DSE XH1137 Manuel utilisateur

XH1137

PCI ADSL Modem

Installation Guide

publication may be reproduced, transmitted, transcribed, stored in a

retrieval system, or translated into any language or computer

language, in any form or by any means, electronic, mechanical,

magnetic, optical, chemical, manual or otherwise, without the prior

written permission of DSE(NZ)Ltd.

Disclaimer

DSE(NZ)Ltd makes no representations or warranties, either expressed

or implied, with respect to the contents hereof and specifically

disclaims any warranties, merchantability or fitness for any particular

purpose. Any software described in this manual is sold or licensed "as

is". Should the programs prove defective following their purchase, the

buyer (and not DSE(NZ)Ltd, its distributor, or its dealer) assumes the

entire cost of all necessary servicing, repair, and any incidental or

consequential damages resulting from any defect in the software.

Further, DSE(NZ)Ltd reserves the right to revise this publication and to

make changes from time to time in the contents hereof without

obligation to notify any person of such revision or changes.

All brand and product names mentioned in this manual are trademarks

and/or registered trademarks of their respective holders.

Warning

This is a Class A product. In a domestic environment, this product may

cause radio interference in which case the user may be required to

take adequate measures.

XH1137 – DSE ADSL PCI Modem

Contents

1INTRODUCTION...........................................................................4

2INTERNET SECURITY.................................................................4

3ADSL SERVICE............................................................................5

4FEATURES & SPECIFICATIONS.................................................6

5TELCO CONNECTION SETTINGS..............................................7

5.1 TELECOM & XTRA SETTINGS.....................................................8

5.2 OTHER TELCOS & ISP SETTINGS..............................................9

6HARDWARE INSTALLATION....................................................10

6.1 ABOUT ADSL SPLITTER & FILTERS.........................................10

6.2 INSTALLATION OF THE DSE ADSL LINE FILTER.......................11

6.2.1 Filter Installation Rules..................................................11

6.3 IMPORTANT ANTISTATIC PRECAUTIONS....................................12

6.4 PCI CARD INSTALLATION.........................................................13

7SOFTWARE INSTALLATION.....................................................15

7.1 LOCATION OF DRIVER FILES.....................................................15

7.2 WINDOWS 95 DRIVER INSTALLATION.......................................16

7.3 WINDOWS 98 DRIVER INSTALLATION........................................18

7.4 WINDOWS 2000 & XP DRIVER INSTALLATION .........................20

7.5 WINDOWS ME DRIVER INSTALLATION .....................................22

7.6 WINDOWS NT4.0 USERS........................................................24

7.6.1 Installation for RFC1483/1577.........................................24

7.6.2 Installation for RFC2364..................................................27

8NETWORKING SETTINGS........................................................30

8.1 WINDOWS 95/98.....................................................................30

8.1.1 Configuring RFC1483/1577/2364 .................................30

8.1.2 Configuring RFC1483/1577 ..........................................31

8.1.3 Configuring RFC2364....................................................33

8.2 WINDOWS 2000 & XP............................................................34

8.2.1 Configuring RFC1483/1577/2364................................. 34

8.2.2 Configuring RFC1483/1577.......................................... 35

8.2.3 Configuring RFC2364 ................................................... 36

8.3 WINDOWS ME....................................................................... 37

8.3.1 Configuring RFC1483/1577/2364................................. 37

8.3.2 Configuring RFC1483/1577.......................................... 38

8.4 WINDOWS NT4.0................................................................... 41

8.4.1 Configuring RFC1483/1577/2364................................. 41

8.4.2 Configuring RFC1483/1577.......................................... 42

8.4.3 Configuring RFC2364................................................... 43

9SUPPORT................................................................................... 44

10 GLOSSARY OF TERMS......................................................... 45

XH1137 – DSE ADSL PCI Modem

1Introduction

The DSE PCI ADSL Modem is an “always on” high-speed broadband

device for connection to the Internet. Using existing twisted pair

telephone lines, ADSL technology provides data rates over 100 times

the speed of a traditional analog modem, without an interruption in

telephone service. ADSL is the ideal solution for high-bandwidth

applications such as access to a corporate network, Internet access,

and video delivery.

The DSE ADSL Modem provides line speeds of up to 8Mbps

downstream (to your computer) and up to 1Mbps upstream (to the

Internet), depending on telephone line conditions. A point-to-point

connection is established between the computer and the central office

of the ADSL service provider, the computer is always connected - this

eliminates dial-up time and simplifies connectivity issues.

The DSE PCI ADSL modem is an easy to install Plug & Play PCI

device that connects directly to your telephone line via a standard BT

telephone plug. The intuitive software interface allows you to easily

configure the necessary settings with ease.

2Internet Security

As ADSL provides a permanent connection from your computer to the

Internet, the possibility exists for hackers and viruses to obtain data

from your computer. To this end, we strongly recommend that you

install suitable Firewall software on your computer. The software

should be installed and configured according to the manufacturers

instructions and should be running the entire time your DSE ADSL

Modem is connected to the Internet. For more information on this

topic, please contact your local Dick Smith Electronics store or search

the Internet using the words “Firewall Software Security”. Suitable

search sites include www.google.com or www.yahoo.com

3ADSL Service

In order to use the DSE ADSL Modem you must first have the ADSL

service established at your premises with your local telephone

company, or an Internet Service Provider (ISP). To check if the service

is available in your area:

•Visit your local Dick Smith Electronics store where an employee

will help you to check ADSL service availability. If you wish to sign

up for a Telecom or Xtra ADSL service while you are in-store, the

Telecom account holder will need to be present along with a

current Telecom bill.

•Alternatively visit http://adsl.dse.co.nz and click on the “ADSL –

Services & Links” category. From here, select “ADSL - Check

Service” and then enter your phone number into the appropriate

panel. After a short while you will be advised if the service is

available or not. If the service is available, you can sign up for any

Telecom or Xtra service providing you have a phone account

handy. If the service is not available, you have the option to

“register your interest”. By informing Telecom of your interest, you

may help speed up the installation of the ADSL service in your

area.

•If you have inadvertently purchased any DSE ADSL product and

cannot get the service or it is not suitable, simply return the

product to any Dick Smith Electronics store, in new condition,

complete with packaging and receipt, for a full refund.

XH1137 – DSE ADSL PCI Modem

4Features & Specifications

ADSL Modem Features

•Controllerless Internal PCI ADSL Modem

•ANSI T1.143 Issue 2, ITU-T G.992.1 (G.dmt) and ITU-T G.992.2 (G.lite) compliant

•Discrete Multi-Tone (DMT) line encoding scheme

•Full-rate transmission at up to 8 Mbps downstream and 1 Mbps upstream

•G.lite transmission at up to 1.5 Mbps downstream and 512 Kbps upstream

•Plug-n-Play Installation

•PCI 2.1 Power Management Specification compliant

•Compliant with PCI Local Bus Specification Revision 2.2

•Software upgradable for future feature enhancement

ADSL Chipset

•P4601 ADSL PCI Interface Chip

•11627 Falcon2P DMT Data Pump Chip

•20431 Analog Front End Chip

•20441 Line Driver Chip

ADSL Protocol Support

•RFC-1483 Ethernet Bridging over ATM PVCs

•RFC-1577 Classical Internet Protocol over ATM

•RFC-2364 PPP over ATM PVCs

Operating System Support

•Windows 95, Windows 98, Windows 98SE, Windows 2000, Windows Millenium,

Windows XP & Windows NT 4.0

PTT Approval

•New Zealand Telepermit – PTC 272-01-019

Connectors

•1 x RJ11 Telephone socket for Telephone line

Temperature

•Operating : 10oto 45o Celsius (50o to 113 o Fahrenheit)

•Non-Operating : -25o to 70o Celsius (13 o to 158o Fahrenheit)

Humidity

•Operating : 30% to 80% Relative Humidity (Non-Condensing)

•Non-Operating : 10% to 95% Relative Humidity (Non-Condensing)

Minimum System Requirements

•Pentium II 300MHz (min) with 64MB RAM

Package contents.

Carefully unpack and remove the contents. If any if the following items are missing or

damaged, contact the Dick Smith Electronics store that you purchased the modem

from.

•1x XH1137 DSE ADSL PCI Modem

•1x Telephone line cord with RJ11 plugs at either end

•1x RJ11 to BT Phone Plug Adapter

•1x Installation Guide

•1x Driver CD with Application Software

5Telco Connection settings

High Speed ADSL Internet is a complex service generally provided to

you by 2 companies:

1. A telecommunications company (like Telecom) who’s

responsibility it is to send and receive high speed computer data

from your premises to your nearest phone exchange.

2. An Internet Service Provider (ISP like Xtra) who is responsible for

connecting your high-speed data from the phone exchange to the

Internet.

XH1137 – DSE ADSL PCI Modem

5.1 Telecom & Xtra Settings

At the time of writing, Telecom New Zealand has issued the following

information to customers wishing to use their JetStream & JetStart

ADSL services.

•Operating Mode set to: G.992.1, G.DMT or ANSI T1.413 iss 2

(but not G.Lite or G.992.2)

•VPI Value set to: 0

•VCI Value set to: 100

•Protocol set to: PPP over ATM (PPPoA) (RFC2364) with VC-

multiplexed encapsulation

•Username and password are set according to the user ID for the

service you are trying to connect to (either ISP or corporate). The

user name must be set to the user ID followed by an @ symbol

followed by the domain name eg: [email protected]. Note that for the

Xtra service (JetStart & JetStream) the customer user ID has

".xadsl" appended to it ie: "[email protected]". Other ISPs

may or may not have similar requirements – you will need to check

this with your ISP.

•Primary DNS: 202.27.184.3

•Secondary DNS: 202.27.184.5

5.2 Other Telcos & ISP Settings

Other telecommunications companies may offer alternative High

Speed ADSL Internet services supported by this modem.

In the spaces provided, write down the various required settings as a

handy reference. If you are unsure, check with your ISP.

1. Common Internet Protocols used internationally by ADSL service

providers are indicated in the following table. Check with your ISP and

tick the protocol you will be installing.

Standard Protocol Selection Tick

RFC1483 Bridged Ethernet over ATM q

RFC2364 Point-to-Point Protocol over ATM q

RFC1577 Classical Internet Protocol over ATM q

RFC2516 Point-to-Point Protocol over Ethernet q

2. Having determined the ADSL protocol you will be installing, now gather

the connection information supplied by your Telecommunications

Company and or ISP.

VPI value:_________

VCI value: _________

Framing: qVC/MUX qLLC/SNAP

Mode: qANSI T1.413 qITU G.lite qITU G.dmt

For RFC1483 or 2516 For RFC2364 or 1577

Host: User Name:

Domain: Password:

Gateway: Host or IP Address:

IP Address:

Subnet Mask:

DNS/ server add:

Table des matières

Autres manuels DSE Modem

DSE

DSE XH1172 Manuel utilisateur

DSE

DSE XH1148 Manuel utilisateur

DSE

DSE XH9972 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
