡隆插口（图 1）或 6.35mm 插

口。

输出连接

输出端子在后面板，可用香蕉插或铲形插连接。黑色为公共端，

红色为热端。

通常应使用“定压”(70V、100V)端子输出，此时各个扬声器应带

线间变压器，扬声器的总功率应小于功放的额定输出功率。

扬声器在近距离配置时也可用 P1 端子输出，此时相应的扬声器的总阻抗应不低于 4Ω。

注意：

只宜选用一对输出端子；

任何时候都不应把两个“热端”连接在一起。

地（冷端）信号（热端）

图1 三线卡隆公插

信号（热端）

地（冷端）

图2 三线卡隆母插

装箱清单

序号清单数量

1 纯后级广播功放 1 台

2 保修卡 1 份

3 合格证 1 份

4 说明书 1 份

5 包机垫圈 4 个

6 白色 5×19 半沉头十字机丝 4 个

7 保险盒 1 个

8 亮黑 3×8 半圆头十字带介机丝 2 个

9 1500MM/6.3 对莲花头 1 个

10 6.3 转莲花插头 1 个

性能规格

规格

MP1500

MP2000

MP2500

额定输出功率

350W

450W

650W

最小源电动势

≤1000mV

信噪比

≥77dB（宽带）

频率响应

80Hz—16kHz (±3dB)

总谐波失真

≤1% （1kHz，正常工作条件）

指示灯

“电源”, “削顶”, “信号”,“保护” 和“超温”

保护

高温, 直流, 短路

电源

AC220-240V/50-60Hz

额定功耗

700W

850W

1000W

外包装尺寸（L×W×H mm）

530×440×195

机器尺寸（L×W×H mm）

483×380×88

毛重

17kg

19.5kg

20.5kg

净重

14.5kg

17kg

18kg

性能规格如有改变，恕不另行通知。
