Draytek P2261 Manuel utilisateur

Quick Start Guide

European Community Declarations

Manufacturer: DrayTek Corp.

Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu, Taiwan 303

Product: VigorSwitch P2261

DrayTek Corp. declares that VigorSwitch P2261 is in compliance with the following essential requirements and other relevant

provisions of 2004/108/EC.

The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with

the requirements set forth in EN55022/Class A and EN55024/Class A.

The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying with the requirements

set forth in EN60950-1.

Federal Communications Commission (FCC) Statement

This equipment has been tested and found to comply with the limits for a class A computing device pursuant to Subpart J of part

15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial

environment.

GPL Notice

This DrayTek product uses software partially or completely licensed under the terms of the GNU GENERAL PUBLIC

LICENSE. The author of the software does not provide any warranty. A Limited Warranty is offered on DrayTek products. This

Limited Warranty does not cover any software applications or programs.

To download source codes please visit:

http://gplsource.draytek.com

GNU GENERAL PUBLIC LICENSE:

https://gnu.org/licenses/gpl-2.0

Version 2, June 1991

For any question, please feel free to contact DrayTek technical support at support@draytek.com for further information.

Version: 1.2

Date: March 31, 2016

VoIPon www.voipon.co.uk [email protected] Tel: (0)330 088 0195 Fax: +44 (0)1245 808299

Package Content

The 24+2 Giga Port L2 Managed Switch is a standard switch that meets all

IEEE 802.3/u/x/z Gigabit, Fast Ethernet specifications. It is a switch with 24

10/100/1000Mbps TP (20-Port for TP; 4-Port for Combo) and 2-Port

Dual-SFP Fiber management Ethernet ports.

The network administrator can logon the switch to monitor, configure and

control each port’s activity. In addition, the switch implements the QoS

(Quality of Service), VLAN, and Trunking. It is suitable for office

application.

VigorSwitch Rack Mount Kit

CD Ethernet Cable

EU-type power cord

Note: If any of these items is found missing or damaged, please contact

your local supplier for replacement.

VoIPon www.voipon.co.uk [email protected] Tel: (0)330 088 0195 Fax: +44 (0)1245 808299

Descriptions of Panel

LED Explanation

LED Color Explanation

POWER Green Lit when +3.3V power is coming up.

TP Port 1– 24

(RJ45 LEFT)

LINK/ACT Green Lit when connection with remote device is good.

Blinks when any traffic is present.

TP Port 1– 24

(RJ45 RIGHT)

For PoE model Green Lit Green when PoE device is up.

Off when PoE device is down

SFP Port 21-24

LINK/ACT

Green/

Amber

Lit Green when TP connection with remote device is

1000M..

Lit Amber when TP connection with remote device is

100M.

Blinks when any traffic is present.

SFP Port 25-26

LINK/ACT

Green/

Amber

Lit Green when the connection with remote device is

1000M.

Lit Amber when the connection with remote device is

100M.

Blinks when any traffic is present.

Connector Explanation

Interface Description

RESET Used to restart the device to default settings.

CONSOLE Used to perform telnet command control.

LAN P1 – P24 Giga Ethernet Port.

SFP (21 – 26) SFP Fiber Port.

VoIPon www.voipon.co.uk [email protected] Tel: (0)330 088 0195 Fax: +44 (0)1245 808299



Installing Your Switch

A hierarchical network with minimum levels of switch may reduce the timing

delay between server and client station. Basically, with this approach, it will

minimize the number of switches in any one path; will lower the possibility of

network loop and will improve network efficiency. If more than two switches

are connected in the same network, select one switch as Level 1 switch and

connect all other switches to it at Level 2. Server/Host is recommended to

connect to the Level 1 switch. This is general if no VLAN or other special

requirements are applied.

The connection among IP Phone, Access Point and VigorSwitch

Each port can support 30.8W power; the total power supply can reach to 185W.

For other examples of hardware installation, please refer to User’s Guide for

detailed information.

VoIPon www.voipon.co.uk [email protected] Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
