Steel Travel Chair

(TR39-ESV)

Instructions for use

Page 2 of 12TR39-ESV Steel Travel Chair (Issue 2021-05 rev1)

introduction

parts description

1/2 FOLD

BACK

MECHANISM

PARKING

BRAKE

STEPPER

TUBE

BACK

REST

ARM

REST

FOOT

REST

FRONT

CASTOR

PUSH

HANDLE

(TR39-ESV)

The TR39-ESV steel travel chair range is intended to assist the transport of

users with mobility diculties. These wheelchairs are designed for occasional

or frequent use, and can be used indoors and outdoors, but should not be used

on rough terrain. Over-loading the wheelchair is the only known

contraindication, although others may be speciﬁc to an individual or care

environment.

The wheelchair can be manually moved forward and in reverse. The

wheelchairs are transit models, to be operated by the wheelchair attendants

while the occupant is seated. The wheelchairs can support users of up to 115 kg

(18 stone).

These instructions should be read carefully before using the wheelchair. This

product does not have a service manual. The only parts for user assembly are

the footrests. Remove all packaging and stand the wheelchair on the ground.

Separate the arm rests to open the wheelchair, then push the seat down ﬁrmly.

Once the seat is secure and the footrests are attached, the wheelchair is ready

for use.

TR39-ESV Steel Travel Chair (Issue 2021-05 rev1) Page 3 of 8

symbolspreparing for use

A risk assessment must also be performed to assess suitability of the device

for the user. This assessment should include, but not be limited to:

• Small adults (and children)

• Users (and attendants) who lack capacity

• Very active occupants

• Unauthorised access to the wheelchair

Attendants are responsible for determining that they are both mentally and

physically capable of using the wheelchair with minimal risk of harm.

Maximum occupant mass – Exceeding this value marked on your

device can damage the product and put users at risk of harm.

Warning

This wheelchair must not be used as a seat in a motor vehicle.

Users should always transfer to the vehicle's seat and the

wheelchair should be safely stowed away.

Using Parking Brakes

Push the handle on the brake unit until locked in

place. To release the brake, push the handle in the

opposite direction. The brakes should always be

applied when the wheelchair is stationary.

Note: The brake may be visually dierent from shown.

Fitting and Altering the Footrests

To ﬁt the footrests, place them on the two receiver

posts on the frame. Swing inwards until they lock in

position. To remove, press the chrome lever whilst swinging the footrest out.

It is important to attain the correct leg position for optimum comfort.

To adjust the footrest height, turn the bolt at the

bottom clockwise using a

spanner (1). Adjust the

footplate to lengthen or

shorten (2), then turn

anticlockwise to tighten (3).

Note: Always ensure the bolt

is suciently tightened after

adjustment.

LOCK

UNLOCK

Using

parking

brakes

Attaching

footrests

Adjusting

footrests

Page 4 of 8TR39-ESV Steel Travel Chair (Issue 2021-05 rev1)

transfer and use

Before using the wheelchair, read the safety notices below;

• Do not exceed the 10º maximum gradient. Use slow speeds

and do not reverse down a gradient.

• Do not use on escalators.

• The wheelchair is only suitable for single occupancy.

• Keep your feet on the footrests when moving. Do not stand on

the footrests. Overloading can cause harm to the occupant.

• Ensure that ﬁngers and objects do not get caught in the wheel

spokes or any other moving parts during use and assembly.

• Maintain proper balance at all times. Users should not move

their centre of gravity out of the seating area or reach further

than their arm’s length.

• Parking brakes should always be applied when transferring.

• Be aware of hazards in your environment, such as narrow

doorways, steps, household appliances, children’s toys, etc.

• A risk assessment must be performed by a competent person

to ensure the wheelchair is suitable for the user. Consult a

healthcare professional before using assistive medical devices.

• Keep away from heating and ignition sources which may raise

surface temperatures or cause a ﬁre.

Transfer: When transferring in and out of the seat, move the seats as

close as possible to each other. Attendants should always engage parking

brakes during transfer and fold away footrests. If required, attendants are

responsible for being suitably trained and competent to lift occupants with

minimal risk of harm. Good health and safety practice must always be used.

Propelling: Following the safety advice above, attendants should push

from behind using the handgrips. To slow down, apply reverse pressure to the

push handles.

When stationary, the brakes should always be applied.

using a wheelchair belt

Belts are often used to restrain wheelchair occupants during normal use.

However, belts are not necessary parts of this device. Any belts used should

be adjusted to suit each user. When fastened, they should be tight without

causing discomfort or undue pressure. Belts may not be suitable for all users.

Seek professional medical advice before using a wheelchair belt.

Page 5 of 8TR39-ESV Steel Travel Chair (Issue 2021-05 rev1)

steep terrain, kerbs and steps

Steep terrain: These wheelchairs are not designed for use on gradients

beyond 10°. When on a slope, avoid swerving or sudden changes in movement.

Over kerbs: Attendants push down on the stepper tube with a foot to raise

the front castors (when mounting a kerb for example).

To mount, approach the kerb head-on. The attendant uses the stepper tube to

raise the front castors, and lower the front castors on the raised kerb. Then

push the wheelchair forward, lifting it up slightly to mount the kerb if required.

To go down, align the front castors with the kerb edge. Using the tube to keep

the castors raised, tip the user slightly back and slowly lower the wheelchair.

Multiple steps: The wheelchair is not designed to mount staircases, so may

require carrying if no elevators or ramps are available. Attendants are

responsible for being suitably trained and competent to lift the wheelchair with

minimal risk of harm. Do not carry using the handles or any removable sections.

Common misuse

Do not lean or push down on the push handles, as this can

damage the wheelchair.

folding and storage

PADDLE

Folding

the

backrest

Common misuse

The paddle is intended to be pushed. Do not pull

the paddle to fold the backrest.

To fold the backrest, push the black paddle

towards the back post with your thumb (1) whilst

pulling the handle down (2). Repeat this operation

for the other handle. To secure the backrest, lift

both handles together until the folding mechanism

locks automatically.

Do not push down on the handles to raise the wheels, as

this could damage the wheelchair. See steep terrain, kerbs

and steps to mount obstacles using the stepper tube.

This wheelchair is easily foldable to minimise storage space. Once the

footrests have been either folded and swung outwards, or removed (see

footrest adjustment), fold the wheelchair by pulling upwards on the centre

edges of the seat sling. Store with the parking brakes on, in a dry

environment, away from direct sunlight.

Note: The wheelchair may be folded and stored in a motor vehicle.

Page 6 of 8STR39-ESV teel Travel Chair (Issue 2021-05 rev1)

care and maintenance

Do not use a damaged or badly worn wheelchair. Users should routinely check for

any malfunctions or changes in performance. Contact Drive DeVilbiss Healthcare

Ltd or your provider to replace damaged or worn parts.

• Brakes and tyres should be checked before each use, and at least once a month.

• The wheelchair should be kept dust free and cleaned at least once a week.

Upholstery and tyres can be cleaned with a damp cloth and mild soap solution.

Avoid neat bleach or abrasive surface cleaners. Leave to fully dry before reuse.

Metal parts should also be polished once a month with an auto wax. Replace

worn or torn upholstery promptly, as it may not support your body weight.

• Drive DeVilbiss Healthcare Ltd recommend that an approved service engineer

maintains the wheelchair annually, and these items should be repaired,

replaced, adjusted and/or lubricated if required:

•When the product has reached the end of its useful life, follow local recycling

and disposal policies.

• Tyres and castors

• Wheel bearings

•

Brakes

•

Footrest locking mechanism

Seat upholstery

•

Back upholstery

•

Arm pads

•

Back posts

Wheelchair folding mechanism

powerpack installation

This wheelchair is suitable for some retroﬁt

powerpacks, which allow the device to be

controlled electronically. (See Powerpack

example image.)

Powerpacks are not required to use the

wheelchair. The mounting position will need

adapting to be suitable for both the user and the

powerpack used. Any installed powerpack must

be used in line with the manufacturer’s instructions

for use.

For more information about powerpacks, contact

your local dealer.

Powerpack

example

TR39-ESV Steel Travel Chair (Issue 2021-05 rev1) Page 7 of 8

warranty

Your Drive branded product is warranted to be free of defects in materials

and workmanship for one year from date of purchase. This device was built to

exacting standards and carefully inspected prior to shipment. This warranty is

an expression of our conﬁdence in the materials and workmanship of our

products and our assurance to the customer.

In the event of a defect covered by this warranty, we will at our option supply

parts or replace the device. This warranty does not cover device failure due

to owner misuse or negligence, or normal wear and tear. The warranty does

not extend to non-durable components, such as rubber accessories, castors

and grips, which are subject to normal wear and need periodic replacement.

The wheelchair frame has a 5-year warranty.

If you have queries or require full warranty conditions, contact your provider.

accessories and spare parts

Accessories and spare parts are for maintaining your wheelchair. To order

parts which are compatible with these wheelchairs, contact your provider.

Visit www.drivedevilbiss.co.uk to ﬁnd your local stockist. Spare part

catalogues, compatibility charts and other documentation can also be found

on this website. Only use parts approved by Drive DeVilbiss Healthcare Ltd.

speciﬁcation

Model TR39-ESV

Maximum occupant mass 115 kg

Overall length with footrest 84 cm

Overall width 51 cm

Folded width 20 cm

Total mass 12 kg

Static stability 10°

40 cm

48 cm

Seat surface height at front edge 48 cm

Overall height 99 cm

TR39-ESV

Steel Travel Chair (Issue2021-05rev1) Page8of8

support

Formoreinformation, orassistancewithuseandmaintenance, please

contactyourprovider. Userswithvisual, readingorcognitivedisabilities

shouldseekadvicefromtheir provideroraprofessional careproviderforan

appropriateformat. Forthelatestversionofthisdocument, contactDrive

DeVilbissHealthcareLtdusingthedetailsbelow, orcheckourwebsite.

Anyseriousincidentthathasoccurredinrelationtothedeviceshouldbe

reportedtothemanufacturerandthecompetentauthorityofyourMember

State. Pleasequotetheproduct serial codeonall correspondence, whichcan

befoundonthewheelchair frameunder theseat.

ZhenjiangAssureMedical Equipment Co., Ltd

#297ChuqiaoRoad, ZhenjiangCity,

JiangsuProvince, 212009CN

LotusNLB.V.

KoninginJulianaplein10, leVerd,

2595AA, TheHague, NL

DriveDeVilbissHealthcareLtd

Sidhil BusinessPark, Holmfield, Halifax

WestYorkshire, HX29TN, GB

DriveDeVilbissHealthcareLtdprovidethese

instructionsfor useandproductmarkings.

[email protected]

www.drivedevilbiss.co.uk

Service & Maintenance Spares Customer Service

Tel: +44 (0)1422 233136 Tel: +44 (0)1274 475125 Tel: +44 (0) 845 0600 333

Fax: +44 (0)1422 233010 Fax: +44 (0) 845 0600 334

Approvedservicefacility

Table des matières

Autres manuels Drive Aide à la mobilité

Drive

Drive R800RD Manuel utilisateur

Drive

Drive RTL800KD-BK Manuel utilisateur

Drive

Drive 13031-1SV Manuel utilisateur

Drive

Drive 13031SV-KD Manuel utilisateur

Drive

Drive TW011R Manuel utilisateur

Drive

Drive CE 1000 XL Manuel utilisateur

Drive

Drive D577-R Manuel utilisateur

Drive

Drive ROOMBA Manuel utilisateur

Drive

Drive Gecko 700 100 100 Manuel utilisateur

Drive

Drive 11130-2 Manuel utilisateur

Drive

Drive PreserveTech 12011KD-1A Manuel utilisateur

Drive

Drive DUPONT Novaltis Manuel utilisateur

Drive

Drive 10247-4 Manuel utilisateur

Drive

Drive Folding Height-Adjustable Quad Cane Manuel utilisateur

Drive

Drive FC 8025 Manuel utilisateur

Drive

Drive 13085LN Manuel utilisateur

Drive

Drive 2112-3 Manuel utilisateur

Drive

Drive PS001 Manuel utilisateur

Drive

Drive RTL11158KDR Manuel utilisateur

Drive

Drive TR 8023 Manuel utilisateur

Drive

Drive Clever-Lite LS Manuel utilisateur

Drive

Drive FC 2028 Manuel utilisateur

Drive

Drive Diamond Deluxe Manuel utilisateur

Drive

Drive RTL12031KDR Manuel utilisateur

Manuels Aide à la mobilité populaires d'autres marques

Alber

Alber Scalamobil iQ Manuel utilisateur

Ferno

Ferno CCT-PX Manuel utilisateur

HEPRO

HEPRO Gripo Manuel utilisateur

Otto Bock

Otto Bock Pheon 3R62 Manuel utilisateur

NRS Healthcare

NRS Healthcare M11090 Manuel utilisateur

Medline

Medline MDS86835DSHEC Guide d'installation

Guldmann

Guldmann Twin Turner II Manuel utilisateur

Gate

Gate Balder Manuel utilisateur

Decon wheel

Decon wheel TNS Notos Manuel utilisateur

ExoAtlet

ExoAtlet ExoAtlet-II Manuel utilisateur

Invacare

Invacare Storm Series Mode d’emploi

Rhythm Healthcare

Rhythm Healthcare B3800F Manuel utilisateur

AMF-BRUNS

AMF-BRUNS PROTEKTOR Manuel utilisateur

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Manuel utilisateur

Rhythm Healthcare

Rhythm Healthcare C500U Manuel utilisateur

Lumex

Lumex RJ4200A Manuel utilisateur

Rebotec

Rebotec Jumbo Manuel utilisateur

Rehaforum MEDICAL

Rehaforum MEDICAL PR50548 Manuel utilisateur
