Draytek Vigor2862 Series Manuel utilisateur

Vigor2862 Series

VDSL2 Security Firewall

Quick Start Guide

(for Wired Model)

Version: 1.1

Firmware Version: V3.8.5

(For future update, please visit DrayTek web site)

Date: July 14, 2017

iii

Intellectual Property Rights (IPR) Information

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks The following trademarks are used in this document:

Microsoft is a registered trademark of Microsoft Corp.

Windows, Windows 95, 98, Me, NT, 2000, XP, Vista, 7, 8 and Explorer are

trademarks of Microsoft Corp.

Apple and Mac OS are registered trademarks of Apple Inc.

Other products may be trademarks or registered trademarks of their

respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

Read the installation guide thoroughly before you set up the router.

The router is a complicated electronic unit that may be repaired only be

authorized and qualified personnel. Do not try to open or repair the

router yourself.

Do not place the router in a damp or humid place, e.g. a bathroom.

Do not stack the routers.

The router should be used in a sheltered area, within a temperature

range of +5 to +40 Celsius.

Do not expose the router to direct sunlight or other heat sources. The

housing and electronic components may be damaged by direct sunlight or

heat sources.

Do not deploy the cable for LAN connection outdoor to prevent electronic

shock hazards.

Keep the package out of reach of children.

When you want to dispose of the router, please follow local regulations on

conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free

from any defects in workmanship or materials for a period of two (2) years

from the date of purchase from the dealer. Please keep your purchase receipt

in a safe place as it serves as proof of date of purchase. During the warranty

period, and upon proof of purchase, should the product have indications of

failure due to faulty workmanship and/or materials, we will, at our discretion,

repair or replace the defective products or components, without charge for

either parts or labor, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new

or re-manufactured functionally equivalent product of equal value, and will

be offered solely at our discretion. This warranty will not apply if the product

is modified, misused, tampered with, damaged by an act of God, or subjected

to abnormal working conditions. The warranty does not cover the bundled or

licensed software of other vendors. Defects which do not significantly affect

the usability of the product will not be covered by the warranty. We reserve

the right to revise the manual and online documentation and to make changes

from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

EU Declaration of Conformity

We DrayTek Corp. , office at No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu

300, Taiwan , R.O.C., declare under our sole responsibility that the product

Product name: VDSL2 Security Firewall

Model number: Vigor2862, Vigor2862B

Manufacturer: DrayTek Corp.

Address: No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu

300, Taiwan , R.O.C.

is in conformity with the relevant Union harmonisation legislation:

EMC Directive 2014/30/EU , Low Voltage Directive 2014/35/EU , ErP 2009/125/EC and RoHS

2011/65/EU with reference to the following standards

Standard Version / Issue date

EN 55032 2012+AC:2013 class B

EN 61000-3-2 2014 Class A

EN 61000-3-3 2013

EN 55024 2010+A1:2015

EN 60950-1 2006 +A11:2009

+A1:2010 +A12:2011+

A2:2013

EC No. 1275/2008 2008

Hsinchu 22nd June, 2017 Calvin Ma / President .

(place) (date) (Legal Signature)

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause

undesired operation.

Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

The antenna/transmitter should be kept at least 20 cm away from human body.

DrayTek Vigor2862 series VDSL2/ADSL2+ routers are compliant with 47 C.F.R. Part 68.

More update, please visit www.draytek.com.

Be a Registered Owner

Web registration is preferred. You can register your Vigor router via http://www.draytek.com.

Firmware & Tools Updates

Due to the continuous evolution of DrayTek technology, all routers will be regularly upgraded.

Please consult the DrayTek web site for more information on newest firmware, tools and

documents. http://www.draytek.com

vii

1. Introduction........................................................................................................... 1

2. Package Content .................................................................................................. 2

3. Panel Explanation................................................................................................. 3

3.1 Vigor2862/Vigor2862B............................................................................................................... 3

3.4 Notes for Y Cable Application..................................................................................................... 5

4. Hardware Installation ........................................................................................... 6

4.1 Network Connection................................................................................................................... 6

4.2 Wall-Mounted Installation........................................................................................................... 7

5. Software Configuration........................................................................................ 8

5.1 Quick Start Wizard for Network Connection............................................................................... 8

6. Customer Service............................................................................................... 14

Vigor2862/2862B is a VDSL2 router with multi-subnet for secure and efficient

workgroup management. It integrates IP layer QoS, NAT session/bandwidth

management to help users control works well with large bandwidth.

By adopting hardware-based VPN platform and hardware encryption of

AES/DES/3DES, and hardware key hash of SHA-1/MD5, the router increases the

performance of VPN greatly and offers several protocols (such as

IPSec/PPTP/L2TP) with up to 32 VPN tunnels.

The object-based design used in SPI (Stateful Packet Inspection) firewall allows

users to set firewall policy with ease. CSM (Content Security Management)

provides users control and management in IM (Instant Messenger) and P2P (Peer

to Peer) more efficiency than before. In addition, DoS/DDoS prevention and

URL/Web content filter strengthen the security outside and control inside.

Vigor2862/2862B supports USB interface for connecting USB printer to share

printing function, 3G/4G USB modem for network connection, connectivity for

network FTP service, or thermometer for monitoring the temperature change.

Vigor2862B can enhance the transmission rate and enlarge the bandwidth by

combining two standard VDSL2 lines, thus it is able to provide low line prices

instead of expensive leased lines. Meanwhile, the speed of existing connection

established for customers can be increased.

Take a look at the package content. If there is anything missed or damaged,

please contact DrayTek or dealer immediately.

Vigor Router

Quick Start Guide

RJ-45 to RJ-45 Cable

(Annex B)

RJ-11 to RJ-45 Cable (Annex B)

RJ-11 to RJ-11 Cable (Annex A)

Y Cable (B models)

The type of the power adapter depends on the country that the router will be

installed. * The maximum power consumption is 30 Watt.

UK-type Power Adapter

EU-type Power Adapter

USA/Taiwan-type Power Adapter

AU/NZ-type Power Adapter

LED Status Explanation

Off The router is powered off.ACT (Activity) Blinking The router is powered on and running

normally.

On Internet connection is ready.

Off Internet connection is not ready.

WAN2

Blinking The data is transmitting.

On The QoS function is active.QoS Off The QoS function is inactive.

On USB device is connected and ready for use.

Off No USB device is connected.

USB1~2 / USB

Blinking The data is transmitting.

On The router is ready to access Internet through

DSL link.

DSL/DSL 1/2

Blinking Slowly: The DSL connection is ready.

Quickly: The connection is training.

On The Web Content Filter is active. (It is

enabled from Firewall >> General Setup).

WCF

Off WCF is disabled.

On The VPN tunnel is active.

Off VPN services are disabled

VPN

Blinking Traffic is passing through VPN tunnel.

On The DMZ function is enabled.

Off The DMZ function is disabled.

DMZ

Blinking The data is transmitting.

LED on Connector

On The port is connected.

Off The port is disconnected.

Left

LED Blinking The data is transmitting.

LAN

1~4

Right On The port is connected with 1000Mbps.
