Draytek Vigor2765 Series Manuel utilisateur

Vigor2765

35b Series Router

Quick Start Guide

(For RF Model)

Version: 1.5_(01)

Firmware Version: V4.4.2

(For future update, please visit DrayTek web site)

Date: October 18, 2022

Intellectual Property Rights (IPR) Information

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks The following trademarks are used in this document:

Microsoft is a registered trademark of Microsoft Corp.

Windows 8, 10, 11 and Explorer are trademarks of Microsoft Corp.

Apple and Mac OS are registered trademarks of Apple Inc.

Other products may be trademarks or registered trademarks of their

respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

Read the installation guide thoroughly before you set up the router.

The router is a complicated electronic unit that may be repaired only be

authorized and qualified personnel. Do not try to open or repair the

router yourself.

Do not place the router in a damp or humid place, e.g. a bathroom.

Do not stack the routers.

The router should be used in a sheltered area, within a temperature

range of 0 to +40 Celsius.

Do not expose the router to direct sunlight or other heat sources. The

housing and electronic components may be damaged by direct sunlight

or heat sources.

Do not deploy the cable for LAN connection outdoor to prevent

electronic shock hazards.

Keep the package out of reach of children.

When you want to dispose of the router, please follow local regulations

on conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free

from any defects in workmanship or materials for a period of two (2) years

from the date of purchase from the dealer. Please keep your purchase receipt

in a safe place as it serves as proof of date of purchase. During the warranty

period, and upon proof of purchase, should the product have indications of

failure due to faulty workmanship and/or materials, we will, at our discretion,

repair or replace the defective products or components, without charge for

either parts or labor, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new

or re-manufactured functionally equivalent product of equal value, and will

be offered solely at our discretion. This warranty will not apply if the product

is modified, misused, tampered with, damaged by an act of God, or subjected

to abnormal working conditions. The warranty does not cover the bundled or

licensed software of other vendors. Defects which do not significantly affect

the usability of the product will not be covered by the warranty. We reserve

the right to revise the manual and online documentation and to make changes

from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

Declaration of Conformity

Hereby, DrayTek Corporation declares that the radio equipment type Vigor2765 is in compliance with

Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the following internet address:

https://fw.draytek.com.tw/Vigor2765/Document/CE/

Manufacturer: DrayTek Corp.

Address: No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan

Product: Vigor2765 Wireless Series

Frequency Information for Europe area:

2.4GHz WLAN 2412MHz - 2472 MHz, max. TX power: 19.79dBm *1

5GHz WLAN 5160MHz - 5340 MHz, max. TX power: 22.74dBm *2

5480MHz - 5720 MHz, max. TX power: 29.88dBm

Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/

CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/

UK/HR. 5150MHz~5350MHz is for indoor use only.

(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)

This product is designed for DSL and 2.4GHz /5GHz WLAN network throughout the EC region.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause

undesired operation.

iii

RF Exposure Warning

This equipment must be installed and operated in accordance with provided instructions and the

antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20

cm from all persons and must not be co-located or operating in conjunction with any other antenna or

transmitter. End-users and installers must be provided with antenna installation instructions and

transmitter operating conditions for satisfying RF exposure compliance.

Company name ABP International Inc.

Address 13988 Diplomat Drive Suite 180 Dallas TX 75234

ZIP Code 75234 E-mail rmesser@abptech.com

USA Local

Representative Contact Person Mr. Robert

Messer Tel. 19728311600

Caution

Any changes or modifications not expressly approved by the grantee of this device could void the

user's authority to operate the equipment.

The antenna/transmitter should be kept at least 20 cm away from human body.

More update, please visit www.draytek.com.

*The external power supply used for each product will be model dependent.

1 2 3 4 5 6 7 8 9

A Manufacturer CWT CWT CWT CWT CWT APD APD APD APD

B Address No. 222, Sec.

2, Nankan

Rd., Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan

Rd., Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan

Rd., Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan

Rd., Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan

Rd., Lujhu

Township,

Taoyuan

County 338,

Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

2ABB012F UK 2ABB018F UK 2ABL024F UK

2ABL030F UK

2ABN036F UK

WA-12M12FG

WB-18D12FG WA-24Q12FG WA-36A12FG

C Model identifier 2ABB012F EU 2ABB018F EU 2ABL024F EU

2ABL030F EU

2ABN036F EU

WA-12M12FK

WB-18D12FK WA-24Q12FK WA-36A12FK

D Input voltage 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V

Input AC frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60HzE Output voltage DC 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V

F Output current 1.0A 1.5A 2.0A 2.5A 3.0A 1.0A 1.5A 2.0A 3.0A

G Output power 12.0W 18.0W 24.0W 30.0W 36.0W 12.0W 18.0W 24.0W 36.0W

H Average active

efficiency 84.9% 86.2% 87.6% 87.8% 89.8% 83.7% 85.4% 88.6% 88.2%

I Efficiency at low load

10% 73.6% 78.0% 81.3% 83.3% 83.7% 74.5% 80.5% 86.4% 85.4%

J No-load power

consumption 0.07W 0.07W 0.07W 0.07W 0.07W 0.07W 0.10W 0.07W 0.10W

External power supply (Power Adapter) information. For more update, please visit www.draytek.com.

1. Package Content .................................................................................................. 1

2. Panel Explanation................................................................................................. 2

2.1 Vigor2765ac............................................................................................................................... 2

2.2 Vigor2765Vac............................................................................................................................. 4

3. Hardware Installation ........................................................................................... 6

3.1 Network Connection................................................................................................................... 6

3.2 Wall-Mounted Installation........................................................................................................... 7

4. Software Configuration........................................................................................ 8

5. Customer Service............................................................................................... 13

Be a Registered Owner.................................................................................................................. 13

Firmware & Tools Updates............................................................................................................. 13

Take a look at the package content. If there is anything missed or damaged,

please contact DrayTek or dealer immediately.

Vigor router Quick Start Guide, Antenna

RJ-45 Cable (Ethernet) RJ-11 to RJ-11 Cable (Annex A)

RJ-11 to RJ-45 Cable (Annex B) RJ-45 to RJ-45 Cable (Annex B)

The type of the power adapter depends on the country that the router will

be installed. * The maximum power consumption is 17-23 Watt.

UK-type Power Adapter EU-type Power Adapter

USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter

Note

Remove the protective film from the router before use to

ensure ventilation.

LED Status Explanation

Blinking The router is powered on and running normally.

(Activity) Off The router is powered off.

On The DSL link up, waiting for the Internet connection.

Orange Blinking

Slowly - The DSL connection is ready for training.

Quickly - The DSL connection is synchronizing.

On The router is ready to access to the Internet through

DSL link.

(DSL)

Green Blinking

The data is transmitting.

On (Green) The wireless access point is ready.

Blinking (Green) The data is transmitting via wireless connection based

on the rate of 2.4GHz.

Blinking (Orange) Blinks with one second cycle for two minutes. The WPS

function is active.

(Wireless LAN

On/Off/WPS)

Off The wireless access point is turned off.

On (Green) The wireless access point is ready.

Blinking (Green) The data is transmitting via wireless connection based

on the rate of 5GHz.

(Wireless LAN

On/Off/WPS) Blinking (Orange) Blinks with one second cycle for two minutes. The WPS

function is active.

On The LAN port is connected.

Blinking The data is transmitting.

(LAN1/2/3/4) Off The LAN port is disconnected.

On A USB device is connected and active.

(USB) Blinking The data is transmitting.

Interface Description

WLAN

ON/OFF/WPS WLAN On - Press the button and release it within 2 seconds.

When the wireless function is ready, the green LED will be on.

WLAN Off - Press the button and release it within 2 seconds to

turn off the WLAN function. When the wireless function is not

ready, the LED will be off.

WPS - When WPS function is enabled by web user interface,

press this button for more than 2 seconds to wait for client’s

device making

network connection through WPS.

Factory Reset Restore the default settings.

Usage: Turn on the router (ACT LED is blinking). Press the hole

and keep for more than 5 seconds. When you see the ACT LED

begins to blink rapidly than usual, release the button. Then

the router will restart with the factory default configuration.

USB1~USB2 Connector for a USB device (for 3G/4G USB Modem or printer).

P1~P4 Connectors for local networked devices.

DSL Connector for accessing the Internet.

I/O Power Switch.

PWR Connector for a power adapter.

LED Status Explanation

Blinking The router is powered on and running normally.

(Activity) Off The router is powered off.

On The DSL link up, waiting for the Internet connection.

Orange Blinking

Slowly - The DSL connection is ready for training.

Quickly - The DSL connection is synchronizing.

On The router is ready to access to the Internet through

DSL link.

(DSL)

Green Blinking

The data is transmitting.

On The phone connected to this port is off-hook.

Off The phone connected to this port is on-hook.

Blinking A phone call comes.

On (Green) The wireless access point is ready.

Blinking (Green) The data is transmitting via wireless connection based

on the rate of 2.4GHz.

Blinking (Orange) Blinks with one second cycle for two minutes. The WPS

function is active.

(Wireless LAN

On/Off/WPS)

Off The wireless access point is turned off.

On (Green) The wireless access point is ready.

Blinking (Green) The data is transmitting via wireless connection based

on the rate of 5GHz.

(Wireless LAN

On/Off/WPS) Blinking (Orange) Blinks with one second cycle for two minutes. The WPS

function is active.

On The LAN port is connected.

Blinking The data is transmitting.

(LAN1/2/3/4) Off The LAN port is disconnected.

On A USB device is connected and active.

(USB) Blinking The data is transmitting.

Autres manuels pour Vigor2765 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Draytek Routeur réseau

Draytek

Draytek Vigor2910 Series Manuel utilisateur

Draytek

Draytek VigorLTE 200n Manuel utilisateur

Draytek

Draytek Vigor2200 Series Manuel utilisateur

Draytek

Draytek Vigor 2132 Series Manuel utilisateur

Draytek

Draytek Vigor 2710e Manuel utilisateur

Draytek

Draytek Vigor2860 Series Manuel utilisateur

Draytek

Draytek Vigor 2800G Guide de référence

Draytek

Draytek Vigor2762 series Manuel utilisateur

Draytek

Draytek Vigor 2900 Series Manuel utilisateur

Draytek

Draytek Vigor2920n Manuel utilisateur

Draytek

Draytek Vigor2620 Series Manuel utilisateur

Draytek

Draytek Vigor2762 series Manuel utilisateur

Draytek

Draytek Vigor2500V Manuel utilisateur

Draytek

Draytek Vigor1000B Manuel utilisateur

Draytek

Draytek Vigor2915 Series Manuel utilisateur

Draytek

Draytek Vigor2600Ge Manuel de référence

Draytek

Draytek Vigor2925 Series Manuel utilisateur

Draytek

Draytek Vigor2760 Delight Manuel utilisateur

Draytek

Draytek Vigor2762n Manuel utilisateur

Draytek

Draytek Vigor2200 Series Manuel utilisateur

Draytek

Draytek VigorIPPBX 3510 Series Manuel utilisateur

Draytek

Draytek Vigor2710 Series Manuel utilisateur

Draytek

Draytek Vigor 2700 Series Manuel utilisateur

Draytek

Draytek VigorPro 5300 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
